Acmeda AUTOMATE Installation manual

AUTOMATE WIND/ LIGHT SENSOR
INSTALLATION & PROGRAMMING INSTRUCTIONS
FEB 2014
Electronic Limit Tubular Motor
RF500 series Remote Control
RF5
AUTOMATE Wind / Light Detecon Sensor
[Wired]

INSTALLATION
The wind and light sensor can be installed in the following orientaons;
INSTALLATION INSTRUCTIONS
ORIENTATIONS
STEP 2 WIRE THE SENSOR.
STEP 1 REMOVE THE TWO SIDE CAPS TO OPEN THE POWER JUNCTION BOX.
STEP 3 FIX INTO DESIRED POSITION, USING TWO SCREWS PROVIDED.
STEP 4 FIX THE TWO SIDE CAPS BACK INTO POSITION.
ACTIVE
NEUTRAL
FIXING SCREW
SIDE CAP

a. Press the P2 buon on the back of the remote two mes.
b. Press the Seng buon on the sensor once.
The motor will beep and jolt to confirm pairing.
PROGRAMMING WITH AN RF500 SERIES REMOTE
Ensure the WL Sensor is connected to the motor.
a. Press UP buon on WL sensor to close the awning.
b. Press DOWN buon on remote to open the awning.
c. Repeat 2-3 mes.
Using a flat head screw driver set Wind speed and
Light grades to required intensity.
Refer Wind/Light grade preferences.
P2 (x2)
P
2
(x2
)
UP (x1)
SETTING (x1)
WIND GRADE SETTING
LIGHT GRADE SETTING
DOWN (x1)
STEP 2 CHECK CONNECTION
STEP 3 SET WIND/LIGHT GRADES
STEP 1 PAIR WL SENSOR WITH REMOTE

WIND GRADE PREFERENCES
TECHNICAL SPECIFICATIONS
GRADE SUN LIGHT
0 Not acve
1 15K Lux
2 30K Lux
3 45K Lux
4 60K Lux
GRADE WIND SPEED
0/1 15 Km/h
2 30 Km/h
3 45 Km/h
Radio Frequency 433.92 MHz
Control Range 200m
AC Power 230V/50Hz
Size 244mm x 110 mm x 30 mm
Current 0.15A
Consumpon 0.1 was
• Safety code (50 million me without repeat, high security)
• 3 wind grade protecon and 4 different sunlight ranks
• Can control up to 20 receivers
LIGHT GRADE PREFERENCES
If the wind speed is over the seng value for more than 3 seconds, the sensor will close the awning.
If the sun light is over the seng value for 2 minutes, the sensor will open the awning.
If the sun light doesn’t reach the seng value for more than 15 minutes, the sensor will close the awning.
