Acmeda PIUMA User manual


PIUMA
INSTALLATIONMANUAL

December2014


CONTENTS
December2014
ThismanualistobereadinconjunctionwiththeProductSpecifications&Assemblymanual

SECTIONNO.DESCRIPTIONPAGENO.

SECTION1−ITEMSREQUIRED1.1
SECTION2−INSTALLATION2.1
SECTION3–REGULATINGTHEAWNING3.1
SECTION4–REMOVINGTHEAWNING4.1

DISCLAIMER
INTRODUCTION
ThisInstallationmanualhasbeenproducedbyAcmedatosupplythenecessaryinformationforsafeandcorrectinstallationofthissystem.
INSTALLERSRESPONSIBILITY
Beforeinstalling,pleaseread&ensureyouunderstandthesafetyinformationandinstallationinstructionsasdefinedinthisinstallationmanual.
Ifyoudonotfullyunderstandtheseinstructions,contactAcmedaforclarificationbeforeinstalling.
TheInstallerisresponsibletoensurethatallinstallationpersonnelhavebeenadequatelytrainedonthesafe&correctinstallationandoperation.
TheInstallerisresponsibletoensurethataJobSafetyAnalysisorSafeWorkMethodStatementiscompletedpriortoinstallationtoidentifyhazards,todetermine
appropriateriskcontrolmeasuresandtoimplementthecontrolmeasures.
TheInstallerisresponsibletoensurethatsupportingstructuresaresoundandcanadequatelysupporttheload.
TheInstallerisresponsibletoensurethatthedevisesusedtoanchortheproducttothesupportingstructurearesuitablefortheapplication.
SAFETYINFORMATION
EnsureJobSafetyAnalysis/SafeWorkMethodStatementiscompletedandactionstoreducerisksareimplemented.
EnsurethatelectricalworksaredoneonlybyaLICENSEDELECTRICIAN.
DONOTmodifyanyofthecomponentsofthissystem.
PERSONNELREQUIREMENTS
Onlysuitablytrained/qualifiedpersonnelshouldundertakeinstallation.
DISCLAIMER
Acmedahasusedreasonablecareinpreparingtheinformationincludedinthisdocument,butmakesnorepresentationsorwarrantiesastothecompletenessoraccuracy
oftheinformation.Informationissuppliedupontheconditionthatthepersonsreceivingtheinformationwillmaketheirowndeterminationastoitssuitabilityfortheir
purposespriortouse.Acmedaassumesnoliabilitywhatsoeverforanydamagesincurredbyyouresultingfromerrorsinoromissionsfromtheinformationincluded
herein.Acmedareservestherighttomakechangeswithoutfurthernoticetoanyproductstoimprovereliability,functionordesign.
COPYRIGHT
COPYRIGHT©ACMEDA2014
Allrightsreserved.Nopartofthisdocumentmaybereproducedorutilisedinanymeans,byanymeans,electronicormechanicalincludingphotocopying,recordings,or
byanyinformationstorageorretrievalsystem,withouttheexpresspermissionfromAcmeda.


Page1.1piumaInstallationManual|December2014
©Copyright2014|AllRightsReservedAcmeda(InternationalGroup)

SECTION1−ITEMSREQUIRED

TOOLSREQUIRED
Saw
Drill
DrillBits–[specifysizesrequiredifdetailedinassemblymanual]
HighFrequencyWelder
ScrewDriver–PhilipsHead[detailifanyalternatescrewdriversarerequired]
JawPliers[detailifanyalternatepliersarerequired]
Scissors
Stapler
Punchtool/template
MeasuringTape
Pencil
Etc

ADDITIONALITEMSREQUIRED(NOTSUPPLIED)
Toassembleapiuma,thefollowingnon‐stockeditemsarerequired:
Staples[specifysizeifapplicable]
Fabric
Spline[Specifysplinesizesandtype]
Screw[Specifyscrewtype,headtype,size,lengthandmaterial]
Rivet[Specifyheadtype,size,griprangeandmaterial]
Ballast[Specifysizes]
Etc

BLINDITEMSREQUIRED
1. ASSEMBLEDAWNING

2. BRACKETS





Page2.1piumaInstallationManual|December2014
©Copyright2014|AllRightsReservedAcmeda(InternationalGroup)

SECTION2−INSTALLATION

STEP1–DEFINEBRACKETPOSITION
Definethedistanceofthewall/ceilingbracketsandpositionthemonthewall


STEP2–ATTACHAWNINGTOBRACKETS
Insertthesquarebar(A)tothewall/ceilingbrackets(B)positionedpreviously.
Checkdistancerequiredtoinstallsquarebartobrackets(Fig1.1&1.2)




STEP3–TESTAWNING
Afterhavingcheckedthetightnessofthefrontterminalbarconnectingscrews,removethesafetybandsandstrapsfromthearms
andopentheawning.
Fixthefabrictotheterminalbartopreventisfromsliding.
Usescrewsbetweenthesplineandtheextrusion.
Openandclosetheawningtwice.


IMPORTANT
Ensurethattherearenopersons,animalsorthingsinthevicinitywhileopening/closingtheawning.




Page3.1piumaInstallationManual|December2014
©Copyright2014|AllRightsReservedAcmeda(InternationalGroup)

SECTION3–REGULATINGTHEAWNING

Oncetheawninghasbeenassembled,tocheckthatallthecomponentsarecorrectlyfittedyoumust:
•Complete2‐3testcyclesofopening/closingtheawning.
•Regulateanycomponentsthatpreventthecorrectandunimpededopeningandclosingmovementoftheawning.


STEP1‐DESCRIPTION
Ensurethattherearenopersons,animalsorthingsinthevicinitywhileopening/closingtheawning.
I. Slackenthesidescrew(A)ofthefoldingarmsupportusingandallenkey10.
II. Toincreasetheinclination,slackenthesocketheadscrew(B)usingallenkey8.
III. Todecreasetheinclination,tightenthesocket‐headscrew,raisingthefrontterminalbar.

Afterregulation,checkthatthefrontterminalbarisperfectlyhorizontal.


DESCRIPTION
Afterregulation,firmlytightenthesidescrew.
Withtheawningalmostclosed,checkthatthearmsareparallel.
Iftheyarenotparallel,tightenorslackenthedowelintheleverusingAllenkey3,accompanyingthearm.




Page4.1piumaInstallationManual|December2014
©Copyright2014|AllRightsReservedAcmeda(InternationalGroup)

SECTION4–REMOVINGTHEAWNING

•Theawningmustbetakendownbyqualifiedpersonnel.
•Theawningmustbetakendownwhenclosed.

I. Removethescrewsfromthebracketsthatlockthesquarebarinplaceandremovetheawningfromthe
brackets. 


