M498G

Your Potent Multitasker

•The Veriton M498G targets business professionals

seeking stability and the latest technology with

keeping the environment in mind.

•Cutting-edge performance:

9Intel®Core™i processors

9Intel®H57 Express Chipset

9Up to 16Gb DDR3 1066 memory

93 years warranty (1st year on-site)

•Helpful utilities as Veriton control center, Acer

client manager and TPM-based security

•Certified green (Energy Star, EPEAT Silver)

•Modular tool-less chassis

•Solid design with precise lines and visual simplicity

Windows®. Life without Walls™. Acer recommends Windows 7.

Veriton M498G SPECIFICATIONS

Product view 1Optical drive bays

2Media bays

3OneButton Recovery

4Enhanced ventilation

5USB 2.0 ports and audio jacks

6Power switch

7GS-compliant finish

8PS/2 keyboard and mouse ports

9Serial port

10 DVI-D port

11 VGA port

12 USB 2.0 and Ethernet ports

13 Three audio ports

Operating system1Genuine Windows® 7 Professional Downgrade rights to Genuine Windows® XP Professional

Processor1Intel®Core™i5 processor Intel®Core™i3 processor

Chipset1Intel®H57 Express Chipset

Memory1In Configuration: 2GB (2/0/0/0) DDR3 SDRAM or 4GB (2/2/0/0) DDR3 SDRAM

Expansion Slots: Four memory slots: upgradeable up to 16GB

Hard drive1Serial ATA hard disk up to 1 TB RAID 0, 1, 5 ,10 and Intel®Rapid Storage Technology RAID capability2, 3

Optical drive1SuperMulti

Expansion bays One PCI Express® 2.0 x1

Two PCI v2.3 (5V) slots

One PCI Express® 2.0 x16

Graphics Intel®Core™i3/i5 integrated graphics solution4, featuring:

- Intel®HD Graphics support

- Intel®Dynamic Video Memory Technology (Intel®DVMT) support

- Microsoft®DirectX®10 support

Audio Embedded high-definition audio with 5.1-channel surround sound support

Networking LAN: Gigabit Ethernet

I/O ports Front:

•Four USB 2.0 ports

•Multi-in-1 card reader3

•High-definition headphone and microphone jacks

Rear:

•Six USB 2.0 ports

•PS/2 keyboard and mouse ports

•Ethernet (RJ-45) port

•Three audio ports

•VGA port

•Serial port

•DVI-D port

I/O expansion PCI Express®2.0 x16 slot Parallel port connector3

PCI Express®2.0 x1 slot Serial port connector3

Two PCI v2.3 (5 V) slots

Software1Acer Backup Manager

Acer Client Manager

Acer eRecovery Management

Acer Security Suite

Intel®Rapid Storage technology

Veriton ControlCenter (Acer eLock

Management, Acer eSettings Management,

QuickMigration, PowerSaver, SmartBoot,

HelpDesk)5

Adobe®Reader®

McAfee®Internet Security Suite 2009 Trial6

Microsoft®Office 2007 (Ready/Trial) Service

Pack 2

Nero®9 Essentials

Security Acer eLock Management

Padlock and Kensington lock slots

Intrusion alert

TPM module3

OneButton Recovery

Dimensions/Color 7.0" (180mm) W x 17.3" (440mm) D x 13.8" (352mm) H Black/Silver

BIOS Acer PnP BIOS compatible with SMBIOS 2.6

Power supply1300 W

System compliance PC 2001, ENERGY STAR®5.07, GS, EPEAT®Silver8

Certification VCCI, FCC, CE, BSMI, CCC, MET, Nemko (CB & Bauart, GS), UL

Optional

accessories

Acer wireless, USB or PS/2 keyboard and mouse Acer LCD monitor

Mini PCI Express®Wireless LAN card

Warranty Three years limited warranty with limited on-site service for the 1st year9

1. Specifications vary depending on model.

2. Support for RAID 0 and 1 requires two hard drives, RAID 5 requires three, and RAID 10 requires four.

3. Optional.

4. Intel® Core™i7 and Core™i5 700 processors require a discrete graphics card.

5. For models with Windows®7.

6. Trial periods vary depending on the geographic region and specifications: 365-day trial for China,

Hong Kong (Simplified Chinese and Traditional Chinese OS models), Taiwan and Singapore; 60-day trial for other

regions.

7. Trial periods vary depending on the geographic region and specifications: 365-day trial for China,

Hong Kong (Simplified Chinese and Traditional Chinese OS models), Taiwan and Singapore; 60-day trial for other

regions.

8. ENERGY STAR®5.0 is available only on G models.

9. EPEAT®Silver is only available for the M498G model.

10. On-site service applies to the continental U.S. and Canada only and may not be available in all locations. In those

areas where on-site service is provided,a technician will be dispatched, if necessary, following efforts to resolve the

problem by telephone support.
