Acer Altos G330 Series User manual

Acer Altos G330 Series
User’s Guide
AA G330_UG_EN-cop.fm Page i Friday, November 24, 2006 11:29 AM

Changes may be made periodically to the information in this publication without obligation
to notify any person of such revision or changes. Such changes will be incorporated in new
editions of this manual or supplementary documents and publications. This company makes
no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims the implied warranties of merchantability or fitness for a
particular purpose.
Record the model number, serial number, purchase date, and place of purchase information in
the space provided below. The serial number and model number are recorded on the label
affixed to the unit. All correspondence concerning the unit should include these information.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopy, recording, or otherwise,
without the prior written permission of Acer Incorporated.
Model Name : G330
Part Number: MU.R2600.007
Purchase Date:
Place of Purchase:
Copyright © 2006 Acer Incorporated
All Rights Reserved.
Acer Altos G330 Series
User’s Guide
Acer and the Acer logo are registered trademarks of Acer Inc. Other company’s product
names or trademarks are used herein for identification purposes only and belong to their
respective companies.
Acer Altos G330 Series
AA G330_UG_EN-cop.fm Page ii Friday, November 24, 2006 11:29 AM

iii
Notices
FCC declaration of conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
The following local manufacturer/importer is responsible for this declaration:
FCC notice
Class A devices do not have an FCC logo or FCC IDE on the label. Class B devices
have an FCC logo or FCC IDE on the label.
Class B equipment
This device has been tested and found to comply with the limits for a Class B
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This device generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
Product:
Model number:
Name of responsible party:
Address of responsible party:
Contact person:
Phone number:
Fax number:
Server
G330
Acer America Corporation
2641 Orchard Parkway, San Jose
CA 95134, U. S. A.
Mr. Young Kim
408-922-2909
408-922-2606
AA G330_UG_EN-cop.fm Page iii Friday, November 24, 2006 11:29 AM

iv
However, there is no guarantee that interference will not occur in a particular
installation. If this device does cause harmful interference to radio or television
reception, which can be determined by turning the device off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the device and receiver
• Connect the device into an outlet on a circuit different from that to which
the receiver is connected
• Consult the dealer or an experienced radio/television technician for help
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables
to maintain compliance with FCC regulations.
Notice: Peripheral devices
Only peripherals (input/output devices, terminals, printers, etc.) certified to
comply with the Class B limits may be attached to this equipment. Operation
with noncertified peripherals is likely to result in interference to radio and TV
reception.
Caution: Changes or modifications not expressly approved by the
manufacturer could void the user’s authority, which is granted by
the Federal Communications Commission, to operate this server.
Notice: Canadian users
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Remarque à l'intention des utilisateurs canadiens
Cet appareil numérique de la classe B est conforme a la norme NMB-003 du
Canada.
AA G330_UG_EN-cop.fm Page iv Friday, November 24, 2006 11:29 AM

v
Laser compliance statement
The CD or DVD drive used with this computer is a laser product. The CD or DVD
drive's classification label (shown below) is located on the drive.
CLASS 1 LASER PRODUCT
CAUTION: INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO
BEAM.
APPAREIL A LASER DE CLASSE 1 PRODUIT
LASERATTENTION: RADIATION DU FAISCEAU LASER INVISIBLE EN CAS
D'OUVERTURE. EVITTER TOUTE EXPOSITION AUX RAYONS.
LUOKAN 1 LASERLAITE LASER KLASSE 1
VORSICHT: UNSICHTBARE LASERSTRAHLUNG, WENN ABDECKUNG GEÖFFNET
NICHT DEM STRAHLL AUSSETZEN.
PRODUCTO LÁSER DE LA CLASE I
ADVERTENCIA: RADIACIÓN LÁSER INVISIBLE AL SER ABIERTO. EVITE
EXPONERSE A LOS RAYOS.
ADVARSEL: LASERSTRÅLING VEDÅBNING SE IKKE IND I STRÅLEN.
VARO: LAVATTAESSA OLET ALTTINA LASERSÅTEILYLLE.
VARNING: LASERSTRÅLNING NÅR DENNA DEL ÅR ÖPPNAD ÅLÅ TUIJOTA
SÅTEESEENSTIRRA EJ IN I STRÅLEN.
VARNING: LASERSTRÅLNING NAR DENNA DEL ÅR ÖPPNADSTIRRA EJ IN I
STRÅLEN.
ADVARSEL: LASERSTRÅLING NAR DEKSEL ÅPNESSTIRR IKKE INN I STRÅLEN.
Macrovision copyright protection notice
"U.S Patent Nos. 4,631,603; 4,819,098; 4,907,093; 5,315,448; and 6,516,132."
This product incorporates copyright protection technology that is protected by
U.S. patents and other intellectual property rights. Use of this copyright
protection technology must be authorized by Macrovision, and is intended for
home and other limited viewing uses only unless otherwise authorized by
Macrovision. Reverse engineering or disassembly is prohibited.
AA G330_UG_EN-cop.fm Page v Friday, November 24, 2006 11:29 AM

vi
CE declaration of conformity
We,
Acer Computer (Shanghai) Limited
3F, No. 168 Xizang Medium Road, Huangpu District,
Shanghai, China
Contact Person: Mr. Easy Lai
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
Hereby declare that:
Is compliant with the essential requirements and other relevant provisions of
the following EC directives, and that all the necessary steps have been taken
and are in force to assure that production units of the same product will
continue to comply with these requirements.
• EMC Directive 89/336/EEC, amended by 92/31/EEC and 93/68/EEC as
attested by conformity with the following harmonized standards:
• EN55022:1998 + A1:2000 + A2:2003, AS/NZS CISPR22:2002, Class B
• EN55024:1998 + A1:2001 + A2:2003
• EN61000-3-2:2000, Class D
• EN61000-3-3:1995 + A1:2001
• Low Voltage Directive 73/23/EEC as attested by conformity with the
following harmonized standard:
• EN60950-1:2001
• RoHS Directive 2002/95/EC on the Restriction of the Use of certain
Hazardous Substances in Electrical and Electronic Equipment
Product:
Trade name:
Model number:
SKU number:
Server
Acer
G330
G33xx ("x" = 0~9, a~z, A~Z or blank)
Director, Acer Computer (Shanghai) Limited
November 20, 2006
AA G330_UG_EN-cop.fm Page vi Friday, November 24, 2006 6:14 PM

vii
Declaration of conformity for EU countries
Hereby, Acer, declares that this PC series is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
Russian regulatory certification compliance
AA G330_UG_EN-cop.fm Page vii Friday, November 24, 2006 11:29 AM

viii
Information for your safety and
comfort
Safety instructions
Read these instructions carefully. Keep this document for future reference.
Follow all warnings and instructions marked on the product.
Turning the product off before cleaning
Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
CAUTION for plug as disconnecting device
Observe the following guidelines when connecting and disconnecting power to
the power supply unit:
• Install the power supply unit before connecting the power cord to the AC
power outlet.
• Unplug the power cord before removing the power supply unit from the
server.
• If the system has multiple sources of power, disconnect power from the
system by unplugging all power cords from the power supplies.
CAUTION for accessibility
Be sure that the power outlet you plug the power cord into is easily accessible
and located as close to the equipment operator as possible. When you need to
disconnect power to the equipment, be sure to unplug the power cord from the
electrical outlet.
Usage warnings
• Do not use this product near water. Never spill liquid of any kind onto or
into the product.
• Do not place this product on an unstable cart, stand or table. If the
product falls, it could be seriously damaged.
AA G330_UG_EN-cop.fm Page viii Friday, November 24, 2006 11:29 AM

ix
• Slots and openings are provided for ventilation to ensure reliable
operation of the product and to protect it from overheating. These
openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug or other similar surface.
This product should never be placed near or over a radiator or heat
register, or in a built-in installation unless proper ventilation is provided.
• Never push objects of any kind into this product through cabinet slots as
they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock.
• To avoid damage of internal components and to prevent battery leakage,
do not place the product on a vibrating surface.
• Never use it under sporting, exercising, or any vibrating environment
which will probably cause unexpected short current or damage rotor
devices, hard drives, optical drives, and even exposure risk from lithium
battery pack.
Using electrical power
• This product should be operated from the type of power indicated on the
marking label. If you are not sure of the type of power available, consult
your dealer or local power company.
• Do not allow anything to rest on the power cord. Do not locate this
product where people will walk on the cord.
• If an extension cord is used with this product, make sure that the total
ampere rating of the equipment plugged into the extension cord does not
exceed the extension cord ampere rating. Also, make sure that the total
rating of all products plugged into the wall outlet does not exceed the fuse
rating.
• Do not overload a power outlet, strip or receptacle by plugging in too
many devices. The overall system load must not exceed 80% of the branch
circuit rating. If power strips are used, the load should not exceed 80% of
the power strip's input rating.
• This product's power supply is equipped with a three-wire grounded plug.
The plug only fits in a grounded power outlet. Make sure the power
outlet is properly grounded before inserting the power supply plug. Do
not insert the plug into a non-grounded power outlet. Contact your
electrician for details.
AA G330_UG_EN-cop.fm Page ix Friday, November 24, 2006 11:29 AM

x
Warning! The grounding pin is a safety feature. Using a
power outlet that is not properly grounded may result in
electric shock and/or injury.
Note: The grounding pin also provides good protection from
unexpected noise produced by other nearby electrical devices that
may interfere with the performance of this product.
• Use the product only with the supplied power supply cord set. If you need
to replace the power cord set, make sure that the new power cord meets
the following requirements: detachable type, UL listed/CSA certified, type
SPT-2, rated 7 A 125 V minimum, VDE approved or its equivalent, 4.6
meters (15 feet) maximum length.
Safe listening
Follow these instructions, suggested by hearing experts,to protect your hearing.
• Gradually increase the volume until you can hear it clearly and comfortably
and without distortion.
• After setting the volume level, do not increase it after your ears adjust.
• Limit the amount of time listening to music at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can't hear people speaking near you.
Product servicing
Do not attempt to service this product yourself, as opening or removing covers
may expose you to dangerous voltage points or other risks. Refer all servicing
to qualified service personnel.
Unplug this product from the wall outlet and refer servicing to qualified service
personnel when:
• the power cord or plug is damaged, cut or frayed
• liquid was spilled into the product
• the product was exposed to rain or water
• the product has been dropped or the case has been damaged
AA G330_UG_EN-cop.fm Page x Friday, November 24, 2006 11:29 AM

xi
• the product exhibits a distinct change in performance, indicating a need
for service
• the product does not operate normally after following the operating
instructions
Note: Adjust only those controls that are covered by the
operating instructions, since improper adjustment of other
controls may result in damage and will often require extensive
work by a qualified technician to restore the product to normal
condition.
Disposal instructions
Do not throw this electronic device into the trash when discarding. To minimize
pollution and ensure utmost protection of the global environment, please
recycle. For more information on the Waste from Electrical and Electronics
Equipment (WEEE) regulations, visit http://global.acer.com/about/
sustainability.htm.
Mercury advisory
For projectors or electronic products containing an LCD/CRT monitor or display:
Lamp(s) inside this product contain mercury and must be recycled or disposed of
according to local, state or federal laws. For more information, contact the
Electronic Industries Alliance at http://www.eiae.org. For lamp-specific disposal
information, check http://www.lamprecycle.org.
AA G330_UG_EN-cop.fm Page xi Friday, November 24, 2006 11:29 AM

xii
Tips and information for comfortable use
Computer users may complain of eyestrain and headaches after prolonged use.
Users are also at risk of physical injury after long hours of working in front of a
computer. Long work periods, bad posture, poor work habits, stress,
inadequate working conditions, personal health and other factors greatly
increase the risk of physical injury.
Incorrect computer usage may lead to carpal tunnel syndrome, tendonitis,
tenosynovitis or other musculoskeletal disorders. The following symptoms may
appear in the hands, wrists, arms, shoulders, neck or back:
• numbness, or a burning or tingling sensation
• aching, soreness or tenderness
• pain, swelling or throbbing
• stiffness or tightness
• coldness or weakness
If you have these symptoms, or any other recurring or persistent discomfort
and/or pain related to computer use, consult a physician immediately and
inform your company's health and safety department.
The following sections provide tips for more comfortable computer use.
Finding your comfort zone
Find your comfort zone by adjusting the viewing angle of the monitor, using a
footrest, or raising your sitting height to achieve maximum comfort. Observe
the following tips:
• Refrain from staying too long in one fixed posture.
• Avoid slouching forward and/or leaning backward.
• Stand up and walk around regularly to remove the strain on your leg
muscles.
• Take short rests to relax your neck and shoulders.
• Avoid tensing your muscles or shrugging your shoulders.
• Install the external display, keyboard and mouse properly and within
comfortable reach.
• If you view your monitor more than your documents, place the display at
the center of your desk to minimize neck strain.
AA G330_UG_EN-cop.fm Page xii Friday, November 24, 2006 11:29 AM

xiii
Taking care of your vision
Long viewing hours, wearing incorrect glasses or contact lenses, glare, excessive
room lighting, poorly focused screens, very small typefaces and low-contrast
displays could stress your eyes. The following items provide suggestions on how
to reduce eyestrain.
•Eyes
• Rest your eyes frequently.
• Give your eyes regular breaks by looking away from the monitor and
focusing on a distant point.
• Blink frequently to keep your eyes from drying out.
•Display
• Keep your display clean.
• Keep your head at a higher level than the top edge of the display so
your eyes point downward when looking at the middle of the display.
• Adjust the display brightness and/or contrast to a comfortable level
for enhanced text readability and graphics clarity.
• Eliminate glare and reflections by:
– placing your display in such a way that the side faces the window or
any light source
– minimizing room light by using drapes, shades or blinds
– using a task light
– changing the display's viewing angle
– using a glare-reduction filter
– using a display visor, such as a piece of cardboard extended from
the display's top front edge
• Avoid adjusting your display to an awkward viewing angle.
• Avoid looking at bright light sources, such as open windows, for
extended periods of time.
AA G330_UG_EN-cop.fm Page xiii Friday, November 24, 2006 11:29 AM

xiv
Developing good work habits
Develop the following work habits to make your computer use more relaxing
and productive:
• Take short breaks regularly and often.
• Perform some stretching exercises.
• Breathe fresh air as often as possible.
• Exercise regularly and maintain a healthy body.
Warning! We do not recommend using the computer on a
couch or bed. If this is unavoidable, work for only short
periods, take breaks regularly, and do some stretching
exercises.
AA G330_UG_EN-cop.fm Page xiv Friday, November 24, 2006 11:29 AM

Contents
1 System tour 1
System specifications 3
Performance 3
Mechanical 6
External and internal structure 7
Front panel 7
Rear panel 8
Internal components 9
System boards 10
Mainboard 10
Backplane board 11
System jumpers 12
System LED indicators 13
Front panel LED indicators 13
Hot-plug HDD LED indicators 14
LAN port LED indicators 14
2 System setup 15
Setting up the system 17
Pre-installation requirements 17
Connecting peripherals 18
Turning on the system 19
Power-on problems 20
Turning off the system 21
3 System upgrade 23
Installation precautions 25
ESD precautions 25
Pre-installation instructions 26
Post-installation instructions 26
Opening the server 27
Removing the side panel 27
Removing the front bezels 28
Configuring a 5-25 inch storage device 29
Configuring a hard drive 31
Upgrading the processor 35
Upgrading the system memory 40
Installing an expansion card 44
Replacing the CMOS battery 47

4 System BIOS 51
BIOS overview 53
Entering BIOS setup 54
BIOS setup interface 54
BIOS setup navigation keys 54
BIOS setup primary menus 56
Main menu 56
Advanced menu 57
Security menu 67
Server Management menu 72
Boot Options menu 75
Error Manager 77
Exit menu 78
Clearing the CMOS RAM 80
Upgrading the BIOS 81
5 System troubleshooting 83
Pre-troubleshooting procedure 85
Resetting the system 85
Initial system startup problems 86
Initial troubleshooting checklist 87
Hardware diagnostic testing 88
Checking the boot-up status 88
Verifying the condition of the storage devices 89
Confirming loading of the operating system 89
Component troubleshooting 90
POST beep codes 94
Appendix A: Intel Active Management
Technology 95
Intel AMT overview 97
Intel AMT features 97
Intel AMT functions 97
Intel AMT BIOS Extension menu 98
Enabling the IAMT BIOS Extension menu 98
Configuring the initial IAMT BIOS settings 99

Appendix B: SATA RAID configuration 103
SATA RAID configuration utilities 105
Onboard Intel SATA RAID configuration 105
Onboard LSI SATA RAID configuration 107
Appendix C: SAS RAID configuration 109
SAS RAID configuration support 111
Entering the Adaptec SAS/SATA
Configuration Utility 111
Creating the RAID 1 volume 111
Index 113

1 System tour

The Acer Altos G330 server is a single processor
system featuring the latest in computing
technology. It hosts a range of powerful and
flexible features designed to meet the needs
of various network environments. From simple
networking functions to computing-intensive
applications, the Altos G330 delivers.
