SCSI RAID DATA SHEET
The Adaptec PCI-X zero-channel RAID
(ZCR) card offers the ideal solution for
customers who want an affordable, flexible
upgrade path to advanced RAID. The
Adaptec SCSI RAID 2020ZCR and
2025ZCR cards provide an affordable, high-
performance solution to businesses
requiring data protection. The low profile
form factor is ideal for workstations and
high-density server environments.
The Adaptec SCSI RAID 2020ZCR and
2025ZCR cards take advantage of the
system motherboard’s existing UltraU320
SCSI I/O channels by using complementary
logic designed on the motherboard. This
innovative approach reduces the cost of the
RAID card by eliminating the need for a
SCSI I/O chip on the card. The Adaptec
2020ZCR and 2025ZCR cards offer high-
speed throughput, scalability, space-saving
features, and a cost-effective upgrade path
toafull-featured PCI-X RAID solution.
Configuration and Interoperability
The Adaptec 2020ZCR requires
motherboards with a 64-bit PCI/PCI-X slot
supporting Adaptec Embedded RAID Logic
(EMRL) or Intel RAIDIOS Logic.
The Adaptec 2025ZCR is a “credit card size”
RAID card that plugs into a specially
designed small form factor PCI-X
connector (an SODIMM connector
attached to the PCI-X bus via EMRL) on
Ultra320 motherboards. This unique design
gives high-density servers advanced RAID
protection and performance without
sacrificing a PCI-X slot, making it ideal for
1U applications.
Easy-to-use storage management
The Adaptec 2020ZCR and 2025ZCR
operate under Adaptec Storage Manager™,a
storage management tool that centralizes
management of all Adaptec host-based and
all hardware based RAID products. The
software enables remote management,
monitoring, and configuration of RAID
arraysthroughsecure, encrypted remote
communications. The intuitive RAID
management tool provides pop-up tips and
online help tosimplify the creationand
management of RAID arrays.
Compatibility, Reliability, and Support
Adaptec zero-channel RAID cards are
designedto work with motherboards
incorporating a complementary logic, such
as Adaptec Embedded RAID logic (EMRL)
or Intel RAIDIOS logic. Like all Adaptec
products, the Adaptec SCSI RAID ZCR
cards have been extensively tested with
third-party systems and SCSI devices to
deliver the utmost in compatibility, now
and in the future. They are backed by a 3-
year warranty and industry leading Adaptec
technical support.
For information on the latest supported
kernels, or to download the latest Adaptec
drivers, visit our website at www.adaptec.com
Adaptec®SCSI Zero-Channel
RAID Controller Family
(2020ZCR/2025ZCR)
Innovative PCI-X zero-channel design for an easy
and cost-effective upgrade to RAID 5
Product Highlights
PCI-X (64/133MHz)
performance
Unique form factors ideal for
high-density server environments
Adds advanced RAID
functionality to onboard Adaptec
SCSI
Consumes 75% less power than
comparable one- and two-
channel RAID cards
Supports RAID levels 0, 1, 10, 5,
50, and JBOD
Simplifies array management
with easy-to-use Adaptec
Storage Manager software (ASM)
Intel EM64-T and AMD-64 ready
RoHS compliant

Copyright 2007 Adaptec, Inc. All rights reserved. Adaptec, the Adaptec logo, Snap Appliance, the Snap Appliance logo, Snap Server, Snap Disk, GuardianOS, SnapOS, and Snap Server Storage Manager are trademarks of Adaptec, Inc.,
whichmaybe registered in some jurisdictions. Microsoft and Windows are registered trademarks of Microsoft Corporation, used under license. All other trademarks used are owned by their respective owners.
Information supplied by Adaptec, Inc., is believed to be accurate and reliable at the time of printing, but Adaptec, Inc., assumes no responsibility for any errors that may appear in this document. Adaptec, Inc., reserves the right,
withoutnotice, to make changes in product design or specifcations. Information is subject to change without notice.
P/N: 986889-012 Printed in U.S.A. 09/07 4913_1.1
Adaptec® SCSI Zero-Channel RAID Family
SCSI RAID DATA SHEET
Adaptec, Inc.
691 South Milpitas Boulevard
Milpitas, California 95035
Tel: [phone]
Fax: [phone]
Literature Requests:
US and Canada: 1 [phone] or [phone]
World Wide Web: http://www.adaptec.com
Pre-Sales Support:US and Canada: 1 [phone] or [phone]
Pre-Sales Support:Europe: Tel: [phone] or Fax: [phone]
Adaptec SCSI RAID 2020ZCR Controller
Ordering Part Number: 2039300-R
Adaptec SCSI RAID 2025ZCR Controller
Ordering Part Number: 2250200-R
Why to Buy? Affordable, low-profile RAID design – easily upgrades onboard
SCSI to RAID
“Credit card size” RAID design – easily upgrades onboard
SCSI to RAID
Environment Ideal for PCI-X servers and workstations implementing
Adaptec SCSI zero-channel RAID
Ideal for PCI-X servers and workstations implementing
Adaptec SCSI zero-channel RAID
Device support 15 SCSI devices per channel 15 SCSI devices per channel
Data transfer rates Up to 320 MB/s per channel Up to 320 MB/s per channel
RAID levels 0, 1, 10, 5, 50, JBOD 0, 1, 10, 5, 50, JBOD
Cache memory 64MB, ECC SDRAM 64MB, ECC SDRAM
Bus type PCI-X 64-bit/133 MHz PCI-X 64-bit/133 MHz
System requirements
Intel PC or equivalent with PCI or PCI-X slots supporting
Embedded RAID logic (EMRL) or Intel RAIDIOS logic
Intel PC or equivalent with specially-designed small form
factor PCI connector supporting Adaptec Embedded RAID
logic (EMRL)
Operating System support
Windows® Server 2003, Windows XP, Windows 2000, Red Hat
and SUSE Linux, SCO UnixWare and Caldera OpenUNIX (for
latest supported kernels visit www.adaptec.com)
Windows® Server 2003, Windows XP, Windows 2000, Red Hat
and SUSE Linux, SCO UnixWare and Caldera OpenUNIX (for
latest supported kernels visit www.adaptec.com)
Key RAID features
Optimized Disk Utilization
Online Capacity Expansion
RAID level Migration
Background Initialization (for immediate RAID availability)
SNMP support
Enclosure Management Ready
S.M.A.R.T.support(Drive error Tracking)
SES/SAF-TE support
Command line interface (CLI) for automated scripts
Hot Swap and Hot Spare
Optimized Disk Utilization
Online Capacity Expansion
RAID level Migration
Background Initialization (for immediate RAID availability)
SNMP support
Enclosure Management Ready
S.M.A.R.T.support(Drive error Tracking)
SES/SAF-TE support
Command line interface (CLI) for automated scripts
Hot Swap and Hot Spare
Software in kit Adaptec Storage Manager (ASM) GUI, BIOS configuration
utility (ACU), Command Line Interface (CLI))
Adaptec Storage Manager (ASM) GUI, BIOS configuration
utility (ACU), Command Line Interface (CLI)
Physical dimensions Low-profile: 2.5in H x 6.6in L
6.25cm H x 16.5cm L
3.2in H x 3.8in L
8cm H x 9.5cm L
Operating Temperature 0to 55 degrees C 0 to 55 degrees C
Power Requirements 1amp @ 3.3V 1 amp @ 3.3V
Warranty 3years 3 years
2020ZCR 2025ZCR
