UniPatch®Modular System
UniPatch

5/08 • 102117AE Broadcast and Entertainment Products
86
www.adc.com • [phone] • 1-800-366-3891
UniPatch®Modular System
Overview
The UniPatch® modular patching system with universal chassis allows you to combine data, audio,
and video patching modules in a single two-rack-unit modular panel. Order a mix of jack and backplane
modules to create a totally custom patching system, or order a preconfigured panel RS-422 data jacks.
You can start with only a few modules and add or change modules as needed. The universal chassis
with mix-and-match jack and backplane modules provides the ultimate in flexibility.
Modular Chassis for
Unprecedented Flexibility
Loaded UniPatch Chassis
Features
Jacks and backplanes have a modular design •
and t into the rugged high-density card cage
chassis. Just plug in a module to add more
jacks or backplane connectors
Modularity lets you start small and add •
modules and cards as needed
Individual circuits are easily replaced without •
disturbing other circuits
Backplanes available in high-density 64-circuit •
bantam audio, high-density 32-port data,
standard-density 24-port data, and video
options
Gold-plated card edge connectors tested to •
withstand heavy use and vibration
Shallow 7" deep chassis is perfect for •
mobile applications
Mix-and-Match
Plug-in Jack Modules
The following modules (details on following pages)
may be assembled on site in mix and match
combinations. Data and bantam modules may be
ordered in a fully loaded preconfigured chassis.
Features
Category 3 compliant RS-422 modules •
for demanding professional data patching
applications
Bantam audio modules in user-selectable •
normalled congurations
Video modules for analog, SD, HD, and •
analog component
AES 110 • W to 75 W coaxial baluns
BNC bulkhead feedthroughs•
Category 5, 5e and 6 data patching•
RS-422 Data Midsize Video Bantam Audio Video RGBS RGB Video
UniPatch

5/08 • 102117AE Broadcast and Entertainment Products
87
www.adc.com • [phone] • 1-800-366-3891
UniPatch®Modular System
Backplane Options (mix-and-match)
Ten different backplane connector types are available, and because they come in modular units, they
can be mixed and matched like the jack modules. Each backplane supports up to eight jack modules.
AMP 50-Pin Receptacle
Rear Module
(for data)
(VPRM-A50-W)
Dsub9, RS-422
Rear Module
(for data)
(VPRM-D9-W)
EDAC 90-Pin
Rear Module
(for data)
(VPRM-E90-W EDAC)
QCP MKII
Rear Module
(for data)
(VPRM-MKII-W)
Features
Available modules:•
Dsub9 connectors–
AMP Champ 50-pin receptacle–
EDAC 3-pin plug–
EDAC 90-pin plug–
QCP MKII for data 20x8–
QCP MKII for audio 12x8–
EDAC 3-pin
Rear Module
(for audio)
(VPRM-BAN-E3)
QCP MKII
Rear Module
(for audio)
(VPRM-BAN-MKII)
UniPatch

5/08 • 102117AE Broadcast and Entertainment Products
88
www.adc.com • [phone] • 1-800-366-3891
Unipatch Modular Systems
GigE Modules
Gigabit Ethernet Jack Module
LSA-PLUS® 8-Circuit Backplane Module
DM-GIGE
VPRM-GIGE-LSA
(rear view)
Features:
Dense pack patching •
Minimum of 30,000 patch cycles•
Normal-through patch by exception•
Modular design (can be removed without •
disturbing adjacent circuits)
Gold-plated contacts on switches and card •
edge connectors
Keyed opening for proper patch cord •
orientation
Features:
Patented LSA-PLUS• ® termination system
modules can be removed individually for
easier wiring
Number designation labels included•
Designation strip and window included for •
custom labeling
Designed for solid or stranded wire•
Eliminates the need for additional connectors •
and connector labor
Note: For complete configuration and ordering
information, please refer to Data Section.
UniPatch

5/08 • 102117AE Broadcast and Entertainment Products
89
www.adc.com • [phone] • 1-800-366-3891
UniPatch®Modular System
RS-422 Modules
The UniPatch® Category 3 compliant RS-422
module raises the standard in machine control
patching with its quality and robust design. Now
you can patch machine control data properly
using reliable, durable, military-grade jacks rated
for 30,000 insertion/withdrawal cycles. Each
circuit switches all ten pins, making the module
fully SMPTE 207M compliant. Compared to other
systems employing light-duty RJ45 connectors
rated at fewer than 500 insertion/withdrawal
cycles or bantam jacks that do not switch all
signal lines, the UniPatch RS-422 module is a
significant advance in machine control patching.
Features
The standard in professional data patching•
Durable military-grade switch system rated for 30,000 insertion/withdrawal cycles. Unlike RJ45 systems, •
suitable for heavy daily professional use.
Fully SMPTE 207M compliant circuits switch all ten pins, unlike bantam systems, which do not switch all •
ground pins, potentially causing problems
Tough military-grade, gold-plated switch with long cantilever beam springs and unique self-wiping contacts •
ensures against premature wear and provides positive contact force
RS-422 cards offer the highest density available. Up to 32 modules in two rack units for 33 percent •
greater density
Normalled or non-normalled cards available•
Modular termination options: Dsub9, DB-25, EDAC 90-pin plug, QCP II, Ultra Patch, standard-density, •
24 per frame, or Dsub9 high-density, 32 per frame (requires thin shell strain relief)
Keyed for proper patch cord orientation•
Category 3 compliant for 10 Base-T data•
UniPatch

5/08 • 102117AE Broadcast and Entertainment Products
90
www.adc.com • [phone] • 1-800-366-3891
UniPatch®Modular System
Bantam Audio Modules
The bantam audio jack modules for the
UniPatch® system are perfectly designed
for professional digital and analog audio
applications. Up to 32 modules plug into
the UniPatch chassis to provide a 64-circuit
(128 jacks) configuration when fully loaded,
matching typical router configurations. Each
module contains two circuits and four WECO-
standard precision bantam jacks designed for
long life. High-performance switches allow
flexible normalling and grounds for each circuit.
Large .440" x .325" designations provide
enough room for three lines of text.
Features
High-density, selectable normals, and excellent reliability•
33 percent higher density than conventional frame-type bantam bays. Up to 32 cards in a frame with •
2 circuits (4 jacks) per card for a total of 64 circuits (128 jacks)
32-across spacing exactly matches typical router congurations and provides larger designation area•
Switch-selectable normals and grounds for each circuit: normals strapped (NS), half-normal (HN), bussed •
ground (BG), or no normals (NN)
WECO-standard jacks meet or exceed MIL-STD-202 for mechanical durability as well as corrosion, salt spray, •
thermal shock, moisture resistance, and vibration
Precision-molded housing and sturdy, integrated all metal springs rated for 10,000 insertion/withdrawal •
cycles. Gold crossbar, self-cleaning contacts ensure a positive connection
Modular termination options: QCP II, EDAC 3-pin plug, EDAC 90-pin plug, DB-25, AMP Champ 50-pin •
receptacle, or QCP IV with 4-foot umbilical Ultra Patch panel
Snap-on designation holders accept individual labels without tools; conventional chassis-wide designation •
strips are also available. Large designations provide enough room for three lines of text
Fully compliant 110 • W circuit board meets demanding AES specications
Two circuits per card
Precision Impedance Matched DIP Switch
UniPatch

5/08 • 102117AE Broadcast and Entertainment Products
91
www.adc.com • [phone] • 1-800-366-3891
UniPatch®Modular System
Video Modules
RGBHV Video Module
(VM-RGBHV-MVJ-BK)
ADC offers a full line of UniPatch® video patching
modules, making it easy to assemble a custom
video patch panel for any application. Modules
are available for analog, SD, HD, or component
video. Included in the selection of jacks are
the standard size SVJ, midsize MVJ, and MUSA
SMJ-series HD jacks for outstanding performance
at high-definition data rates and beyond.
Standard Size Video Module
also available with CJ2020N75
terminated single jacks
(VM-2014-BK)
RGB, PrPBY HD Video Module
(VM-RGB-MVJ-BK)
Standard Size HD Video Module
(VM-SVJ-BK)
Midsize HD Video Module
(VM-MVJ-BK)
Features
Standard jacks mount 24 across, midsize jacks •
mount 32 across
Standard-size, HD video modules contain •
SVJ-2 normalled-through Super Video Jacks
with or without termination
Standard size straight-through modules •
contain CJ2014N jacks without termination or
CJ2020N-75 jacks with termination
Midsize HD video modules contain MVJ-3 •
normalled-through Super Video Jacks with
or without termination
Midsize straight-through modules contain •
CJ3014/4014 jacks without termination or
CJ3014N-75/4014N-75 jacks with termination
MUSA modules contain SMJ-2100 HD-rated •
MUSA standard jacks.
Modules are available for analog component •
video in the following congurations: RGB,
PrPBY, RGBS, and RGBHV
Large designations snap on without tools •
providing enough space for four rows of text
All modules provided with colored inserts to allow the user to customize for any use.
UniPatch

5/08 • 102117AE Broadcast and Entertainment Products
92
www.adc.com • [phone] • 1-800-366-3891
UniPatch®Modular System
AES Balun Modules
The patented AES 110 W to 75 W balun modules
provide precision impedance matching for
interfacing balanced twisted pair AES audio to
unbalanced coaxial audio. Eliminate the nuisance
of XLR soldering and the mess of baluns hanging
from equipment. Replace them with this clean,
simple solution.
UniPatch System fully loaded with 16 AES balun modules for 64 110-75 Wcircuits
(allows modules to be mounted either way)
For in-line baluns, see page 75
Features
Mounts on side of equipment rack with velcro •
or can be rack mounted
Modules contain four circuits for up to 64 •
circuits per 2 RU chassis
Works with quick-to-install QCP punchdown •
termination modules or EDAC 3-pin plug
1 Vp-p plug-in pad is available for equipment •
that cannot accept high-input voltages.
Plug-in pad feature allows each circuit to
be tailored for 1 Vp-p operation in 1dB
increments to -20dB
New splitter module provides 2-in/4-out •
passive split/110 W to 75 W converter
AES 110 Wto 75 WConverter
(AM-411075-E3-FF)
(front view) (rear view)
AES 110 Wto
75 WConverter
(AM-411075-MKII)
AES 2:4 Splitter
(AM-2110-475-E3)
Precision Transformers,
Glass Epoxy Circuit Board,
True 75 WBNC Connectors
UniPatch

5/08 • 102117AE Broadcast and Entertainment Products
93
www.adc.com • [phone] • 1-800-366-3891
UniPatch®Modular System
Ordering Information
Description Catalog Number
Empty Chassis
Empty UniPatch® chassis, black, supplied with VP-DES-343-32 kit VP2232-BK
Empty UniPatch chassis, gray, supplied with VP-DES-343-32 kit VP2232-G
Bantam Audio Fully Loaded Chassis
64-circuit loaded system QCP II, black* VP2232-BANQCP-BK
64-circuit loaded system EDAC 3-pin plug, black* VP2232-BANE3-BK
RS-422 Data Fully Loaded Chassis - normalled**
24-circuit Dsub9 normalled, gray, no backshell kits VP2224-D9-G
24-circuit Dsub9 normalled, black, no backshell kits VP2224-D9-BK
32-circuit Dsub9 normalled, gray, no backshell kits VP2232-D9-G
32-circuit Dsub9 normalled, black, no backshell kits VP2232-D9-BK
32-circuit Dsub9 normalled, black, with backshell kits VP2232-D9-BK-S
32-circuit Dsub9 normalled, gray, with backshell kits VP2232-D9-G-S
RS-422 Data Fully Loaded Systems - non-normalled**
24-circuit Dsub9 non-normalled, black, no backshell kits VP2224-NND9-BK
32-circuit Dsub9 non-normalled, black, no backshell kits VP2232-NND9-BK
32-circuit Dsub9 non-normalled, gray, no backshell kits VP2232-NND9-G
* Normal congurations on bantam audio cards to be set by user.
32-circuit Dsub9 systems require the use of a thin backshell kit.
** The thin backshell Dsub9 provides strain relief for standard
Dsub9 connectors. This shell kit is highly recommended
on 32-circuit UniPatch RS-422 systems and is included
where indicated.
The backshell kits are found on page 95.
Dsub9 Thin Backshell Kit
(Does not include Dsub9 connec-
tor, included wtih -S only.)
Ordering Information
Description Catalog Number
Traditional RS-422 Patch Panels
RS-422 2x12 non-normalled RJ45, black PEM-9NCDA1-BK-NN
RS-422 2x24 dual bantam to Dsub9 normalled PPB3-5R422D9NS
RS-422 2x12 dual bantam to Dsub9 normalled PPB3-5R422D9NS-12
UniPatch

5/08 • 102117AE Broadcast and Entertainment Products
94
www.adc.com • [phone] • 1-800-366-3891
UniPatch®Modular System
Ordering Information
Description
Required
Chassis Space Catalog Number
AES Balun Modules
AES 110 W to 75 W, 4-circuit BNC to QCP II 2 spaces AM-411075-MKII
AES 110 W to 75 W, 4-circuit BNC to EDAC 3-pin plug 2 spaces AM-411075-E3
AES 110 W to 75 W, 4-circuit BNC to EDAC 3-pin plug, front facing 2 spaces AM-411075-E3-FF
2:4 splitter balun module 110 W to 75 W2 spaces AM-2110-475-E3
Plug-in pad (replace “XX" with 01 to -20db) qty: 25 each - SCAP-XX
Audio Modules
Bantam audio, adjustable normals, 2-circuit (4 jacks), black 1 space AM-BAN-BK
Data Modules
2-port GigE normalling jack module: PCB with green masking 1 space DM-GIGE
2-port GigE non-normalling jack module: PCB with black masking 1 space DM-GIGE-NN
RS-422 data, 10-pin, normals through, black 1 space DM-422-BK
RS-422 data, 10-pin, normals through, gray 1 space DM-422-G
RS-422 data, 10-pin, non-normalled, black 1 space DM-422-NN-BK
RS-422 data, 10-pin, non-normalled, gray 1 space DM-422-NN-G
Ethernet data, Cat 5 RJ-RJ non normalled coupler, black 1 space DM-RJC5-BK
Ethernet data, blank adapter, black 1 space DM-6S-BK
Universal Blank Modules
Blank module, black 4 spaces DM-BLANK-BK
Blank module, gray 4 spaces DM-BLANK-G
Video Modules†
Standard, CJ2020N-75 terminated single, 3-circuit, black 4 spaces VM-2020-BK
Standard, Super Video Jack SVJ-2, 3-circuit, black 4 spaces VM-SVJ-BK
Standard, Super Video Jack SVJ-2T, terminated, 3-circuit, black 4 spaces VM-SVJT-BK
Midsize, Super Video Jack MVJ-3, 4-circuit, black 4 spaces VM-MVJ-BK
Midsize, Super Video Jack MVJ-3T, 4-circuit, terminated, black 4 spaces VM-MVJT-BK
Midsize, Super Video Jack MVJ-3, 4-circuit, gray 4 spaces VM-MVJ-G
Midsize, Super Video Jack MVJ-3T, 4-circuit, terminated, gray 4 spaces VM-MVJT-G
Midsize, MVJ-3, RGB+HV, black 4 spaces VM-RGBHV-MVJ-BK
Midsize, MVJ-3T, RGB+HV, terminated, black 4 spaces VM-RGBHV-MVJT-BK
Midsize, MVJ-3, RGB, PrPBY HD module, black 4 spaces VM-RGB-MVJ-BK
Midsize, MVJ-3T, RGB, PrPBY HD module, terminated, black 4 spaces VM-RGB-MVJT-BK
Midsize, CJ3014/4014N, 4-circuit, black 4 spaces VM-CJMID2-BK
Midsize, CJ3014/4014N-75, 4-circuit, terminated, black 4 spaces VM-CJMIDT2-BK
Midsize, CJ3014/4014N-75, 4-circuit, terminated, gray 4 spaces VM-CJMIDT2-G
Note: Conventional XLR baluns listed on page 76.
†Video circuits are supplied with designations and circuit indications.
Ordering information continues on next page.
UniPatch

5/08 • 102117AE Broadcast and Entertainment Products
95
www.adc.com • [phone] • 1-800-366-3891
UniPatch®Modular System
Ordering Information
Description Catalog Number
Rear Modules for Audio and Data Applications
Audio QCP II, 8-circuit for bantam audio applications VPRM-BAN-MKII
Audio EDAC 3-pin plug, 8-circuit for audio applications VPRM-BAN-E3
DB-9, 32-circuit Ultra Patch, 3-foot umbilical, white, for audio applications VPRM-3DB9-W
Universal AMP 50-pin receptacle, 8-circuit, RS-422, white VPRM-A50-W
Gigabit Ethernet LSA-PLUS® 8-circuit backplane module VPRM-GIGE-LSA
Universal DB-9, 8-circuit, RS-422, white, for data applications VPRM-D9-W
Universal EDAC 90-pin plug, 8-circuit, RS-422, white VPRM-E90-W
Universal QCP II, 8x10 circuit, white, for data applications VPRM-MKII-W
Ordering Information
Description Catalog Number
Accessories
Dsub9 thin backshell connector kit, 1 count DB9-TSHELL1-KIT
Dsub9 thin backshell connector kit, 16 count DB9-TSHELL16-KIT
Dsub9 thin backshell connector kit, 64 count DB9-TSHELL64-KIT
Patch cord kit with two RS-422 ends, 10-pin black, no cable PC-422-KIT
Bantam audio module extraction tool VP-BAN-TOOL
Rear cable management kit (mounts in rear rack rails), black PPI-EXT-BAR-BK
Rear cable management kit (mounts in rear rack rails), gray PPI-EXT-BAR-G
Replacement Designation Strip Kits*
Kit of 2 pieces, 17" x .640" full-length designation strips
(includes window and mounting screws)
VP-DES-680-32
Kit of 128 windows, .440" x .343" designation windows for bantam modules VP-DES-BAN
Kit of 16 windows, 2.01" x .343" designation windows for video modules VP-DES-VIDEO
Kit of 4 pieces, 4.174" x .289" designation strips for bantam, video or data modules
(includes windows and mounting screws)
VP-DES-343-4
Kit of 2 pieces, 17" x .289" designation strips for loaded bantam or data chassis
(includes windows and mounting screws. Order two kits for loaded bantam systems)
VP-DES-343-32
* See UniPatch® Installation Guide ADCP-75-009 for additional information on selecting the correct designation
kit for your UniPatch system. Designations are supplied with chassis and system congurations; kits are for
replacement only
UniPatch

5/08 • 102117AE Broadcast and Entertainment Products
96
www.adc.com • [phone] • 1-800-366-3891
UniPatch®Modular System
Ordering Information
UniPatch Data Patch Cord
Description Catalog Number
Gigabit Ethernet and RS422 Cat 6 Patch Cords
0.6 m (2 ft) PC-GIGE-2
0.9 m (3 ft) PC-GIGE-3
1.2 m (4 ft) PC-GIGE-4
1.8 m (6 ft) PC-GIGE-6
UniPatch®Data Patch Cords
UniPatch RS-422 10-pin black 2' PC-422-2BK
UniPatch RS-422 10-pin black 3' PC-422-3BK
UniPatch RS-422 10-pin black 4' PC-422-4BK
UniPatch RS-422 10-pin black 6' PC-422-6BK
UniPatch RS-422 10-pin to RJ45, black 2' PC-422-RJ45-2BK
UniPatch RS-422 10-pin to RJ45, black 3' PC-422-RJ45-3BK
UniPatch RS-422 10-pin to RJ45, black 4' PC-422-RJ45-4BK
UniPatch RS-422 10-pin to RJ45, black 6' PC-422-RJ45-6BK
Traditional Data Patch Cords
RJ45-RJ45 1', blue TP5ETA-BL01
RJ45-RJ45 2', blue TP5ETA-BL02
RJ45-RJ45 3', blue TP5ETA-BL03
RJ45-RJ45 4', blue TP5ETA-BL04
Dual bantam to single RJ45, 72" PAT-100904
Dual bantam to dual RJ45, 72" PAT-100900-006
UniPatch
