Acnodes APW4017 User manual

User Manual
All rights reserved. Product description and product specifications are subject to change without notice.
For lastest product information, please visit Acnodes’ website at www.acnodes.com
14628 Central Ave. Chino, CA91710 Tel: [phone] Fax: [phone]
© Copyright 2019Acnodes Corp.
APW4017
17.3" 4K LCD Panel
Aluminum Front Bezel
Panel / VESA Mount Ready
Industrial Monitors

Legal Information
First English printing, March 2019
Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness
of the contents. The information in this document is subject to change without notice. We are not liable for any injury or
loss that results from the use of this equipment.
Safety Instructions
Please read all of these instructions carefully before you use the device. Save this manual for
future reference.
■Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
■Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with
temperatures not exceeding 40º Celsius (104º Fahrenheit).
■When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and causing
damage to other equipment or injury to persons nearby.
■When the equipment is in an open position, do not cover, block or in any way obstruct the gap between it and the
power supply. Proper air convection is necessary to keep it from overheating.
■Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
■If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage and current
labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be higher than the one listed
on the equipment’s ratings label.
■Observe all precautions and warnings attached to the equipment.
■If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent being
damaged by transient over-voltage.
■Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to the power
supply or on other hardware may cause damage, fire or electrical shock.
■Only qualified service personnel should open the chassis. Opening it yourself could damage the equipment and
invalidate its warranty.
■If any part of the equipment becomes damaged or stops functioning, have it checked by qualified service personnel.
What the warranty does not cover
■Any product, on which the serial number has been defaced, modified or removed.
■Damage, deterioration or malfunction resulting from:
□Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or
failure to follow instructions supplied with the product.
□Repair or attempted repair by anyone not authorized by us.
□Any damage of the product due to shipment.
□Removal or installation of the product.
□Causes external to the product, such as electric power fluctuation or failure.
□Use of supplies or parts not meeting our specif cations.
□Normal wear and tear.
□Any other causes which does not relate to a product defect.
■Removal, installation, and set-up service charges.
Regulatory Notices Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
Any changes or modif cations made to this equipment may void the user’s authority to operate this equipment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
■Re-position or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Contents
< Part. 1 > APW4017
1.1 Package Content P.1
1.2 Structure Diagram & Dimension P.2 - 3
1.3 Mounting Hardware & Installation P.4
< Part. 2 > Specifications / OSD
2.1 P.5 - 6
2.2 P.7 - 9
2.3
Product Specifications
On-screen Display Operation ( OSD )
Picture In Picture ( PIP ) / Picture By Picture ( PBP ) P.10 -11
< Part. 3 > Options
P.12
P.13
P.14
P.15
P.16 - 17
P.18
3.1
3.2
3.3
3.4
3.5
3.6
3.7
Option Table
Remote Controller ( RC-2 )
3G / HD / SD-SDI input
MCS Multi-display Control Solution
Touchscreen & Driver
DC Power : 12V / 24V / 48V / 125V
MIL-type or lockable connector P.19

■It is very important to mount the equipment in a suitable cabinet or on a stable surface.
■Make sure the place has a good ventilation, is out of direct sunlight, away from sources of
excessive dust, dirt, heat, water, moisture and vibration.
Before Installation
Caution :
3
4
■To avoid the risk of electric shock, make sure your hands are dry before unplugging your monitor
from or plugging your monitor into an electrical outlet.
■When you clean your monitor, do not press down on the LCD screen. Pressing down on the screen
can scratch or damage your display. Pressure damage is not covered under warranty.
■Use only cleansers made specifically for cleaning monitors and monitor screens. Cleansers not
made to clean monitors and monitor screens can scratch the LCD display or strip off the finish.
■Do not spray any kind of liquid directly onto the screen or case of your monitor. Spraying liquids
directly onto the screen or case can cause damage which is not covered under warranty.
■Do not use paper towels or abrasive pads to clean your monitor. Using an abrasive pad or any
wood based paper product such as paper towels can scratch your LCD screen.
Cleaning Your Monitor
To clean your LCD safely, please follow these steps :
Disconnect the power cord.
Gently wipe the surface using a clean, dry microfiber cloth. Use as little pressure as possible.
1
2
Cleaning Tough Marks and Smudges
To remove tough marks and smudges, please follow these steps :
1
2
Disconnect the power cord.
Spray a small amount of non-abrasive cleanser on a microfiber cloth.
Caution : Do not spray or apply any liquids directly onto the monitor. Always apply the solution to
your microfiber cloth first, not directly on the parts you are cleaning.
Gently wipe the surface. Use as little pressure as possible.
Wait until your monitor is completely dry before plugging it in and powering it up.
Unpacking
The equipment comes with the standard parts shown in package content. Check and make sure
they are included and in good condition. If anything is missing, or damaged, contact the
supplier immediately.
How To Clean Your LCD Monitor

P. 1
17.3” 4K LCD Display x 1
6ft DP cable x 1
Power adapter x 1
Power cord x 1
Mounting hardware x 1 pack
APW4017
Basic I/O
Power
Audio out
HDMI 1.4 HDMI 2.0 DP
< Part 1 > APW4017
< 1.1 > Package Content
17.3” 4K LCD Display

P. 2
Rear case
LCD panel
6mm aluminum front bezel
Audio speaker, pair
LCD membrane
1
2
3
4
5
1
2
3
5
4
APW4017
Model Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
APW4017 440.5 x 53.6 x 293 mm
17.3 x 2.1 x 11.5 inch
615 x 113 x 523 mm
24.2 x 4.4 x 20.6 inch
5.2 kg
11.4 lb
8.0 kg
17.6 lb
Front View
Rear View
Side View
Bottom View
< 1.2 > Structure Diagram
17.3” 4K LCD Display

P. 3
Front View Side View
Rear View
UNIT : mm
1mm = 0.03937 inch
< 1.2 > Dimension
17.3” 4K LCD Display
M6*4pcs
M4*8pcs
APW4017

P. 4
1
x 2 pcs
Mounting
bracket x 4 pcs
M4*6mm screw
2 3
x 4 pcs
M4*50mm screw
Hardware set part no. UV-BK#2
■Install 2 mounting brackets with 4 x M4*6mm screws
■Adjust the LCD panel with 4 x M4*50mm screws and f x it on the surface.
Steps
■Hardware and M6*4 pcs for VESA mount are not provided
VESA mount ( 100*100mm )
( II ) VESA mount ( 100*100mm )
< 1.3 > VESA Installation
( I ) Panel mount
17.3” 4K LCD Display

P. 5
Protection 6mm front bezel or NEMA 4 / IP65
Front Panel Black, RAL 9005
Rear Casing Black, RAL 9005
VESA mount 100 x 100 mm
Universal mount -
Desktop stand Option
Panel mount Bundled
LCD Panel
Panel Size (diagonal ) 17.3-inch Widescreen TFT color LCD
Native Resolution 3840 x 2160
Brightness ( typ. ) 400
Contrast Ratio ( typ. ) 1000:1
Colors 16.7 M, 8-bit
Viewing Angle ( L/R/U/D ) 89/89/89/89
Response Time ( ms )
16
Dot pitch ( mm ) 0.0995
Display Area ( mm ) 382.12H x 214.94V
Surface treatment Anti-glare
Surface hardness 3H
Backlight Type LED
MTBF ( hrs ) 20,000
Video
Digital Display port DP 1.2 / HDCP 1.3
HDMI HDMI 2.0 / HDCP 2.2
HDMI 1.4 / HDCP 1.4
Audio
Output
Connector 3.5mm stereo jack
Resistance / Power level 30kΩ / 2.8V
Speaker:
Dual Stereo 2W x 2
*When the audio output is connected, speaker output is OFF
Power
Input Auto-sensing 100 to 240VAC, 50 / 60Hz
Consumption:
Screen ON Max. 29W
Power saving mode Max. 9W
Power button OFF Max. 2W
Compliance
EMC FCC & CE certif ed
Safety CE / LVD certif ed
Environment RoHS2 & REACH compliant
Mechanical Design
< Part 2 >
< 2.1 > Product Specifications
17.3” 4K LCD Display

Environmental Conditions
Operating Temperature 0 to 55°C degree
Humidity 20~90%, non-condensing
Altitude 16,000 ft
Storage /
Non-operating
Temperature -20 to 60°C degree
Humidity 5~90%, non-condensing
Altitude 40,000 ft
Shock 10G acceleration ( 11ms duration )
Vibration 10~300Hz 0.5G RMS random vibration
Applicable Format
Display Port Input PC Signal 3840 x 2160 x 60Hz
1920 x 1080 x 60Hz
1600 x 1200 x 60Hz
1360 x 768 x 60Hz
1280 x 1024 x 60 / 75Hz
1280 x 768 x 60Hz
1024 x 768 x 60 / 70 / 75Hz
800 x 600 x 60 / 72 / 75Hz
720 x 400 x 70Hz
640 x 480 x 60 / 72 / 75Hz
Audio Signal 2ch Linear PCM
HDMI Input HDMI 2.0 3840 x 2160 x 60Hz
HDMI 2.0 / 1.4 3840 x 2160 x 30Hz
1920 x 1080 x 50 / 60Hz ( 1080p )
1920 x 1080 x 25 / 30Hz ( 1080i )
1280 x 720 x 50 / 60Hz ( 720p )
720 x 480 x 50 / 60Hz ( 576p / 480p )
Audio Signal 2ch Linear PCM
*In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio signals, the LCD
may display incorrectly on a full screen. If so, please adjust the display card setting on display size to f x the issue.
Physical SpecifIcation
Product (W x D x H) mm
inch
Packing (W x D x H) mm
inch
615 x 113 x 523
24.2 x 4.4 x 20.6
Net Weight 5.2 kg / 11.4 lb (6mm front bezel)
Gross Weight 8.0 kg / 17.6 lb (6mm front bezel)
Chassis color Dark
Chassis materials Aluminum
440.5 x 53.6 x 293
17.3 x 2.1 x 11.5
P. 6
< 2.1 > Product Specifications
17.3” 4K LCD Display
5.9 kg / 13 lb (NEMA4 / IP65)
8.7 kg / 19.1 lb (NEMA4 / IP65)
