Danfoss Link HP-kit User manual

MAKING MODERN LIVING POSSIBLE
Danfoss Heat Pumps
Danfoss Link™ HP-kit
Installation instructions

2
VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
Introduction
The Danfoss Link HP kit (HP)* is one of the accessories available for Danfoss Link™. The kit enables your
heat pump to communicate wirelessly** with other Danfoss Link™units in your heating system. An
example of a wireless solution for DHP-H is shown in the gure below.
q
e
tyu
r
w
HP-kit for DHP-H en
* The heat pump kit can also be used with Danfoss Online 2, with the exception of product numbers
086L2381 and 086L2382.
** Please note that all buildings may have obstructions which can impact on communication and the
maximum transmission distance. If you encounter problems with wireless communication, the wireless
signal can be amplied by means of Danfoss Link CF-RU repeater units.
Key to symbols
q Heat Pump (HP) tliving connect®
wGateWay yRoom Sensor (RS)
eDCM03 uHydronic Controller (HC)
rLink Central Controller (CC)

3VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
Quick Installation Guide
^
^
^
^
+
-
+
-
21
34
Note the following when installing the Danfoss Link™HP kit:
•Installation and positioning must be done in accordance with applicable laws and regulations.
•The Danfoss Link™HP kit only works in conjunction with heat pumps DHP-H/L/A 2009 or later, using soft-
ware version 1.34 or later, and DHP-AQ with software version 2.2 or later. The Danfoss Link™HP kit is not
suitable for heat pumps with a cooling function (DHP-C and heat pumps with a cooling module).
Tip!
• The
?
key on the Danfoss Link™ CC panel can be used at any time during installation.
• Always check for the latest software version at www.link.danfoss.com before installation. See the section on software
upgrades in the Danfoss Link™ CC Installation Manual.
Install all mains powered units
rst and add them to the network
Create rooms and add battery-powered
units one at a time
Perform the network test with the Dan-
foss Link ™ CC is in its nal location
Install the components of
the Danfoss Link™ HP kit
“OK”

4
VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
Installation, HP kit for Danfoss DHP-H/L/A
The HP kit’s main components comprise a GateWay card, tted inside the heat pump, and a DCM03, which
communicates wirelessly with the other parts of the heating system.
Danfoss Link™CC is used to control the system. Ensure that this control unit has the latest software
installed to avoid problems when installing the HP kit.
1. Check the software version on the control unit display. Press the left arrow
on the heating pump control until the display changes to “Service menu”.
2. Press “minus” until the cursor reaches the “Version” menu.
3. Press the “right arrow”. This will bring up the software version in the display.
Danfoss Link™to
DHP-H/L/A requires software version 1.34 or later.
Contents
Verify the contents of the HP kit. The delivery must contain the
following:
Description Quantity
DCM03
DCM03 cable
GateWay (incl. power cable)
GateWay cable
Mounting clips
This manual
1
1
1
1
4
1
Mount the GateWay card inside the heat pump on the prepared holes in the electrical panel. The DCM03
unit must be positioned outside the heat pump in order to be able to communicate wirelessly with
Danfoss Link™CC. The DCM03 unit must not be installed on the heat pump as the metal cabinet may
suppress the wireless signals. A network test will show if the location provides the necessary signal
conditions.
Fitting the GateWay card
Location
Safety precautions
CInstallation must be carried out in accordance with applicable laws and regulations, as well as
these instructions.
CThe terminal blocks are live and can be highly dangerous due to the risk of electric shock. The
power supply must be disconnected before commencing electrical installation.
≥ 2.2
Service menu
- Installation
- Version
+
_
< >
1
2
3
!
1. Open the cover by turning the open/close mechanism, after which the
cover can be lifted off. Be careful with the display cable behind the
cover.
≥1.34
or later

5VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
Connecting the GateWay cable
x4
q
COM
qq
qq
w
2. Fit 4 x “plastic clips” qin the prepared holes in
the electrical panel.
3. Press the GateWay card into the clip until the
card qlocks into place.
4. Attach the GateWay cable to the card in the
socket marked COM w.
5. Depending on the configuration, i.e. which other cards are already in the heat pump, connect the
other end of the GateWay cable as follows (A, B or C):
COM
COM
EXT
COM
EXT
COM
COM
EXT
EXT
EXT
COM
A. Heat pump without electronic
expansion card (Standard):
Connect the GateWay cable
directly to the terminal marked
EXT on the relay card.
B. Heat pump with electronic
expansion card:
Connect the GateWay cable to
the contact marked EXT on the
expansion card.
C. Air/water heat pump with
expansion card.
If the expansion card and defrost
card are already installed in the
heat pump, connect the GateWay
cable to the contact marked EXT
on the defrost card.
en

6
VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
CRead the safety precautions before beginning the
electrical installation.
1. Connect the enclosed wires to the GateWay card con-
tact marked 230VAC q.
2. Connect the other end of the cable to the terminal
block on the electrical panel.
3. Connect the blue cable to connection point N1b and
the black cable to connection point 217 in the terminal
bank.
4. To connect the cables:
•Insert a flat screwdriver in the hole below the hole
in which the cable is to be installed. Next, press the
screwdriver downwards to release locking mecha-
nism q.
•Insert the stripped section of the cable into the
upper hole while pulling the screwdriver out at the
same time. Make sure that the cable is securely in
place in the terminal.
Fitting DCM03
COM
2
1
COM
q
Electrical Installation
1. Attach the DCM03 cable to the GateWay card q. Route
the DCM03 cable wup through the inside of the heat
pump and out again through the cable bushing on
the top.
2. Remove the rear panel of the DCM03 unit by pressing
in the spring-loaded plates on the sides q and pull the
rear panel downwards wso that it can be removed.
q
w
N1
N1b
215 216
217


N1b
217

7VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
3. Using the rear panel as a template, mark perpendicular
drill holes at a suitable height on the wall close to the
heat pump.
4. Drill holes with a diameter suitable for the rawlplugs
and screws to be used. The size and type of screw will
depend on the wall material. Screws and rawlplugs are
not included in the installation kit.
5. Insert the rawlplugs into the drilled holes and screw the
rear panel securely into position.
6. Re-fit the front.
7. Connect the DCM03 cable to the outlet marked RS 485 on
the DCM03 unit.
8. Secure the cable to the wall using cable clamps.
RS 485
Start-up
CBefore connecting power to the GateWay card, make sure that the electrical installation has been
carried out correctly and that there is no risk of injury or damage.
1. Start the heat pump as specified in the heat pump installation guide.
2. Connect to Danfoss Link™ CC (see Chapter “Connection to Danfoss Link™ CC”)
en

8
VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
Danfoss HP kit for DHP-AQ
The installation kit q for the DHP-AQ series consists of a power supply, where a DIN rail is connected to
the DHP-AQ control (MAXI +60, MIDI or MINI). The DCM03 unit w is wall-mounted outside the control unit
so that it can communicate wirelessly with the Danfoss Link TM CC 3 panel. The Danfoss Link™CC epanel
communicates with the other Danfoss Link™ components in the heating system.
An example of a heating system with wireless units is shown in the gure below. The Danfoss Link™
components are indicated with a dotted line.
1
2
3
4 5 6
Legend
q Heat pump r living connect®
w DCM03 t Room sensor (RS)
e Link Central Controller (CC) y Hydronic controller (HC)
Delivery check
Check the delivery contents of 086L2382:
Description Qty. Pos.
AC/DC transformer (power supply DCM03)
Cable 230VAC - ACDC switching supply
DCM03
Connection cable DHP-AQ-DCM03
DIN rail (for ACDC transformer assembly)
Membrane nipple
Screws
Installation manual
1
1
1
1
1
1
4
1
A
B
C
D
E
F
G
-
II
Danfoss HP kit for DHP-AQ
A
B
C
D
E
F
G

9VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
Safety instructions
CInstallation must be carried out in accordance with applicable laws and regulations, as well as
these instructions.
CThe cables are live and may cause fatal electrical shock. The heat pump power supply must be
switched off before commencing electrical installation.
Software version
1. Check the software version on the DHP-AQ control
display. Press the left arrow on the heating pump
control until the display changes to “Service menu”.
2. Press “minus” until the cursor reaches the “Version”
menu.
3. Press the “right arrow”. This will bring up the
software version in the display. Link™for DHP-AQ
requires a softwareversion of 2.2 or newer.
≥ 2.2
Service menu
- Installation
- Version
+
_
< >
Location
The power supply must be mounted inside the heat pump control in the prepared holes in the electrical
panel. The DCM03 device is designed to be mounted on a wall as close as possible to the heat pump. The
distance is limited by the length of the DCM03 connection cable.
Installing the power supply
1. Switch off the power to the heat pump.
CRead the safety instructions before connect-
ing any wiring.

10
VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
2. Mount the DIN rail in the prepared holes in the electrical panel. Fasten the rail using screws and a
suitable tool. Self-tapping screws may also be used.
1. The cover is opened by turning the open/close
mechanism, after which the cover can be lifted off.
Be careful with the display cable behind the cover.
1
2
3
!
2. Attach the converter by first placing it on the upper part
of the fitting and then snapping it into position.

11 VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
Wiring
1. Connect the grey wire to the L terminal and the blue wire to the N terminal.
2. Route the cables through the electrical cabinet
and connect the grey wire to L 1:1 and the blue
wire to N on the connector bank.
3. Connect the DCM03 cable, red to + (positive)
and white to - (negative).
LN
2II
1
L1:1L1:1
N
L1:1 N
II
2
1
+
III
Červený
Rød
Rot
Red
Rojo
Rouge
Rosso
Rood
Rød
Czerwony
Красный
Punainen
Röd

12
VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
8. Connect the DCM03 cable to the free RJ45 connection on the relay
card. Pass the cable up through the cable lead-in and through the
membrane nipple. Adjust the length and press the membrane
nipple back.
Fitting DCM03
1. Remove the DCM03 unit rear panel by pressing in the spring-loaded plates on the side of the unit
and pulling the rear panel downwards until it can be removed.
2. Using the rear panel as a template, mark perpendicular boreholes at a suitable height on the wall
next to the heat pump.
3. Drill a hole with a diameter that can accommodate the rawlplugs and screws to be used. Screws
and rawlplugs are not included in the installation kit.
4. Insert the plugs in the holes and fasten the rear panel.
5. Re-fit the front.
6. Connect the DCM03 cable to the outlet marked RS 485 on the DCM03 unit.
7. Secure the cable with cable clamps at a suitable distance on the wall.
q
w
RJ45
III
RS 485

13 VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
Connection to Danfoss Link™ CC
CBefore connecting to a power outlet, make sure that the electrical installation has been carried out
correctly and that there is no risk of injury or damage.
Note!
The heat pump must be added to the network as a service unit. For more information about connecting to
networks see the accompanying Danfoss Link™ CC Installation Manual.
Add any dedicated repeaters (CF-RU) BEFORE adding the heat pump to the wireless network.
Note!
During installation, the distance between Danfoss Link™ CC and DCM03 must not exceed 1.5 metres.
Rooms and units
?
1
Service functions
Add service unit
?
2
Rooms and units
?
Start registration
Add service unit
3
Click here to add the DCM03 module to Danfoss Link ™CC.
• Start the heat pump
• Remove the front panel from the Danfoss Link™ CC by carefully
pulling it o. Pull near the edges of the panel.
• Press the Setup button for three seconds to open the service
area.
Connect other service and room units, e.g. HC oor heating and living connect radiator thermostats. Start
with the service units. For more information about connecting other units, see the accompanying Danfoss
Link ™ CC installation instructions.
Connecting other units to Danfoss Link™ CC, wireless connection

14
VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
The heat pump has now been added to the wireless system and is ready to be integrated with other
units in the system (e.g. Danfoss HC oor heating and/or living connect® radiator thermostats). This is
done via the Service menu using the following settings:
Conducting a network test after adding a new unit
Entering basic settings in Danfoss Link™ CC
Status and troubleshooting
?
1
Service functions
Network
?
2
Status and troubleshooting
?
1
Service functions
Unit management
?
2
Rooms and units
?
4
Select Unit
System integration System integration
? ?
5 6
System integration System integration
?
Start network test
Status of wireless network
3
?
Congure Unit
Unit management
3
Once the installation is complete, a network test must be carried out to ensure that communication
between all added units and Danfoss Link CC™ is stable.
Note! Do not carry out the network test until Danfoss Link™ CC has been tting in its nal position.
When the network test completes, Danfoss Link™ CC waits for the battery-powered units to be activated
and registered. Follow the on-screen instructions. If the network test completes without problems, no
further interaction will be required. If the network test runs slowly, Danfoss Link™ CC will guide you
through the troubleshooting procedures and provide useful tips as to how to speed up the process.
Heat pump
Rooms and units

15 VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
Troubleshooting
If an error occurs in communication with the GateWay card, the heat pump and DCM03, this may be
indicated in a number of dierent ways.
If the heating system is in operation when the error occurs, a yellow warning icon will be shown in the
Danfoss Link™CC display.
Refer to the instructions in chapter 7.1 in the installation manual for Danfoss Link™CC for more information
about the error and suggestions for suitable remedial measures.
If the wireless communication between Danfoss Link™CC and DCM03 does not work, check the follow-
ing:
1. Cable connections
2. Check that the units are connected to the mains and that they are switched on (LEDs illuminating
correctly).
3. Check that DCM is set to Danfoss Link™integration and not to Danfoss Online. By pressing the DCM
button quickly three times, you will switch between showing status for Danfoss Online and Dan-
foss Link™integration. The LEDs on DCM03 (both red and green) flash rapidly 3 times when status
changes from Danfoss Online to Danfoss Link™integration. When switching from Danfoss Link™
integration to Danfoss Online, the lights flash twice and more slowly.
4. Check LED on the GateWay card:
•Start-up: Flashing, on 90% off 10%.
•Approval DCM-HP: on 50% off 50% (rapid).
•Approval failed: on 75% off 25% (flashes twice (slowly) with a long pause in between).
•Send settings to DCM: on 50% off 50% (slow).
•Everything OK: 100% (constant light).
5. Check whether DCM03 has been registered correctly in the Danfoss Link CC™panel in accordance
with the Danfoss Link™CC Installation Manual, Chapter 4, ”Adding service units”.
6. Has a network test been performed to check whether all units in the heating system are working? See
the Danfoss Link™CC Installation Manual, Chapter 4.9 “Performing a network test”.
7. There may be too much distance between DCM03 and Danfoss Link™CC, or wireless communica-
tion may be obstructed because of physical objects or other obstructions. Try a new location for the
DCM03 until a good signal strength is obtained. If this is not possible due to physical components
of the building, use a repeater (CF-RU). Install this repeater between the Danfoss Link™CC and the
DCM03 unit.
8. In rare cases, it may be necessary to delete the heat pump as a service unit and then re-install it.
Follow the instructions in Chapter 5.3 in the Danfoss Link™CC Installation Manual about how to
remove a service unit.
9. The faulty component in the HP kit may need to be replaced. First, delete the service unit as
described in the Danfoss Link™CC Installation Manual. Next, add a replacement unit.
NOTE! If you restore the factory settings, you must also re-install all the units.

16
VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
When DanfossLink™ CC are used in conjunction with Online 2*, they can be integrated in the following two ways:
•System integration
•No system integration
“No system integration” is the default method during installation. When system integration is selected, Danfoss
Link™CC manages most functions in the heat pump. In this case, the functions controlled by Danfoss Link CC™ are
locked in relation to Online. The table below shows the relationship between disabled and enabled functions from
an Online perspective.
Tab Section Function System integr. No system
integr.
Status Indoor temperature (value: ROOM
(+/-)
No Yes
Details Heat curve Curve No Yes
Min No Yes
Max No Yes
+5 ºC No Yes
0 ºC No Yes
-5 ºC No Yes
Heat stop Yes Yes
Room factor No Yes
Danfoss DHP-AQ Calendar
control
Temperature decrease No Yes
Hot water block Yes Yes
Quiet mode Yes Yes
EVU mode Yes Yes
Yes Yes
Danfoss DHP-H, L Calendar
control
Temperature decrease No Yes
No = Function cannot be changed via Online when the system is in ”system integration”
Yes = Function can be changed Online regardless of whether system integration has been enabled or not
Using the Online application, you can change the integration options and go from “System integration” to “No
system integration” and take control of the function settings and vice versa.
Using Danfoss Link™ CC with Online 2
* The following does not apply to HP kits with product numbers: 086L2381 and 086L2382, as these are not
compatible with Online 2.

17 VIIFR102 © Danfoss 03/2014
Installation manual Danfoss Link™ HP kit
Recycling instructions
When the crossed-out wastepaper basket symbol is shown on the product, it means that the product is
subject to European Parliament and Council Directive 2002/96/EC. Locate your nearest recycling centre for
electrical and electronic products. Adhere to local regulations and do not put old products (e.g. batteries) in
your general household waste. By properly disposing of your old products you can help to reduce negative
impacts on the environment and public health.
en

18
VIIFR102 © Danfoss 08/2013

19
VIIFR102 © Danfoss 08/2013

83
VIIFR102 © Danfoss 08/2013
Danfoss Heat Pumps
Box 950
671 29 ARVIKA
Phone [phone]
E-mail: [email protected]
Internet: www.heating.danfoss.com
Danfoss assumes no responsibility whatsoever for any errors occurring in catalogues, brochures or other printed material. Danfoss reserves the right to
make changes to (the design of) its products with no prior warning.
The same applies to products already on order provided that the previously agreed specications remain unchanged.
All trademarks in this material are the property of the respective company. Danfoss and the Danfoss logotype are trademarks which belong to Danfoss
A/S. All rights reserved.
