Acumentrics Rugged-UPS 1252 Series Manual

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 1 © Acumentrics Corporation 2007-2008
1252 Rugged-UPS

 Series

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 2 © Acumentrics Corporation 2007-2008
NOTE: An issue or revision date for this manual is shown at the bottom of each page. If more than three
years have elapsed since this date, contact Acumentrics Corporation to determine if additional product
information updates are available. The latest revision of the manual is also available at
www.acumentrics.com.
Rugged-UPS is a registered trademark of Acumentrics Corporation.
Copyright 2007-2008 by Acumentrics Corporation. All rights reserved. Reproduction in whole or in
part without permission is prohibited. All other trademarks are the property of their respective owners.
20 Southwest Park
Westwood, MA. 02090
Telephone: [phone]
www.acumentrics.com

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 3 © Acumentrics Corporation 2007-2008
1252 Rugged-UPS



Series ........................................................................................................................... 1
Section 1 ........................................................................................................................................................ 5
General Information ...................................................................................................................................... 5
Product Description ................................................................................................................................... 5
Operation Topology ................................................................................................................................... 5
Important Safety Instructions..................................................................................................................... 6
How to use this Manual ............................................................................................................................. 7
Manual Updates ........................................................................................................................................ 7
Unpacking.................................................................................................................................................. 7
Optional Accessories................................................................................................................................. 7
Symbols Used on the Equipment ..............................................................................................................8
Warranty .................................................................................................................................................... 9
Life Support Use Information..................................................................................................................... 9
Specifications .......................................................................................................................................... 10
Diagnostics .............................................................................................................................................. 11
Section 2 ........................................................................................................................................................ 12
Operation ....................................................................................................................................................... 12
Controls & Indicators of Rugged UPSSeries....................................................................................... 12
Front Bezel .................................................................................................................................. 12
Rear Panel Rugged UPS............................................................................................................. 14
Rugged UPS Series Model Numbers and Options: .................................................................... 14
Acumentrics Part Numbering System ..................................................................................................... 14
Setup ....................................................................................................................................................... 15
SNMP Capability and Operation ............................................................................................................. 15
Start-Up ................................................................................................................................................... 20
Extended Run Modules ........................................................................................................................... 20
Operation ................................................................................................................................................. 21
Reset the Circuit Breaker ............................................................................................................ 21
Battery Status .............................................................................................................................. 21
Audible Alarm .............................................................................................................................. 21
Shutdown Procedures ................................................................................................................. 22
Preparation for Movement ........................................................................................................... 22
Operation under extreme heat..................................................................................................... 22
Operation under Extreme Cold.................................................................................................... 22
Operation under High Humidity ................................................................................................... 22
Input / Output Connections......................................................................................................................22
Pin Connections ...................................................................................................................................... 23
Remote Operation using Communications Port .......................................................................... 23
Communications Interface Pin Out Functionality (DB9):............................................................. 23
Pin Out Specifications: ................................................................................................................ 24
Section 3 ........................................................................................................................................................ 28
Maintenance and Trouble Shooting ............................................................................................................ 28
Maintenance and Battery Storage ...........................................................................................................28
Charge Battery ........................................................................................................................................ 28
General Maintenance .............................................................................................................................. 29

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 4 © Acumentrics Corporation 2007-2008
Inspection .................................................................................................................................... 29
Cleaning....................................................................................................................................... 29
Troubleshooting Procedures ................................................................................................................... 29
END. ........................................................................................................................................................ 31

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 5 © Acumentrics Corporation 2007-2008
Section 1
General Information
NOTE: Your Rugged-UPS

1252 Series device may or may not contain all the features
listed in this manual depending on your particular configuration.
Product Description
The Acumentrics Rugged-UPS1252 is specifically designed for worldwide deployment in harsh
physical and electrical environments. The Rugged-UPS1252 provides 1250VA of nominal 115VAC
output from an input of 80-265VAC 47-440Hz or 22-32 VDC (optional 20-32 VDC). This wide voltage and
frequency tolerance enables the rugged series to operate from generators in the field, or any international
power standard. This durable and versatile system contains advanced on-line technology to provide
highly reliable power back up and conditioning for the most sensitive electronic devices. Optional
shipboard models do not have output neutral tied to ground.
The Rugged-UPS1252 utilizes a unique FlowThru design which maximizes internal cooling while
sealing electronic components from the damaging effects of moisture, airborne particles, and other
contaminates in the operating environment.
The Rugged-UPS1252 is an ON-LINE Power Factor Corrected (PFC), Uninterruptible Power Supply
(UPS). This UPS accepts a wide range of voltage and frequency inputs to allow it to provide clean,
reliable AC power to sensitive electronic equipment. This true on-line, double conversion UPS continually
creates a pure sinewave AC output from a DC bus, thus protecting your equipment from surges, spikes,
brownouts, blackouts and noise.
The UPS is designed as a free-standing, self contained unit. It is supplied with adhesive-attached vinyl
bumpers on the bottom of the UPS chassis. Various fixed mounting points are provided on the chassis to
allow for tray, rail, or customer configured hard-mount systems.
Operation Topology
AC Input
Universal
Power Factor
Corrected Boost
Converter
Output EMI
Filter
Isolated
DC/DC Boost
Converter
400
VDC
BUS
115 VAC, 60 Hz* 1250VA
Optional - 230 VAC,
60 Hz* 1250VA
50 Hz* 1000VA
DC/AC
Inverter
Isolation
Transformer
DC/DC
Converter
Aux 24/48 VDC
Battery Charger
Input EMI
Filter
Input EMI
Filter
Battery
Solid
State
Electronic
Switch
DC Input
Computer
Comm Port
Aux Port

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 6 © Acumentrics Corporation 2007-2008
Important Safety
Instructions
Save These Instructions. This manual contains important instructions that should be followed during
installation and maintenance of the UPS and batteries. Please read all instructions before operating the
equipment and save this manual for future reference.
WARNINGS
•DANGEROUS VOLTAGE is used in the operation of this equipment. DEATH ON CONTACT may
result if personnel fail to observe appropriate safety precautions.
•There are NO user serviceable parts in this unit. Do NOT remove cover. Under no circumstances is
the top cover to be removed other than by the equipment manufacturer. Repairs are performed only
by factory trained service personnel.
•The Rugged-UPS1252 series is designed to be deployed in environments where the unit may be
exposed to high humidity and precipitation; however, hardware damage or electric shock may result
if the unit is submerged during operation.
•To prevent injury to personnel or equipment damage, the UPS requires two persons to lift and carry.
•To reduce the risk of electric shock, disconnect the UPS from the mains before installing a computer
interface signal cable (when used). Reconnect the power cord only after all signaling
interconnections have been made.
•Connect the UPS to a two-pole, three-wire grounding mains receptacle. The receptacle must be
connected to appropriate branch protection (fuse or circuit breaker). Connection to any other type of
receptacle may result in a shock hazard and may violate local electrical codes.
•Do NOT obstruct the air intake in the front of the unit or the exhaust outlet at the rear of the Rugged-
UPS1252. Sufficient airflow through the Rugged-UPSis vital to its operation.
•This UPS has an internal energy source (the battery) that cannot be de-energized by the user. The
output may be energized when the unit is not connected to a mains supply.
•To properly de-energize the UPS in an emergency, move the Power ON switch to the OFF position
and disconnect the power cord from the mains and remove battery pack.
•Avoid installing the UPS in locations where there is water or excessive humidity.
•Do not operate or make electrical connections while standing near or within puddles of water. Avoid
installing the Rugged-UPS1252 in locations where the unit will be subjected to extended
exposure to water.
•Do not allow water or any foreign object to get inside the UPS. Do not put objects containing liquid
on or near the unit.
•To reduce the risk of overheating, avoid exposing the unit to the direct rays of the sun. Avoid
installing the unit near heat emitting appliances such as a room heater or stove.
Batteries
•The batteries used by this UPS contain lead and pose a hazard to the environment and human
health if NOT disposed of properly. Proper disposal of the batteries is required. Please refer to local
codes for proper disposal requirements or return the unit to a factory authorized Service Center for
battery replacement or disposal.
•Lead-acid batteries are used in this equipment. Do not use any battery which shows signs of
damage such as: bulging, swelling, disfigurement, brown liquid in plastic wrap, or inflated plastic
wrap and leakage.
•Battery replacement should be performed by personnel familiar with the danger of batteries. Keep
unauthorized personnel away from the batteries.

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 7 © Acumentrics Corporation 2007-2008
(Continuation…) WARNINGS
•The batteries will eventually become too weak to provide rated autonomous operation. To obtain
battery replacement or repair service, please call the Customer Service telephone number written on
the back cover of this manual for information on the Service Center nearest you.
•Do NOT smoke near batteries. Sparks, flames or other sources of ignition may cause a battery
explosion.
•Use gloves and wear protective eye equipment whenever working with batteries.
•When replacing the Battery Pack, ensure the connectors located in the rear of the battery pack do
NOT come in contact with any metals, liquids, etc. a risk of electrical shock and high short circuit
current may exist.
•A battery can present a risk of electrical shock and high short circuit current. When replacing
batteries, wrist watches and jewelry such as rings should be removed. Use tools with insulated
handles.
How to use this
Manual
The Rugged-UPS1252 Operator’s Guide provides information operators need for safe and effective
use and care of the Rugged-UPS1252 products. It is important that all persons using this product read
and understand all the information contained within.
This manual is written for users who will be using the Rugged-UPS1252 for AC Input, optional DC
Input, AC Output, optional DC Output, with Battery Pack, (ACG1252R-18B). Features (options) that are
present in this manual that do NOT correspond with your device should be disregarded.
Please read thoroughly the Safety Considerations and Warning Section.
Manual Updates
Acumentrics Corporation provides manual updates to inform customers of changes in device information
and use. The updates will be available at the Acumentrics website www.acumentrics.com.
All users should carefully review each manual update to understand its significance and then file it in its
appropriate section within this manual for subsequent reference.
Unpacking
Carefully inspect each container for damage. If damage is sustained during transit it is not covered under
warranty. If the shipping container or cushion material is damaged, it should be kept until the contents
have been checked for completeness and the unit has been checked for mechanical and electrical
integrity. If the contents are incomplete, if there is mechanical damage, or if the instrument does not pass
its electrical test, customers should contact Customer Service at Acumentrics Corporation (800)-332-
0277.
Optional
Accessories
•ACG9012 Rack mount kit for standard 19” cabinets with depths from 20” - 26”
•ACG9200 10’ AC input cable w/ pigtails
•ACG9201 AC output cable
•ACG9202 DC Input cable
•ACG18BP Full Battery Pack
•ACG1252XRBP Extended run battery chassis
•ACG1UBP 1U high extended run battery chassis
*NOTE: If damage is caused by third party cables the warranty is void.

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 8 © Acumentrics Corporation 2007-2008
Symbols Used on the
Equipment
Any or all of the following symbols may be used in this manual or on the equipment.
DANGER
High Voltage present. This symbol alerts the user of uninsulated “dangerous
high voltage” within the product’s enclosure that may be hazardous to the user and
nearby personnel.
ATTENTION
Refer to the Operator’s Guide for more information. This symbol is
intended to alert the user to the presence of important operating and maintenance
instructions accompanying the device.
DO NOT
throw in the trash. This UPS contains sealed lead-acid batteries. Batteries
should not be discarded in the trash.
RECYCLE
batteries. This UPS contains sealed lead-acid batteries that must be
recycled.
DANGER Risk of explosion if used in the presence of flammable anesthetics.
Alternating current.
Equipotentiality.
Fusible link.
Protective (earth) ground terminal.

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 9 © Acumentrics Corporation 2007-2008
Warranty
Acumentrics warrants the equipment, when properly applied and operated within specified conditions,
against faulty materials or workmanship for a period of one (1) year from the date of original manufacture.
For equipment sites within the United States and Canada, this warranty covers repair or replacement of
defective equipment at the discretion of Acumentrics. Repair will be from Acumentrics' factory.
Replacement parts and warranty labor will be borne by Acumentrics. For equipment located outside of
the United States and Canada, Acumentrics only covers faulty parts. Equipment repaired or replaced
pursuant to this warranty shall be warranted for the non-expired portion of the warranty applying to the
original equipment. The warranty shall be void if (a) the equipment is damaged by Buyer, is improperly
used, is subjected to an adverse operating environment, or is operated outside the limits of its electrical
specifications; (b) the equipment is repaired or modified by anyone other than Acumentrics approved
personnel; or (c) has been used in a manner contrary to its operating manual or other written instruction.
When an alarmed failure or field test suggest that equipment may be faulty, whether in or out of the
warranty period, a full report of the difficulty should be telephoned to the Acumentrics Customer Service
Department. Upon receipt of this report, the Service Department will provide the assistance required to
repair or replace the equipment.
Acumentrics will not be liable for any associated costs incurred by the user, installing contractor, or
wholesaler as a direct or indirect result of failure or in the replacement of defective, in-warranty
equipment, unless Acumentrics grants prior approval. Unauthorized returns of equipment for in-warranty
repairs will be subject to an inspection and handling charge of $50 plus any repair and all transportation
charges. Buyer must obtain return/replacement authorization from the Customer Service Department and
indicate the Return Authorization Number that will be provided on the outside of the return packaging
materials. Buyer is responsible for shipping charges, shipping insurance, and packaging the equipment
securely to avoid shipping damage, using the original packaging. If this packaging is no longer available,
Buyer shall contact the Customer Service Department for instructions prior to returning equipment. Any
technical advice furnished before or after delivery in regard to use or application of equipment is furnished
on the basis that it represents Acumentrics' best judgment under the circumstances, but it is used at
Buyer's sole risk.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTY OR MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, AND/OR ANY OTHER OBLIGATION OR LIABILITY ON
THE PART OF ACUMENTRICS.
The sole and exclusive remedy for breach of any warranty, express or implied, and the only obligation of
Acumentrics there under, shall be the repair or replacement of defective equipment or, at Acumentrics'
option, refund of the purchase price or substitution with a new replacement product. Acumentrics shall in
no way be responsible for any consequential damages, of any kind or nature whatsoever, resulting from
the breach of any warranty, express or implied.
Life Support Use
Information
Life Support Policy
As a general policy, Acumentrics Corporation does not recommend the use of any of its products in life
support applications where failure or malfunction of the Acumentrics product can be reasonably expected
to cause failure of the life support device or to significantly affect its safety or effectiveness. Acumentrics
does not recommend the use of any of its products in direct patient care. Acumentrics will not knowingly
sell its products for use in such applications unless it receives in writing assurances satisfactory to
Acumentrics that (a) the risks of injury or damage have been minimized, (b) the customer assumes all
such risks, and (c) the liability of Acumentrics is adequately protected under the circumstances.
Examples of devices considered to be life support devices are neonatal oxygen analyzers, nerve
stimulators (whether used for anesthesia, pain relief, or other purposes), auto transfusion devices, blood
pumps, defibrillators, arrhythmia detectors and alarms, pace makers, hemodialysis systems, peritoneal
dialysis systems, neonatal ventilator incubators, ventilators for both adults and infants, anesthesia
ventilators, and infusion pumps as well as any other devices designated as “critical” by the U.S. FDA.

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 10 © Acumentrics Corporation 2007-2008
Specifications
General
Size 3.5” in. high x 17” in. wide x 24 in. deep”
Weight 60 lbs. (with battery pack)
46 lbs. (with no battery pack)
Input Specifications
Input AC Voltage 80-265 VAC
Input DC Voltage 22 – 32 VDC…. (Option of 20 – 32 VDC)
Frequency 47-400 Hz
AC Input Circuit Breaker Rating 20 A
Input Power Factor 0.8 minimum (.99 Typical)
Efficiency w/ 1000 Watt Load ACη=.86
DCη=.80
Output Specifications
Continuous Output Power 1250 VA / 1000W
AC Output Voltage 115 VAC ± 5%
AC Output Frequency 60Hz ± .5%
AC Output Waveform Sinusoidal
Total Harmonic Distortion 1.5% with resistive load
Environmental
Operating Temperature -18°C to 50°C
Storage Temperature -32°C to 66°C (Refer to Battery Maintenance Section
for more information on Battery Storage).
Humidity 10% to 95% relative humidity, non-condensing
Battery Pack
Type (2) Zero Maintenance, Valve Regulated Lead Acid
Batteries
Total Weight 14 lbs (6kg)
Voltage Two each 12V / 9Ah
Recharge Time 4 hours to 90% of present capacity
Operating Time 4 minutes at full load typical.
Low Battery Indicator LED indicators on the front panel.

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 11 © Acumentrics Corporation 2007-2008
Diagnostics
A computer contained within the device performs self-diagnostic tests whenever the product is initially
turned ON and periodically during operation. During operation the Overtemp and/or Overload indicators
will illuminate if a fault is detected. If this occurs, turn the unit OFF and then ON, and recheck the
indicators. Contact authorized personnel if any one of the indicators remains illuminated and is NOT
justified.

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 12 © Acumentrics Corporation 2007-2008
Section 2
Operation
Controls & Indicators of Rugged UPS

Series
Front Bezel
This section illustrates and describes the controls, indicators, ports, & connectors
NOTE: These are rotated on this model.
1. ON/OFF – Alarm Disable Switch
The self-centering toggle switch is capable of turning the Rugged UPSON, OFF, and disabling the
audible alarm. Hold the switch in the ON position for at least 5 seconds to supply power to the
Rugged UPSand enable the audible alarms. Briefly hold the switch in the OFF position to turn the
Rugged UPSoff. To disable the audible alarm, briefly hold switch for approximately 1 second in the
ON position while the Rugged UPSis on. The alarm cannot be disabled during initial start-up of the
device.
2. Fan Intake
The Fan Intake pulls air into the Rugged-UPS 1252to assist with the cooling of the system. Air is
exhausted through the rear outlet of the device. Ensure that both the fan intake and rear exhaust are
NOT obstructed so that the operation of the Rugged-UPS-1252 is not compromised.
1
2
1
3
4
5
6
7
8
9
10

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 13 © Acumentrics Corporation 2007-2008
3. Load Indicators
Measures and displays the load being applied to the Rugged UPS. When all five indicator lights
are illuminated a full load (1250 VA) is being applied to the Rugged UPS. When there are NO
indicators illuminated there is NO load being applied to the Rugged UPS.
4. Battery Status Indicators
Displays the charging level of the battery pack. When ALL five indicator lights are illuminated the
battery pack is fully charged to its present capacity and on external power. When battery pack
charge is near depletion, the last LED blinks and the alarm beeps one per second before low-battery
shutdown occurs.
When the UPS switches to internal DC, the battery pack charge decreases and fewer LED’s remain
illuminated and operating time becomes shorter.
5. On AC Line
This indicator is illuminated when the Rugged UPSis supplying power to the loads from the AC
connection source. This indicator will begin flashing during 80 VAC and 265 VAC operation to
indicate the operating point is close to tolerance. This indicator is NOT illuminated when the AC
source drops below 80 VAC causing the Rugged UPSto switch to external DC. If external DC is
unavailable the Rugged UPSwill switch to Internal DC.
6. On External DC
An isolated DC input of 22-32 VDC or optional 20 – 32V VDC volts allows for operation from vehicle
power.
7. On Internal DC
An audible tone briefly sounds and then the indicator illuminates when the unit is supplying power to
the loads from the internal battery pack.
8. Replace Battery
This indicator illuminates when the battery has reached the end of its usable life (battery voltage is
below 19.8 VDC). Momentarily holding the ON switch for one second, after replacing the battery, will
clear the “Battery Fault” indicator without turning the device OFF.
9. Overload
This indicator will remain illuminated and an audible tone will continuously sound when the Rugged
UPScapacity load is exceeded by the loads connected to the Rugged UPS.
10. Over Temperature
This indicator will remain illuminated and an audible tone will continuously sound when the Rugged
UPSinternal operating temperature has exceeded safe operating limits. The Rugged UPSwill
shut down if the condition persists.

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 14 © Acumentrics Corporation 2007-2008
Rear Panel Rugged UPS
Device model “ACG1252R-18B” Rear Panel shown below. There are six connectors on the UPS: an AC
and optional DC Input power connector, for external power sources; an AC and optional DC power output
connector, for supplying power to loads; a 9 pin “D” type female communication port connector
compatible with RS-232 or optional SNMP connector; and an auxiliary port “D” type 25 pin female
connector used by the manufacturer to program units. The AC Input Breaker will trip when the current
exceeds the UPS’s capacity. Refer to the Rear Panel photo and callouts below.
.
Rugged UPS Series Model Numbers and Options:
Acumentrics Part
Numbering System
ACG1252
R
-
24
-
1
8
B
N
“U”- Represents AC & DC Input.
“R”- Represents AC Input
Represents a device with continuous output power of
1250 VA / 1000W.
NOTE:
When a particular designation is missing from the Part Number then that option is NOT present in the device.
Indicates UPS’ internal battery is present
SNMP Capability (N)
24VDC / DC optional output
External Battery
(Extended Run)
AC Input
DC Output
Ext DC
Input
Auxiliary Port Comm Port
Circuit
Breaker
Fan
AC Output

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 15 © Acumentrics Corporation 2007-2008
Setup
•Ensure the AC Circuit Breaker, located in the rear of the device, is OFF.
•Connect ground wire to ground stud, located in the rear of the unit, and secure with wing nut.
•Connect AC source to AC Input connector
•Connect DC source to DC Input Connector.
•Connect AC Load to AC Output Connector.
•Connect DC Load to DC Output Connector.
SNMP Capability
and Operation
•The Ethernet interface consists of a 10/100 Base T network interface using a standard RJ45
connector.
•SNMP v3 protocol is supported with DHCP enabled.
•The interface card has its own MAC address, which is included with the documentation.
•The UPS supports a standard UPS MIB and may be accessed by using a MIB browser that
supports SNMP v3 . Refer to table 1 for supported features and default values.
•The following is the SNMP v3 parameters for use with a MIB browser
Agent port - 161
Read community – Public
Write community – Private
Version – 3
USM user – “initial”
Authorized algorithm – MD5
Privacy algorithm – DES
Authorized password – none
Privacy password – none
MAC ID: 00:40:9D:2B:6C:FB (unique to each module and will be labeled on unit)

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 16 © Acumentrics Corporation 2007-2008
MIB/Instance Variable Type Description Value
Range
Access
upsObjects(1).upsIdent(1) upsIdentManufacturer(1) String The name of the UPS manufacturer. Read
upsObjects(1).upsIdent(1) upsIdentModel(2) String The UPS Model designation. Read
UpsIdentUPSSoftwareupsObjects(1).upsIdent(1)
Version(3)
String The UPS firmware/software
version(s). This variable may or may
not have the same value as
upsIdentAgentSoftwareVersion in
some implementations.
Read
UpsIdentAgentSoftwareupsObjects(1).upsIdent(1)
Version(4)
String The UPS agent software version.
This variable may or may not have the
same value as
upsIdentUPSSoftwareVersion in
some implementations.
Read
upsObjects(1).upsIdent(1) upsIdentName(5) String A string identifying the UPS. . Read
upsObjects(1).upsIdent(1) upsIdentAttachedDevices(6) String A string identifying the devices
attached to the output(s) of the UPS.
This object should be set by the
administrator.
Write
1:unknown
2:Normal
battery
3:Low
battery
4:Depleted
upsObjects(1).upsBattery(2 upsBatteryStatus(1) int The indication of the capacity
remaining in the UPS system's
batteries. A value of battery Normal
indicates that the remaining run-time
is greater than
upsConfigLowBattTime. A value of
batteryLow indicates that the
remaining battery run-time is less than
or equal to upsConfigLowBattTime. A
value of batteryDepleted indicates
that the UPS will be unable to sustain
the present load when and if the utility
power is lost (including the possibility
that the utility power is currently
absent and the UPS is unable to
sustain the output).
battery
Read

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 17 © Acumentrics Corporation 2007-2008
upsObjects(1).upsBattery(2 upsSecondsOnBattery(2) int If the unit is on battery power, the
elapsed time since the UPS last
switched to battery power, or the time
since the network management
subsystem was last restarted,
whichever is less. Zero shall be
returned if the unit is not on battery
power.
Read
UpsEstimatedMinutesupsObjects(1).upsBattery(2
Remaining(3)
int An estimate of the time to battery
charge depletion under the present
load conditions if the utility power is
off and remains off, or if it were to be
lost and remain off.
Read
UpsEstimatedChargeupsObjects(1).upsBattery(2
Remaining(4)
int An estimate of the battery charge
remaining expressed as a percent of
full charge.
Read
upsObjects(1).upsBattery(2 upsBatteryVoltage(5) int The magnitude of the present battery
voltage.
Read
upsObjects(1).upsBattery(2 upsBatteryTemperature(7) int The ambient temperature at or near
the UPS Battery casing.
Read
upsObjects(1).upsInput(3) upsInputLineBads(1) int A count of the number of times the
input entered an out-of-tolerance
condition as defined by the
manufacturer. This count is
incremented by one each time the
input transitions from zero out-of-
tolerance lines to one or more input
lines out-of-tolerance.
Read
upsObjects(1).upsInput(3).upsInputTable(3).upsInputEntry(1) upsInputVoltage(3) int The magnitude of the present input
voltage.
Read
1: other
2: none
3: normal
4: bypass
5: battery
6: booster
upsObjects(1).upsOutput(4) upsOutputSource(1) int The present source of output power.
The enumeration none(2) indicates
that there is no source of output
power (and therefore no output
power), for example, the system has
opened the output breaker.
7: reducer
Read
upsObjects(1).upsOutput(4)
.upsOutputTable(4).upsOutputEntry(1)
upsOutputVoltage(2) int The present output voltage. Read
upsObjects(1).upsOutput(4). upsOutputPower(4) int The present output true power. Read

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 18 © Acumentrics Corporation 2007-2008
upsOutputTable(4).upsOutputEntry(1)
upsObjects(1).upsOutput(4).
upsOutputTable(4).upsOutputEntry(1)
upsOutputPercentLoad(5) int The percentage of the UPS power
capacity presently being used on this
output line, i.e., the greater of the
percent load of true power capacity
and the percent load of VA.
Read
upsObjects(1).upsAlarm(6) upsAlarmsPresent(1) int The present number of active alarm
conditions.
Read
upsObjects(1).upsAlarm(6).
upsAlarmTable(2).upsAlarmEntry(1)
upsAlarmDescr(2) OID A reference to an alarm description
object. The object referenced should
not be accessible, but rather be used
to provide a unique description of the
alarm condition.
See Alarm
definitions
Read
upsObjects(1).upsAlarm(6). Time
upsAlarmTable(2).upsAlarmEntry(1)
upsAlarmTime(3)
Stamp
The value of sysUpTime when the
alarm condition was detected. If the
alarm condition was detected at the
time of agent startup and presumably
existed before agent startup, the
value of upsAlarmTime shall equal 0.
Read
upsObjects(1).upsControl(8) upsShutdownAfterDelay(2 int Setting this object will shutdown (i.e.,
turn off)either the UPS output or the
UPS system (as determinedby the
value of upsShutdownType at the
time ofshutdown)
Write
upsObjects(1).upsControl(8) upsStartupAfterDelay(3) int Setting this object will start the output
after the indicated number of
seconds, including starting the UPS, if
necessary. Setting this object to 0 will
cause the startup to occur
immediately. Setting this object to -1
will abort the countdown.
Write
upsTraps(2) upsTrapOnBattery(1) Trap The UPS is operating on battery
power. This trap is persistent and is
present at one minute intervals until
the UPS either turns off or is no
longer running onbattery.
Read

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 19 © Acumentrics Corporation 2007-2008
UpsTrapAlarmEntry
upsTraps(2)
Added(3)
Trap This trap is sent each time an alarm is
inserted intoto the alarm table. It is
sent on the insertion of all alarms
except for upsAlarmOnBattery and
upsAlarmTestInProgress.
Read
UpsTrapAlarmEntryupsTraps(2)
Removed(4)
Trap This trap is sent each time an alarm is
removed fromthe alarm table. It is
sent on the removal of allalarms
except for upsAlarmTestInProgress.
Read
upsObjects(1).upsAlarm(6).upsWellKnownAlarms(3) upsAlarmOnBattery(2) OID The UPS is drawing power from the
batteries.
Read
upsObjects(1).upsAlarm(6).upsWellKnownAlarms(3) upsAlarmLowBattery(3) OID The remaining battery run-time is less
than or equal to
upsConfigLowBattTime.
Read
UpsAlarmDepletedupsObjects(1).upsAlarm(6).upsWellKnownAlarms(3)
Battery(4)
OID The UPS will be unable to sustain the
present load when and if the utility
power is lost.
Read
upsObjects(1).upsAlarm(6).upsWellKnownAlarms(3) upsAlarmTempBad(5) OID A temperature is out of tolerance. Read
upsObjects(1).upsAlarm(6).upsWellKnownAlarms(3) upsAlarmInputBad(6) OID An input condition is out of tolerance. Read
upsObjects(1).upsAlarm(6).upsWellKnownAlarms(3) upsAlarmOutputBad(7) OID An output condition (other than
OutputOverload) isout of tolerance.
Read
UpsAlarmOutputupsObjects(1).upsAlarm(6).upsWellKnownAlarms(3)
Overload(8)
OID The output load exceeds the UPS
output capacity.
Read
UpsAlarmOutputOffupsObjects(1).upsAlarm(6).upsWellKnownAlarms(3)
AsRequested(11)
OID The UPS has shutdown as requested,
i.e., the output is off.
Read
UpsAlarmUpsOffupsObjects(1).upsAlarm(6).upsWellKnownAlarms(3)
AsRequested(12)
OID The entire UPS has shutdown as
commanded.
Read
UpsAlarmUpsOutputupsObjects(1).upsAlarm(6).upsWellKnownAlarms(3)
Off(14)
OID The output of the UPS is in the off
state.
Read
UpsAlarmUpsSystemupsObjects(1).upsAlarm(6).upsWellKnownAlarms(3)
Off(15)
OID The UPS system is in the off state. Read
upsObjects(1).upsAlarm(6).upsWellKnownAlarms(3) upsAlarmGeneralFault(18) OID A general fault in the UPS has been
detected.
Read

Operator’s Guide for Rugged-UPS
TM
1252 Series
91-0120 Rev. B 20 © Acumentrics Corporation 2007-2008
Start-Up
Normal Start-up is starting with external AC and /or DC Power available to the UPS.
•Verify the UPS is properly connected and that external AC and/or DC power is applied to the
UPS.
•Verify the ground cable is attached.
•Turn the AC Circuit Breaker switch to ON.
•Hold the ON/OFF switch in the ON position for up to 5 seconds and then release the switch.
NOTE: If the electronics (e.g. capacitors) are fully discharged, failure to follow this step will
create a false failure.
•After 10 seconds has elapsed, verify the following indicators illuminate:
•Battery Status indicators are illuminated identifying a battery is present and appropriate charge
status when the device is operating on battery only.
•AC Line indicator will illuminate when AC source is present.
•DC Line indicator will illuminate when DC source is present.
•Load indicators are illuminated.
Start-up on Internal Battery Pack (cold starting): when NO External power is available, the UPS can be
started using its internal battery pack. If the battery pack is fully charged, the UPS will operate up to 4
minutes at full load typical.
•Hold the ON/OFF switch in the ON position for approximately 1 – 5 seconds and then release the
switch.
•To prolong the battery charge, turn on only those loads which are absolutely necessary.
•The “On Internal DC” indicator will be illuminated. Monitor the battery status via the Battery
Status indicators. Indicators identify the present capacity of the battery pack and the audible
alarm beeps twice every fifteen (15) seconds. As the charge on the battery pack depletes, the
battery status indicators will extinguish. An audible alarm will begin to sound every second with
the second to last indicator blinking and will continue until the last indicator is blinking indicating
the battery pack is nearly depleted and low-battery shutdown is imminent.
NOTE: To minimize the risk of arching on the battery connectors please be sure when inserting
or removing the battery pack that the unit has AC input connected.
NOTE: The battery indicators identify the charge status of the battery when operating on
battery ONLY. The battery capacity diminishes over time.
Extended Run
Modules
The Rugged-UPS
TM
1252 has optional extended run capability, using either the ACG1252XRBP (2U
high) or the ACG1UBP (1U high). Both modules are shipped with an extended run battery cable,
appropriate for the model being used.
There are two versions of the ACG1UBP. Both have an internal fuse. The connector pins are not
energized until connected to the Rugged-UPS
TM
1252. The UPS cannot “cold start” with only the 1U
Extended Run Battery Pack – the UPS’s internal battery pack or AC input power / optional DC input
power must be present for added safety. The LED Panel Indicator is illuminated when the unit is
charging / discharging, or when in stand-by mode.
