ADA INSTRUMENTS CUBE 2-360 GREEN User manual

Line Laser
OPERATING MANUAL
CUBE 2-360 GREEN
adainstruments.com

2English
1
2
4
5
3
4
4
6
7
2
1
3

3
THE MANUFACTURE RESERVES THE RIGHT TO MAKE CHANGES (NOT
HAVING AN IMPACT ON THE SPECIFICATIONS) TO THE DESIGN,
COMPLETE SET WITHOUT GIVING PRIOR WARNING.
APPLICATION
Line laser ADA CUBE 2-360 Green is designed to check the horizontal and
vertical position of the surfaces of the elements of building structures and
also to transfer the angle of inclination of the structural part to similar
parts during construction and installation works.
SPECIFICATIONS
Laser beam ....................................................Horizontal line 360°/vertical line 360°
Light sources ................................................ 2 laser diodes with laser emission
wave length of 532 nm
Laser safety class ........................................ Class 2, <1mW
Accuracy ......................................................... ±3mm/10m
Self-leveling range ....................................... ±4°
Operating range with/without receiver ...... 230/130 ft (70/40 m)
Power source ................................................ Li-ion battery 3.7 V / 3xAA 1,5V
Tripod thread ................................................ 2x1/4”
Operating temperature ............................. -5°C +45°C
Weight ............................................................. 0,86 lb (390 g)
FUNCTIONAL DESCRIPTION
1. Emitting a horizontal and vertical laser line.
2. Quick self-leveling: when line accuracy is out of the range the laser
line ashes and the warning sound is produced.
3. Compensator locking system for safe transportation.
4. Intermediate compensator locking system for slope operation.
5. Indoor and outdoor performance function.
English

4English
LASER LINES
FEATURES
1. Vertical laser beam (V) / Horizontal laser beam (H)
2. Detector mode
3. Battery compartment
4. Tripod mount 1/4’’
5. Compensator switch (ON/X/OFF)
6. Vertical laser window
7. Horizontal laser window
SAFETY INSTRUCTIONS
Please follow up instructions given in operating manual. Do not stare into
beam. Laser beam can lead to eye injury (even from greater distances).
Do not aim laser beam at persons or animals. The laser plane should be
set up so that the beam path is not at normal eye level. Use the line laser
for measuring jobs only.
Do not open line laser housing. Repairs should be carried out by autho-
rized workshops only. Please contact your local dealer. Do not remove
warning labels or safety instructions. Keep line laser away from children.
Do not use line laser in explosive environment.
OPERATION
Cube 2-360 Green is a reliable and convenient line laser. It will be irreplace-
able instrument for many years.
1. Before use, remove battery compartment cover. Insert three batteries
into battery compartment with proper polarity, then put the cover back.
2. Set the compensator locking grip (5) into ON position.
If the switch is ON,that means the power is on and the compensator is working.
If the switch (5) is in intermediate position, that means the power is opened,the
compensation is still locked, but it will not warn if you issue the slope. It’s
the hand-mode.
1
2

5
If the switch (5) is OFF, that means that the line laser is o, the compensator
is also locked.
3. Press button (1) to switch the vertical beam on. Press button (1)once again
to switch the horizontal beam on. Press button (1) to switch the horizontal
and vertical beams on. Switch on only necessary laser lines in order to save
battery life.
4. Press button (2). The mode “outside” is activated. Press button (2) once
again. The tool begins to operate in “inside” mode. Use the detector of laser
beam for this mode. See the operating manual for the operation with detector.
TO CHECK THE ACCURACY
TO CHECK THE ACCURACY OF LINE LASER (SLOPE OF PLANE)
Place the line laser on the tripod 5m away from the wall so the horizontal
laser line will be directed to the wall.
Switch on the power. The line laser starts to self-level. Mark point A on the
wall to show the contact of laser beam with the wall. Turn the line laser by
90° and mark points В, С, D on the wall. Measure distance “h” between the
highest and lowest points (these are A and D points in the picture).
If “h”is ≤ 6 mm, the measurement accuracy is good. If “h” exceeds 6 mm,
apply service center.
TO CHECK PLUMB
Choose a wall and set laser 5m away from the wall. Mark point A on the
wall, please note the distance from point A to ground should be 3m. Hang
a plumb line from A point to ground and nd a plumb point B on ground.
turn on the laser and make the vertical laser line meet the point B, along
the vertical laser line on the wall and measure the distance 3m from point
B to another point C. Point C must be on the vertical laser line, it means the
height of C point is 3m.
Measure the distance from point A to point C, if the distance is over 2 mm,
please, contact with seller to calibrate the laser.
English
3

6English
CARE AND CLEANING
Please handle measuring line laser with care. Clean with soft cloth only
after any use. If necessary damp cloth with some water. If line laser is wet
clean and dry it carefully. Pack it up only if it is perfectly dry. Transport in
original container/case only.
Note: During transport On/O compensator lock (5) must be set to posi-
tion “OFF”. Disregard may lead to damage of compensator.
SPECIFIC REASONS FOR ERRONEOUS MEASURING RESULTS
• Measurements through glass or plastic windows;
• Dirty laser emitting window;
• After line laser has been dropped or hit. Please check the accuracy;
• Large uctuation of temperature: if instrument will beused in cold areas
after it has been stored in warm areas (or the other way round) please wait
some minutes before carrying out measurements.
ELECTROMAGNETIC ACCEPTABILITY (EMC)
• It cannot be completely excluded that this instrument will disturb other
instruments (e.g. navigation systems);
• will be disturbed by other instruments (e.g. intensive electromagnetic ra-
diation nearby industrial facilities or radio transmitters).
PRODUCT LIFE
Product life of the tool is 7 years. The battery and the tool should never
be placed in municipal waste. Date of production, manufacturer’s contact
information, country of origin are indicated on the product sticker.
LASER CLASS 2 WARNING LABEL ON THE LINE LASER
LASER CLASSIFICATION
The line laser is a laser class 2 laser product accortding to DIN IEC 60825-
1:2014. It is allowed to use unit without further safety precautions.
4

7English
WARRANTY
This product is warranted by the manufacturer to the original purchaser to
be free from defects in material and workmanship under normal use for a
period of two (2) years from the date of purchase. During the warranty pe-
riod, and upon proof of purchase, the product will be repaired or replaced
(with the same or similar model at manufactures option), without charge
for either parts of labour. In case of a defect please contact the dealer
where you originally purchased this product. The warranty will not apply
to this product if it has been misused, abused or altered. Without limiting
the foregoing, leakage of the battery, bending or dropping the unit are
presumed to be defects resulting from misuse or abuse.
EXCEPTIONS FROM RESPONSIBILITY
The user of this product is expected to follow the instructions given in op-
erators’ manual. Although all instruments left our warehouse in perfect
condition and adjustment the user is expected to carry out periodic checks
of the product’s accuracy and general performance. The manufacturer,
or its representatives, assumes no responsibility of results of a faulty or
intentional usage or misuse including any direct, indirect, consequential
damage, and loss of prots. The manufacturer, or its representatives, as-
sumes no responsibility for consequential damage, and loss of prots by
any disaster (earthquake, storm, ood ...), re, accident, or an act of a third
party and/or a usage in other than usual conditions.
The manufacturer, or its representatives, assumes no responsibility for
any damage, and loss of prots due to a change of data, loss of data and
interruption of business etc., caused by using the product or an unusable
product. The manufacturer, or its representatives, assumes no responsi-
bility for any damage, and loss of prots caused by usage other thsn ex-
plained in the users’ manual.
The manufacturer, or its representatives, assumes no responsibility for
damage caused by wrong movement or action due to connecting with oth-
er products.

8English
WARRANTY DOESN’T EXTEND TO FOLLOWING CASES:
1. If the standard or serial product number will be changed, erased, re-
moved or wil be unreadable.
2. Periodic maintenance, repair or changing parts as a result of their nor-
mal runout.
3. All adaptations and modications with the purpose of improvement
and expansion of normal sphere of product application, mentioned in the
service instruction, without tentative written agreement of the expert pro-
vider.
4. Service by anyone other than an authorized service center.
5. Damage to products or parts caused by misuse, including, without lim-
itation, misapplication or nrgligence of the terms of service instruction.
6. Power supply units, chargers, accessories, wearing parts.
7. Products, damaged from mishandling, faulty adjustment, maintenance
with low-quality and non-standard materials, presence of any liquids and
foreign objects inside the product.
8. Acts of God and/or actions of third persons.
9. In case of unwarranted repair till the end of warranty period because
of damages during the operation of the product, it’s transportation and
storing, warranty doesn’t resume.

9
English
WARRANTY CARD
Name and model of the product __________________________________________
Serial number___________________________Date of sale______________________
Name of commercial organization ________________________________________
stamp of commercial organization
Warranty period for the instrument explotation is 24 months after the
date of original retail purchase.
During this warranty period the owner of the product has the right for
free repair of his instrument in case of manufacturing defects.
Warranty is valid only with original warranty card, fully and clear lled
(stamp or mark of thr seller is obligatory).
Technical examination of instruments for fault identication which is
under the warranty, is made only in the authorized service center.
In no event shall manufacturer be liable before the client for direct or
consequential damages, loss of prot or any other damage which occur
in the result of the instrument outage.
The product is received in the state of operability, without any visible
damages, in full completeness. It is tested in my presence. I have no
complaints to the product quality. I am familiar with the conditions of
qarranty service and i agree.
purchaser signature _______________________________
