Decon wheel G5 Modulair User manual

2021-02-01
Assembly instructions for G5 Modulair
MEM6123 and MEM6124
1. Remove wheels and brakes.
2. Check the correct placement for the eMove, and that it is axle Ø12,0 x 51 with
Part Number: XOE-2530E-BO and Spacer with Part Number: XOE-25383-00.
13
14

2021-02-01
3. Assembly the plates according to pictures.
Parts for right side mounting:
Item No. Part Number Qty Description
1 XSM16M 1 Nut M16X1 Low
2 XSM8BR 1 Plain Washer M8
3 XSM8X45 1 Screw M8x45
4 XSM8ML 1 Locknut M8
5 405239 1 Nordlock Washer
6 100 400 008 2 Spacer
7 100 400 009 2 Spacer
8 100 400 001 1 Spacer
9 HW063 1 Hub sleeve
10 XSM16FJ 1 Single Coil Washer M16
11 100 400 004 1 Spacer
12 XOE-22294-BO 1 Right Bracket Hole 16
13 XOE-25383-00 1 Spacer
14 93440-120520 1 Circlip
Note! If you only order the mounting set, the axle, axle spacer and the Circlip are not
included, for replacement see the service manual.
4. Assemble the back placed battery bag.

2021-02-01
Åtdragningsmoment / Tightening torque
Metriska grovgängor, stål.
Metric coarse threads, steel.
Gänga / Thread
Åtdragningsmoment / Tightening
torque
M3
1,2 Nm
M4
3 Nm
M5
6 Nm
M6
10 Nm
M8
25 Nm
M10
50 Nm
M12
85 Nm
Navhylsor.
Sleeves.
Gänga / Thread
Åtdragningsmoment / Tightening
torque
M16x1
30 Nm
M18x1
40 Nm
