Acer AR360 F2 User manual

1
Acer AR360 F2 specifications
Product overview
The AR360 F2 dual-socket server delivers excellent performance, availability and expansion capability in a
space-saving design. The Acer AR360 F2 server is perfect for dense computing, virtualization and
clustering, as well as dedicated tasks requiring maximum compute and IO performance. With advanced
management and reliability features, this 1U rack server is optimized for enterprise-level operations in
departments and branch offices.
Internal view
1
2 x 700W 80 PLUS Gold-level (1+1 redundant, hot-swappable)
2
2 x dual-port Intel®I350 Ethernet Controllers
3
2 x Intel®Xeon®E5-2600 family processors
4
N+1 redundant system fans
5
2 x PCIe®3.0 expansion slots
6
24 x DDR3 ECC registered / 16 x DDR3 ECC unbuffered DIMMs
7
Up to 8 x 2.5" SATA / SAS HDDs

2
Acer AR360 F2 specifications
Front View
Front I/O
1
LED indicators: power, HDD activity, LAN
2
Power button
3
Up to 8 x 2.5" SATA / SAS HDDs
Rear View
Rear I/O
1
2 x 700W 80 PLUS®Gold-level (1+1 redundant, hot-swappable)
2
PS2 mouse and keyboard ports
3
Management port (RJ-45)
4
2 x USB ports
5
Serial port
6
Video port
7
4 x Gigabit LAN ports (RJ-45)

3
Acer AR360 F2 specifications
What's New
New Intel®Xeon®E5-2600 family processors
Hot-pluggable/redundant power supply with 80 PLUS®Gold-level efficiency
Smart Server Manager v1.2 with improved management functionality
Product Specifications
Processors and Chipset
Up to two Intel®Xeon®E5-2600 family processors
Chipset: Intel®C606
Memory
Up to 24 x DDR3 registered DIMMs or up to 16 x DDR3 unbuffered DIMMs
Network Controllers
2 x dual-port Intel®I350 Ethernet Controllers
Storage
Hard disk form factor: 2.5”
Type: SAS / SATA / SSD with hot-plug capability
2.5” Maximum capacity:
Up to 16 TB SATA HDD (1 TB 2.5" x 16 HDDs)
Up to 14.4 TB SAS (900 GB 2.5” x 16 HDDs)
Storage Controllers
Intel® 606 chipset with SCU (8 x 3 Gb/s SATA / SAS ports) with RAID 0, 1, 10 support
Onboard SAS support for RAID 0, 1, 10
Optional hardware SAS RAID controller with RAID 0, 1, 10, 5, 6, 50, 60 and BBU support
Expansion slots
2 x PCIe®3.0 x16 (x16 connector) (full-height, half-length)
Management
Acer Smart Server Manager
System ID LED buttons, System Health LED
Acer Smart Console for server management and KVM over IP remote management
BIOS
UEFI BIOS
SMBIOS 2.7
Deployment/Serviceability
Acer Smart Setup
BIOS Update Tool
IPMI Firmware Update Tool

4
Acer AR360 F2 specifications
Operating Systems
Windows Server®2008 (includes Hyper-V™)
Windows Server®2008 R2 (includes Hyper-V™)
Red Hat Enterprise Linux 5
Red Hat Enterprise Linux 6
SUSE Linux Enterprise Server 10
SUSE Linux Enterprise Server 11
VMware ESXi™5.0
Citrix®XenServer 6.0
Input/output interface
Front
One Power/off button
LED indicators: power, HDD activity, LAN, ID, and System status
Rear
PS2 mouse and keyboard port
2 x USB 2.0 ports
4 x Gigabit LAN port (RJ-45)
Video port
Serial port
System ID LED
Management port (RJ-45)
Optical drive
1x Slim type SATA SuperMulti Optical Drive
Graphics
BMC embedded controller
128 MB shared video memory
16 MB dedicated
Chassis/Form Factor
1U rack-optimized
Power Supply
2 x 700 W 80 PLUS®Gold-level efficient easy-swap power supply units (1+1 redundant, hot-
swappable)
Security
HDD mechanical lock
Chassis intrusion alert
Administrator/user password
Power-on password
Setup password
Device boot control
Optional TPM (v1.2-compliant)
Secure command line interface (SSH)
Secure browser interface (Secure socket layer - SSL support)
Secure IPMI LAN interface (Authentication, Integrity, and Confidentiality algorithm)

5
Acer AR360 F2 specifications
Regulatory Compliant Standards
EMC
FCC (Class A)
CE (Class A)
CCC
BSMI
Safety
MET
CB
Nemko/GS
Environmental Specifications
Dimensions
438.4 (W) x 675.5 (D) x 43.6 (H) mm (17.26 x 26.57 x 1.71 inches)
Weight
Maximum
25 kg (55.11 lbs.)
Minimum (includes a single HDD, CPU and
RAM, and PSU)
18.5 kg (40.78 lbs.)
System inlet
temperature
Operating
0°- 40°C (32°- 104°F)
Non-operating
-20°- 60°C (-4°- 140°F)
Relative
humidity
Operating
8 - 90 %
Non-operating
5 - 95 %
Acoustics
Idle
LWAd
4.7BA
LpAm
28dBA
Operating
LWAd
4.7BA (max not over 7.0BA)
LpAm
28dBA
Power
Rated Steady –state power
700 W
Maximum Peak Power
752.1 W
BTU rating
2567.600 BTU/hr at 100 - 240 VAC

6
Acer AR360 F2 specifications
Technical specifications
PCIe®specifications
The primary I/O bus for the main board is PCIe®Gen3. The following table lists the characteristics of the
PCI-E bus segments. Details about each bus segment follow the table.
NOTE: The signaling bit rate of PCI Express is 8.0Gbit/s one direction per lane for Gen 3
Expansion
slot
Number
Type
Bus
width1
Voltage
Connector
Location
Length
PCIe x16
1
PCIe Gen3
x16
3.3V
x16
Left riser
Full height
Half length
PCIe x16
1
PCIe Gen3
x16
3.3V
x16
Left riser
Full height
Half length
NOTE:
1. Indicates the number of physical electrical lanes running to a PCIe® connector.
2. Default bus assignment (in decimal). Inserting cards with PCI™ bridges may alter the actual bus
assignment number.
3. Slots are enumerated differently based on the operating system. Microsoft® operating systems
enumerate Device ID by bus starting from the lowest bus to the highest.

7
Acer AR360 F2 specifications
Onboard storage specifications
Item
Description
Controller
Intel®606 Platform Controller Hub
Simultaneous drive transfer channels
8 onboard SATA / SAS ports
Max throughput per channel
3 Gb/s
Data transfer method
Non-RAID mode
RAID mode
Drive type supported
Serial ATA; Serial Attached SCSI (SAS)
RAID levels support
RAID 0, 1, 10, (Intel software RAID)
RAID 0, 1, 10 (LSI software RAID)
NOTE: Intel software RAID only supports Windows OS
RAID function support
Supports multiple logical volumes
Setup through ROM based Array Configuration Utility
Installation scripting support
RAID OS support
Windows Server®2008
Windows Server®2008 R2
Windows Server®2003
Red Hat Enterprise Linux 5 / 6
SuSE Linux Enterprise Server 10 / 11
Additional features
NCQ (Native Command Queuing)
Onboard LAN specifications
Item
Description
Controller
2 x dual-port Intel®I350 Ethernet Controllers
Network interface
10Base-T / 100Base-TX / 1000Base-T
Compatibility standards
IEEE 802.3 Ethernet interface for 10BASE-T
IEEE 802.3ab Ethernet interface for 1000BASE-T
IEEE 802.3u Ethernet interface for 100BASE-TX
Manageability
NC-SI, SMBus
PXE, iSCSI boot
Virtualization acceleration
Virtual Machine Device Queues (VMDq)
PCI-SIG SR-IOV implementation
Connector
RJ-45
Supported cable type
CAT 5e wire

8
Acer AR360 F2 specifications
Memory specifications and population
Item
Description
Supported memory types
Registered DDR3 800 / 1066 / 1333 / 1600 MHz
Unbuffered DDR3 800 / 1066 / 1333 MHz
NOTE: Acer does not qualify mixed memory configurations of
memory type, capacity or make.
Population
Acer’s validated memory populations are listed below.
NOTE: Support for 8 / 16 GB DIMMs may vary by regional
availability.
Supported Memory Population
•Each CPU controls twelve DIMM slots. The DIMM slots support four channel DDR3- registered /
unbuffered ECC memory modules. Each channel has three sockets. The farthest socket to CPU is
socket 1 (P1DIMMA1, P1DIMMB1, P1DIMMC1, P1DIMMD1, P2DIMME1, P2DIMMF1, P2DIMMG1,
P2DIMMH1,in blue color), while the nearest one is socket 3 (P1DIMMA3, P1DIMMB3, P1DIMMC3,
P1DIMMD3, P2DIMME3, P2DIMMF3, P2DIMMG3, P2DIMMH3 in black color). For all memory modes,
the socket 1 in each channel needs to be populated first. If socket 1 is empty, socket 2 and 3 can’t be
used. The higher rank and bigger capacity DIMM is suggested to be installed from slot 1.
•3 DIMMs per channel configuration is only supported by single rank and dual rank RDIMM. For UDIMM
and quad rank RDIMM, maximum 2 DIMMs per channel is able to be supported.
•When you are using a single-processor server, you should install the memory module into P1DIMMA1
to P1DIMMD3 slots.
•The P2DIMME1 to P2DIMMH3 slots are enabled when CPU2 is installed on the main board.
•For the system to function, DIMM modules must be installed following the population table listed below.
DIMM module of the same type, size and manufacturer is recommended to be used in a system.

9
Acer AR360 F2 specifications
Independent mode:
Single processor configuration guide:
DIMM
Total No. of DIMM
P1DIMMA1
P1DIMMA2
P1DIMMA3
P1DIMMB1
P1DIMMB2
P1DIMMB3
P1DIMMD3
P1DIMMD2
P1DIMMD1
P1DIMMC3
P1DIMMC2
P1DIMMC1
4
x
x
x
x
8
x
x
x
x
x
x
x
x
12*
x
x
x
x
x
x
x
x
x
x
x
x
SR,DR RDIMM only
* 3 DIMM per channel is only supported by single rank and dual rank RDIMM. For UDIMM and quad rank
RDIMM, maximum two DIMMs per channel.
NOTE: Support depends on 16GB DIMM availability
Dual processor configuration guide:
DIMM
Total No. of DIMM
P1DIMMA1
P1DIMMA2
P1DIMMA3
P1DIMMB1
P1DIMMB2
P1DIMMB3
P1DIMMD3
P1DIMMD2
P1DIMMD1
P1DIMMC3
P1DIMMC2
P1DIMMC1
P2DIMME1
P2DIMME2
P2DIMME3
P2DIMMF1
P2DIMMF2
P2DIMMF3
P2DIMMH3
P2DIMMH2
P2DIMMH1
P2DIMMG3
P2DIMMG2
P2DIMMG1
8
x
x
x
x
x
x
x
x
16
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
24*
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
SR, DR RDIMM only
* 3 DIMM per channel is only supported by single rank and dual rank RDIMM. For UDIMM and quad rank
RDIMM, maximum two DIMMs per channel is supported.

10
Acer AR360 F2 specifications
NOTE: Populate the memory of CPU2 to same as CPU1.
NOTE: support depends on 16GB DIMM availability
Mirroring mode:
•For mirroring mode, the memory image in channel A is maintained the same as channel C and channel
B is maintained the same as channel D. Therefore, the effective size of memory is reduced by at least
one-half.
•The DIMM configuration in mirrored channels must be identical. Channel A & channel C with identical
DIMMs and also channel B & channel D with identical DIMMs. The DIMM type, size, manufacturer
should be the same.
•Same rule is applied to the CPU2
•3 DIMM per channel is only supported by single rank and dual rank RDIMM.
•For UDIMM and quad rank RDIMM, maximum two DIMMs per channel.
Lockstep mode:
•Channel A and channel B are paired and channel C and channel D are paired in lockstep mode.
•Lockstep mode is the only mode to support x8 SDDC.
•Lockstep channels must be populated identically. Channel A & channel B with identical DIMMs and
also channel C &channel D with identical DIMMs. The DIMM type, size, manufacturer should be the
same.
•Same rule is applied to the CPU2.
•3 DIMM per channel is only supported by single rank and dual rank RDIMM.
•For UDIMM and quad rank RDIMM, maximum two DIMMs per channel.
Rank Sparing mode:
•An unused spare rank is reserved on each channel. The spare rank is used to copy the contents of a
failing rank on the channel to keep a system working when a rank starts to fail. The reserved rank is
not able to be used before the other rank fail.
•3 DIMM per channel is only supported by single rank and dual rank RDIMM.
•For UDIMM and quad rank RDIMM, maximum two DIMMs per channel.
•For 1 DIMM per channel configuration, only quad rank RDIMM is supported for rank sparing.
Memory Identification
Generally, there are some memory information printed on the label of DIMM, but different vendor may have
different format. For example:
4GB 2Rx4 PC3-10600R xx xx xxx
1. Density
1GB, 2GB, 4GB, 8GB, 16GB
