Chapter 1 Introduction
ACE-B7400 is an All-in-One gaming control box based on AMD most
advanced Fusion platform which integrates AMD Radeon HD 6310 graphic
controller. It is designed for slot machine and AWP machine which requires
powerful 3D video performance. Besides powerful integrated graphic controller,
ACE-B7400 integrates all gaming control features.
1.1 Specifications
Items Description
CPU Thermal Module Fan with heat sink
CPU Board ACE-B7400
CPU AMD FT1 processors
Single Core:T52R 1.5GHz (18W)
Dual Core:T48N 1.4GHz (18W)
System Memory 1. 2 x DDR3 So-DIMM slots
2. Maximum up to 8 Giga Bytes
3. 1 x 1GB DDR3 SDRAM pre-installed
Storage 1. CF socket x 2
2. Optional 2.5” HDD bay
Extension Not available
Front Panel A. DVI-D
B. DVI-I connector
C. 2x (RJ45 Giga LAN + 2 USB)
D. 1 x 2 USB connector
E. COM1 to COM 4 (Male DB9)
F. Power & HDD LED
Rear Panel A. 2x 16 pin micro fit connector for digital input
B. 2x 20 pin micro fit connector for digital output
C. 1x 14 pin micro fit connector for COM
D. 1x 6 pin for audio
E. 1x 8 pin micro fit connector for power input
Internal I/O 1. 2 x USB 2.0
2. On board intrusion switch
3. 1x intrusion input from on board 2-pin JST connector
4

System fan 2x temperature controllable system fan
Operation
temperature 0 to 60 Degrees Celsius
Expansion Module Not Available
Power requirement Power supply from external
1. +12V & +24V from 8-pin Micro fit connector
1.2 Package Contents
Check if the following items are included in the package.
 Quick Manual
 AR-B7400 board
 1 x Software Utility CD
5

1.3 Block Diagram
6

Chapter 2 H/W Information
This chapter describes the installation of ACE-B7400. At first, it shows
the Function diagram and the layout of ACE-B7400. It then describes the
unpacking information which you should read carefully, as well as the
jumper/switch settings for the ACE-B7400 configuration.
2.1 I/O Connector and Key parts illustration
(Top Side)
7

LED1
Green LED:
Power On.
Orange LED:
HDD Active.
PWR_BTN1
System Power Button DVI-D1 DVI-D Connector.
DVI-I1
DVI-I
Connector. USB1
USB 2.0 Connector CN25 RJ45 & USB 2.0 Connector
CN26
RJ45 & USB
2.0 Connector COM1_2
RS-232 Connector
(9-bits Protocol supported).
COM3_4
RS-232 Connector
CN7
Gaming Input
Isolation
Connector. CN6
Gaming Input Isolation
Connector.
CN5
Gaming Open-Drain Output
Connector.
CN4
Gaming
Open-Drain
Output
Connector.
CN3
TTL, RS232, RS485, cctalk
selectable connector
(UART RX,TX signal only).
CN2
2.1 ChannelAudio Amplifier
Output Connector.
CN1
System Power
Input
Connector. U43
AMD FT1 APU. (T48N/T52R)
U44
AMD Hudson-E1 Fusion
Controller Hub.
CF1
CF Card Slot
1. CF2
CF Card Slot 2. U40
Acrosser Gaming Core (AGC).
SATA1/SATA2
SATA 3.0
Connectors. MINI-PCIE1
Mini-PCIe Slot.
CN_DIMM1/CN_DIMM2
DDR3 SODIMM Socket.
Maximum total 8GB.
CASESW1
Micro-switch
for Chassis
Open/Close
Detection.
BAT_BH1
CR2032 Battery Holder
for system RTC.
8

Rears-Panel I/O Configurations
CN7
Gaming Input Isolation Connector.
Micro-FIT 3.0mm
2*8 PINs
Pin Signal Pi Signaln
1 Do 9 Buor Switch 1 tton 4
2 Do 10 Buor Switch 2 tton 5
3 Do 11 Buor Switch 3 tton 6
4 Do 12 Buor Switch 4 tton 7
5 Do 13 Buor Switch 5 tton 8
6 Bu 14 Button 1 tton 9
7 Bu 15 Button 2 tton 10
8 Bu 16 Button 3 tton 11
Note:
1.All input pin
logical
high-level is
+5V ~ +24V,
logical low-level
is 0V ~ +1.5V.
CN6
Gaming Input Isolation Connector.
Micro-FIT 3.0mm
2*8 PINs
Pin Signal P Sin ignal
1 B 9 Tutton 12 ouch-Cal Key-Lock
2 B 1 Sutton 13 0 pare Key-Lock
3 B 1 Cutton 14 1 oin-In Signal A
4 B 1 Cutton 15 2 oin-In Signal B
5 Button 13 Bill-In16
6 D 1 Hissolve Key-Lock 4 opper Sensor
7 O 1 GM Key-Lock 5 PI 0
8 S 1 Getup Key-Lock 6 PI 1
Note:
1.
A
ll input pin
logical
high-level is
+5V ~ +24V,
logical low-level
is 0V ~ +1.5V.
2.Coin-In Signal
A, Coin-In
Signal B, Bill-In,
and Hopper
Sensor support
input counter
function.
CN5
Gaming Open-Drain Output Connector.
Pin Signal Pin Signal
1 Ke 11 Coy-in Meter in-Enable
2 Bil 12 Bill-Enablel-in Meter
Micro-FIT 3.0mm
2*10 PINs
3 Co 13 Hoin-in Meter pper-SSR
4 Pa 14 GPy-out Meter O 0
5 Ke 15 GPy-out Meter O 1
6 a GPH nd-pay Meter 1 16 O 2
7 a GPH nd-pay Meter 2 17 O 3
8 Sp 18 GPare Meter O 4
9 GND 19 GND
10 IBUT2 20 GND
Note:
1.Eight Meters
support
pulse-Generato
r function.
2.All output pin is
open-drain
circuit and
operation
maximum
voltage cannot
over +30V.
9

10
CN4
Gaming Open-Drain Output Connector.
Micro-FIT 3.0mm
2*10 PINs
Pin Signal Pin Signal
1 LAMP 1 11 LAMP 9
2 LAMP 2 12 LAMP 10
3 LAMP 3 13 LAMP 11
4 LAMP 4 14 LAMP 12
5 LAMP 5 15 LAMP 13
6 LAMP 6 16 Tower LAMP 1
7 LAMP 7 17 Tower LAMP 2
8 LAMP 8 18 Tower LAMP 3
9 GND 19 GND
10 GND 20 GND
Note:
1.Each LAMP output
supports open-drain
500mA (max) current;
each Tower LAMP
output supports
open-drain 1A (max)
current.
2.All output pin is
open-drain circuit and
operation maximum
voltage cannot over
+30V.
CN3
Two TTL, RS232, RS485, ccTalk selectable connector (UART RX & TX signal only)
Note: mode selected by JP6~JP13 (Please see Appendix A.)
Micro-FIT 3.0mm
2*7 PINs
Pin Signal Pin Signal
1 COM5 TTL/ 232 Tx/ 485 + 8 COM5 TTL/ 232 Rx/ 485 -
2 COM6 TTL/ 232 Tx/ 485 + 9 COM6 TTL/ 232 Rx/ 485 -
3 COM5 ccTalk Data 10 COM6 ccTalk Data
4 COM5 ccTalk Vcc 11 COM6 ccTalk Vcc
5 GND 12 GND
6 GND 13 GND
7 GND 14 GND
CN2
2.1 ChannelAudio Amplifier Output Connector.
Micro-FIT 3.0mm
2*3 PINs
Pin Signal Pin Signal
1 Front Left + 4 Front Left -
2 Front Right + 5 Front Right -
3 LFE + 6 LFE -
Note:
1. Audio Amplifier is
D-type amp.
2.Amplified Right and
Left channel support
10Watt (max) Output,
Amplified LFE channel
supports 20Watt (max)
Output.
CN1
System Power Input Connector.
Micro-FIT 3.0mm
2*4 PINs
Pin Signal Pin Signal
1 +12V 5 +12V
2 GND 6 GND
3 GND 7 GND
4 +12V 8 +24V
Note:
1.+12V Power Input
voltage tolerance is
±10%.
2.+24V Power Input is
only use for cctalk Vs
power supply.

2.2 Connector & Jumper setting definition
(Top Side)
FPIO1
System Power Button &
Reset connector CN_USB1
USB 2.0 Connector CN_USB2 USB 2.0 connector
SYSFAN2
System FAN Connector
2. APUFAN1
APU FAN Connector.
SPAREIO1
JST 2.0mm Gaming
Spare-IO Connector. (16-bits
GPIO)
SW1
8-bit DIP-Switch Input for
AGC. SATA_PWR1
SATA_PWR2
SATA Power Connectors.
CLRCMOS
Clear System CMOS
Jumper.
JP6 ~ JP13
CN3 Output Signal
Selection Jumper (TTL,
RS232, RS485 or ccTalk) SYSFAN1
System FAN Connector
1.
IButtom2
External i-Button Connector.
JP2
JP3
SRAM A, B Clear Jumper.
JP4
JP5
Bill-enable, Coin-enable
Preset Jumper.
BAT_A1,
BAT_B1
Lithium Battery Connector
for SRAM, AGAand secured
RTC.
JP18
RS-485 Terminal Resistor
Selection Jumper for CN3
(UART 6)
JP17
RS-485 Terminal
Resistor Selection
Jumper for CN3 (UART
5)
AUDIO1
Internal 5.1 Channel Audio
Pin-Header.
JP1
cctalk Supply Power
Selection Jumper.
CASESW2
JST 2.0mm Chassis
Open/Close Detection
Connector.
11

Connectors and Jumpers Setting
FPIO1
System Power Button & Reset connector
CN_USB1
CN_USB2
USB 2.0 Connector
Pin Function
1-2 Power Button Connector
3-4 Short: Auto Power-on Open: Power-on by
Pin1-2 Button
5-6 Reset Button Connector
Note:
Default short Pin3-4 beAuto-Power-On
JST 2.0mm
Pin Signal
1 VCC (+5V)
2 Data+
3 Data-
4 GND
5 N.C
SYSFAN2
System FAN Connector 2. APUFAN1 APU FAN Connector.
Pin Signal
1 GND
2 +12V
3 Feedback
Pin Signal
1 GND
2 +12V
3 Feedback
SPAREIO1
JST 2.0mm Gaming Spare-IO Connector.
(16-bits GPIO) SW1
8-bit DIP-Switch Input for AGC.
Pin Signal Pin Signal
1 Bit0 2 Bit8
3 Bit1 4 Bit9
5 Bit2 6 Bit10
7 Bit3 8 Bit11
9 Bit4 10 Bit12
11 Bit5 12 Bit13
13 Bit6 14 Bit14
15 Bit7 16 Bit15
17 GND 18 +3.3V
19 GND 20 +3.3V
SW 1~8 Signal
ON +3.3V
OFF GND
12

SATA_PWR1
SATA_PWR2
SATA Power Connectors. CLRCMOS
Clear System CMOS Jumper.
JST 2.5mm
Pin Signal
1 +12V
2 GND
3 +3.3V
4 +5V
Jumper Function
1-2
(default) Normal
2-3 Clear CMOS
JP6 ~ JP13
CN3 Output Signal Selection Jumper
(TTL, RS232, RS485 or ccTalk) SYSFAN1
System FAN Connector 1.
Please See Appendix A.
(Default set to be RS232)
Pin Signal
1 GND
2 +12V
3 Feedback
IButtom2
External i-Button Connector. JP2 ,JP3
SRAM A, B Clear Jumper.
JST 2.0mm
Pin Signal
1 I-Button Signal
2 GND
Jumper Function
1-2
(default) Normal
2-3 Clear SRAM
JP4 ,JP5
Bill-enable, Coin-enable Preset Jumper. BAT_A1 ,BAT_B1
Lithium Battery Connector for SRAM, AGA
and secured RTC.
Jumper Function
1-2
(default) Preset is “High”.
2-3 Preset is “Low”.
Note:
“High” means Bill-enable, Coin-enable
open-drain output is short to ground.
“Low” means Bill-enable, Coin-enable
open-drain output is open
Pin Signal
1 POWER
2 GND
13

JP18
RS-485 Terminal Resistor Selection Jumper for CN3
(COM 6). JP17
RS-485 Terminal Resistor Selection Jumper for
CN3 (COM 5).
Jum Funper ction Ju Fumper nction
1-2 Termination 1-2 Termination
2-3
(def Non ault)
Note:
Terminal resistor is 120ohm.
2-
(d No
3
efault) n
Note:
Terminal resistor is 120ohm.
AUDIO1
Internal 5.1 Channel Audio Pin-Header. JP1 ccTalk Supply Power Selection Jumper.
Pin Signal Pin Signal
1 Front-L 2 Front-R
3 GND 4 GND
5 Surround-L 6 Surround-R
7 IO4 GND 8 GND
9 Center 10 LFE
Ju Fumper nction
1-
(d +1
2
efault) 2V
2-3 +24V
power is from CN1 external power
supply.
CASESW2
JST 2.0mm Chassis Open/Close Detection
Connector.
Pin Signal
1 Signal
2 GND
14

Appendix A
CN3 Output Signal TTL/RS232/RS485/cctalk Jumper
Configuration
Default configuration of COM-5 and COM-6 are RS-232 mode.
Locations:
CN3 (COM-5) selectable functions
RS-232
(Default) TTL RS-485 ccTalk
Note: Orange block means shorted by a jumper, and others leave it N.C.
15

CN3 (COM-6) selectable functions
RS-232
(Default) TTL RS-485 ccTalk
Note: Orange block means shorted by a jumper, and others leave it N.C.
16

Appendix B
AGC I/O Definition
I : Input I.I: Input with isolation
O.C: Open-Collector Output I/O: Spare Input/Output
Connectors Map
AGC
Channel I/O Type Functions Rear panel
Gaming I/O Onboard Remark
DI0 I Door SW1 CN7 – Pin1 AGA log 0
DI1 I Door SW2 CN7 – Pin2 AGA log 1
DI2 I Door SW3 CN7 – Pin3 AGA log 2
DI3 I Door SW4 CN7 – Pin4 AGA log 3
DI4 I Door SW5 CN7 – Pin5 AGA log 4
DI5 I Door SW6 CASESW1 AGA log 8 ; Onboard
chassis Switch
DI6 I Door SW7 CASESW2 AGA log 9 ; Onboard JST 2.0mm connector for ext.
switch.
DI7 I.I Button 1 CN7 – Pin6
DI8 I.I Button 2 CN7 – Pin7
DI9 I.I Button 3 CN7 – Pin8
DI10 I.I Button 4 CN7 – Pin9
DI11 I.I Button 5 CN7 – Pin10
DI12 I.I Button 6 CN7 – Pin11
DI13 I.I Button 7 CN7 – Pin12
DI14 I.I Button 8 CN7 – Pin13
DI15 I.I Button 9 CN7 – Pin14
DI16 I.I Button 10 CN7 – Pin15
DI17 I.I Button 11 CN7 – Pin16
DI18 I.I Button 12 CN6 – Pin1
DI19 I.I Button 13 CN6 – Pin2
DI20 I.I Button 14 CN6 – Pin3
DI21 I.I Button 15 CN6 – Pin4
DI22 I.I Button 16 CN6 – Pin5
DI23 I.I Dissolve Key-Lock
(Key 1) CN6 – Pin6
DI24 I.I OM Key-Lock
(Key 2) CN6 – Pin7
DI25 I.I Setup Key-Lock
(Hand Pay) (Key 3) CN6 – Pin8
DI26 I.I Touch-Cal Key-Lock
(Key 4) CN6 – Pin9
DI27 I.I Spare Key-Lock
(Key 5) CN6 – Pin10
DI28 I.I Coin-In Signal A CN6 – Pin11 AGC Counter 1
DI29 I.I Coin-In Signal B CN6 – Pin12 AGC Counter 2
17

DI30 I.I Bill-In CN6 – Pin13 AGC Counter 3
DI31 I.I Hopper Sensor CN6 – Pin14 AGC Counter 4
DI32 I.I General Purpose In 0 CN6 – Pin15
DI33 I.I General Purpose In 1 CN6 – Pin16
Connectors Map
AGC
Channel I/O Type Functions Rear panel
Gaming I/O Onboard Remark
DI34 I DIP Switch S1 SW1 –S1
DI35 I DIP Switch S2 SW1 –S2
DI36 I DIP Switch S3 SW1 –S3
DI37 I DIP Switch S4 SW1 –S4
DI38 I DIP Switch S5 SW1 –S5
DI39 I DIP Switch S6 SW1 –S6
DI40 I DIP Switch S7 SW1 –S7
DI41 I DIP Switch S8 SW1 –S8
DO0 O.C. Lamp1 CN4 – Pin1 500mA(max) current
DO1 O.C. Lamp2 CN4 – Pin2 500mA (max) current
DO2 O.C. Lamp3 CN4 – Pin3 500mA (max) current
DO3 O.C. Lamp4 CN4 – Pin4 500mA (max) current
DO4 O.C. Lamp5 CN4 – Pin5 500mA (max) current
DO5 O.C. Lamp6 CN4 – Pin6 500mA (max) current
DO6 O.C. Lamp7 CN4 – Pin7 500mA (max) current
DO7 O.C. Lamp8 CN4 – Pin8 500mA (max) current
DO8 O.C. Lamp9 CN4 – Pin11 500mA (max) current
DO9 O.C. Lamp10 CN4 – Pin12 500mA (max) current
DO10 O.C. Lamp11 CN4 – Pin13 500mA (max) current
DO11 O.C. Lamp12 CN4 – Pin14 500mA (max) current
DO12 O.C. Lamp13 CN4 – Pin15 500mA (max) current
DO13 O.C. Lamp14 CN4 – Pin16 1A (max) current
DO14 O.C. Lamp15 CN4 – Pin17 1A (max) current
DO15 O.C. Lamp16 CN4 – Pin18 1A (max) current
DO16 O.C. Key-In Meter
(Meter 1) CN5 – Pin1 AGC Pulse Generator 1
DO17 O.C. Bill-In Meter
(Meter 2) CN5 – Pin2 AGC Pulse Generator 2
DO18 O.C. Coin-In Meter
(Meter 3) CN5 – Pin3 AGC Pulse Generator 3
DO19 O.C. Pay-Out Meter
(Meter 4) CN5 – Pin4 AGC Pulse Generator 4
DO20 O.C. Key-Out Meter
(Meter 5) CN5 – Pin5 AGC Pulse Generator 5
DO21 O.C. Hand-Pay Meter1
(Meter 6) CN5 – Pin6 AGC Pulse Generator 6
DO22 O.C. Hand-Pay Meter2
(Meter 7) CN5 – Pin7 AGC Pulse Generator 7
DO23 O.C. Spare Meter1
(Meter 8) CN5 – Pin8 AGC Pulse Generator 8
18

DO24 O.C. Coin-Enable CN5 – Pin11
DO25 O.C. Bill-Enable CN5 – Pin12
DO26 O.C. Hopper SSR CN5 – Pin13
DO27 O.C. General Purpose Out 0 CN5 – Pin14
DO28 O.C. General Purpose Out 1 CN5 – Pin15
DO29 O.C. General Purpose Out 2 CN5 – Pin16
DO30 O.C. General Purpose Out 3 CN5 – Pin17
DO31 O.C. General Purpose Out 4 CN5 – Pin18
Connectors Map
AGC
Channel I/O Type Functions Rear panel
Gaming I/O Onboard Remark
GPIO0 I/O Spare I/O bit 0 SPAREIO1
– Pin1
GPIO1 I/O Spare I/O bit 1 SPAREIO1
– Pin2
GPIO2 I/O Spare I/O bit 2 SPAREIO1
– Pin3
GPIO3 I/O Spare I/O bit 3 SPAREIO1
– Pin4
GPIO4 I/O Spare I/O bit 4 SPAREIO1
– Pin5
GPIO5 I/O Spare I/O bit 5 SPAREIO1
– Pin6
GPIO6 I/O Spare I/O bit 6 SPAREIO1
– Pin7
GPIO7 I/O Spare I/O bit 7 SPAREIO1
– Pin8
GPIO8 I/O Spare I/O bit 8 SPAREIO1
– Pin9
GPIO9 I/O Spare I/O bit 9 SPAREIO1
– Pin10
GPIO10 I/O Spare I/O bit 10 SPAREIO1
– Pin11
GPIO11 I/O Spare I/O bit 11 SPAREIO1
– Pin12
GPIO12 I/O Spare I/O bit 12 SPAREIO1
– Pin13
GPIO13 I/O Spare I/O bit 13 SPAREIO1
– Pin14
GPIO14 I/O Spare I/O bit 14 SPAREIO1
– Pin15
GPIO15 I/O Spare I/O bit 15 SPAREIO1
– Pin16
19

Chapter 3 BIOS Settings
This chapter describes the BIOS menu displays and explains how to
perform common tasks needed to get the system up and running. It also gives
detailed explanation of the elements found in each of the BIOS menus. The
following topics are covered:
Main Setup
Advanced Chipset Setup
AMD Setup
SuperIO Setup
Security Setup
Boot Setup
Exit Setup
20
