SERVICE MANUAL
BINKS SV100™ HVLP
PRESSURE FEED SPRAY GUN
7041-6931-1
SPECIFICATIONS
Max. Air Pressure: 175psi/12bar
For HVLP Compliance: 26 psi inlet pressure delivers
(with SV100-693K cap) 10 psi air cap pressures at
12 cfm air volume
For HVLP Compliance: 20 psi inlet pressure delivers
(with SV100-690K cap) 10 psi air cap pressures at
6.5 cfm air volume
Gun Body: Cast Aluminum
Fluid Path: Stainless Steel
Fluid Nozzle: Stainless Steel
Fluid Needle: Stainless Steel
Fluid Inlet Size: 3/8" NPS(M)
Air Inlet Size; 1/4" NPS(M)
Gun Weight: 1.12 lbs. (507 g)
The following instructions provide the necessary information
for the proper maintenance of the Binks SV100 pressure feed
spray gun. Please read and understand all the information in this
document in order to get the maximum performance from your
new SV100 pressure spray gun.
The SV100 spray gun is the result of quality engineering and
development activity. The result is an ergonomic product with
reduced triggering effort and fine atomization. The HVLP air
cap has been specifically designed to comply with local
regulatory air quality restrictions. The specification table details
the operating parameters of the gun to achieve those compliant
conditions. In addition, the relatively low air flow rate of the
SV100 spray gun will help in containing overspray.
The SV100 spray gun should be operated under the safety
directions outlined in this literature. Your safety and the safety
of others depend on your thorough understanding of the
material contained on the Part Sheet.
If you have any questions or do not understand the content in
this literature, call your nearest service representative.

EN
77-2874-R7.5 (6/2016)2 / 8
Binks reserves the right to modify equipment specification without prior notice.
LOCK OUT / TAG-OUT
Failure to de-energize, disconnect, lock out and tag-out all power
sources before performing equipment maintenance could cause
serious injury or death.
OPERATOR TRAINING
All personnel must be trained before operating finishing
equipment.
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture,
malfunction, or start unexpectedly and result in serious injury.
PROJECTILE HAZARD
You may be injured by venting liquids or gases that are released
under pressure, or flying debris.
PINCH POINT HAZARD
Moving parts can crush and cut. Pinch points are basically any
areas where there are moving parts.
INSPECT THE EQUIPMENT DAILY
Inspect the equipment for worn or broken parts on a daily basis.
Do not operate the equipment if you are uncertain about its
condition.
In this part sheet, the words WARNING, CAUTION and NOTE are used to
emphasize important safety information as follows:
Hazards or unsafe practices which
could result in minor personal injury,
product or property damage.
!
CAUTION
Hazards or unsafe practices which
could result in severe personal
injury, death or substantial property
damage.
!
WARNING
Important installation, operation or
maintenance information.
NOTE
Read the following warnings before using this equipment.
READ THE MANUAL
Before operating finishing equipment, read and understand all
safety, operation and maintenance information provided in the
operation manual.
WEAR SAFETY GLASSES
Failure to wear safety glasses with side shields could result in
serious eye injury or blindness.
NEVER MODIFY THE EQUIPMENT
Do not modify the equipment unless the manufacturer provides
written approval.
IT IS THE RESPONSIBILITY OF THE EMPLOYER TO PROVIDE THIS INFORMATION TO THE OPERATOR OF THE EQUIPMENT.
FOR FURTHER SAFETY INFORMATION REGARDING THIS EQUIPMENT, SEE THE GENERAL EQUIPMENT SAFETY BOOKLET (77-5300).
KNOW WHERE AND HOW TO SHUT OFF THE EQUIPMENT
IN CASE OF AN EMERGENCY
PRESSURE RELIEF PROCEDURE
Always follow the pressure relief procedure in the equipment
instruction manual.
NOISE HAZARD
You may be injured by loud noise. Hearing protection may be
required when using this equipment.
STATIC CHARGE
Fluid may develop a static charge that must be dissipated through
proper grounding of the equipment, objects to be sprayed and all
other electrically conductive objects in the dispensing area. Improper
grounding or sparks can cause a hazardous condition and result in
fire, explosion or electric shock and other serious injury.
PROP 65 WARNING
WARNING: This product contains chemicals known to the
State of California to cause cancer and birth defects or other
reproductive harm.
WEAR RESPIRATOR
Toxic fumes can cause serious injury or death if inhaled.
Wear a respirator as recommended by the fluid and solvent
manufacturer’s Safety Data Sheet.
TOXIC FLUID & FUMES
Hazardous fluid or toxic fumes can cause serious injury or death if
splashed in the eyes or on the skin, inhaled, injected or
swallowed. LEARN and KNOW the specific hazards or the fluids
you are using.
KEEP EQUIPMENT GUARDS IN PLACE
Do not operate the equipment if the safety devices have been
removed.
!
WARNING
AUTOMATIC EQUIPMENT
Automatic equipment may start suddenly without warning.
FIRE AND EXPLOSION HAZARD
Improper equipment grounding, poor ventilation, open flame or
sparks can cause a hazardous condition and result in fire or
explosion and serious injury.
MEDICAL ALERT
Any injury caused by high pressure liquid can be serious. If you
are injured or even suspect an injury:
• Go to an emergency room immediately.
• Tell the doctor you suspect an injection injury.
• Show the doctor this medical information or the medical alert
card provided with your airless spray equipment.
• Tell the doctor what kind of fluid you were spraying or
dispensing.
GET IMMEDIATE MEDICAL ATTENTION
To prevent contact with the fluid, please note the following:
• Never point the gun/valve at anyone or any part of the body.
• Never put hand or fingers over the spray tip.
• Never attempt to stop or deflect fluid leaks with your hand,
body, glove or rag.
• Always have the tip guard on the spray gun before spraying.
• Always ensure that the gun trigger safety operates before
spraying.

EN
77-2874-R7.5 (6/2016) 3 / 8
TYPES OF INSTALLATION
5/16” 1/4”
Only 43 PSI at gun inlet
25 feet of 1/4” I.D. hose causes
a drop of 17 PSI between the
air supply and the gun.
(NOT RECOMMENDED)
54 PSI at gun inlet
25 feet of 5/16” I.D. hose
causes a drop of 6 PSI
between the air supply
and the gun. For this reason
Binks recommends the use
of 5/16” hose.
(RECOMMENDED)
With 60 psi applied at air supply
PRESSURE CUP HOOKUP
(Figure 1)
For fine finishing with limited
spraying. Air pressure for
atomization is regulated at extractor;
fluid pressure at cup regulator.
Pressure cup is also available less
regulator.
PRESSURE TANK HOOKUP
(Figure 2)
For medium production spraying
(single regulator). Air pressure for
atomization is regulated at extractor,
fluid pressure at tank regulator.
PRESSURE TANK WITH
2 REGULATORS (Figure 3)
The pressure to the tank is regulated
by the first regulator. The pressure
for
atomization is regulated by the
second regulator.
PRESSURE CIRCULATING
HOOKUP (Figure 4)
For heavy production spraying.
Air pressure atomization regulated
at separator filter. Fluid pressure
regulated at fluid regulator.
AIR PRESSURE
Atomizing pressure must be set
properly to allow for the drop in air
pressure between the regulator and
the spray gun.
Separator filter is important.
Achieving a fine spray finish without the use of a good separator filter is virtually impossible.
A regulator / separator filter serves a double purpose. It eliminates blistering and spotting by
keeping air free of oil and water, and it gives precise air pressure control at the gun.
Binks recommends using Model HFRL-508 Separator Filter / Regulator. See your local
distributor for other models.
Cross section view
showing comparison of inside
hose diameters (actual size).
60 lbs. regulated pressure
Fluid Pressure Cup
FIG 2
Air
Fluid
Outlet
Air
Inlet
Separator Filter
Fluid
Pressure
Tank
FIG 3
FIG 4
Fluid
Regulator
Air Supply
Air Supply
Fluid
Pressure
Tank
Separator
Filter
Air
FIG 1
Air
Cup Regulator
Separator
Filter
Fluid

EN
77-2874-R7.5 (6/2016)4 / 8
OPERATION AND MAINTENANCE FOR BINKS SV100™HVLP SPRAY GUN
Your new SV100 HVLP spray gun is
exceptionally rugged in construction and
is built to stand up under hard,
continuous use. However, like any other
fine precision instrument, its most
efficient operation depends on a
knowledge of its construction, operation
and maintenance. Properly handled and
cared for, it will produce beautiful,
uniform finishing results long after other
spray guns have worn out.
SET-UP FOR SPRAYING
Connecting Gun To Air Hose
Air should be supplied by a suitable
length of 5/16" diameter air hose fitted
with a 1/4" NPS(f) connection at gun
end. For hose lengths over 50', use 3/8"
diameter hose.
Connecting Gun To Fluid Hose
Fluid should be supplied by a suitable
length of 3/8" diameter fluid hose fitted
with a 3/8" NPS(f) connection at gun
end. 1/4" diameter hose is recommended
for use with low viscosity fluids. (Fluid
hoses of different composition are
available for special fluids.)
SPRAY GUN CLEANING
INSTRUCTIONS
In certain states it is now against the law
to spray solvents containing Volatile
Organic Compounds (VOC)’s into the
atmosphere when cleaning a spray gun.
In order to comply with these air quality
laws Binks recommends one of the
following two methods to clean your
spray finishing equipment:
1. Spray solvent through the gun into a
closed system. An enclosed unit or
spray gun cleaning station condenses
solvent vapors back into liquid form
which prevents escape of VOC’s into
the atmosphere.
2. Place spray gun in a washer type
cleaner. This system must totally
enclose the spray gun, cups, nozzles
and other parts during washing,
rinsing and draining cycles. This type
of unit must be able to flush solvent
through the gun without releasing
any VOC vapors into the atmosphere.
Additionally, open containers for storage
or disposal of solvent or solvent-
containing cloth or paper used for
surface preparation and clean-up may
not be used. All containers shall be
nonabsorbent.
Pointers On Cleaning
When used with 1 quart cup, relieve
pressure in the cup. Then unscrew,
empty and carefully rinse cup out with
thinners. Place clean thinners in the cup
and spray this through the gun until it is
clean. Blow air through gun to dry it.
When Used With Pressure
Container
Shut off air supply to container and
release the pressure on the container.
Loosen retaining ring two turns, hold a
piece of cloth wadded in the hand over
the gun nozzle and pull the trigger. The
air will back up through the fluid nozzle
and force the fluid out of the hose into
the container. Empty container. Put
enough thinner into the container to
wash hose and gun thoroughly and spray
this through the gun until it is clean.
Then blow out the fluid hose to dry it
and remove all traces of fluid by
attaching it to the air line.
When used with Paint
Circulating System
Shut off fluid supply and remove fluid
hose from gun. Clean gun with compatible
solvent. To ensure a clean air supply to
your spray gun, use separator filter.
See your Binks distributor for the
correct model.
CAUTION
All parts on a spray gun should be
screwed in hand tight at first; this
will avoid the possibility of cross
threading the parts. If the parts
cannot be turned by hand easily,
make sure you have the correct
parts, unscrew, realign, and try
again. NEVER use undue force in
mating parts.
!

EN
77-2874-R7.5 (6/2016) 5 / 8
BINKS SV100™HVLP PRESSURE FEED SPRAY GUN
ITEM PART
NO. NO. DESCRIPTION QTY.
1 SV100-693K AIR CAP .............................................. 1
1a SV100-690K AIR CAP (not shown)......................... 1
2★— FLUID TIP 1.1 mm............................... 1
2a★— FLUID TIP 1.4 mm (not shown).......... 1
2b• — FLUID TIP 1.8 mm (not shown).......... 1
3★■— GASKET............................................... 1
4k— BAFFLE................................................ 1
5★■•t— GASKET............................................... 1
6★■•t— PACKING............................................. 1
8 — GUN BODY ......................................... 1
9k— SPRAY PATTERN VALVE ..................... 1
10■— U-CUP SEAL ........................................ 2
11■— AIR VALVE SEAT ................................. 1
12 — AIR VALVE STEM ................................ 1
13 ■— AIR VALVE SPRING ............................. 1
14 — AIR VALVE BUSHING.......................... 1
15★— FLUID NEEDLE 1.1 mm....................... 1
15a★— FLUID NEEDLE 1.4 mm (not shown).. 1
15b• — FLUID NEEDLE 1.8 mm (not shown).. 1
16★• — FLUID NEEDLE SPRING....................... 1
17 — FLUID ADJUSTMENT KNOB ............... 1
ITEM PART
NO. NO. DESCRIPTION QTY.
18 — NIPPLE................................................. 1
19 SGK-457 AIR ADJUSTING VALVE ASSEMBLY ... 1
20 — FLUID NIPPLE...................................... 1
21 — WASHER ............................................. 1
22 — NUT..................................................... 1
23 — FLUID NIPPLE ASSEMBLY ................... 1
24 — TRIGGER PIN ASSEMBLY .................... 1
25 — TRIGGER ............................................. 1
26 ■— ASSEMBLY TOOL................................ 1
★K-5052 Pressure Gun Fluid Tip and Needle Replacement Kit
(includes 1.1 and 1.4 mm tips & needles)
• K-5052-18 Pressure Gun Fluid Tip and Needle Replacement Kit
(1.8 mm)
kSGK-454-K Spray Pattern Valve and Baffle
■K-5057 Soft Parts Kit
tSGK-537-K 5 ea. Packings and Baffle Gasket
NOTE: Use 1.1 mm fluid tip/needle with low viscosity materials.
Use 1.4 mm fluid tip/needle with high viscosity materials.
PARTS LIST
(When ordering, please specify Part No.)
TEST AIR CAP KITS
(sold separately)
54-5654 SV100-693
54-5657 SV100-690

EN
77-2874-R7.5 (6/2016)6 / 8
SPRAY TECHNIQUE
The first requirement for a good resultant
finish is the proper handling of the gun. The
gun should be held perpendicular to the
surface being covered and moved parallel
with it. The stroke should be started before
the trigger is pulled and the trigger should be
released before the stroke is ended. This gives
accurate control of the gun and fluid.
The distance between gun and surface should
be 6 to 8 inches depending on fluid and
atomizing pressure. The fluid deposited
should always be even and wet. Lap each
stroke over the preceding stroke to obtain a
uniform finish.
GENERAL SPRAY
INSTRUCTIONS
To reduce overspray and obtain maximum
efficiency, always spray with the lowest
possible fluid/air pressure that produces an
acceptable spray pattern.
Excessive atomizing air pressures can
increase overspray, reduce transfer efficiency,
and with some materials, result in poor finish
quality from dry spray. Atomizing air pressures
should not exceed 10 psi. Compliance can be
checked by having a pressure no greater than
26 psi at the gun inlet.
For best results, use 3 to 6 psi fluid pressure.
Higher than 6 psi fluid pressure may be
required for heavy-bodied materials. Low fluid
pressures will produce a narrower than normal
spray pattern. Generally use up to 20 psi air at
GUN INLET. Unusually heavy, difficult to
atomize fluids may require up to 26 psi air at
gun inlet.
CONTROLLING THE FAN SPRAY
The fan spray is controlled by means of the
side port control assembly. Turning this
control clockwise until it is closed will give a
round spray; turning it counterclockwise will
widen the spray into a fan shape. The fan
spray can be turned anywhere through 360 °
by positioning the air nozzle relative to the
gun. To accomplish this, loosen retaining ring,
position nozzle, then tighten retaining ring.
CONTROLLING THE FLUID FLOW
When used with a pressure assisted cup, an
increase in air pressure will increase the rate
of flow. When fed from a pressure supply, an
increase in the fluid pressure will increase the
rate of flow. Correct fluid nozzle size should
be selected for correct fluid flow rate. The
fluid control knob may be used for minor
adjustment of fluid flow.
AIR NOZZLE, FLUID NOZZLE,
FLUID NEEDLE
1. All nozzles and needles are precision
made. They should be handled with care.
2. Do not make any alterations in the gun.
To do so could cause finishing difficulties.
3. To clean nozzles, soak them in solvent to
dissolve any dried material, then blow
them clean with air.
4. Do not probe any of the holes in the
nozzles with metal instruments.
If probing is necessary, use only a
tool that is softer than brass.
TROUBLESHOOTING
Faulty Spray
A faulty spray pattern is often caused by
improper cleaning resulting in dried materials
around the fluid nozzle tip or in the air nozzle.
Soak these parts in thinners to soften the dried
material and remove with a brush or cloth.
If either the air nozzle or fluid nozzle are
damaged, these parts must be replaced before
perfect spray can be obtained.
Intermittent Spray
If the spray flutters, it is caused by one of the
following faults:
1. Insufficient fluids available. Check supply
and replenish if necessary.
2. Pressure vent tube from gun body to
pressure pot is loose or leaking.
3. Check valve in pressure relief valve is
stuck or blocked.
4. Pressure pot cover not sufficiently tight or
cover gasket defective.
5. Insufficient fluid pressure from standard
pressure pots.
6. Pickup tube in pressure pot bottoming out
if 1-gallon pot is used.
NOTE
To reduce overspray and obtain
maximum efficiency always spray
with the lowest possible atomizing
air pressure.
CAUTION
Never use metal instruments to clean
the air or fluid nozzles. These parts are
carefully machined and any damage to
them will cause faulty spray.
!
OPERATING THE SV100
HVLP SPRAY GUN
BINKS SV100™HVLP PRESSURE FEED SPRAY GUN

EN
77-2874-R7.5 (6/2016) 7 / 8
NOTES

EN
77-2874-R7.5 (6/2016)8 / 8
Carlisle Fluid Technologies reserves the right to modify equipment specications without prior notice.
DeVilbiss®, Ransburg®, MS®, BGK®, and Binks®are registered trademarks of Carlisle Fluid Technologies, Inc.
©2016 Carlisle Fluid Technologies, Inc. All rights reserved.
WARRANTY POLICY
Binks products are covered by Carlisle Fluid Technologies one year materials and workmanship limited warranty.
The use of any parts or accessories, from a source other than Carlisle Fluid Technologies, will void all warranties.
For specic warranty information please contact the closest Carlisle Fluid Technologies location listed below.
Binks is part of Carlisle Fluid Technologies, a global leader in innovative nishing
technologies. For technical assistance or to locate an authorized distributor,
contact one of our international sales and customer support locations.
USA/Canada
[email protected]
Tel: [phone]
Fax: [phone]
United Kingdom
[email protected]
Tel: [phone]
Fax: [phone]
China
[email protected]
Tel: [phone]
Fax: [phone]
Mexico
[email protected]
Tel: [phone]
Fax: [phone]
France
[email protected]
Tel: [phone]
Fax: [phone]
Japan
[email protected]
Tel: [phone]
Fax: [phone]
Brazil
[email protected]
Tel: [phone]
Fax: [phone]
Germany
[email protected]
Tel: [phone]
Fax: [phone]
Australia
[email protected]
Tel: [phone]
Fax: [phone]
For the latest information about our products, visit www.carlisleft.com.
