Acorn Terrazzo-Ware User manual

Acorn Engineering Company
800-488-8999 or 626-336-4561
FAX [phone]
P.O. BOX 3527 • CITY OF INDUSTRY, CA 91744-0527 (U.S.A.)
3030-738-000 Rev. 08/02/18
RECOMMENDED CLEANING &
MAINTENANCE PROCEDURES FOR
TERRAZZO-WARE
MOP SINKS
3. Special or Unusual Conditions
a. Scum on surface caused by soap, make-up, etc:
Use a cleaning powder, such as Ajax, plus lots of elbow grease.
b. Surface cleaning:
Heel marks, plaster, etc. may require abrasive removal. This can be
done with a wet emery cloth. If emery cloth is ineffective, use an 80 to
100 grit aluminum oxide coated paper. Abrasive cloth or paper will result
in a very faint grinding away of the base surface.
c. Penetrated stains:
Stains such as caused by oil, putty, etc., may be removed by scouring
with a cleanser and then soaking stained surface overnight—if need
be—with a commercial bleach such as Linco, etc.
NOTE: Do not use any acid, e.g., muriatic or cleaning agents that contain acid.
1. Finish Recommendation
Mop sinks are finished prior to shipment, if further sealing is required, use
Spartan Cote Cement Sealer or Equivalent.
2. Regular Cleaning
To maintain the original terrazzo appearance, clean regularly with a liquid
detergent such as Joy, Liquid Ajax or Spic and Span (for the latter, prepare a
solution containing 1/2 cup of Spic and Span in a gallon of water). Scrub with a
stiff bristled, non-metallic scrub brush and then rinse thoroughly.
M O P S I N K S

I N S T A L L A T I O N I N S T R U C T I O N S
1
REMOVE MOP BASE CAREFULLY
FROM CARTON
AVOID STANDING
MOP SINK ON END
REMOVE PACKAGING
WITH CARE
ACORN
ACORN ENGINEERING
COMPANY
RECOMMENDED
1/4" SPACE
1/4"
GROUT EXPOSED
SIDES
DOTTED AREA IS
FOR MOP SINK
SUB FLOOR
SAND OR
MORTAR BED
3030-738-000 Rev. 08/02/18
HANDLING
Carefully remove Mop Sink from carton at
installation point. Avoid placing Mop Sink on
its edge. (This precaution will prevent
damage to corners of Mop Sink.)
METHOD FOR CHECKING FACE OF Mop
Sink FOR TRANSPORTATION DAMAGE:
A. Wipe face of Mop Sink with a wet cloth
(Water).
B. When the water evaporates, any slight
crack in the Mop Sink will be
noticeable.
TERRAZZO-WARE Mop Sink
800-488-8999 or 626-336-4561
FAX [phone]
P.O. BOX 3527 • CITY OF INDUSTRY, CA 91744-0527 (U.S.A.)
LEVELING
Level Mop Sink carefully. For proper
installation, establish a 1/4" clearance between
Mop Sink and the walls. A layer of mortar or
sand must be placed in area where the Mop
Sink is to be installed. This procedure is
recommended in order to support Mop Sink
should the sub floor be uneven. Grout should
be exposed along edges.
*NOTE: Inspect and test for proper
drainage.
NOTE: Mortar or sand must cover the entire
area between Mop Sink and building floor.
WARNING!
DO NOT DROP MOP SINK OVER EXPOSED
PIPE.
It is advisable to remove drain pipe and set
Mop Sink in place. Insert pipe through drain in
Mop Sink back into “P” trap. Tighten with an
internal pipe wrench.
2 2
2 3
Mop Sinks
DO NOT DROP ON PIPE
REINSERT PIPE AND TIGHTEN
WITH AN INTERNAL WRENCH
REMOVE PIPE
FROM TRAP

WARNING!
MODELS WITH TILING FLANGE OPTIONS:
A. Do not let rough wall material overlap
flange.
B. Do not attach flange to building wall.
C. Let finished wall (tile, etc.) overlap and
rest on shoulder.
LATH,
PLASTER
BOARD, ETC.
DO NOT ATTACH
FLANGE TO WALL
CAULKING
A B C
I N S T A L L A T I O N I N S T R U C T I O N S
3030-738-000 Rev. 08/02/18
RECOMMENDED PROCEDURE.
INSTALLATION INSTRUCTIONS:
1. Cut drain pipe to extend 1-3/8" into
drain body. Drain pipe should be even
with top of gasket when installation is
completed. Position Mop Sink over
3" waste pipe making sure that pipe is
centered in drain body.
2. Lubricate gasket with soap solution and
stretch over 3" pipe with letters facing up.
3. Push gasket as far as possible into joint.
4. Using a hammer and caulking tool or
1/4" X 3/4" X 6" piece of wood instead
of a caulking tool, work around the
gasket with a series of blows and
gradually drive gasket into drain body
until it bottoms. Drain pipe should be
even with the top of gasket.
5. Test connection before covering or
concealing. To test: plug 3" drain and fill
receptor with water. Check for leaks.
Verify proper drainage. This must be
done before finishing walls.
ACORN ENGINEERING
COMPANY
TERRAZZO-WARE Mop Sink
800-488-8999 or 626-336-4561
FAX [phone]
P.O. BOX 3527 • CITY OF INDUSTRY, CA 91744-0527 (U.S.A.)
2 5
4
Mop Sinks
#4
#1
TILE, ETC.
#2 & #3
NOTE: 3" WASTE
PIPE AND “P” TRAP
BY OTHERS.
ABC
FINISHED
FLOOR
3" WASTE PIPE
(BY OTHERS)
BASE
1-3/8"
ALTERNATE PROCEDURE
A. TAMP OAKUM TO 5/8" DEPTH
B. POUR MOLTEN LEAD.
C. TAMP LEAD CAREFULLY.
OPTIONAL -KDG or
GASKET BY OTHERS
