active fun TP Genius Octagonal Blue Quick guide

Warning!
Important! These instructions must be followed for safe assembly and use.
Please retain for future reference.
TP402 10ft TP Genius Octagonal Blue Trampoline
TP403 12ft TP Genius Octagonal Blue Trampoline
Instructions for assembly maintenance and use.
TP Genius Octagonal Blue
Trampoline with SurroundSafe
Maximum single user weights / Age range
TP402 10ft TP Genius Octagonal Blue Trampoline - Maximum single user weight 105kg - 6yrs+
TP403 12ft TP Genius Octagonal Blue Trampoline - Maximum single user weight 130kg - 6yrs+
TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.
CHILDREN MUST NOT USE THE EQUIPMENT UNTIL PROPERLY INSTALLED.
THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT SUITABLE FOR CHILDREN UNDER 36 MONTHS.
REMOVE ALL PACKAGING BEFORE GIVING TO YOUR CHILDREN.
ONLY FOR DOMESTIC USE. FOR OUTDOOR USE. ADULT SUPERVISION IS REQUIRED.
ANCHORS THAT ARE SUPPLIED WITH THIS PRODUCT MUST BE FITTED BEFORE USE.

lOnly one user. Collision hazard
lAlways close the net opening before practice
lPractice without shoes
lDo not use the mat when it is wet
lEmpty pockets and hands before practice
lAlways Jump in the middle of the mat
lDo not exit the mat by a jump
lLimit the time of continuous usage (make regular stops)
lRegular maintenance is required.
Neglecting regular maintenance can lead to a risk for users
lCheck all nuts and bolts for tightness and tighten when required
lCheck that all spring-loaded (pit pin) joints are still intact and cannot become dislodged
during play
lCheck all coverings for bolts and sharp edges and replace when required
lKeep away from fire
lRetain the maintenance instruction manual
Warning!
IMPORTANT, BEFORE YOU BEGIN, READ THIS MANUAL
Thank you for buying this Trampoline. The trampoline is designed and manufactured to provide
you and your family with many years of fun and exercise but, for your benefit and safety, please
read this manual carefully and in full before assembling and using your trampoline. Then, please
retain this manual for future reference.
! WARNING !
Do not land on head or neck. Paralysis or death can result even if you land in the
middle of the trampoline mat (bed).
Do not land on knees.
To reduce the chance of landing on your head or neck, do not do somersaults
(flips).
Only one person at a time on the trampoline.
Multiple jumpers increase the chances of loss of control, collision, and falling off.
This can result in broken head, neck, back, or leg.
2TP Genius Round Blue Trampoline with SurroundSafe

ASSEMBLY INFORMATION
Trampolines must be assembled by an adult. They must be erected exactly in accordance with the assembly instructions,
which follow. Enlisting the aid of a helper will make assembly easier. This trampoline does not require any additional
tools to assemble. Please take an inventory of all parts before assembly and ensure that all parts listed are included.
Also please take care during assembly as the manufacturing process can sometimes result in the occasional sharp edge
and small pieces of waste metalwork. The use of gloves to protect your hands from pinch points during assembly is also
recommended. Should there be any missing parts, the toy must not be used until replacement parts have been fitted.
Spares: Email: [e-mail]
SITING
The trampoline must always be used in a well lit area. Under no circumstances should it be positioned on a hard surface
such as concrete or asphalt, unless the ground under the trampoline plus the recommended freespace area is covered
with a safety surface (please refer to diagram on page 17). Examples of suitable surfaces are grass, sand or a play surface
intended for this use. The trampoline must be placed on a level
surface. A minimum of 2.5 metres of overhead clearance is
required for this product. Adequate horizontal clearance must be
maintained from objects and possible hazards including electric
power wiring, tree limbs and fencing. Keep away from fire.
ATTENTION - HIGH WINDS
Ground stakes are the ideal way to stop your trampoline
frame moving while in use. However they will not protect
against wind damage. Due to the extreme weather
conditions experienced over recent years we advise that
you always disassemble your trampoline and store it
away safely when high winds are anticipated.
YOUR NEW TRAMPOLINE - IMPORTANT PLEASE READ
USAGE
This trampoline is designed and made for family outdoor domestic use only. The trampoline is not intended for use outside
of these guidelines. The user should be either barefoot, in socks, or wearing gymnastic shoes. Misuse can result in injury.
Inspect the trampoline before use and always replace worn, defective or missing parts.
Warning for domestic use only!
SUPERVISION
Children should always be supervised while they are playing on trampolines and should be instructed not to use the
trampoline in an inappropriate or hazardous manner. We recommend that they do not wear loose-fitting clothing or
jewellery that may catch or snag during play. Ensure that younger children do not walk or crawl underneath the trampoline
and keep the area around and underneath free from all solid objects at all times.
WEATHER CONDITIONS
Special care should be taken as weather conditions change. In particular, a wet trampoline mat (bed) is too slippery for safe
jumping. Gusty or severe winds can cause jumpers to lose control. To reduce the chance of injury, use the trampoline only
under appropriate weather conditions. In cold weather, tongues and lips can stick to metalwork at subzero temperatures.
In warmer and sunnier weather, parts can become hot, and the temperature should be regularly checked during play,
especially metal parts.
WATER PLAY
Many surfaces can become slippery during water play. Extra caution and supervision is required when combining water
(e.g. paddling pools, aqua slides etc.) with other forms of outdoor play.
GENERAL SAFETY GUIDELINES - IMPORTANT PLEASE READ
3TP Genius Round Blue Trampoline with SurroundSafe

1. Trampolines are rebounding devices which propel the user to unaccustomed heights, and into a variety of body
movements. Rebounding off the trampoline, striking the frame or springs, or improperly landing on the trampoline
may cause injury.
2. All purchasers and all persons using the trampoline must become familiar with the manufacturers recommendations
for the proper assembly, use and care of the trampoline. Each user must also be alert to his/her own limitations in
the execution of trampoline skills. Assembly instructions, selected precautions and suggestions for the care and
maintenance of the trampoline are included in this user’s manual to promote safe, enjoyable use of this equipment.
3. It is the responsibility of the owner to ensure that all users of this trampoline are adequately informed of all warnings
and safety instructions.
4. Never allow more than one (1) person on the trampoline at a time. Multiple jumpers increases the chance of
someone becoming injured. Jumpers may collide with one another, fall off the trampoline, fall on or through
the springs, or land incorrectly on the mat.
5. Always secure the trampoline against unauthorized and unsupervised use.
6. Inspect the trampoline before each use and replace any worn, defective, or missing parts.The following conditions
could represent potential hazards:
(1) Missing, improperly positioned, or insecurely attached frame padding,
(2) Punctures, frays, tears, or holes worn in the bed or frame padding,
(3) Deterioration in the stitching or fabric of the bed or frame padding,
(4) Ruptured springs,
(5) A bent or broken frame,
(6) A sagging bed, or sharp protrusions on the frame or suspension system.
7. Adult supervision of children - Children should always be supervised while they are playing on the trampoline
fitted with a Bounce Surround and should be instructed not to use it in an inappropriate or hazardous manner.
In particular be aware of:
Use trampoline surround only with mature, knowledgeable supervision
Do not attempt to jump over the Surround
Do not attempt to crawl under the Surround.
Do not intentionally rebound off the Surround.
Do not hang from, kick, cut or climb on the Surround.
Wear clothing free of drawstrings, hooks, loops or anything that could get caught in the barrier.
Do not attach anything to the surround that is not a manufacturer-approved accessory or part of the surround system.
Enter and exit the surround only at the surround door or opening designated for that purpose.
BEFORE YOU BEGIN, REMEMBER
USING YOUR TRAMPOLINE - IMPORTANT SAFETY INFORMATION
1. Always bounce in the centre of the bed. Bouncing near the edge of the bed can lead to injury and can also
stretch the springs.
2. Avoid bouncing too high. Stay low until you can control your bounce and land consistently in the middle of the bed.
3. Learn basic bounces and body positions thoroughly before trying more advanced skills. Attempting a
manoeuvre beyond present skill levels increases the chance of loss of control. A controlled jump is one where the
landing is in the same spot as the take off. Before learning a more difficult manoeuvre, the preceding one should be
performed consistently under control.
4. Do not attempt somersaults without proper instruction and supervision. Landing on your head or neck, even in the
middle of the trampoline mat increases the risk of a broken neck, which can result in paralysis or death.
5. To regain control and stop your jump, bend your knees sharply when you land.
6. Do not bounce for too long or when tired.
7. Do not use the trampoline when under the influence of alcohol or drugs.
BOUNCING
4
5
TP Genius Octagonal Blue Trampoline with SurroundSafe

GENERAL
Your trampoline is designed to stand outside all year round and generally requires very little maintenance. However, a little
care and forethought can add years to your trampoline’s life. Remember that the bed (mat) and frame pads are made of
synthetic materials and are easily damaged by cigarette ends, fireworks and bonfire debris.
lCheck all nuts and bolts for tightness and tighten when required.
lCheck that all spring-loaded (pit pin) joints are still intact and cannot become dislodged during play.
lCheck all coverings for bolts and sharp edges and replace when required.
lRetain the maintenance instruction manual.
FRAME
Do not sit or stand on the frame or the frame pads while the trampoline is in use as this restricts the frames natural reflex
action. Oil or petroleum jelly applied where the springs hook into the frame will reduce squeaking and frame hole wear.
If surface rust appears it should be removed with either a wire brush or coarse sandpaper, and the area treated with a
non-toxic paint.
THE MAT
The mat (bed) will,over the years, be gradually weakened by the effects of ultra violet radiation. Therefore, the more it can be
protected from direct sunlight the longer it will last. A little mould or mildew should not harm the mat.
Do make sure that shoes are removed before bouncing and ensure that any other sharp objects such as belt buckles,
brooches and jewellery are removed too.
THE SPRINGS
Do not stand on the springs whilst the trampoline is in use. Try not to bounce on to the springs. They are not designed for
this sort of stress and can become stretched, misshapen and weakened. If you find you have any stretched springs, it is
important to replace them as soon as possible to avoid damage to the trampoline mat and avoid overloading and therefore
damaging the remaining good springs
FIRE RISKS AND DISPOSAL
Never allow toys to be placed or used near a fire. When it becomes necessary to dispose of your equipment, remove all
bolts and disassemble. Store out of the reach of children until it can be properly disposed of.
JUMPER’S ROLE IN PREVENTING ACCIDENTS
Education on the part of the user is a must for safety. Users must first learn a low controlled bounce and the basic landing
positions and combinations before proceeding to intermediate skills. Jumpers must understand why they have to master
“control” before they can start thinking about other moves. Understanding the proper progression of skills in jumping on a
trampoline must be the first lesson.
SUPERVISORS ROLE IN PREVENTING ACCIDENTS
It is the responsibility of the supervisors of trampoline users to provide knowledgeable and mature supervision. They need
to know and enforce all the rules and warnings set forth in this manual in order to minimize the likelihood of accidents and
injuries and to inform users of these rules. During periods of time when supervision is unavailable or inadequate, this may
require that the trampoline be disassembled, placed in a secure area, or otherwise secured against unauthorized use. It is
the responsibility of the supervisor to be sure that the users are fully aware of the safety guidelines which are printed on the
pads.
These instructions are issued in the interest of child safety, and we do ask you to follow our advice.
METHODS OF ACCIDENT PREVENTION
CARE AND MAINTENANCE OF YOUR TRAMPOLINE
4
5TP Genius Octagonal Blue Trampoline with SurroundSafe

CONTENTS 10ft and 12ft TRAMPOLINE FRAME- Please Check
10ft FC8699 x56
12ft FC8699 x72
10ft FC4202
12ft FC4201
10ft FC3068 x8
12ft FC3071 x8
16x FA8606
16x FA8607
10ft FM5741 x8
12ft FM5743 x8
10ft & 12ft BFC3067 x8
Tools
1x FC8681
CONTENTS SURROUND
10ft FB7804
12ft FB7805
10ft & 12ft PFC3062 x8
10ft TS0344 x1
12ft TS0345 x1
10ft DP7879 x1
12ft DP7880 x1
FB6048 x1
FB6046/6049 x1
10ft & 12ft
10ft 1180mm FC2090 x8
12ft 1410mm FC2091 x8
FC3061 1910mm x8
10ft & 12ft
24x FC2016
PM0947 x8
10ft & 12ft
8x PM93028x PM9301 8x WF9873
PM8156 x1
10ft & 12ft
1x FC8162
1x 4mm
2x 5mm
8x FA7460 8x FA5094 8x FA8008
10ft & 12ft
280mm
FM5730 x8
6TP Genius Octagonal Blue Trampoline with SurroundSafe

FRAME ASSEMBLY
x2 5mm
x16
x16
x16
x16
x8
x8 x8
x8
1
2
Lay Parts
out like this
x8
7TP Genius Octagonal Blue Trampoline with SurroundSafe
Stage
1
Stage
2

9
8TP Genius Octagonal Blue Trampoline with SurroundSafe
Stage
3
Stage
4

1st
5t
h7
th
4t
h3r
d
8t
h6
th
2nd
1st
5th7th
4th3rd
8th6th
2nd
1st
5th7th
4th3rd
8th6th
2nd
1st
5th7th
4th3rd
8th6th
2nd
10ft x56
12ft x72
x1
9TP Genius Octagonal Blue Trampoline with SurroundSafe
Stage
5

x8 x8
x1
x8
10ft 1180mm FC2090 x8
12ft 1410mm FC2091 x8
x8
Stage
7
Assembly Tip
Place surround on trampoline
frame/mat as shown
to help assemble surround
top rim and uprights.
x8
x8
11
10 TP Genius Octagonal Blue Trampoline with SurroundSafe
Stage
6

1x FB6048
A
B
8x FA7460
8x FA5094
8x FA8008
Stage
8
11 TP Genius Octagonal Blue Trampoline with SurroundSafe

Stage
9
x8
A B
Important Tip
Place short
foams on first.
Important Tip
Place long foams on top
of short foams and secure
with elastic ties.
13
12 TP Genius Octagonal Blue Trampoline with SurroundSafe
x24
x8

A
B
C
A
B
C
B C D
FB6046/6049 x1
10ft & 12ftt
FB6046/6049 x1
10ft & 12ftt
A
B
C
A
Start here
PM8156 x1
10ft & 12ft
1x
10ft & 12ft
13 TP Genius Octagonal Blue Trampoline with SurroundSafe
Stage
10
Stage
11

10ft DP7879 x1
12ft DP7880 x1
14
15
TP Genius Octagonal Blue Trampoline with SurroundSafe
Stage
12
Stage
13

Outside
Skirt
Pull surround around
the uprights
Repeat until all hooks
are fastened
Outside
Skirt
Underside
Skirt
Underside
Skirt
15 TP Genius Octagonal Blue Trampoline with SurroundSafe
Stage
14

x8
16 TP Genius Octagonal Blue Trampoline with SurroundSafe
17
Stage
15
Stage
16

Recommended Free Space:
The Safe Play Area refers to the zone extending 250cm (2.5 metres) beyond the toy on all sides and 250cm (2.5 metres)
above the toy. The Safe Play Area must be free from all structures, landscaping, trees and branches, rocks, wires,
sprinkler heads and other similar obstacles to safe play. Children can be seriously injured running or colliding into such
obstacles.
Trampoline dimensions:
Frame
12ft/Dia
366cm
Mat
313cm
Frame
10ft/Dia
305cm
Mat
254cm
90cm90cm
359cm420cm
270cm
270cm
TP402 TP403 Genius Octagonal Trampolines
10ft 12ft
250cm
250cm
250cm
Recommended safe play area:
250cm
17 TP Genius Octagonal Blue Trampoline with SurroundSafe

18 TP Genius Octagonal Blue Trampoline with SurroundSafe
19

19 TP Genius Octagonal Blue Trampoline with SurroundSafe

Designed in the UK by Robovision Ltd t/a TP Toys
Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England
For assembly advice, please email [email protected] or call 01525 722769 (office hours).
Made in China
www.tptoys.com
Instruction Part No: IN6069 Issue-B 22.03.17
Register your new TP product on line now at
www.tptoys.com/product registration
Thank you for purchasing this TP product. To find out all about your product guarantee and register
your purchase, please visit www.tptoys.com/productregistration
We want to give you the very best service. By registering your purchase now, we will be able to deal
with any guarantee issues very quickly and efficiently in the future. Thank you.
Your TP Guarantee Number/Product Batch No is
