active fun Infinity Leap TP499 Quick guide

TP499 Infinity Leap Trampoline
Instructions for assembly, maintenance and safe use.
Robovision Ltd t/a TP Toys
Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England
www.tptoys.com
We constantly strive to improve our assembly instructions. To see the most current version of this
instruction for assembly, maintenance and safe use. Please visit the product page at tptoys.com
Build Time
4 Hrs
x2
WARNINGS!
Patent GB2516510B
Patent Pending PCT/GB2018/053589
THIS PRODUCT CONTAINS SMALL PARTS
AND IS NOT SUITABLE FOR CHILDREN
UNDER 36 MONTHS. SMALL PARTS ARE A
CHOKING HAZARD.
ONLY FOR DOMESTIC USE. FOR OUTDOOR
USE ONLY.
TOY MUST BE ASSEMBLED BY AN ADULT
BEFORE USE.
CHILDREN MUST NOT USE THE EQUIPMENT
UNTIL PROPERLY INSTALLED.
ADULT SUPERVISION IS REQUIRED.
ONLY ONE USER. COLLISION HAZARD.
REMOVE ALL PACKAGING BEFORE GIVING
TO YOUR CHILDREN.
RETAIN PACKAGING FOR FUTURE
REFERENCE.
SHOES NOT TO BE WORN WHILE JUMPING.
ALWAYS CLOSE THE NET OPENING BEFORE
JUMPING
ALWAYS JUMP IN THE MIDDLE OF THE MAT.
DO NOT EAT WHILE JUMPING.
DO NOT EXIT BY A JUMP.
DO NOT USE THE MAT WHEN WET.
EMPTY POCKETS AND HANDS BEFORE
USING THE TRAMPOLINE.
LIMIT THE TIME OF CONTINUOUS USAGE
(MAKE REGULAR STOPS).
DO NOT USE IN STRONG WIND CONDITIONS
AND SECURE THE TRAMPOLINE.
THE NET SHOULD BE REPLACED EVERY 2
YEARS.
THIS PRODUCT IS INTENDED FOR USE BY
CHILDREN AGED 6 YEARS +.
WARNING: MAXIMUM SINGLE USER
WEIGHT 120KG
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 1 06/06/2019 11:18

2TP Infinity Leap Trampoline
IMPORTANT, BEFORE YOU BEGIN, READ THIS MANUAL
Thank you for buying this Trampoline. The trampoline is designed and
manufactured to provide many years of fun and exercise but, for your
child’s benefit and safety, please read this manual carefully and in full
before assembling and using your trampoline. Then, please retain this
manual for future reference.
Warnings!
lOnly one user. Collision hazard.
lAdult supervision of children - Children should always be supervised while
they are playing on the trampoline.
lUsers should not use the trampoline in an inappropriate or hazardous manner.
lDo not attempt somersaults.
lJump without shoes.
lDo not use the mat when it is wet.
lAlways close the net opening before jumping
lAlways jump in the middle of the mat.
lDo not exit the mat by a jump.
lDo not eat while jumping.
lLimit the time of continuous use (make regular stops).
lRegular maintenance is required.
Neglecting regular maintenance can lead to a risk for users.
lCheck all nuts and bolts for tightness and tighten when required.
l check that all spring-loaded (pit pin) joints are still intact and cannot become
dislodged during play.
lCheck all surfaces for sharp edges and replace when required.
lWear clothing that is free of drawstrings, hooks, loops, buckles or anything that
could get caught in the trampoline.
lDo not use in strong wind conditions.
lIn certain countries during winter period, it is recommended to store the
trampoline indoors.
lKeep away from fire.
lThe mat should be replaced every 2 years.
lRetain the maintenance instruction manual.
ASSEMBLY
1. The trampoline must be assembled by an adult.
2. The trampoline must be erected in accordance with the assembly instructions.
3. Enlisting the aid of a helper will make assembly easier.
4. Take care during assembly as the manufacturing process can sometimes result
in the occasional sharp edge and small pieces of waste metalwork. The use of
gloves to protect hands from pinch points is also recommended.
5. Should there be any missing parts, the trampoline must not be used until
replacement parts have been obtained.
6. Any changes to this toy including changing or adding an accessory, must be done
in accordance with our instructions. Failure to do this will render your guarantee
null and void and may make your product unsafe.
7. Retain the instructions for assembly, maintenance and safe use for future
reference.
SITE PLANNING
1. Place the trampoline in a well-lit area.
2. Do not position the trampoline on a hard surface such as concrete.
3. Position the trampoline on an impact-absorbing surface, such as grass, wood
chip, sand, rubber or synthetic compounds.
4. Ensure the trampoline is on a level surface.
5. Ensure the safe play free space area (see Page 3) is maintained.
6. Provide additional clearance for wires, tree branches, walls, fences and other
possible hazards.
7. Do not place the trampoline on top of other objects, or store anything under the
trampoline.
8. Disassemble the trampoline and store away safely when high winds are
anticipated.
CARE AND MAINTENANCE
Improper maintenance or lack of care can lead to your trampoline deteriorating
prematurely. Please follow these care instructions to ensure that your trampoline
remains safe and lasts for as long as possible.
Metal Rust and Corrosion
1. Some areas of the trampoline are particularly prone to rusting: Places where
water can become trapped. Hollow sections of steel (which can appear in good
condition on the outside, while hiding rust on the inside). Sections where different
metal components join.
2. Inspect the inside of all frame tubes and poles regularly, and remove any water
from the inside surfaces.
3. Check tube and pole connection areas for rust.
4. Use general purpose grease on steel connection areas to reduce the chance of
corrosion and wear.
5. Avoid excessively cleaning steel components, as it may reduce the effectiveness
of the protective coatings.
6. If surface rust appears it should be removed with a wire brush or coarse
sandpaper, and the area treated with a non-toxic paint.
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 2 06/06/2019 11:18

3TP Infinity Leap Trampoline
Textile Deterioration
1. Clean the trampoline mat with a soft sponge only to avoid prematurely wearing the
textiles.
2. Avoid using powerful soaps or detergents; they can damage the textiles.
3. Wipe dry with an absorbent cloth any water left after rain.
4. Remove shoes before using the trampoline along with sharp objects like belt
buckles.
5. In certain countries during the winter period, the snow load and the very low
temperature can damage the trampoline. It is recommended to remove the snow
and store the trampoline indoors.
SAFETY CHECKS
1. Inspect the trampoline before and after use for component deterioration, which can
happen over time from use and from environmental and weather conditions.
2. Replace any worn, defective, or missing parts immediately, and through TP Toys
only.
3. Regularly check all nuts and bolts for tightness and adjust when required.
4. Check all surfaces for sharp and protruding edges.
5. Check the surface of the mat for foreign objects, and remove them.
6. Use only TP Toys-made accessories with, or on, our trampolines.
Safe play free space area
INSPECTION CHECKLIST
Frame Tubes and Legs
Rust spots
Cracking on the curved
areas
Distortion of spring
holes
Twisted or stretched
steel
Sharp protrusions
Broken or missing push
pins
Distorted push pin holes
Broken welds
Net Upright Poles
Rusting
Cracking on the curved
areas
Twisted or stretched
steel
Sharp protrusions
Bent or twisted joints
Cracks in the joints
Rusty fluid leaking out of
the joints
Broken or missing push
pins
Distorted push pin holes
Mat
Holes
Burn marks
Frayed yarn
Broken sewing threads
Sagging fabric
Faded or torn fabric
UV damage
Surround Net
Holes
Burn marks
Frayed yarn
Broken sewing threads
Stretched mesh
Torn edge belts
Stretched seams
Faded materials
Detached top rods
Damaged top rod
connectors
UV damage
Frame Pads
Holes
Burn marks
Frayed yarn
Broken sewing threads
Stretched seams
Faded materials
UV damage
Springs
Rusting
Stretched, misshapen or
weakened
250cm
250cm
250cm
The safe play area refers to the
zone extending 200cm around
the toys on all sides and 250cm
above the toy. The safe play
area must be free from all
obstacles.
Safe play
This trampoline is not intended to be buried into the ground.
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 3 06/06/2019 11:18

4TP Infinity Leap Trampoline
FB3035 x6 FB3034 x2
TMP0607 x1
TMP0606 x1
TMP0605
x1
TMP0608
x1
Pack 1
MT5314 x1
MT5313 x1
PR5647 143cm x6
PR5649 167cm x2
PM9953
x2
PM9954
x2
PM9955
x2
PM9956
x2
PM9957
x8
PM9968
x16
6m MI1122 x2
SA1 x1
M8 x 60mm
FA2848
x8
M10 x 50mm
FA3841
x8
M6 x 44mm
FA2849
x8 M5 x 18mm
FA28450
x8
SP0001
FC8681
x1
Tools Supplied Tools required (not supplied)
M5
x1
M4
x1
Lubricating
Spray
SA2
x8
EL9063 x12 EL9064 x22
MI1123 x1
45cm
MI1124 x2
2.05m
EL9065 x1
150cm
FB3045 x10
220cm
FB3044 x3
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 4 06/06/2019 11:18

5TP Infinity Leap Trampoline
Pack 5
FC7999 x88
MT5319
x4
Pack 6
TS3499 x1
MT5320
x2
MT5322
x1
MT5321
x1
Pack 4
MT5311 x4
MT5312 x2
EL9066
x15
Pack 3
MT5326 x2
MT5325 x6
MT5327 x8
Pack 2
TM0604 x1
MT5315 x2
MT5316 x1
MT5318 x1
MT5317 x1
MT5323 x1
MT5324 x1
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 5 06/06/2019 11:19

1
6TP Infinity Leap Trampoline
Lay parts out like this
MT5312
MT5312
MT5319
MT5319
MT5319
MT5319
MT5320
MT5320
MT5315
MT5315
MT5316
MT5311
MT5311
MT5311
MT5311
MT5313
MT5314
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 6 06/06/2019 11:19

32
7TP Infinity Leap Trampoline
MT5311 x1
Small Square
Pressing
MT5319
x1
Large Square
Pressing
MT5312 x1
MT5319
x1
Large Square
Pressing
1
MT5312
2
MT5312
Lubricating
Spray
Lubricating
Spray
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 7 06/06/2019 11:19

4
8TP Infinity Leap Trampoline
MT5311 x1
MT5319
x1
Large Square
Pressing
1 2
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 8 06/06/2019 11:19

5
9TP Infinity Leap Trampoline
MT5319
x1 MT5313 x1
1
2
Large Square
Pressing
Small Square
Pressing
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 9 06/06/2019 11:19

6
10 TP Infinity Leap Trampoline
MT5311 x1
MT5322
x1
12
Large Square
Pressing
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 10 06/06/2019 11:19

7
11 TP Infinity Leap Trampoline
MT5320
x1 MT5312 x1
Large Square
Pressing
1
2
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 11 06/06/2019 11:19

8
12 TP Infinity Leap Trampoline
MT5311 x1
MT5320
x1
2
Large Square
Pressing
1
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 12 06/06/2019 11:19

9
13 TP Infinity Leap Trampoline
MT5321
x1
MT5314 x1
Large Square
Pressing
Small Square
Pressing
2
1
3
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 13 06/06/2019 11:19

10
14 TP Infinity Leap Trampoline
FC7999 x4
TM0604 x1
5
5
5
5
1
2
3
4
5
1
2345
1
2
3
4
5
1
2345
21
5
4
3
2
1
x4
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 14 06/06/2019 11:19

11
15 TP Infinity Leap Trampoline
MT5315 x2 MT5316 x1
1
2
3
MT5315
MT5315
MT5316
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 15 06/06/2019 11:19

12
16 TP Infinity Leap Trampoline
MT5318 x1
MT5317 x1
MT5323 x1
MT5324 x1
M10 x 50mm
FA3841
x4
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 16 06/06/2019 11:19

13
17 TP Infinity Leap Trampoline
1
2
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 17 06/06/2019 11:19

14
18 TP Infinity Leap Trampoline
M10 x 50mm
FA3841
x4
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 18 06/06/2019 11:19

15
19 TP Infinity Leap Trampoline
1 2
FC7999 x8 FC7999 x14
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 19 06/06/2019 11:19

16
20 TP Infinity Leap Trampoline
3 4
FC7999 x16 FC7999 x46
TP499 Infinity Trampoline IN0499 Issue-A 06.06.19 Landscape V2.indd 20 06/06/2019 11:19
