ADC HIGAIN H2TU-R-402 LIST 7G Original operating instructions

THE H2TU-R-402 LIST 7G/LIST 7H
The H2TU-R-402 List 7G/List 7H (H2TU-R) functions as the remote end of a
repeaterless T1 transmission system when connected toa HiGain®, Wideband System
3190, or Soneplex®HDSL2 line unit (H2TU-C). The H2TU-R-402 List 7G is line
powered and the H2TU-R-402 List 7H is locally powered. Setting new standards for
interoperability and efficiency, HiGain HDSL2 modules transmit 1.544 Mbps T1
payload on one unconditioned copper pair over the full Carrier Service Area (CSA)
range.
FEATURES
SPECIFICATIONS
Front panel: status LEDs, craft port, DS1 monitor
jacks, and loopback control pushbuttons for test
access
Maintenance screens for inventory, provisioning,
performance monitoring, and troubleshooting,
including:
•Remote provisioning through TL1 FDL
commands
•Loop attenuation and insertion loss reporting
•HDSL2 Tip/Ring reversal indication
•Power Back Off (PBON and PBOC) for
configuring HDSL2 transmit power to reduce
crosstalk
•Automatic circuit retrain to ensure quality
service
•Enhanced lightning protection
Operating Temperature -40°F to +149°F (-40°C to + 65°C)
Operating Humidity 5% to 95% non-condensing
Line Power Consumption 2.7 Watts
Electrical Protection Secondary surge and power cross-protection on
all DS1 and HDSL2 ports
Mounting Any 400 or 200 mechanics shelf
HDSL2 Line Rate 1.552 Mbps Overlapped Pulse amplitude
modulated Transmission with Interlocking
Spectra (OPTIS)
HDSL2 Output +16.5 dBm ±0.5 dBm, 135Ω
DS1 Pulse Output 0 dB, -7.5 dB, -15 dB
DS1 Receiver Sensitivity 0 dB to -36 dB at 100Ω
Maximum Insertion Loss 35 dB at 196 KHz, 135Ω
Maximum Loop Attenuation 28 dB
DS1 Line Rate 1.544 Mbps ±200 bps
DS1 Line Format Alternate Mark Inversion (AMI) or Bipolar with
8-zero Substitution (B8ZS)
DS1 Frame Format Extended SuperFrame (ESF), SuperFrame (SF),
or Unframed (UNFR)
INSTALLATION
1Align the H2TU-R with the enclosure slot guides and slide the unit in until it
touches the backplane card-edge connector.
2Place your thumbs on the H2TU-R front panel and push the unit into the
card-edge connector.
Continued
Wear an antistatic wrist strap when installing the H2TU-R.
Avoid touching components on the circuit board.
Remote enclosure
H2TU-R-402
H0260-A
!
H2TU-R-402 LIST 7G (LINE POWER)
H2TU-R-402 LIST 7H (LOCAL POWER)
REMOTE UNIT
QUICK INSTALLATION
FCC Class A Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Limited Warranty
Product warranty is determined by your service agreement. Contact your sales representative or Customer
Service for details.
Modifications
Any changes or modifications made to this device that are not expressly approved by ADC DSL Systems,
Inc. voids the user's warranty.
All wiring external to the products should follow the provisions of the current edition of the National
Electrical Code.
Standards Compliance
This equipment has been tested and verified to comply with the applicable sections of the following safety
standards:
❑GR 63-CORE - Network Equipment-Building System (NEBS) Requirements
❑GR 1089-CORE - Electromagnetic Compatibility and Electrical Safety
❑Binational standard, UL-60950/CSA C22.2 No. 60950-00 Third Edition: Safety of Information
Technology Equipment.
Trademark Information
ADC is a registered trademark of ADC Telecommunications, Inc. Other product names mentioned in this
installation guide are used for identification purposes only and may be trademarks or registered trademarks
of their respective companies.
Copyright Information
© 2003 ADC DSL Systems, Inc. All rights reserved. Information contained in this document is company
private to ADC DSL Systems, Inc., and shall not be modified, used, copied, reproduced or disclosed in
whole or in part without the written consent of ADC.
ADC DSL Systems, Inc.
14402 Franklin Avenue
Tustin, CA 92780-7013
Tel: [phone]
Fax: [phone]
Technical Assistance
Tel: [phone] x73223
Tel: [phone]
Fax: [phone]
Email: [e-mail]
´,W:¶8!¨
Product Catalogs: H2TU-R-L7G, H2TU-R-L7H
CLEIs: VAR1AATA, VAR110YA
Document: LTPH-QI-1222-01
1255268
HIGAIN
March 28, 2003
