ADC HiGain HXU-358 User manual

HiGain
HiGain
HXU-358 V1.04 MULTIPLEXER UNIT
PRODUCT CATALOG: HXU-358 V1.04
PART NUMBER: 1154681
CLEI: VAPHCDDD
TECHNICAL PRACTICE

LTPH-TP-1044-01, Issue 1
ii April 6, 2001 HXU-358 V1.04
Revision History of This Practice
Copyright
April 6, 2001
© 2001 ADC DSL Systems, Inc. All rights reserved.
Trademark Information
ADC and Soneplex are registered trademarks of ADC Telecommunications, Inc.
HiGain is a registered trademark of PairGain Technologies, Inc. No right, license, or
interest to such trademarks is granted hereunder, and you agree that no such right,
license, or interest shall be asserted by you with respect to such trademark.
Other product names mentioned in this practice are used for identification purposes
only and may be trademarks or registered trademarks of their respective companies.
Disclaimer of Liability
Information contained in this document is company private to ADC DSL Systems,Inc.,
and shall not be modified, used, copied, reproduced or disclosed in whole or in part
without the written consent of ADC.
Contents herein are current as of the date of publication. ADC reserves the right to
change the contents without prior notice. In no event shall ADC be liable for any
damages resulting from loss of data, loss of use, or loss of profits, and ADC further
disclaims any and all liability for indirect, incidental, special, consequential or other
similar damages. This disclaimer of liability applies to all products, publications and
services during and after the warranty period.
Issue Release Date Revisions Made
1April 6, 2001 Initial release.

LTPH-TP-1044-01, Issue 1 Using This Technical Practice
HXU-358 V1.04 April 6, 2001 iii
USING THIS TECHNICAL PRACTICE
Identified by icons, three types of messages appear in the text:
For a list of abbreviations used in this document, refer to “Appendix D -
Service and Support” on page 59.
UNPACK AND INSPECT YOUR SHIPMENT
Upon receipt of the equipment:
1Unpack the container and inspect the product for signs of damage. If the
equipment has been damaged in transit, immediately report the extent of
the damage to the transportation company and to your sales
representative. When storing the equipment for a prolonged period, use
the original container.
2Verify the contents using the packing list to ensure complete and
accurate shipment.
Notes contain information about special circumstances.
Caution symbols indicate the possibility of personal injury or
equipment damage.
The Electrostatic Discharge (ESD) symbol indicates that a
deviceorassemblyissusceptibletodamagefromelectrostatic
discharge.

Unpack and Inspect Your Shipment LTPH-TP-1044-01, Issue 1
iv April 6, 2001 HXU-358 V1.04

LTPH-TP-1044-01, Issue 1 Table of Contents
HXU-358 V1.04 April 6, 2001 v
TABLE OF CONTENTS
Overview _______________________________________________ 1
Features.................................................................................... 1
Compatibility ........................................................................... 2
Application...............................................................................3
Front Panel...............................................................................4
HXU-358 Installation for Wideband 3190 or ACE Systems _____ 6
Provisioning ____________________________________________ 9
Accessing the Management Interface...................................... 9
Logging On To the System through the HMU........ 10
Selecting a Shelf...................................................... 11
Configuring the HMU to Access the HXU-358...... 11
Accessing HXU-358................................................ 12
Setting Date and Time (For ACE Chassis Installation only). 16
Entering System Name .......................................................... 17
Configuring the DS3 Port ......................................................18
Configuring the T1/E1 Ports..................................................20
Changing T1 to E1 Configurations for the Wideband
3190 or ACE Chassis ....................................... 22
Other Configuration Options ................................................. 23
Changing the Password ...........................................24
Download Software Updates................................... 25
Cross Connecting..................................................... 26
Restoring Defaults................................................... 28
Setting Autologout Time......................................... 29
Editing Circuit IDs .................................................. 30
Performance Monitoring_________________________________ 31
Monitor Menu........................................................................ 31

Table of Contents LTPH-TP-1044-01, Issue 1
vi April 6, 2001 HXU-358 V1.04
History Menu..........................................................................36
Performance Monitoring History.............................37
Alarms......................................................................39
Event Log.................................................................41
Testing_________________________________________________42
Executing a Loopback............................................................42
Test Access Interface..............................................................45
Accessing the Test Head..........................................45
Protection Switching ..............................................................50
Appendix A - Specifications _______________________________51
Appendix B - HXU-358 Installation for ACE Chassis __________53
Appendix C - Technical Reference__________________________56
Time-slot Assignment Switch (TSA).....................................57
M13 Multiplexer.....................................................................57
Appendix D - Service and Support__________________________59
Technical Support...................................................................59
Returns....................................................................................59
Appendix E - Abbreviations _______________________________62
Certification and Warranty _________________Inside Back Cover

LTPH-TP-1044-01, Issue 1 List of Figures
HXU-358 V1.04 April 6, 2001 vii
LIST OF FIGURES
1. System Overview.................................................................................. 3
2. HXU-358 V1.04 Front Panel................................................................ 4
3. HXU-358 Installed in a Wideband 3190.............................................. 5
4. Installing an HXU-358 Multiplexer Card.............................................7
5. Management Interface........................................................................ 10
6. HXU-358 Main Menu ........................................................................ 12
7. HXU-358 Menu Tree ......................................................................... 13
8. Main Menu: T1/E1 Port Status........................................................... 14
9. Config Menu: Date and Time............................................................. 16
10. Config Menu: Card ID........................................................................ 17
11. Config Menu: DS3 Port...................................................................... 18
12. Config Menu: T1/E1 Ports ................................................................. 20
13. Config Menu: Password ..................................................................... 24
14. Config Menu: SW Download............................................................. 25
15. Config Menu: X-Connect................................................................... 26
16. Config Menu: Restore Defaults.......................................................... 28
17. Config Menu: Autologout Defaults.................................................... 29
18. Config Menu: Autologout Defaults.................................................... 30
19. Monitor Menu..................................................................................... 31
20. Monitor Menu: Active Alarms........................................................... 33
21. Monitor Menu: Clear TMS Count......................................................35
22. History Menu: PM History................................................................. 36
23. History Menu: PM History for a T1/E1 Port......................................37
24. History Menu: PM History for DS3 Port ...........................................38
25. History Menu: T1/E1 Port Alarm History.......................................... 39
26. History Menu: DS3 Alarm History .................................................... 40

List of Figures LTPH-TP-1044-01, Issue 1
viii April 6, 2001 HXU-358 V1.04
27. History Menu: Event Log ...................................................................41
28. Test Menu: T1/E1 Loopback ..............................................................42
29. System Loopbacks in Wideband 3190 Applications ..........................43
30. Internal Test Head...............................................................................46
31. Breaking Type Internal Test ...............................................................47
32. Monitor Type External Test................................................................49
33. Test Menu: Protection Switch.............................................................50
34. HXU-358 V1.04 Craft Port (Front View)...........................................53
35. ACE Craft Port (Rear View)...............................................................55
36. Simplified Block Diagram..................................................................56
37. Basic M13 Multiplexer .......................................................................58

LTPH-TP-1044-01, Issue 1 List of Tables
HXU-358 V1.04 April 6, 2001 ix
LIST OF TABLES
1. HXU-358 V1.04 Front Panel Description............................................ 4
2. HXU-358 Main Menu Options........................................................... 15
3. HXU-358 DS3 Service Modes........................................................... 19
4. HXU-358 T1/E1 Service Modes........................................................ 21
5. T1/E1 and DS3 Error Definitions....................................................... 32
6. Alarm Descriptions............................................................................. 34
7. Event Log Descriptions...................................................................... 41
8. System Loopback Definitions ........................................................... 44

List of Tables LTPH-TP-1044-01, Issue 1
x April 6, 2001 HXU-358 V1.04

LTPH-TP-1044-01, Issue 1 Overview
HXU-358 V1.04 April 6, 2001 1
OVERVIEW
The HiGain®Multiplexer Unit, HXU-358 V1.04, is the multiplexing
component of the Soneplex®Wideband 3190 system. It can also be installed
in the HiGain Access Concentrator Express (ACE) chassis, a single-rack
enclosure (see “Appendix B - HXU-358 Installation for ACE Chassis”on
page 53 for more information). The HXU-358 multiplexes 28 DS1 lines into
a single Digital Signal, level 3 (DS3) interface at a signal rate of
44.736 Mbps.
The Wideband 3190 typically incorporates two HXU-358s, one board
functioning as the active board, the other as a standby. This redundancy
provides backup protection. In the event of a failure, the active relinquishes
control to the standby HXU-358 within 50 ms.
FEATURES
•Complete software provisioning
•Advanced management using Terminal Access Option (TAO) or
Transaction Language 1 (TL1) software through an HMU-319
•Advanced internal test head functionality for DS1/E1 line testing and
fault sectionalization
•Digital Acess Cross-connect (DACs) switching at the DS1/E1 level
•Software-selectable DS3 local and network loopback
•DS1 line code and loopback options
•Downloadable software
•Automatic and manual protection switching
•Password protection
•Internal and external diagnostics testing
•Dry contact alarm relay
•Office alarms (Major, Minor, Far-End, Critical)
•Front-panel status indicators
•Support for T1 and E1 line interfaces

Overview LTPH-TP-1044-01, Issue 1
2 April 6, 2001 HXU-358 V1.04
•Digital Access Cross-connect Switching (DACS)
•Front-panel test jacks for external test access as well as a backplane test
interface
•Front-panel RS-232 craft port for direct connection to a maintenance terminal
•Support for an external fail-safe alarm
COMPATIBILITY
The HXU-358 is compatible with Wideband 3190 (HMS-357 and HMS-358)
managed shelves as well as HiGain ACE chassis, single-rack enclosures.
If you are installing an HXU-358 in a Wideband 3190 or ACE
chassis that has a different multiplexer model, contact
Customer Service (see “Appendix D - Service and Support”
on page 59). Do not mix multiplexers in a system.
Do not mix multiplexers of differing software revision levels
unless specifically directed, doing so activates a software
mismatch alarm. This alarm indicates that software versions
are incompatible for long-term operation. Transfer of
configuration information is performed.

LTPH-TP-1044-01, Issue 1 Overview
HXU-358 V1.04 April 6, 2001 3
APPLICATION
The HXU-358 allows you to combine up to 28 T1 lines or up to 21 E1 line
into one high speed DS3 interface, thus providing a substantial cost savings
over transporting 28 individual HDSL/DS-1 lines through a carrier’s
network.
Figure 1. System Overview
PFMDF DS3
NID 28
NID 1 Wideband 3190
PBX
DSU/CSU
DACS 1/3
Office B
Office A Office C
DS1
HRE-420
HRE-420

Overview LTPH-TP-1044-01, Issue 1
4 April 6, 2001 HXU-358 V1.04
FRONT PANEL
Figure 2 shows the front panel of the HXU-358 multiplexer.
Figure 2. HXU-358 V1.04 Front Panel
Table 1. HXU-358 V1.04 Front Panel Description
Front-Panel Feature Function
Status LEDs
CR Critical alarm (red)
MJ Major alarm (red)
MN Minor alarm (yellow)
FE Far-End alarm (yellow)
PWR Power on (green)
LB Loopback operation (yellow)
FAULT Fault indication (red)
ABNORMAL Abnormal indication (yellow)
ACTIVE Active indication (green)
Craft port RS-232 connector for serial communications with a
maintenance terminal.
Test connector Provides a test access interface.
HXU-358 TEST
IN
RS232
L
FLT
ABN
ACT
CR
MJ
MN
FE
PWR
LB
OUT
Status LEDs Test connectorCraft port

LTPH-TP-1044-01, Issue 1 Overview
HXU-358 V1.04 April 6, 2001 5
Figure 3 displays the appearance of HXU-358s after they are installed in a
Wideband 3190 or ACE. (The designation of active and standby is not
determined by physical location.) For installation information see “HXU-358
Installation for Wideband 3190 or ACE Systems”on page 6.
Figure 3. HXU-358 Installed in a Wideband 3190
FLT (fault)
RS-232 port Test connector
ABN (abnormal)
Active multiplexer Standby multiplexer
ACT (active)
MJ (major alarm)
CR (critical alarm)
HXU-358
TEST
IN
RS232
L
FLT
ABN
ACT
CR
MJ
MN
FE
PWR
LB
OUT
LB (loopback)
PWR (power)
FE (far end alarm)
MN (minor alarm)
HXU-358 TEST
IN
RS232
L
FLT
ABN
ACT
CR
MJ
MN
FE
PWR
LB
OUT
HXU-358 TEST
IN
RS232
L
FLT
ABN
ACT
CR
MJ
MN
FE
PWR
LB
OUT

HXU-358 Installation for Wideband 3190 or ACE Systems LTPH-TP-1044-01, Issue 1
6 April 6, 2001 HXU-358 V1.04
HXU-358 INSTALLATION FOR
WIDEBAND 3190 OR ACE SYSTEMS
The following sections document HXU-358 installation procedures for
Wideband 3190 (HMS-357 and HMS-358) and ACE (ACE-Com, List 1)
systems.
Before installing the HXU-358,visually check itspackaging to
ensure that it has sustained no shipping damage.
Immediately report any damage to the shipping agent.
The HXU-358 multiplexer card can be damaged by
electrostatic discharge (ESD).
•Always wear an antistatic wrist strap connected to
equipment ground when handling the card.
(The Wideband 3190 provides an ESD strap input above
the HMU slot and on the chassis backplane.)
•When working with the HXU-358, place it on an electrically
grounded antistatic mat.
•Properly store in antistatic packing material any HXU-358
that is removed from the Wideband 3190.

LTPH-TP-1044-01, Issue 1 HXU-358 Installation for Wideband 3190 or ACE Systems
HXU-358 V1.04 April 6, 2001 7
Figure 4. Installing an HXU-358 Multiplexer Card
HXU-358 multiplexer cards are installed in the front of the Wideband 3190
or ACE chassis.
1Unscrew the two hold-down lugs on each side of the chassis front cover.
The cover folds down.
2Connect your ESD wrist strap to the ESD strap input above the HiGain
Management Unit (HMU) slot or above multiplexer slot A in the ACE.
An ESD touchplate is integrated on top of the card’s front panel for
added anti-static protection.
3Align the edges of the replacement card with the slot guides in the
multiplexer tray.
4Grasping the card eject tabs, gently push the card into the bay.
5Firmly press in on the tabs until the card snaps into place.
If you are installing an HXU-358 in a Wideband 3190 that has
a legacy multiplexer (HXU-357), contact Customer Service. A
mixed system is not allowed.
HXU-358 Wideband 319
0
ESD strap input
Card eject tab
HXU-358 TEST
IN
RS232 OUT
FLT
ABN
ACT
CR
MJ
MN
LB
PWR
FE
ESD touchplate

HXU-358 Installation for Wideband 3190 or ACE Systems LTPH-TP-1044-01, Issue 1
8 April 6, 2001 HXU-358 V1.04
When the card snaps into place, power is supplied to the unit and the
LEDs flash momentarily. The PWR LED and ACTIVE LED on the
active multiplexer remain illuminated. The LEDs on the inactive
(standby) multiplexer should be off, except for the PWR LED.
If you are replacing a HiGain Multiplexer Unit (HXU) in a
working system, the standby replacement HXU-358 is
automatically configured for that system by the active
HXU-358 in the shelf.

LTPH-TP-1044-01, Issue 1 Provisioning
HXU-358 V1.04 April 6, 2001 9
PROVISIONING
Using Terminal Access Option (TAO) management software, the HMU-319
configures and manages the HXU-358.
Refer to the Wideband 3190 installation guide and the technical practice for
the HMU-319 for complete information about connecting a maintenance
terminal.
For installation in ACE chassis, see “Appendix B - HXU-358 Installation for
ACE Chassis”on page 53.
Also, refer to your Central Office (CO) system plans for provisioning details.
ACCESSING THE MANAGEMENT INTERFACE
The HiGain Management Unit interface presents the user with an interactive,
text-based, menu-driven interface that configures, monitors, and controls a
Wideband 3190 and all the components that it comprises. By connecting a
local or remote maintenance terminal to the HMU-319, yougain access to the
craft port user interface which displays menus and prompts to guide you
through a provisioning process. This process involves:
•Logging On To the System through the HMU (see page 10)
•Selecting a Shelf (see page 11)
•Configuring the HMU to Access the HXU-358 (see page 11)
•Accessing HXU-358 (see page 12)
Figure 5 on page 10 shows the general structure of the TAO software. It
provides access to the HLU maintenance terminal screens and to the
HXU-358 software interface.
If you would likemore information about the HMU, refer to the
technical practice for the HMU-319 or the Provisioning
Reference section of the Wideband 3190 Installation Guide.

Provisioning LTPH-TP-1044-01, Issue 1
10 April 6, 2001 HXU-358 V1.04
Logging On To the System through the HMU
Figure 5 shows an overview of the Management Interface. Briefly review this
figure before logging on to the system.
Figure 5. Management Interface
Logon Screen
Alarm Management Screen
(enable/disable HLUs)
HXU-358 Menu
(multiplexer)
Line Unit
MaintenanceTerminal
Main Menu
(configure, monitor)
Local IP address
Subnet mask
Gateway IP address
Shelf ID
Mux type
Reset HMU
Ethernet connection
Change data and time
Fan monitoring
TAO timeout
Alarm promotion
Exit
Shelf Options Screen
Network Status Screen
(multishelf systems only)
Shelf Status Screen
Login to TL1
User ID: superuser
User password: public#1
Type TAO
View shelf status summary
Select shelf
View line units status summary
Select a line unit
Select Alarm Management
SSC Management
Select Mux
Select Shelf Options
Select Network Screen
Refresh Screen
Logout
Exit TAO
Monitor
History
Config
Test
Inventory
Quit
Help
TL1 orTAO Logoff
Main
Logon Screen
User publicpassword:
Type TAO or*
* Depending upon your configuration, the logon screen will be one of the two variable listed here.
Please refer to the HMU-319 technical practice for more information.
