ACMER LightBurn User manual
Install LightBurn
Introduction
Create Device
Software introduction and
basic parameter setting
Connecting device
Import image
Begain engraving
01
02
04
06
08
09
12
Thank you for purchasing ACMER Laser
Engraving Cutting Machine. We are dedicated
to producing low-price, high-quality Laser
Engraving Cutting Machine and hope
you have as much fun using it as we did create it.
If you have any issues/questions regarding
the contents in the kit, please fill out a Service
Ticket on our Support page.
If you have any issues/questions regarding the
contents in the kit, please fill out a Service Ticket
on our Support page creating a Service Ticket
will serve as your official request for ACMERsupport.
Our Customer Support Team will contact you within
48 hours.
First of all, lightburn is a third-party software.Because its functions are relatively complete
and suitable for most laser engraving machinesin the market, we recommend you to use this
software.
Secondly, lightburn gives new users a 30 day trial period. If you need to use it continuously,
you need to pay for it.
Lastly, if you encounter any problems in using lightburn, you can get technical support from
our community.
https://www.facebook.com/groups/636514078064476/
1
01
Tips:
Before you use lightburn to operate the engraving machine, please ensure that your computer
has installed the CH340 driver. If not, please install the driver according to the instructions on page
16 of the manual.
2
02
2.1 Obtain the LightBurn software installation package
2.1.1 Get the software installation package
from the official website 2.1.2Get the software installation package
from the official website
https://lightburnsoftware.com/pages/
trial-version-try-before-you-buy
Select the version suitable for
your computer to download
}
The attached memory card has a pre downloaded
installation package. The version may lag. You can
manually update to the latest version after installation.
2
03
2.2 installation
Check create desktop icon
click Next click Next Check the last item
click Finish
Double click the install program to install the software,This version is not necessarily the latest version.
2
03
3.1 creat device
3
04
3.1.1 Normally, when you open the software for the first time,
you will be prompted to create a device.
3.1.2 If there is no prompt or the dialog box is closed accidentally,
you can modify it here
2
3.2 creat device
3
choose Create Manually choose GRBL,then click Next choose Serial/USB
Name your device and set your
engraving range
Choose Rear Left as the origin of
your device
Confirm your equipment parameters
and click finish
05
2
03
4.1
Software introduction
4
06
05
1
44445
4444444442
44443
44444
44446
1.Function bar: Here you can open or save the
software, adjust the parameters of the software,
including the language, and the basic parameter
settings of your device.
2.Drawing tool bar: Here, you can use the graphics
tools of the software to create the graphics or text
you want.
3.Image display area: Place the picture or figure
you want to engrave in this area, and the area size
corresponds to the actual engraving range of your
device.
4.Machine status bar: There are many windows in
this area. You can see the real-time instructions of
the machine operation, the basic parameters and
line layers of the graphics you want to carve, etc
5.Online operation bar: In this area, you can
operate your machine online, such as starting
or stopping engraving, predicting engraving
borders, etc
6.Line layer bar: Select different line layers for
your graphics to adjust different parameters
2
03
4.2
basic parameter setting
4
07
Functin bar: The parameters of these two items can be set as shown in the figure, and can be adjusted according to special needs.
It should be noted that the parameters in the dashed box cannot be changed.
2
03
5.1
Connect USB
5
08
Tips: Before connecting the machine, please confirm that your computer has installed the CH340 driver. If not, please install the driver
according to the operating instructions in the manual. Confirm that your bit rate is 115200. See the previous page for baud rate settings.
Confirm that the port is not occupied.
Connect the computer
Connect the machine
5.2
Software Settings
Select the right port and the
right machine
If the connection is
successful, the control
bar window will
prompt ‘OK’.
2
03
6
09
Choose ‘File’--> ‘Import’
to load your picture.
6.1
Load image
Tips: Make sure your picture is within the range of 400mm* 410mm and cannot exceed the solid wireframe.
You can adjust the size and position by entering values or scaling the picture.
0309
2
03
6
10
6.2
Adjust image
Right click the image and select Adjust Image. In the pop-up
dialog box, adjust the brightness, contrast and other parameters
of the image to ensure a good carving result.
0310
2
03
6
11
6.3
set engraving parameters
Set engraving speed
and power.
Set DPI value.
1
2
3
Set Sculpt Mode.
Double click the image line layer in the line‘cuts/layers’
window, and adjust the corresponding parameters in the
order shown in the figure in the pop-up dialog box.
2
03
7
12
7.1
1
3
2
5
1. Switch from ‘Cut / Layers’ window to ‘Move’
window,.
2. Move the laser head to the appropriate position by
button or manually.
3. Set engraving origin point.
4. Click Frame to let the engraving machine simulate
the engraving range to ensure that the laser head can
carve normally within the engraving range. Repeat
steps 2 and 3 if the scope is inappropriate.
4
5. After everything is OK, you can start carving.
