ADC ML-96 User manual

ML-96 Parts Manual
Phase 7
2001
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: [phone] / Fax: [phone]
E-mail: [e-mail]
www.amdry.com
ADC Part No. 450569-5

Retain This Manual In ASafe Place For Future Reference
American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product
is properly maintained, it will provide many years of safe, efficient, and trouble free operation.
ONLY qualified technicians should service this equipment.
OBSERVE ALL SAFETY PRECAUTIONS displayedon theequipment orspecified inthe installation manualincluded
with the dryer.
The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.
We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to
make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to
change or discontinue models.
Important
For your convenience, log the following information:
DATE OF PURCHASE ____________________________________________________ MODEL NO. ______________
RESELLER’S NAME _________________________________________________________________________________
SERIAL NUMBER(S) __________________________________________________________________________________
____________________________________________________________________________________________________
____________________________________________________________________________________________________
Replacement parts can be obtained from your reseller or theADC factory. When ordering replacement parts from the
factory, youcanFAX yourordertoADCat [phone]or telephoneyour orderdirectlyto theADCPartsDepartment
at [phone]. Please specify the dryer model number and serial number in addition to the description and part
number, so that your order is processed accurately and promptly.
The illustrations on the following pages may not depict your particular dryer exactly. The illustrations are a composite
of the various dryer models. Be sure to check the descriptions of the parts thoroughly before ordering.
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser d’essence
ni d’autres vapeurs ou liquides
inflammables à proximité de cet appareil
ou de tout autre appareil.
ML-96
“IMPORTANT NOTE TO PURCHASER”
Information must be obtained from your local gas supplier on the
instructions to be followed if the user smells gas. These
instructionsmustbe posted in aprominentlocation near the dryer.

Table of Contents
Control Door Assembly ...............................................................................................................................4
Phase 7 OPL Microprocessor Control Panel Assembly .............................................................................5
Main Door / Front Panel Assembly .............................................................................................................6
Main Door Assembly ...................................................................................................................................7
Main Door Switch Assembly .......................................................................................................................8
Temperature Sensor Bracket Assembly .....................................................................................................9
Wrapper Assembly....................................................................................................................................10
Lint Drawer Assembly ............................................................................................................................... 11
Tumbler Assembly ....................................................................................................................................12
Phase 7 Rotational SensorAssembly.......................................................................................................13
Idler Shaft Assembly .................................................................................................................................14
Drive Shaft Assembly................................................................................................................................15
Drive Motor Assembly ...............................................................................................................................16
Direct Spark Ignition Burner Assembly .....................................................................................................18
Motorized Impellor (Fan) Assembly ..........................................................................................................20
Pneumatic Valve Assembly.......................................................................................................................21
Reversing Relay Panel Assembly for Models Mfd. prior to February 10, 2006........................................22
Reversing Relay Panel Assembly for 208-240 Volts for Models Mfd. as of February 10, 2006...............23
Reversing Relay Panel Assembly for 380-416 Volts for Models Mfd. as of March 2, 2006 .....................24
Reversing Relay Panel Assembly for 460-480 Volts for Models Mfd. as of March 2, 2006 .....................25
Air Jet Assembly for Models Mfd. prior to April 2, 2004............................................................................26
Air Jet Assembly for Models Mfd. as of April 2, 2004 ...............................................................................27
Sail Switch Assembly ................................................................................................................................28
F.S.S. Temperature Probe Assembly........................................................................................................29
F.S.S. Solenoid Assembly for Models Mfd. prior to October 2, 2002 .......................................................30
F.S.S. Solenoid Assembly for Models Mfd. as of October 2, 2002...........................................................31
Exhaust Collar Assembly ..........................................................................................................................32
