0English
PROTRONIC-T, 230 V AC
Washbasin sink mixer with mixing lever
Please refer to the graphics in the German Installation and Operating Instructions.
0Table of Contents
1. Abbreviations and Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4. Important Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Description of Product
5. Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6. Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
7. Scope of Delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
8. Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
9. Installation Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation, Function and Commissioning
10. Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
11. Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
12. Controlling the Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
13. Programmable Function Parameters . . . . . . . . . . . . . . . . . . . . . . 7
Maintenance
14. Maintenance and Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
15. Replacing an Aerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
16. Replacing the Grit Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
17. Replacing the Non-return Valve . . . . . . . . . . . . . . . . . . . . . . . . . . 8
18. Replacing the Solenoid Valve Cartridge . . . . . . . . . . . . . . . . . . . . 9
19. Fault Correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
20. Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
EN
[email protected] - www.hygiene-shop.eu

4
ZMI_001_2000105118-PRTR0006_#SEN_#AQU_#V1.fm
1. Abbreviations and Units
2. Key
Warning!
Failure to observe can result in injury or even death.
Caution!
Failure to observe can result in material damage.
☞Important!
Failure to observe can cause the product to malfunction.
☞Useful information for optimally handling the product.
3. Warranty
Liability is accepted according to the General Terms and Conditions of Business and
Supply.
Use original replacement parts only!
4. Important Notes
• Installation, commissioning and maintenance are to be performed only by a
qualified technician according to the instructions provided and in accordance with
legal requirements and acknowledged rules of technology.
• All technical connection regulations specified by the local water and electricity
supply utility companies must be complied with.
• All rights reserved to make technical alterations.
DN Nominal diameter in mm
EA-Nr. European Article Number
FAR-Best.-Nr. Franke-Aquarotter Order No.
Conversion 1 mm = 0.03937 inches
1 inch = 25.4 mm
All length specifications in the graphics are in mm.
[email protected] - www.hygiene-shop.eu

5
ZMI_001_2000105118-PRTR0006_#SEN_#AQU_#V1.fm
5. Application
PROTRONIC-T mains-operated, opto-electronically controlled washbasin mixer
DN 15 with aerator with integrated flow rate regulator, with connection to hot and
cold water. With temperature-selector lever and plug-in power supply, 230 V AC.
6. Technical Specifications
7. Scope of Delivery
8. Dimensions
9. Installation Example
Minimum flow pressure: 1.0 bar
Recommended flow
pressure:
1–5 bar
Maximum operating
pressure:
10 bar
Calculation flow rate:
0,07 l/s 0,07 l/s
Operating voltage: 230 V AC
Operating voltage: 12 V DC
Type of protection: Tap IP55
Plug-in power supply IP20
Quantity Description
1 PROTRONIC-T pillar tap
with non-return valves and filters
1 Cleaning clip
1 Plug-in power supply 230 V AC/12 V DC
1 Fixing set
1 Installation and Operating Instructions
X Extension cable FAR Order No.
0.6 m without –
3.6 m 3.0 m 2000101456
10.6 m 10.0 m 2000101457
[email protected] - www.hygiene-shop.eu

6
ZMI_001_2000105118-PRTR0006_#SEN_#AQU_#V1.fm
10. Assembly Instructions
Warning!
Use the fitting only with non-return valves and the grit filters specified.
Failure to observe can result in an increased bacterial load in drinking water and
cause a health risk or even risk of death.
☞Important!
Before installing, flush the pipes in compliance with DIN 1988.
☞Do not shorten the connector hoses located at the fitting.
☞Connect the fitting only to the original plug-in power supply. Connect the plug-in
power supply only to a socket carrying 230 V/50 Hz.
10.1 Install the fitting (a) on the washbasin (b).
☞Important!
Observe the range settings when installing on a stainless steel washbasin
Chapter 13.
☞The corner valves (c) must be provided by the customer.
10.2 Screw the connecting hose (d) on to the corner valve.
10.3 Insert the plug-in power supply into the socket.
10.4 Connect the line between the fitting and the power supply.
11. Function
11.1 Allow your hand to approach the sensor.
• Water flows.
11.2 Remove your hand from the sensor.
• Water flow stops automatically after a set flow duration.
☞The range of the sensor and the flow duration can be adjusted with the optional
remote control (FAR Order No. 2000101087).
☞Important!
Reflecting surfaces can influence the sensor. There is a risk of having permanent
reflections. ((see Chapter 13. for adjusting the sensor range).
“Auto-flush” function
Caution!
When the “Auto flush” function is used, the flow of water must be ensured.
• The "Auto-flush" function ensures that forced flushing takes place to exchange the
water in the tap lines after 24 or 72 hours of non-use.
• The “Auto-flush” function can only be switched on with the optional remote control
(FAR-Order-No. 2000101087).
• This function is switched off at the factory.
[email protected] - www.hygiene-shop.eu

7
ZMI_001_2000105118-PRTR0006_#SEN_#AQU_#V1.fm
12. Controlling the Temperature
Sink mixer with mixing lever
12.1 Set the mixing lever (a) in the desired position.
13. Programmable Function Parameters
The optional remote control FAR Order No. 2000101087 offers the following
functions:
– Range can be set (3-20 cm)
– Turn-off delay can be set (0-10 s)
– Continuous flow can be switched to 3.5 min or 11 min.
– Switching off the fitting
– Basic settings can be restored
– Test mode for simulation without water
– Setting automatic safety switch-off (2–210 s)
– Automatic flushing can be activated
☞Important!
Reflecting surfaces can influence the sensor. There is a risk of having permanent
reflections. The range must be reduced for installations on reflecting surfaces such
as stainless steel washbasins. If this is not sufficient, an additional base/spacing ring
is available (see Chapter 20.).
14. Maintenance and Servicing
Depending on the quality of the water, the local conditions and the rules and
regulations applicable on site, the fitting must be maintained and serviced at regular
intervals.
Perform maintenance on the following components:
• Aerators (see Chapter 15.)
• Filters (see Chapter 16.)
• Non-return valves (see Chapter 17.)
14.1 Push up the cleaning clip (a) in front of the sensor.
☞The fitting is in sleep mode.
14.2 Properly use suitable cleaning agents that are not harmful to the fittings and rinse
with water after use. High-pressure cleaners must not be used for cleaning.
[email protected] - www.hygiene-shop.eu

8
ZMI_001_2000105118-PRTR0006_#SEN_#AQU_#V1.fm
15. Replacing an Aerator
15.1 Use an open-end spanner to unscrew and replace the aerator (a).
16. Replacing the Grit Filters
Filter for corner valve
16.1 Close the corner valves (c).
16.2 Trigger the valve.
16.3 Unscrew the connector hoses (a) from the corner valves.
16.4 Replace the grit filters (b).
16.5 Reassemble in the reverse order.
Filter, solenoid valve cartridge
16.6 Remove the solenoid valve cartridge (see Chapter 18.).
16.7 Use a flat nose pliers to pull the filter (d) out.
16.8 Replace the filter.
☞Important!
Ensure correct installation position. The rib of the filter must not lie on the flow-
through hole.
16.9 Reassemble in the reverse order.
17. Replacing the Non-return Valve
Warning!
All non-return valves must always be replaced as a group.
Failure to observe can result in an increased bacterial load in drinking water and
cause a health risk or even risk of death.
17.1 Close the corner valves (b).
17.2 Trigger the valve.
17.3 Unscrew the connector hoses (a) from the corner valves.
17.4 Take out the grit filters(c).
17.5 Take out the non-return valve (d).
☞Important!
Be careful to insert the non-return valves and grit filters the right way round.
17.6 Reassemble in the reverse order.
[email protected] - www.hygiene-shop.eu

9
ZMI_001_2000105118-PRTR0006_#SEN_#AQU_#V1.fm
18. Replacing the Solenoid Valve Cartridge
18.1 Close the corner valves.
18.2 Trigger the valve.
18.3 Loosen the screw (a) with an Allan key.
18.4 Pull the housing (b) from the base (c).
18.5 Remove the screws (d).
18.6 Remove the mounting bracket (e).
18.7 Remove and replace the solenoid valve cartridge (f).
18.8 Reassemble in the reverse order.
19. Fault Correction
If you are unable to correct a fault or if the fault is not described in the fault correction
section, please inform our customer service department!
Fault Cause Remedy
Water does not flow – Voltage supply interrupted ➯Restore it
– Water-flow volume regulator closed ➯Open it
– Grit filters are clogged with dirt ➯Clean them
– Cleaning clip in front of the fitting ➯Remove
– Solenoid valve faulty ➯Replace it
Water flows
continuously
– Solenoid valve faulty ➯Replace it
Water flow too weak – Corner valves not fully opened ➯Open it
– Grit filters are clogged with dirt ➯Clean them
– Aerator calcified ➯Replace it
– Solenoid valve faulty ➯Replace it
– Supply pressure too low ➯Check it
Water is too hot – Cold water is turned off ➯Open it
– Filter in cold-water part is dirty ➯Replace it
– Non-return valve faulty ➯Replace it
Water is too cold – Hot water is turned off ➯Open it
– Filter in hot-water part is dirty ➯Replace it
– Non-return valve faulty ➯Replace it
[email protected] - www.hygiene-shop.eu

10
ZMI_001_2000105118-PRTR0006_#SEN_#AQU_#V1.fm
20. Replacement Parts
Designation Order No.
1 Aerator with
flow rate regulator
(PU 10 pcs.) . . . . . . . . . . . . . . . . . 2000104691
2 Solenoid valve cartridge
with grit filter . . . . . . . . . . . . . . . . 2000104456
3 Cleaning clip . . . . . . . . . . . . . . . . 2000105795
4 Maintenance kit comprising:
O-rings
Screws
Grit filters. . . . . . . . . . . . . . . . . 2000104898
5 Mixing lever with screw. . . . . . . . . 2000105821
Designation Order No.
6 Plug-in power supply . . . . . . . . . . 2000105814
7 Installation kit comprising:
Non-return valve
Grit filters . . . . . . . . . . . . . . . . . 2000105106
8 Hose . . . . . . . . . . . . . . . . . . . . . . . 2000105960
Accessories Order No.
9 Remote control . . . . . . . . . . . . . . . 2000101087
10 Base for installation
on stainless steel washbasin . . . . 2000105834
[email protected] - www.hygiene-shop.eu
