Acrosser Technology AMB-IB75N1/A Installation guide

P/N:220010441-G 1
AMB-IB75N1/A/B v1.0 Quick Manual
Content:
1. Main board illustration ‧‧‧‧‧‧‧‧‧‧‧‧‧ P.1
2. Connector pin define
a. DDR3 DIMM connector
‧‧‧‧‧‧‧‧‧‧‧‧‧ P.2
b. SATA connector
‧‧‧‧‧‧‧‧‧‧‧‧‧ P.2
c. FAN connector
‧‧‧‧‧‧‧‧‧‧‧‧‧ P.2
d. LAN1~LAN8, CN_2USB1,
LED1~LED3, COM1, RST1, CN3, CN4
‧‧‧‧‧‧‧‧‧‧‧ P.3
e. CF Socket
‧‧‧‧‧‧‧‧‧‧‧‧‧ P.5
f. ATX Power Connector & VGA Conncetor ‧‧‧‧‧‧‧‧‧‧
P.5
g. Other connector
‧‧‧‧‧‧‧‧‧‧‧‧‧ P.6
1.Main board illustration
P/N:220010441-G 2
2.Locations of IO ports & Jumper settings definition
12 11 1
0
9
8
7
6
5
4
3
2
1
1
7
1
6
1
5
14 1
3
22 21 2
0
1
9
1
8
2
5
24 2
3
2
6
3
4
33
32
31
30
2
9
2
8
2
7
35
36

P/N:220010441-G 3
3.Connector pin define
a. DDR3 DIMM Connector
DIMM1
DIMM2
Standard
DDR3 DIMM
connector
b. SATA connector
SATA1 (SATA III)
SATA2 (SATA II)
Standard SATA connector
c. FAN Connector
SYSFAN3
SYSFAN2
SYSFAN1
PIN Signal
1 GND
2 +12V
3 FAN Speed
Detect
3 Pin, Pitch:2.54mm
P/N:220010441-G 4
CPUFAN1
PIN Signal
1 GND
2 +12V
3 FAN Speed
Detect
4 FAN PWM
Control
4 Pin, Pitch:2.54mm
d. LAN1~LAN8, CN_2USB1, LED1~LED3, COM1, RST1, CN3, CN4
LAN1 RJ45 LAN Connector
LAN LED table:
LED ON/OFF Status
LED1
OFF 10Mbps
Green 100Mbps
Orange 1000Mbps
LED2 Yellow Link/Active
OFF LAN OFF
LAN2 RJ45 LAN Connector
LAN3 RJ45 LAN Connector
LAN4 RJ45 LAN Connector
LAN5 RJ45 LAN Connector
LAN6 RJ45 LAN Connector
LAN7 RJ45 LAN Connector
LAN8 RJ45 LAN Connector

P/N:220010441-G 5
CN_2USB1
Standard USB 3.0 Type-Aconnector
LED3 COM1
Green1: Power ON LED.
Green2: HDD LED
Yellow1: LAN3&LAN4 Bypass
LED.
Yellow2: LAN1&LAN2 Bypass
LED.
RS-232, RJ45 connector
PIN Signal PIN Signal
1 RTS 5GND
2 DTR 6SIN
3 SOUT 7DSR
4 GND 8CTS
RST1 LED2
Push this button to reset the
system.
UP :
Green1: Link LED
Yellow1: Active LED
Down :
Green2: Link LED
Yellow2: Active LED
CN3, CN4 LED1
Dual SFP Connector.
1000BASE-SX/LX SMALL
FORM-FACTOR
PLUGGABLE (SFP) OPTICAL FIBER
TRANSCEIVER OR MINI-GBIC
CONNECTOR
UP :
Green1: Link LED
Yellow1: Active LED
Down :
Green2: Link LED
Yellow2: Active LED
P/N:220010441-G 6
e. CF Socket
CF1 CF CARD Socket
f. ATX Power Connector & VGA Connector
ATXPWR1 ATX Power Supply Input
FP_VGA1 VGA Wafer Connector ATX12V1 ATX12V Power Input

P/N:220010441-G 7
g. Other Connector
JP2
(For LAN1/LAN2 Bypass
Function Select.).
PIN Function
1-2 Forced Normal (Default)
2-3 Controlled By CPLD
Open Forced Bypass
CPLD1 For CPLD Firmware Update
PIN Signal PIN Signal
1 3VDUAL 2 G_TDO
3 G_TDI 4 NC
5 NC 6 G_TMS
7 GND 8 G_TCK
JP4
(For LAN3/LAN4 Bypass Function
Select.).
LCM1 LCM signal connector
PIN Function
1-2 Forced Normal (Default)
2-3 Controlled By CPLD
Ope
n Forced Bypass
PIN Signal PIN Signal
1 3VDUAL 2 G_TDO
3 G_TDI 4 NC
5 NC 6 G_TMS
7 GND 8 G_TCK
RTC1 CMOS Backup Battery: LPC1 LPC Header For Port’80 Debug
PIN Signal PIN Signal
1 33MHz 2 LAD1
3 Reset 4 LAD0
5 FRAME# 6 VCC3
7 LAD3 8 GND
9 LAD2 10 GND
An onboard battery saves the CMOS
memory to keep the BIOS information
stays on even after disconnected
your system with power source. Nevertheless,
this backup battery exhausts after
some five years.
P/N:220010441-G 8
SPI1 SPI BIOS firmware Update
Header
PIN Signal PIN Signal
1 CS0 2 VCC3
3 MISO 4 HOLD#
5 WP# 6 SPICLK
7 GND 8 MOSI
9 NC 10 NC
CCMOS1 CMOS Memory Clearing Header
Extended Models Information
Model Name Model Parts Difference Remark
ANR-IB75N1 Intel GbE LAN x8
ANR-IB75N1A Intel GbE LAN x8 + 2 Fiber CN3
ANR-IB75N1B Intel GbE LAN x8 + 4 Fiber CN3 CN4
