ACME PoliSpray 3 User manual

Acme Manufacturing Company
4240 N. Atlantic Blvd.
Auburn Hills, Michigan 48326 U.S.A.
Phone [phone]
Fax [phone]
[e-mail]
Acme Manufacturing Company
www.acmemfg.com
Acme PoliSpray 3
Description
PoliSpray 3 is a high-pressure spray gun, designed for the application of abrasive
compounds.
Characteristics:
High exit velocity to overcome the turbulence created by fast rotating buffs
by means of the OW-Head
Precise volume metering due to the fast acting exit valve by means of OW-
Head
Precise volume metering of each compound shot
Optimized maintenance with interchangeable One-Way Spray Head (OW)
Fast and easy nozzle replacement and air bleeding
Optional remote spray head with flexible extension
Ready for use with electronic controls
Technical Data
Weight 3.74 lbs (1700 g)
Width 2.750" (69.85mm)
Length 10.250" (260.35mm)
Air Connector G –1/8"
Media Hose G –3/8"–sleeve NW 13
Metering Volume 0.5 –6.0 cc
Air Pressure 72 psi –89 psi (5-6 Bar)
Compound Pressure Minimum 72 psi (5 Bar)

Acme Manufacturing Company
4240 N. Atlantic Blvd.
Auburn Hills, Michigan 48326 U.S.A.
Phone [phone]
Fax [phone]
[e-mail]
Acme Manufacturing Company
www.acmemfg.com
Caution: Pay close attention to the safety information on the last page!
Installation
The gun body has a through-hole Ø 12 mm for mounting.
A quick-connect air coupler (94) requiring a pneumatic hose Ø 8/6 mm is attached.
3/2-way valve is recommended. Normally closed when de-energized.
Dead closed by electromagnetic manipulation
Opening time at least 0.5 seconds
Delay time at least 1.5 second
The valve should be located as near to the spray gun as possible.
The compound connection (15) requires a hose with an inside diameter of 12 mm.
Start-up
The spray gun timers are to be set accordingly per process requirements. Gun
opening (firing side of cycle) at 0.5 seconds and delay to be no less than 1.5
seconds.
Install the necessary nozzle into the spray head (44) for required spray coverage.
Open the stop-cock (13) for de-aeration, put a screwdriver into the gap between
nozzle nut and spray head; pry the nozzle nut forward until compound discharges in
a continuous flow without interruptions of air.
Manually fire the gun by using the manual switch on pneumatic solenoid.
DO NOT FIRE THE GUN AT ANYTHING OTHER THEN THE MEDIA OR THE PART TO
BE FINISHED. HIGH PRESSURE DISCHARGE CAN CAUSE SERIOUS INJURY IF
POINTED AND FIRED AT A PERSON.

Acme Manufacturing Company
4240 N. Atlantic Blvd.
Auburn Hills, Michigan 48326 U.S.A.
Phone [phone]
Fax [phone]
[e-mail]
Acme Manufacturing Company
www.acmemfg.com
Adjust the compound volume with knurled knob (26) by turning clockwise for less
volume and counterclockwise for increase volume.
Tips for Troubleshooting
Air in the Spray gun
De-aerate the gun (see –“start-up”) until compound flows without
interruption of air
Compound does not discharge from gun
Tip is blocked, remove tip and clean or replace it
Check valve (17) for blockage
oExamine function of check valve:
Fill gun body with compound
Lock stop-cock (13)
Actuate pneumatic valve
oIf compound emerges, check valve (17) is broken, clean or replace
Check air pressure, does it meet required minimum
oIncrease to minimum required pressure (72 psi –5 bar) or greater
Pneumatic piston assembly does not retract
oPneumatic cylinder (35) is dirty, open and clean
Compound connection clogs
oDe-aeration (see "start-up"), if no compound flows, check the hose
connection for blockage and clean as required
Compound pressure to low
oDe-aeration (see “start-up”), if little or no compound discharges,
increase line pressure by adjusting pump or pressure pot settings
OW-Head Failure
oIf the OW head cannot be de-aerated, replace the head

Acme Manufacturing Company
4240 N. Atlantic Blvd.
Auburn Hills, Michigan 48326 U.S.A.
Phone [phone]
Fax [phone]
[e-mail]
Acme Manufacturing Company
www.acmemfg.com
OW-Head leaks
oLeaks from nozzle
oCompound emerges from the bleed bores on OW-Head
Replace OW-Head
Compound leaks from bleed holes in main body (28)
oReplacement of plunger (36) and cup seal (9) are required
(replacement of compression spring (37) should also be done at this
time)
When dismounting and cleaning the spray gun, it is necessary to use the
drawing with parts list.
Safety
The following safety recommendations should be followed when doing any work
on the spray gun:
Never point the spray gun at other personnel
Before any repair or maintenance work may be carried out, spray gun must
be disconnected from compressed air and pressure must be released
Always wear protective glasses
Close compound supply stopcock
Before start-up and after each repair or maintenance work, all nuts, bolts and
connections should be reviewed to confirm that all are tight and properly
installed
Pay attention to the warnings and advices of the compound, buff and
equipment manufacturer
Do not use aggressive cleaners or boiling water to clean gun or parts.
Nozzles can be cleaned with compressed air or warm water and compressed
air. Exterior of gun can be cleaned with a damp cloth or fiber brush.
Changes in the interest of improvements and technical progress are reserved.

Acme Manufacturing Company
4240 N. Atlantic Blvd.
Auburn Hills, Michigan 48326 U.S.A.
Phone [phone]
Fax [phone]
[e-mail]
Acme Manufacturing Company
www.acmemfg.com
Maintenance
When disassembling the gun for maintenance, it is important to keep all parts that are to
be reused clean. During the reassembly on the cup seal, plunger and compression
spring, it is important to use grease during this process. A light oil should be used to
coat the cylinder wall (35) and flat seal (20).
Spare Parts List
These parts are wear items and should be kept in stock at all times.
Item Number
Description
Part Number
9
Cup Seal
230 090
17
Check Valve
230 170
20
Flat Seal
230 200
36
Plunger
230 360
37
Compression Spring
230 370
44
OW Head
700 550
