USER'S MANUAL
Thank you very much for purchasing the EGX-30.
• To ensure correct and safe usage with a full under-
standing of this product's performance, please be sure
to read through this manual completely and store it in
a safe location.
• Unauthorized copying or transferral, in whole or in
part, of this manual is prohibited.
• The contents of this operation manual and the
specifications of this product are subject to change
without notice.
• The operation manual and the product have been
prepared and tested as much as possible. If you find
any misprint or error, please inform us.
• Roland DG Corp. assumes no responsibility for any
direct or indirect loss or damage which may occur
through use of this product, regardless of any failure to
perform on the part of this product.
• Roland DG Corp. assumes no responsibility for any
direct or indirect loss or damage which may occur
with respect to any article made using this product.

Operating Instructions
KEEP WORK AREA CLEAN. Cluttered areas and benches
invites accidents.
DON’T USE IN DANGEROUS ENVIRONMENT. Don’t
use power tools in damp or wet locations, or expose them to
rain. Keep work area well lighted.
DISCONNECT TOOLS before servicing; when changing
accessories, such as blades, bits, cutters, and like.
REDUCE THE RISK OF UNINTENTIONAL STARTING.
Make sure the switch is in off position before plugging in.
USE RECOMMENDED ACCESSORIES. Consult the
owner’s manual for recommended accessories. The use of
improper accessories may cause risk of injury to persons.
NEVER LEAVE TOOL RUNNING UNATTENDED.
TURN POWER OFF. Don’t leave tool until it comes to a
complete stop.
NOTICE Grounding Instructions
Do not modify the plug provided - if it will not fit the outlet,
have the proper outlet installed by a qualified electrician.
Check with qualified electrician or service personnel if the
grounding instructions are not completely understood, or if in
doubt as to whether the tool is properly grounded.
Use only 3-wire extension cords that have 3-prong
grounding plugs and 3-pole receptacles that accept the tool’s
plug.
Repair or replace damaged or worn out cord immediately.
For Canada
CLASS A NOTICE
This Class A digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
CLASSE A AVIS
Cet appareil numérique de la classe A respecte toutes les
exigences du Règlement sur le matériel brouilleur du
Canada.
ROLAND DG CORPORATION
1-6-4 Shinmiyakoda, Hamamatsu-shi, Shizuoka-ken, JAPAN 431-2103
MODEL NAME : See the MODEL given on the rating plate.
RELEVANT DIRECTIVE : EC MACHINERY DIRECTIVE (98/37/EC)
EC LOWVOLTAGE DIRECTIVE (73/23/EEC)
EC ELECTROMAGNETIC COMPATIBILITY DIRECTIVE (89/336/EEC)
WARNING
This is a Class A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
For the USA
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE
STATEMENT
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated
in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference
to radio communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Unauthorized changes or modification to this system can void
the users authority to operate this equipment.
The I/O cables between this equipment and the computing
device must be shielded.

11
Copyright © 2001 Roland DG Corporation
Windows®and Windows NT®are registered trademarks or trademarks of Microsoft®Corporation in the United States and/or other
countries.
i486 and Pentium are registered trademarks of Intel Corporation in the United States.
IBM is a registered trademark of International Business Corporation.
Other company names and product name are trademarks or registerd trademarks of their respective holders.
http : //www.rolanddg. com/
Table of Contents
To Ensure Safe Use.................................................................................................................. 2
About the Labels Affixed to the Unit.................................................................... 4
Pour utiliser en toute sécurité ............................................................................................. 5
À propos des étiquettes collées sur l'appareil..................................................... 7
1 Great Features ........................................................................................................................... 8
2 Confirmation of Included Items .................................................................................................. 8
3 Part Names ................................................................................................................................ 9
4 Task Flow ................................................................................................................................. 10
5 Installation and Connections.................................................................................................... 11
Installation ................................................................................................................................................ 11
Connections ............................................................................................................................................. 11
Installing the Software.............................................................................................................................. 12
Interface Setup......................................................................................................................................... 15
Powerup ................................................................................................................................................... 15
6 Before Starting to Cut ................................................................................................................ 16
Loading the Material................................................................................................................................. 16
Installing a Tool......................................................................................................................................... 17
Setting the Origin Point ............................................................................................................................ 20
About Tools and Materials........................................................................................................................ 20
Test Cutting .............................................................................................................................................. 21
Setting Cutting Conditions........................................................................................................................ 21
Attaching a Vacuum Cleaner .................................................................................................................... 22
7 Sending Cutting Data............................................................................................................... 23
Changes That Can Be Made While Cutting ............................................................................................. 23
8 Ending Cutting Operations....................................................................................................... 23
9 Maintenance ............................................................................................................................ 24
These are maintenance tasks that should be performed by the user. ..................................................... 24
Recommended Service Checking............................................................................................................ 24
10 If There's a Problem................................................................................................................. 25
Appendix A List of Options........................................................................................................... 26
Appendix B Instruction Support Chart .........................................................................................26
Appendix C Specifications ........................................................................................................... 27

22
To Ensure Safe Use
Used for instructions intended to alert the user to the risk of death or severe
injury should the unit be used improperly.
About and Notices
Used for instructions intended to alert the user to the risk of injury or material
damage should the unit be used improperly.
* Material damage refers to damage or other adverse effects caused with
respect to the home and all its furnishings, as well to domestic animals or
pets.
About the Symbols
The symbol alerts the user to important instructions or warnings. The specific meaning of
the symbol is determined by the design contained within the triangle. The symbol at left means
"danger of electrocution."
The symbol alerts the user to items that must never be carried out (are forbidden). The
specific thing that must not be done is indicated by the design contained within the circle. The
symbol at left means the unit must never be disassembled.
The symbol alerts the user to things that must be carried out. The specific thing that must
be done is indicated by the design contained within the circle. The symbol at left means the
power-cord plug must be unplugged from the outlet.
Do not disassemble, repair, or
modify.
Doing so may lead to fire or abnormal
operation resulting in injury.
Use only with the power cord
included with this product.
Use with other than the included power cord
may lead to fire or electrocution.
Ground the unit with the ground
wire.
Failure to do so may result in risk of
electrical shock in the even of a mechanical
problem.
Do not use while in an abnormal
state (i.e., emitting smoke, burning
odor, unusual noise, or the like).
Doing so may result in fire or electrical
shock.
Immediately switch off the power, unplug
the power cord from the electrical outlet,
and contact your authorized Roland DG
Corp. dealer or service center.
Do not use with a damaged power
cord or plug, or with a loose
electrical outlet.
Use with any other
power supply may
lead to fire or
electrocution.
Do not injure or modify the electrical
power cord, nor subject it to
excessive bends, twists, pulls,
binding, or pinching, nor place any
object of weight on it.
Doing so may
damage the
electrical power
cord, leading to
electrocution or fire.
Do not use with any electrical power
supply that does not meet the
ratings displayed on the unit.
Use with any other power supply may lead
to fire or electrocution.

33
Do not inadvertently allow the
hands, or hair near the rotating parts
while in operation.
They may become
caught in the tool,
resulting in injury.
When not in use for extended
periods, unplug the power cord from
the electrical outlet.
Failure to do so may
result in danger of
shock, electrocution,
or fire due to
deterioration of the
electrical insulation.
When unplugging the electrical
power cord from the power outlet,
grasp the plug, not the cord.
Unplugging by pulling the cord may damage
it, leading to fire or electrocution.
Do not attempt to unplug the power
cord with wet hands.
Doing so may
result in electrical
shock.
Do not allow liquids, metal objects
or flammables inside the machine.
Such materials
can cause fire.
Install on a stable surface.
Failure to do so
may result in falling
of the unit, leading
to injury.
Wash hands when finished.
Wash hands with
water to remove
any adhering
cutting chips.
Do not use cutting oil when
performing cutting.
Perform dry cutting
with no cutting oil.
Use of cutting oil
may result in fire
or machine failure.
Use a vacuum cleaner to remove
cutting dust. Do not use any blower
like airbrush.
Otherwise, dust
spread in the air
may harm your
health or damage
this machine.

44
About the Labels Affixed to the Unit
These labels are affixed to the body of this product.
The following figure describes the location and content of these messages.
: Indicates information to prevent machine breakdown or malfunction and ensure correct use.
: Indicates a handy tip or advice regarding use.
In addition to the and symbols, the symbols shown below are also used.
Model name
Rating label
Use a rated power supply.
NOTICE
Keep fingers away from the
tool while the tool is rotating.
Do not inadvertently allow
the hands, hair, or necktie
near the rotating parts
while in operation.

55
Utilisé pour avertir l'utilisateur d'un risque de décès ou de blessure grave en
cas de mauvaise utilisation de l'appareil.
Avis sur les avertissements
Utilisé pour avertir l'utilisateur d'un risque de blessure ou de dommage
matériel en cas de mauvaise utilisation de l'appareil.
* Par dommage matériel, il est entendu dommage ou tout autre effet
indésirable sur la maison, tous les meubles et même les animaux
domestiques.
À propos des symboles
Le symbole attire l'attention de l'utilisateur sur les instructions importantes ou les
avertissements. Le sens précis du symbole est déterminé par le dessin à l'intérieur du triangle.
Le symbole à gauche signifie "danger d'électrocution".
Le symbole avertit l'utilisateur de ce qu'il ne doit pas faire, ce qui est interdit. La chose
spécifique à ne pas faire est indiquée par le dessin à l'intérieur du cercle. Le symbole à gauche
signifie que l'appareil ne doit jamais être démonté.
Le symbole prévient l'utilisateur sur ce qu'il doit faire. La chose spécifique à faire est
indiquée par le dessin à l'intérieur du cercle. Le symbole à gauche signifie que le fil électrique
doit être débranché de la prise.
Pour utiliser en toute sécurité
Ne pas démonter, réparer ou
modifier.
Le non-respect de cette consigne pourrait
causer un incendie ou provoquer des
opérations anormales entraînant des
blessures.
Mettre l'appareil à la masse avec une
prise de terre.
Le non-respect de cette consigne pourrait
entraîner des décharges électriques en
cas de problème mécanique.
Utiliser seulement avec une
alimentation de mêmes
caractéristiques électriques que
celles indiquées sur l'appareil.
Une utilisation avec toute autre alimentation
électrique pourrait provoquer un incendie
ou une électrocution.
N'utilisez que le cordon
d'alimentation fourni avec ce
produit.
L'utilisation avec un autre cordon
d'alimentation que celui fourni pourrait
entrainer un risque d'incendie ou
d'électrocution.
Ne pas utiliser si l'appareil est dans
un état anormal (c'est-à-dire s'il y a
émission de fumée, odeur de brûlé,
bruit inhabituel etc.).
Le non-respect de cette consigne pourrait
provoquer un incendie ou des décharges
électriques.
Couper immédiatement l'alimentation
secondaire et ensuite l'alimentation
principale. Débranchez le fil électrique et
contacter votre revendeur ou votre centre
de service de la société Roland DG
autorisé.

66
Ne pas utiliser avec une fiche ou un
fil électrique endommagé ou avec
une prise mal fixée.
Une négligence à
ce niveau pourrait
provoquer un
incendie ou une
électrocution.
Ne pas endommager ou modifier le
fil électrique. Ne pas le plier, le
tordre, l'étirer, l'attacher ou le serrer
de façon excessive. Ne pas mettre
d'objet ou de poids dessus.
Une négligence à ce niveau pourrait
endommager le fil
électrique ce qui
risquerait de
provoquer une
électrocution ou
un incendie.
Débrancher le fil lorsque l'appareil
reste inutilisé pendant une longue
période.
Une négligence à ce niveau pourrait
provoquer des décharges électriques,
une électrocution ou
un incendie dû à une
détérioration de
l'isolation électrique.
Saisir la fiche et non le fil électrique
lorsque vous débranchez.
Débrancher en tirant sur le fil pourrait
l'endommager et risquer de provoquer un
incendie ou une électrocution.
Ne pas essayer de débrancher le fil
avec des mains mouillées.
Une négligence à
ce niveau pourrait
provoquer des
décharges
électriques.
Ne pas introduire de liquide, d'objet
métallique ou inflammable dans
l'appareil.
Ce genre de
matériel peut
provoquer un
incendie.
Se laver les mains après la coupe.
Se laver les mains
à l'eau pour en
enlever toutes les
rognures de coupe
qui peuvent y
adhérer.
Retirer la poussière de coupe à
l'aide d'un aspirateur. Ne pas utiliser
d'appareil soufflant, par exemple un
pinceau à air (aérographe).
La poussière
répandue dans l'air
par un appareil
soufflant est un
risque pour la
santé et peut
endommager
l'appareil.
Installer l’appareil sur une surface
stable.
Une négligence à
ce niveau pourrait
provoquer la chute
de l’appareil et
entraîner des
blessures.
Ne pas utiliser d'huile de coupe.
Faire des coupes à sec,
sans huile de coupe.
Utiliser de l'huile de
coupe risque de
provoquer un incendie
ou une panne
de l'appareil.
Garder les mains, cheveux et
cravates éloignés des pièces
tournantes pendant que
l'appareil fonctionne.
Sinon ils peuvent se
prendre dans l'outil,
ce qui causera des
blessures.

77
À propos des étiquettes collées sur l'appareil
Ces étiquettes sont collées àl'extérieur de l'appareil.
Les dessins suivants indiquent l'endroit et le contenu des messages.
Nom du modèle
Étiquette des caractéristiques
électriques
Utiliser l'alimentation appropriée
Garder les doigts loin de
l'outil pendant qu'il tourne.
Garder les mains,
cheveux et cravates
éloignés des pièces
tournantes pendant que
l'appareil fonctionne.

8
1 Great Features
Hexagonal screw-
driver -- 1
Adhesive sheet for
securing material
-- 1 sheet
Dust collector hose
and duct -- 1
2 Confirmation of Included Items
Character cutter -- 1 Spanner -- 1
Plate
Engraving - ENGRAVER
You can engrave nametags and other plastic plates.
The character cutter is usually used for engraving.
Test material -- 1
Power cord -- 1Hexagonal wrench
-- 1
Engraving-tool
holder -- 1
User's manual -- 1
This product is packed with the following accessory items in addition to the EGX-30. Before using the EGX-30, check to make
sure that all items are included.
Diamond scraper
adapter -- 1
This scribes the surface of materials such as aluminum or brass. An optional diamond scraper that has diamond chips
embedded in its tip of the cutter is used to engrave the surface of the material by scraping. This produces a lustrous engraved
area and an attractive finish, especially when aluminum is used.
Scoring - SCORE
Tools that can be used with the EGX-30 are optionally available from Roland DG Corp. For details, see "Appendix A List of
Options"
Roland Software Pakage
CD-ROM -- 1

9
3 Part Names
The table grips the workpiece
to be cut.
(Described on the following
page.)
Tool carriage
Control Panel
Table
Front
Rear
Power switch
Depth regulator nose
This secures the depth regulator
nose or tool adapter in place.
Tool mounting screw
This is used to attach the
character cutter for engraving
and to adjust the amount of
blade extension.
Dust collector hose port
This is where the dust collector
is attached to take up cuttings
while engraving is in progress.
Removing the Safe-transport Retainers
Retainers are attached at the locations shown in the
figure to ensure safety when transporting this
product.
Use the hexagonal wrench included with the unit to
remove the retainers before use. (Once removed, the
retainers should be stored in a safe place because they
are needed again when repacking the product.)
A serial (RS-232C) cable is
connected here.
Serial connector
Parallel connector
A parallel (printer) cable is
connected here.
The power cord included with the
machine connected here.
Power connector
Safe-transport
Retainer

10
Control Panel
rpm knob
This sets the spindle
speed (in rpm).
SPEED knob
This sets the cutting
speed.
SELECT key
This selects the cutting mode.
The LED for the selected mode lights up.
5. Load the material and install the tool.
6. Set the origin point.
7. Set the cutting conditions (test cut).
10. Switch off the power.
11. Clean up.
4. Switch on the power to the EGX-30.
2. Install the driver software and set up the interface.
3. Use a software application to create the data.
1. Install and connect the computer and the EGX-30.
Follow the steps shown below to work with materials on the EGX-30.
4 Task Flow
9. End operations.
8. Send the data from the computer to perform machining.
SET SURFACE / TEST key
Pressed briefly: When the character cutter has been installed, this moves the tool up or down.
Held down for one second or longer: Performs test cutting.
PAUSE / VIEW key
Pressed briefly: Pauses operation.
Held down for two seconds or longer: Moves the tool carriage to the rear right (the
VIEW position) and pauses operation.
The functions of these keys
differ depending on whether
the key is pressed briefly
and immediately released or
held down for a certain
length of time.
ORIGIN POINT / SET ORIGIN POINT key
Pressed briefly: Moves the tool carriage to the origin point.
Held down for two seconds or longer: Makes the present position of the tool carriage the
origin point.
Held down
Pressed
briefly
These are used to move the tool carriage in the direction of the arrow.
Hold down the key for faster movement.
ARROW keys

11
5 Installation and Connections
Never install this unit in any of the following situations, as it could result in damage:
Places where the installation surface is unstable or not level.
Places with excessive electrical noise.
Places with excessive humidity or dust.
Places with poor ventilation, because the EGX-30 generates considerable heat during operation.
Places with excessive vibration.
Places exposed to strong illumination or direct sunlight.
When arranging setup space for the EGX-30, make sure you have a space that is at least 800 mm (32 in.) wide, 800 mm (32 in.) in
depth, and 600 mm (24 in.) in height.
Always make sure that the power is off on both the computer and the EGX-30 whenever any cables are
connected or disconnected.
Securely connect the power cord, computer I/O cable and so on so that they will not be unplugged and cause
failure during operation.
Cables are available separately. One which you are sure matches the model of computer being used should be
selected.
Serial (RS-232C) cable
(sold separately)
Screws
Parallel cable
(sold separately)
Lock-use pins
Use either a parallel
cable or serial cable
to connect.
Power cord
RS-232Cconnector
onthecomputer Printer connector
on the computer
Rear View
Screws
Install on a stable surface.
Failure to do so
may result in falling
of the unit, leading
to injury.
NOTICE
Do not use with a damaged power
cord or plug, or with a loose
electrical outlet.
Use with any other
power supply may
lead to fire or
electrocution.
NOTICE
Installation
Connections

12
The included CD-ROM contains several pieces of software for operating the EGX-30.
Setting Up the Program
Switch on the computer and start Windows.
1Place the CD from the Roland Software Package in
the CD-ROM drive.
The Setup menu appears automatically.
2
When the screen shown below appears, click the in [Click here], then choose [EGX-30].
Click [Install].
To view the description of a program, click the button. To view the manual, click the button.
(There are manuals in PDF format for the programs that the button references. Acrobat Reader is required to view PDF
files.)
3
* When setting up the software under Windows XP, Windows 2000 and Windows NT 4.0, log on as the member of a group [Adminis-
trators] or [Power Users].
For more information about groups, refer to the documentation for Windows.
If there are programs you don't want to install, then
clear their check boxes before you click [Install].
System Requirements
<Dr.Engrave>
Installing the Software
- Microsoft®Windows®95, Windows 98, Windows Me, Windows NT®4.0, Windows 2000, or Windows XP operating system
- The minimum required CPU for the operating system (Pentium®or higher recommended)
- The minimum amount of required RAM for the operating system (32 Mbytes or more recommended)
- 10 Mbytes or more of free hard disk space for installation

13
The Setup program starts. Follow the messages to carry
out setup and finish setting up the program.
4
When all installation finishes, the screen show below
appears.
Click [Close].
7
* When the setup for one program finishes, the
setup for the next program starts.
In the interval until the next setup starts, a dialog
box showing the progress of processing is
displayed.
The driver settings appear.
When you make the settings for the communication
parameters of EGX-30, make the parameters match the
values displayed here.
Click [Close] to finish installing the driver.
6
If the following screen appears while installing the
driver, click the drop-down arrow and choose the port
for the cable connected to the computer.
When using an RS-232C (serial) cable
[COM1:] or [COM2:]
When using a printer (parallel) cable
[LPT1:] or [LPT2:]
5
After returning to the menu screen for installation, click
.
8
Remove the CD-ROM from the CD-ROM drive.
9

14
How to use Help
From the [Help] menu, click [Contents].
1Clicking on text that is green and underlined (by a
solid or dotted line) displays an explanation.
2
Clicking on an image area that contains an explana-
tion displays the explanation.
3
When the pointer moves over green underlined text, it
changes to a pointing hand ( ).
When the pointer moves over a location where an explana-
tion is included, it changes to a pointing hand ( ).
Tip
When there's a [?] button on screen
When there's a [Help] button on
screen.
Clicking [Help] lets you view help for the window or
software.
Clicking [?] in the upper-right corner of the window makes
the mouse pointer change to a question mark ( ). You
can then move the pointer over any item you wish to
learn more about, then click on the item to display an
explanation of it.
If you have trouble using the program or driver, see the help screens. Help contains information such as descriptions of software opera-
tion, explanations of commands, and tips for using the software more effectively.

15
SET ORIGINVIEWTEST
Interface Setup
12
4
3
Switch on the EGX-30 power switch.
(The PAUSE LED flashes at this time.) Press the PAUSE/VIEW key.
The tool carriage moves to the left rear.
Communication parameters for a serial connection
The tool carriage stops when it reaches the VIEW
position (inner right-hand side).
To ensure safety, operation of the EGX-30 is paused when the power is switched on.
Press the PAUSE/VIEW key to end the paused state.
Powerup
EGX-30 automatically detects the type of interface (parallel or serial) from the first batch of data sent from the computer
after the power is switched on.
When using a serial connection for the interface, however, the communication parameters on the computer should be set
as follows.
The communication parameters for the EGX-30 are locked in and cannot be changed.
The EGX-30 is now ready to receive data.
Stop bit 1bit
Data bit 8bit
Parity None
Baud rate 9600bps
Handshake Hardware

16
6 Before Starting to Cut
Loading the Material
If the material is not secured correctly, it may not be cut as intended.
Some examples of material loading are shown below. Refer to these to use the appropriate method for the material at hand to
secure it in place.
* Be sure that the tool carriage is at the VIEW position ( inner right-hand side ) before loading material.
Adhesive sheet for
securing material Double-sided
tape
Bottom of the
material
Using the included adhesive sheet... Using commercially available
double-sided tape...
Material

17
5Tighten the screw securely to secure the cutter in
place.
Gently lower the cutter until the tip of the cutter
touches the surface of the material. 6
Hexagonal
screw driver
Material surface
3
Installing a Tool
The steps for installing a tool are shown below. Follow these steps to install the appropriate tool for the task.
For Engraving (Character Cutter) * Use SELECT key to choose "ENGRAVER" as the mode.
1
When installing a cutter for engraving, make sure the tip of the cutter protrudes beyond the surface of the material by an amount
equal to the depth of engraving to be performed.
Move the tool carriage to a position over the material surface, then install the cutter.
2
Press the SET SURFACE key to lower the tool,
then loosen the screw for the engraving-tool holder.
Provisionally tighten the character cutter in the
engraving-tool holder, and install the engraving-tool
holder on the tool carriage.
Loosen the tool mounting screw and insert the depth
regulator nose in the tool carriage.
Hexagonal
screw driver
Install the depth regulator nose as shown in the
figure.
1. Line up the
protrusion with
the groove on
the front, and fit
it in the groove.
3. Retighten the tool
mounting screw to
secure the nose in
place.
2. Rotate in the
direction of
the arrow.
The spanner included with
the unit is 3 mm (1/8 in.) thick,
and can be used as to check
the width of the space.
Screw
part 3 mm (1/8 in.)
Adjust the screw so to make
this space 3 mm (1/8 in.).
4
Hexagonal
screw driver
2. Rotate in the direction
of the arrow.
1. Turn in the direction
of the arrow to
tighten provisionally.
Engraving-
tool holder
Use the spanner to tighten and secure in place.

18
Rotate in the direction of
the arrow and remove.
Use the spanner to
tighten and secure in place.
How to Remove the Cutter for Engraving
Rotate in the direction of
the arrow, line up with the
groove, and remove.
Loosen
Engraving-
tool holder
7Press the SET SURFACE key to raise the cutter.
Use the spanner to turn the depth regulator nose in the direction of the arrow to extend the blade depth to the desired
engraving depth.
Turning the nose by an amount
equal to the length of one side
causes the tool to be extended
by 0.125 mm (0.005 in.).
(One turn corresponds to
0.75 mm (0.03 in.) )
Spanner
When engraving an acrylic panel, the depth that can be engraved at one time is about 0.25 mm (0.01 in.).
To engrave to engrave to a greater depth, repeat the same engraving several times, increasing the amount
of blade extension with each pass until the desired engraving depth is reached.
Example: Engraving to a depth of 1 mm (0.04 in.)
[Number of engraving passes] : 4
[Amount of blade extension]
1st pass: 0.25 mm (0.01 in.) -> 2nd pass: 0.5 mm (0.02 in.) ->
3rd pass: 0.75 mm (0.03 in.) -> 4th pass: 1 mm (0.04 in.)
How to Remove
the Depth Regulator Nose
