ADA INSTRUMENTS 2D Basic Level User manual

Manufacturer: ADAINSTRUMENTS Address: WWW.ADAINSTRUMENTS.COM
Operating manual
Laser level
Model: 2D BASIC LEVEL
MEASUREMENT FOUNDATION

MEASUREMENT FOUNDATION
2D BASIC LEVEL
2
2D BASIC LEVEL
ADA
MEASUREMENT FOUNDATION
WWW.ADAINSTRUMENTS.COM
3
3
3
4
5
5
6
6
8
8
9
9
10
10
12
13
16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2D BASIC LEVEL
MEASUREMENT FOUNDATION
2D BASIC LEVEL2D BASIC LEVEL
3
1. CAUTIONS
Cross line laser level - 2D BASIC LEVEL model - is an up-to-date functional and multi-prism device designed for
indoor and outdoor performance. The device emits:
one horizontal laser line (beam scan angle of 180°)
one vertical laser line (beam scan angle of 160°);
down point laser.
Do not look at the laser beam!
Do not install the device on the eye level!
Before using the device, do read this operating manual!
2. TECHNICAL REQUIREMENTS
2.1. FUNCTIONAL DESCRIPTION
Emitting a horizontal and vertical laser line.
Quick self-leveling: when line accuracy is out of the range
the laser line ashes and the warning sound is produced.
Low battery indication: the power LED ashes and warning
sound is produced.
Rotation base with scale convenient for use (range 1°).
Compensator locking system for safe transportation
Indoor and outdoor performance function
Back-lighted bubble level
Pic.1

MEASUREMENT FOUNDATION
2D BASIC LEVEL
4
2D BASIC LEVEL
2.2. FEATURES
1.Laser beam power-on button
2.Back-lighted bubble level (V/H/VH)
3.Indoor/outdoor performance indicator
4.Indoor/outdoor performance power-on button
5.Battery compartment
6.Compensator locking grip (ON/X/OFF switch)
7.Adjusting screws
8.Base with scale
9.Horizontal laser window
10.Vertical laser window
1
2
3
4
5
6
78
10
9

2D BASIC LEVEL
MEASUREMENT FOUNDATION
2D BASIC LEVEL2D BASIC LEVEL
5
3. KIT
Laser level ADA 2D Basic Level, bag, operating manual, glasses, target plate, 3xAA batteries.
2.3. SPECIFICATIONS
Laser Horizontal/vertical laser lines (angle between lines is 90°)/down point
Light sources 3 laser diodes with laser emission wave length of 635 nm
Laser safety class Class 2, <1mW
Accuracy ±1 5mm/5 meters
Self-leveling range ±3°
Operating range with/without receiver 40/20 m
Circular level response 60’’/2 mm
Power source 3 alkaline batteries, AA type
Operation time Approx. 15 hours, if everything is on
Tripod thread 5/8”
Operating temperature -5°C +45°C
Weight 0.25kg

MEASUREMENT FOUNDATION
2D BASIC LEVEL
6
2D BASIC LEVEL
4. SAFETY REQUIREMENTS AND CARE
Follow safety requirements! Don’t face and stare at laser beam!
Laser level- Is an accurate Instrument, which should be stored and used with care.
Avoid shaking and vibrations! Store the Instrument and It’s accessories only In the carrying case.
In case of high humidity and low temperature, dry out the Instrument and clean It after the usage.
Do not store the Instrument at a temperature below -20°C and above 50°C, otherwise the Instrument can be
out of action.
Don’t put the Instrument Into the carrying case If the Instrument or case are wet. To avoid moisture condensa-
tion Inside the Instrument- dry out the case and laser Instrument!
Check regularly Instrument adjustment!
Keep the lens clean and dry. To clean the Instrument use a soft cotton napkin!
5. ORDER WORKING
1. Before use, remove battery compartment cover. Insert three batteries into battery compartment with proper
polarity, the put the cover back (Pic. 2).
2. Set the compensator locking grip into ON position, two laser beams and back-lighted bubble level will be
on.
If the switch is ON,that means the power and the compensation are opened.
If the switch is X, that means the power is opened,the compensation is still locked ,but we
can still issue the lines and dot if you push the keypad,also it will not warn if you issue the
slope. It’s the hand-mode.
If the switch is OFF, that means shut off the power,the compensation is also locked.
3. Press V/H button - horizontal beam will turn on. Press the button V/H one more time
- vertical laser beam will turn on. Again press the button V/H - horizontal and vertical
beams will turn on. Pic.2

2D BASIC LEVEL
MEASUREMENT FOUNDATION
2D BASIC LEVEL2D BASIC LEVEL
7
4. Press the button of device mode “indoor/outdoor”, indicator will light. The
device works in “outdoor” mode. Press the button one more time. The device
will work in “indoor” mode.
5. During battery change, or when the device is on, control lamp may light
or warning sound may be produced. This indicated for low battery charge.
Please, change the batteries.

MEASUREMENT FOUNDATION
2D BASIC LEVEL
8
2D BASIC LEVEL

2D BASIC LEVEL
MEASUREMENT FOUNDATION
2D BASIC LEVEL2D BASIC LEVEL
9

MEASUREMENT FOUNDATION
2D BASIC LEVEL
10
2D BASIC LEVEL

2D BASIC LEVEL
MEASUREMENT FOUNDATION
2D BASIC LEVEL2D BASIC LEVEL
11
CARE AND CLEANING
Please handle measuring instrument with care. Clean with soft cloth only after any use. If necessary damp cloth with some
water. If instrument is wet clean and dry it carefully. Pack it up only if it is perfectly dry. Transport in original container/case only.
Note: During transport On/Off compensator lock (3) must be set to position “OFF”. Disregard may lead to damage of compen-
sator.
SPECIFIC REASONS FOR ERRONEOUS MEASURING RESULTS
Measurements through glass or plastic windows;
Dirty laser emitting window;
After instrument has been dropped or hit. Please check the accuracy.
Large uctuation of temperature: if instrument will be used in cold areas after it has been stored in warm areas (or the
other way round) please wait some minutes before carrying out measurements.
ELECTROMAGNETIC ACCEPTABILITY (EMC)
It cannot be completely excluded that this instrument will disturb other instruments (e.g. navigation systems);
will be disturbed by other instruments (e.g. intensive electromagnetic radiation nearby industrial facilities or radio trans-
mitters).
•
•
•
•
•
•

MEASUREMENT FOUNDATION
2D BASIC LEVEL
12
2D BASIC LEVEL
LASER CLASSIFICATION
The instrument is a laser class 2 laser product accortding to DIN IEC 60825-1:2007. It is allowed to use unit without
further safety precautions.
SAFETY INSTRUCTIONS
Please follow up instructions given in operators’ manual.
Do not stare into beam. Laser beam can lead to eye injury (even from greater distances).
Do not aim laser beam at persons or animals.
The laser plane should be set up above eye level of persons.
Use the instrument for measuring jobs only.
Do not open instrument housing. Repairs should be carried out by authorized workshops only. Please contact your
local dealer.
Do not remove warning labels or safety instructions.
Keep instrument away from children.
Do not use instrument in explosive environment.
WARRANTY
This product is warranted by the manufacturer to the original purchaser to be free from defects in material and work-
manship under normal use for a period of two (2) years from the date of purchase.
During the warranty period, and upon proof of purchase, the product will be repaired or replaced (with the same or
similar model at manufactures option), without charge for either parts of labour.
In case of a defect please contact the dealer where you originally purchased this product. The warranty will not apply

2D BASIC LEVEL
MEASUREMENT FOUNDATION
2D BASIC LEVEL2D BASIC LEVEL
13
to this product if it has been misused, abused or altered. Withiut limiting the foregoing, leakage of the battery, bending or drop-
ping the unit are presumed to be defects resulting from misuse or abuse.
EXCEPTIONS FROM RESPONSIBILITY
The user of this product is expected to follow the instructions given in operators’ manual.
Although all instruments left our warehouse in perfect condition and adjustment the user is expected to carry out periodic
checks of the product’s accuracy and general performance.
The manufacturer, or its representatives, assumes no responsibility of results of a faulty or intentional usage or misuse includ-
ing any direct, indirect, consequential damage, and loss of prots.
The manufacturer, or its representatives, assumes no responsibility for consequential damage, and loss of prots by any
disaster (earthquake, storm, ood ...), re, accident, or an act of a third party and/or a usage in other than usual conditions.
The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of prots due to a change of
data, loss of data and interruption of business etc., caused by using the product or an unusable product.
The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of prots caused by usage other
thsn explained in the users’ manual.
The manufacturer, or its representatives, assumes no responsibility for damage caused by wrong movement or action due to
connecting with other products.

WARRANTY DOESN’T EXTEND TO FOLLOWING CASES:
1. If the standard or serial product number will be changed, erased, removed or wil be unreadable.
2. Periodic maintenance, repair or changing parts as a result of their normal runout.
3. All adaptations and modications with the purpose of improvement and expansion of normal sphere of product ap-
plication, mentioned in the service instruction, without tentative written agreement of the expert provider.
4. Service by anyone other than an authorized service center.
5. Damage to products or parts caused by misuse, including, without limitation, misapplication or nrgligence of the terms
of service instruction.
6. Power supply units, chargers, accessories, wearing parts.
7. Products, damaged from mishandling, faulty adjustment, maintenance with low-quality and non-standard materials,
presence of any liquids and foreign objects inside the product.
8. Acts of God and/or actions of third persons.
9. In case of unwarranted repair till the end of warranty period because of damages during the operation of the product,
it’s transportation and storing, warranty doesn’t resume.
For more information you can visit our website WWW.ADAINSTRUMENTS.COM
or write the letter with your questions on [email protected]

WARRANTY CARD
Name and model of the product ________________________________________________
Serial number ________________date of sale_______________________
Name of commercial organization _____________________stamp of commercial organization
Warranty period for the instrument explotation is 24 months after the date of original retail purchase. It extends to the equipment, imported
on the RF territory by ofcial importer.
During this warranty period the owner of the product has the right for free repair of his instrument in case of manufacturing defects.
Warranty is valid only with original warranty card, fully and clear lled (stamp or mark of thr seller is obligatory).
Technical examination of instruments for fault identication which is under the warranty, is made only in the authorized service center.
In no event shall manufacturer be liable before the client for direct or consewuential damages, loss of prot or any other damage which
occur in the result of the instrument outage.
The product is received in the state of operability, without any visible damages, in full completeness. It is tested in my presence. I have no
complaints to the product quality. I am familiar with the conditions of qarranty service and i agree.
purchaser signature _______________________________
Before operating you should read service instruction!
If you have any questions about the warranty service and technical support contact seller of this product

Certicate of acceptance and sale
__________________________________________________________________________
__________________________________________________________________________
___________________________________________________________№_____________
name and model of the instrument
Corresponds to ______________________________________________________________
designation of standard and technical requirements
Data of issue _______________________________________________________________
Stamp of quality control department
Price
Sold ___________________________________ Date of sale ______________________
name of commercial establishment

MEASUREMENT FOUNDATION
Руководство по эксплуатации
Лазерный нивелир
Модель: 2D BASIC LEVEL
Производитель: ADAINSTRUMENTS Адрес: WWW.ADAINSTRUMENTS.COM

MEASUREMENT FOUNDATION
2D BASIC LEVEL
18
2D BASIC LEVEL
Оглавление
19
19
19
20
21
21
22
22
24
24
25
25
26
26
29
30
33
. . . . . . . . . . . . . . . . . . . . . . . . .

2D BASIC LEVEL
MEASUREMENT FOUNDATION
2D BASIC LEVEL2D BASIC LEVEL
19
1. ОБЩИЕ УКАЗАНИЯ
Лазерный нивелир: модель - 2D BASIC LEVEL - это современный, функциональный, мультипризменный прибор,
предназначенный для работ внутри помещений и на улице. Прибор проецирует:
- одну горизонтальную линию (угол развертки луча 180°)
- одну вертикальную линию (угол развертки луча 160°)
- точку отвеса
Не смотрите на лазерный луч! Не устанавливайте прибор на уровне глаз!
Перед началом работы, ОБЯЗАТЕЛЬНО, ознакомьтесь
с руководством по эксплуатации!
2. ТЕХНИЧЕСКИЕ ТРЕБОВАНИЯ
2.1. ФУНКЦИОНАЛЬНЫЕ ХАРАКТЕРИСТИКИ ПРИБОРА
Прибор излучает вертикальную и горизонтальную линии, точку отвеса.
Удобное в использовании вращающееся основание со шкалой
(интервал 1°) и микрометрическим винтом.
Быстрое самовыравнивание: лазерный луч мигает и
подается предупреждающий звуковой сигнал, когда прибор
отклонен на угол, выходящий за диапазон выравнивания.
Индикатор низкого заряда батарей: контрольная лампочка
загорается и подается предупреждающий звуковой сигнал.
Блокировка компенсатора для безопасной транспортировки.
Промежуточная блокировка компенсатора для работы
под наклоном.
Функция работы внутри помещения/ на улице.
Пузырьковый уровень с подсветкой.
. . . . . . . . . . . . . . . . . . . . . . . . .
Рис.1

MEASUREMENT FOUNDATION
2D BASIC LEVEL
20
2D BASIC LEVEL
1. Кнопка включения лазерного луча
2. Круглый пузырьковый уровень с подсветкой (V/H/VH)
3. Индикатор работы внутри помещения/ на улице
4. Кнопка включения режима работы внутри
помещения/ на улице
5. Батарейный отсек
6. Ручка блокировки компенсатора (ON/X/OFF)
7. Регулировочные винты
8. Основание со шкалой
9. Горизонтальное окно лазера
10. Вертикальное окно лазера
1
2
3
4
2.2. ОПИСАНИЕ ПРИБОРА
5
6
78
10
9
