1 PRODUCT DESCRIPTION
1.1 GENERAL
ACU6 is a telematics product for vehicles. It provides data connection over cellular networks for embedded
telematics applications. It also provides data connection for other devices in the vehicle, such as the
infotainment head unit.
ACU6 has WLAN functionality and can act as both access point and station.
Hands-free voice calls are possible for telematics services, like emergency calls and breakdown calls. A voice
call is started by using specific buttons in the car, or automatically triggered after a crash. The voice call is set
up to a pre-defined number (depending on country).
The product can be attached to external antennas, but also have internal antennas that can be used if e.g. an
external antenna would be broken. There is also an internal backup battery that is used if the external power
source (vehicle battery) is lost.
1.2 CONNECTORS
1. Violet Fakra (code D) LTE main antenna
2. Red Fakra LTE diversity antenna
3. Blue Fakra GNSS antenna
4. Violet Fakra (code H) WLAN antenna
5. HSD connector Ethernet and USB
6. 22-pin JAE Main connector (power supply, CAN, buttons, audio...)
1.3 SIM
The product has an internal eSIM that is soldered to the PCB.
It is also possible to attach a micro-SIM (3FF) to a SIM tray inside the product. The SIM card is placed in the
SIM tray during manufacturing. The product is not designed so that the user can replace the SIM.
Title Revision & Status Doc Id Distribution Page (No Pages)
ACU6 User Manual -
103360002
1.2
Released
0000-0000 ACTIA Group 5 (15)
COPYRIGHT © 2018 ACTIA NORDIC AB PROPRIETARY & CONFIDENTIAL
1.4 POWER SUPPLY
1.4.1 External supply
Operating voltage range: 8-16 VDC. Nominal 13.8V.
1.4.2 Backup battery
ACU6 can also be operated without external power source using an internal rechargeable battery. In this
mode some functionality is disabled.
1.5 TEMPERATURE RANGE
Operating temperature range: -20 - +55°C.
Title Revision & Status Doc Id Distribution Page (No Pages)
ACU6 User Manual -
103360002
1.2
Released
0000-0000 ACTIA Group 6 (15)
COPYRIGHT © 2018 ACTIA NORDIC AB PROPRIETARY & CONFIDENTIAL
2 RF DESCRIPTION
2.1 GENERAL
ACU6 supports different radio technologies:
Cellular
WLAN 2.4GHz AP and STA
WLAN 5GHz AP
Bluetooth
GNSS
When the product is in normal operation mode and powered by external power source all technologies can
be activated. When powered by the internal backup battery only cellular and GNSS can be activated.
2.2 CELLULAR
ACU6 uses an embedded CAT 6 LTE modem.
Both internal or external cellular antennas can be used.
2.2.1 Bands and output power
Technology Bands Max. ouput power
GSM/GPRS/EDGE
850/900/1800/1900
Class 4 (+33dBm ±2dB) for EGSM850
and EGSM900
Class 1 (+30dBm ±2dB) for GSM1800
and GSM1900
Class E2 (+27dBm ± 3dB) for GSM
850 8-PSK and GSM 900 8-PSK
Class E2 (+26dBm +3 /-4dB) for GSM
1800 8-PSK and GSM 1900 8-PSK
WCDMA/HSPA II (1900), IV (1700), V (850) Class 3 (+24dBm +1/-3dB)
LTE FDD Bd2 (1900), Bd4 (1700), Bd5 (850), Bd12 (700),
Bd66 (1700) Class 3 (+23dBm ±2dB)
Title Revision & Status Doc Id Distribution Page (No Pages)
ACU6 User Manual -
103360002
1.2
Released
0000-0000 ACTIA Group 7 (15)
COPYRIGHT © 2018 ACTIA NORDIC AB PROPRIETARY & CONFIDENTIAL
2.2.2 Carrier aggregation
The following table lists the supported CA configurations (supported band combinations).
Downlink CA Bandwidth combination set
Intra-band continuous
CA_2C 0
CA_5B 0,1
CA_12B 0
CA_66B 0
CA_66C 0
Intra-band non-continuous
CA_2A-2A 0
CA_4A-4A 0,1
CA_66A-66A 0
Inter-band (two bands)
CA_2A-5A 0,1
CA_2A-12A 0,1,2
CA_4A-5A 0,1
CA_4A-12A 0,1,2,3,4,5
CA_5A-66A 0
CA_12A-66A 0,1,2,3,4,5
2.3 WLAN
ACU6 supports WLAN 802.11b/g/n/ac on 2.4 and 5GHz.
On 2.4GHz ACU6 can act as Access Point (AP) or Station (STA). On 5GHz only AP is supported.
Dual band simultaneous (DBS) operation is supported with 2.4GHz STA and 5GHz AP.
Tables below show supported channels and maximum output power (tolerance +/- 2dB).
Title Revision & Status Doc Id Distribution Page (No Pages)
ACU6 User Manual -
103360002
1.2
Released
0000-0000 ACTIA Group 8 (15)
COPYRIGHT © 2018 ACTIA NORDIC AB PROPRIETARY & CONFIDENTIAL
2.3.1 2.4GHz
ACU6 can act as Access Point (AP) or Station (STA) on 2.4GHz. Both internal or external WLAN antennas can
be used.
Channel
Max. power set
with external
antenna
Max. power set
with internal
antenna
1 – 11 13 dBm 13 dBm
2.3.2 5GHz
ACU6 can act as Access Point (AP) on 5GHz. Both internal or external WLAN antennas can be used.
2.3.2.1 20 MHz bandwidth
Channel
Max. power set
with external
antenna
Max. power set
with internal
antenna
36 USA: 12 dBm
Canada: 11dBm
USA: 12 dBm
Canada: 8dBm
40 USA: 12 dBm
Canada: 11dBm
USA: 12 dBm
Canada: 8dBm
44 USA: 12 dBm
Canada: 11dBm
USA: 12 dBm
Canada: 8dBm
48
USA: 12 dBm
Canada: 11dBm
USA: 12 dBm
Canada: 8dBm
149 17 dBm 17 dBm
153 17 dBm 17 dBm
157 17 dBm 17 dBm
161 17 dBm 17 dBm
165 17 dBm 17 dBm
Title Revision & Status Doc Id Distribution Page (No Pages)
ACU6 User Manual -
103360002
1.2
Released
0000-0000 ACTIA Group 9 (15)
COPYRIGHT © 2018 ACTIA NORDIC AB PROPRIETARY & CONFIDENTIAL
2.3.2.2 40 MHz bandwidth
Channel
Max. power set
with external
antenna
Max. power set
with internal
antenna
38 10 dBm
USA: 10 dBm
Canada: 8dBm
46 USA: 13 dBm
Canada: 11dBm
USA: 13 dBm
Canada: 8dBm
151 17 dBm 17 dBm
159 17 dBm 17 dBm
2.3.2.3 80 MHz bandwidth
Channel
Max. power set
with external
antenna
Max. power set
with internal
antenna
42 10 dBm USA: 10 dBm
Canada: 8dBm
155
15 dBm 15 dBm
2.4 BLUETOOTH
Both Bluetooth Classic and Bluetooth Low Energy (BLE) is supported.
Output power class 1.
2.5 GNSS
System Band
GPS L1
GLONASS L1 FDMA
Galileo L1
Beidou B1
Title Revision & Status Doc Id Distribution Page (No Pages)
ACU6 User Manual -
103360002
1.2
Released
0000-0000 ACTIA Group 10 (15)
COPYRIGHT © 2018 ACTIA NORDIC AB PROPRIETARY & CONFIDENTIAL
3 FUNCTIONAL DESCRIPTION
3.1 CAN CONNECTION
ACU6 has a CAN interface for connection to CAN buss vehicles. CAN data can be sent and received.
3.2 WLAN STATION
The unit ca be set in a mode where it acts like a WLAN station. This mode can e.g. be used for connection to
a hotspot in a workshop.
3.3 WLAN ACCESS POINT
ACU6 can act as a WLAN access point for passengers in the car. User interface needs to be implemented in
an external unit, e.g. in a head unit with display.
3.4 DATA GATEWAY
ACU6 acts as a data gateway for the WLAN access point and other ECUs in the vehicle. It can e.g. provide
internet connectivity for the head unit.
3.5 POSITIONING INFORMATION
The product can send GNSS position data on the CAN bus. The GNSS data can be used by other ECUs in the
vehicle, for instance the navigation system.
3.6 TELEMATICS APPLICATIONS
The product hosts a number of telematics applications. Some examples:
3.6.1 Automatic emergency call
If the car is in a crash and the SRS control unit indicates seat belt pretensioners, airbags or inflatable curtain
has deployed, an automatic call is sent to an OEM’s customer call center. ACU6 does not support 911
emergency calls.
Should the vehicle´s power feed be compromised the TCU has it’s own backup battery in order to self-
sustain the emergency call process.
3.6.2 Manual emergency call
It is also possible to manually start an emergency call to a customer call center by pressing a button.
3.6.3 Theft warning
The call center and the car owner are contacted with a data message if the car alarm indicates the car is
being stolen. The ACU6 is connected to the cloud and can detect tampering such as towing or power
manipulation. The ACU6 will the engage theft notification and enter alert mode.
3.6.4 Stolen vehicle tracking
The call center can initiate tracking of the car if it has been reported stolen. The vehicle location will then be
reported to the call center.
Title Revision & Status Doc Id Distribution Page (No Pages)
ACU6 User Manual -
103360002
1.2
Released
0000-0000 ACTIA Group 11 (15)
COPYRIGHT © 2018 ACTIA NORDIC AB PROPRIETARY & CONFIDENTIAL
Tracking updates of the vehicle can be adjusted depending on power usage. ACU6 is complying with the
Thatcham S5 classification.
3.6.5 Remote vehicle immobilization
If the car has been reported stolen the call center can instruct the car not to start.
3.6.6 Remote door unlock
The call center or the car owner can unlock the car remotely.
Title Revision & Status Doc Id Distribution Page (No Pages)
ACU6 User Manual -
103360002
1.2
Released
0000-0000 ACTIA Group 12 (15)
COPYRIGHT © 2018 ACTIA NORDIC AB PROPRIETARY & CONFIDENTIAL
4 INSTALLATION AND MAINTENANCE
4.1 INSTALLATION
The product is factory fitted in vehicles. It is not possible to buy this product separately.
4.2 CABLE HARNESS
Wire insulation and tubing in cable harness shall comply with IEC 60332-1-2, IEC 60332-1-3, IEC 60332-2-2 or
IEC/TS 60695-11-21.
4.3 SAFETY DISTANCE
Minimum safety distance for the device and the internal transmitting antennas is 22 cm.
Minimum safety distance for external antennas is 23 cm.
4.4 MAINTENANCE
The status of the product can be read via diagnostic connections using special workshop tools. In addition,
other ECUs monitor the communication from the product and in case of missing/invalid communication, the
Central Electronic Module in the vehicle is alerted, and will display a warning to the driver.
Maintenance and replacement of the product can only be performed by certified workshops.
Title Revision & Status Doc Id Distribution Page (No Pages)
ACU6 User Manual -
103360002
1.2
Released
0000-0000 ACTIA Group 13 (15)
COPYRIGHT © 2018 ACTIA NORDIC AB PROPRIETARY & CONFIDENTIAL
5 REGULATORY CERTIFICATIONS
5.1 USA (FCC)
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
5.1.1 FCC Warnings and Notices
WARNING: The FCC requires the user to be notified that any changes or modifications made to this device
that are not expressly approved by ACTIA Nordic AB could void the user's authority to operate the
equipment.
RF EXPOSURE WARNING: This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum distance 23 cm
between the radiator and your body. This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
5.1.2 OEM Requirements
Following text should be printed in the user manual for vehicles in US:
Type Approval USA
FCC ID: 2AGKK103360002
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
WARNING: Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Title Revision & Status Doc Id Distribution Page (No Pages)
ACU6 User Manual -
103360002
1.2
Released
0000-0000 ACTIA Group 14 (15)
COPYRIGHT © 2018 ACTIA NORDIC AB PROPRIETARY & CONFIDENTIAL
5.2 CANADA (ISED)
5.2.1 ISED Warnings and Notices
This device is compliant with the Radio-Electrical Standards for Radio Devices for Canadian Industry exempt
from license. Operation is permitted under the following two conditions: (1) the device shall not produce any
interference, and (2) the user of the device must accept any received radio-electrical interference, even if
the interference is likely to compromise its operation.
This radio transmitter 20839-103360002 has been approved by Innovation, Science and Economic
Development Canada to operate with the antenna types listed below, with the maximum permissible gain
indicated. Antenna types not included in this list that have a gain greater than the maximum gain indicated
for any type listed are strictly prohibited for use with this device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Le présent émetteur radio 20839-103360002 a été approuvé par Innovation, Sciences et Développement
économique Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain
admissible maximal. Les types d'antenne non inclus dans cette liste, et dont le gain est supérieur au gain
maximal indiqué pour tout type figurant sur la liste, sont strictement interdits pour l'exploitation de
l'émetteur.
Technology
Type
Max.
gain
Imedance
Cellular LTE1
Calearo
7680588 3,2 dBi 50 ohm
WLAN Calearo
7750162 3,0 dBi 50 ohm
5.2.2 OEM Requirements
Following text should be printed in the user manual for vehicles in Canada:
Type Approval Canada
IC: 20839-103360002
This device contains license-exempt transmitters/receivers that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS standard(s)]. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR
d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes:
Title Revision & Status Doc Id Distribution Page (No Pages)
ACU6 User Manual -
103360002
1.2
Released
0000-0000 ACTIA Group 15 (15)
COPYRIGHT © 2018 ACTIA NORDIC AB PROPRIETARY & CONFIDENTIAL
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Other manuals for ACU6
1
Table of contents
