Acnodes KDS 61916 User manual

20947 Currier Road Suite #H
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
KDS 61916
19” 1280 x 1024 / 1152 X 900 LCD
SUN-keys keyboard / track abll
16 port USB KVM switch
» Specifications
» Features
Material:
Heavy-duty steel
Keyboard and track ball (USB-type):
101 keys keyboard with 10keys key-pad
Sun keys:
STOP, HELP, AGAIN PROPS, UNDO, FIND, OPEN COPY, CUT, PASTE
and FRONT
3-buttons track ball
LCD Panel:
Size: 19"
Resolution: 1280x1024
Sun resolution: 1152x900
Atuo switch between Sun and PC display resolution
Brightness (cd/m^): 250nit
Contrast Ratio: 700 : 1
Response time:
Tr=15ms/ Tf=10ms
Pixel pitch: 0.242mm (H) x 0.242mm (W)
Viewing Angle: 170° Horizontal and 170° Vertical
Backlighs: 4 CCFTs
Colors: 16.7M colors
MTBF: 30,000 hours
KVM Switch:
16 port USB KVM switch
Connector type: proprietary DB-15 KVM connector
Cascades level: 8 levels, up to 128 servers
built-in microprocessor to emulation for each port boots up
processor
Input VGA resolution: 1,920 x 1,440
Auto Scan Mode: monitoring your server at interval 5 to 99s
Supprt hot-pluggable cable and built-in KVM switch buttons
Multi-platform: Suns, PCs, IBMs, HPs, Compaq & DELL
KVM switch Connector:
16 x D-Sub 15 pin (female) for VGA / Keyboard / Track ball
(drawer side)
1 x D-sub 15 pin for cascades port
Cable:
16 x 6' cable for VGA / Keyboard /Track ball
Optional for 10' or 15'
KVM side: 1 D-sub 15 pin proprietary KVM connector
Server side: 1 D-sub 15 pin VGA and 1 x USB connecors
Drawer Design:
High load-rating slide rail with angle bracket
extension up to 31.1” depth
Optional Extension bracket to 36" depth
Power adapter:
External 110/220VAC power adapter
Color:
Black
Operation Temperature:
0ºC to 50ºC
Weight:
40 lb
Safty:
FCC, CE
Dimension:
19"(W) x 23.62"(D) x 1.75"(H)
» Ordering Guide
» Options
CD-6U: 6’ USB KVM cable
CD-10U: 10’ USB KVM cable
CD-15U: 15’ USB KVM cable
» 1U compact design, only 23.6" depth
» 19" 1280 x 1024 / 1152 x 900 LCD
» OSD (On Screen Display) function
» 101 keys keyboard with built-in Sun keys & 10-keys keypad
» 3-buttons track ball
» 16 ports USB KVM switch
» 110/220VAC power adapter
KDS 61916:
1U, 19" 1280x1024 / 1152x900 TFT LCD, 16 port USB KVM
switch , 101-keys SUN-keys keyboard 3-buttons track ball, Black
color
