Acre Carbon Ultralight User manual

1. To unfold the rollator, simply pull the
handles outwards.
2. Push downwards on the outer rails
of the seat in one swift motion, until
you hear a signicant click from the
locking mechanism.
3. If you are in doubt whether the
folding mechanism is correctly
locked e.g. in a noisy environment,
please check that the locking hook
under the seat is properly locked
into place.
Unfolding
1. Lift the seat by the cut-out in
the centre to release the locking
mechanism.
2. To ensure that the rollator is
completely folded, push the handles
toward each other.
Folding
Height adjustment of the handles
Due to ergonomically as well as safety
reasons it is important that the height
of the handles are adjusted correctly.
The correct adjustment of the handles
is very individual.
A rule of thumb is that the handles
should be level with your wrist when
standing in an upright position.
If you are in doubt, consult your
physical therapist, occupational
therapist or another specialist.
1. Press on the height adjustment
button on the frame with one hand
while pulling the handle with the
other.
2. Adjust the handle to the desired
height and release the height
adjustment button.
3. Check that the handle is locked in a
secure position by moving it up and
down and the height adjustment
button is in the locked position.
Use of the Carbon Ultralight
Carbon Ultralight is equipped with two
independent brakes acting on the rear
wheels.
1. Pull the brake levers upwards to
activate the brake. The lever moves
back to the neutral position when the
brake lever is released.
2. The parking brake is activated by
pressing the brake lever down until
you hear a click sound. Release the
parking brake by pulling the brake
lever back to the neutral position.
Adjustment of the brakes
The brake should be adjusted if the
brake force applied to the wheel
is insucient (this can occur if the
tyres are worn) or the parking brake
is dicult to activate (which is most
often seen after replacement of a worn
down tire). Always set the handle to
the desired height before the brake is
adjusted as the positon may cause a
little variation of the brake adjustment.
1. Adjust the brake with a 2mm Allen
wrench.
Insert the Allen wrench into the
adjustment screw through the hole in
the front of the brake unit.
2. The brake is tightened by turning the
adjustment screw clockwise (viewed
from the front) and loosened by
turning the adjustment screw
counter-clockwise (viewed from the
front).
Always engage both parking brakes when you sit on the seat.
Under normal circumstances both brakes should be activated
simultaneously.
Be aware that when only one brake is activated, Carbon Ultralight will turn to
the same side as the engaged brake.
Do not store with the parking brake activated as prolonged activation of
the parking brake can leave visible marks on the wheel and decrease the
braking performance.
Kerb lifter
Even though Carbon Ultralight is the
world’s lightest walker and therefore
is easier to lift, it is equipped with a
kerb lifter that makes it easier to get
over smaller obstacles like kerbs and
low steps. This is particularly helpful
if heavy objects are transported in a
front-mounted basket or bag.
1. Carefully press on the kerb lifter with
a foot.
2. Pull sligthely by the handles to lift the
front wheels o the ground.
Be aware that the stability of
Carbon Ultralight changes when it
is reclined.
Be cautious and try to bypass
rather than climb high obstacles.
Brakes
CLICK!
CLICK!

Tested and approved according to EN ISO 11199-2:2005
Accessories
Carbon Ultralight can be made even more useful with original accessories. A
full display of our range can be found at www.byacre.com.
All of our accessories are model specic, and o course tested with it to ensure
your safety.
The accessories should always be installed according to the manual that
comes with the product. Maximum payload for bags and baskets are always
specied in the manual.
Never use non-original accessories with the rollator, as this could pose a
potential risk for your safety.
Maintenance & cleaning
Carbon Ultralight should be regularly maintained by removing dust and dirt.
Pay special attention to keeping the brakes and wheel hub clean.
All surfaces can be cleaned with a textile cloth and clean water, if necessary
with a little non-abrasive detergent. Wipe with a dry cloth afterwards. Do not
use paper towels as these can scratch the surfaces.
It may be necessary to tighten one or more screws with a T25 or a H3 key.
Parts subject to wear such as wheels and brakes should be replaced in good
time before they may pose a security risk. Any defective part must be replaced
immediately.
Never use the Carbon Ultralight if it is in any way defective. Contact your
dealer for servicing.
Safety precautions before use
Attention: When unfolding the rollator, please check that the rollator is securely
locked in place with an audible click.
Before each use, check that the brakes are working properly.
The rollator shall not be used by people weighing over 130kg/286 lbs. It is not
suitable for transporting heavy loads or people.
The rollator is not a toy.
Check that the height adjustment of the handles are correctly engaged and
the handle bars are not set higher than the marked maximum setting.
Do not change / modify the rollator. Such action could negatively impact the
safety of using the rollator and expire the manufacturer’s liability.
Safety instructions for use
Attention: Always activate both parking brakes before sitting down and while
seated. Do not use the rollator to drive a person around and do not move the
rollator while seated. The rollator is not designed to carry a person while in
motion.
For your own safety, you should not stand on the Carbon Ultralight, nor lean
backwards, sideways or forward while seated.
Do not tilt the rollator more than max. 5 degrees to the side. This could cause
risk of falling!
Do not attach bags or other items to the handles. This can cause the rollator to
fall
Always use the brakes when stopping or parking. The brake can be pulled up a
little to decrease the speed while walking.
For good support and safe walking, the rollator must be held close to the body.
Walking upright and looking ahead improves balance. Particular care should
be taken when going down curbs.
Do not push the rollator far in front of you, as this creates a risk of falling.
Note that the rolling speed of the rollator can be faster than your walking
speed and create a risk of falling.
Do not use the rollator on stairs.
Always make sure that your clothes are not trapped or stuck in the handles or
in other parts of the rollator.
While driving on public transport, sitting on the rollator is not safe.
Congratulations with your new Carbon Ultralight rollator.
Humbly speaking, it is the world’s lightest rollator.
In order to utilise all the possibilities the Carbon
Ultralight provides, it is important that you carefully
study this user manual.
Warranty
Carbon Ultralight is covered by
a 2 year warranty. The warranty
does not cover moving parts,
misuse and normal wear.
byACRE oers additional warran-
ty on the frame.
Simply register your product at
www.byacre.com within three
months after the purchase
To keep the warranty please
remember to save your proof of
purchase.
Designed in Denmark,
handcrafted in China
byACRE ApS
I.C. Modewegsvej 1
2800 Lyngby
Denmark
Carbon Ultralight
THE LIGHTEST ROLLATOR IN THE WORLD
ENGLISH
Weight w/o
accessories:
Height:
Width:
Length:
Seat width:
Seat height:
Wheel diameter:
Max user weight:
4,8 kg
790-910 mm
615 mm
660 mm
410 mm
560 mm
200 mm
130 kg
4,8 kg
790-910 mm
625 mm
660 mm
420 mm
610 mm
200 mm
130 kg
4,9 kg
790-910 mm
675 mm
660 mm
470 mm
610 mm
200 mm
130 kg
Technical data
Compact Regular Comfort
