ADC PG-Flex FLL-812 User manual

PWR
LOOP 1
LOOP 2
SYNC
SYNC
TEST
ALARM
MARGIN
MARGIN
FAULT
RS 232
FLL 812
LINE UNIT
LIST
Section SCP-FLL812-011-01H
PG-Flex
24 Channel Universal
Central Office Line Unit
Technical Practice
Model List CLEI Code
FLL-812 1A VACHDTNC~~

March 13, 2003 SCP-FLL812-011-01H
ADC Telecommunications, Inc. i
REVISION HISTORY
Copyright © 2003 ADC DSL Systems, Inc. All Rights Reserved.
ADC is a registered trademark of ADC Telecommunications, Inc. PG-Flex is a registered trademark of ADC DSL
Systems, Inc. No right, license, or interest to such trademarks is granted hereunder, and you agree that you shall
assert no such right, license, or interest with respect to such trademarks.
Other product names mentioned in this document are used for identification purposes only and may be trademarks
or registered trademarks of their respective companies.
Information contained in this document is company private to ADC DSL Systems, Inc., and shall not be modified,
used, copied, reproduced or disclosed in whole or in part without the written consent of ADC.
Contents herein are current as of the date of publication. ADC reserves the right to change specifications at any time
without notice. Information furnished by ADC is believed to be accurate and reliable. In no event shall ADC be liable
for any damages resulting from the loss of data, loss of use, or loss of profits and ADC further disclaims any and all
liability for indirect, incidental, special, consequential or other similar damages. This disclaimer of liability applies to
all products, publications and services during and after the warranty period.
Revision Release Date Revisions Made
01 March 13, 2003 Initial Release

SCP-FLL812-011-01H March 13, 2003
ii ADC Telecommunications, Inc.
USING THIS TECHNICAL PRACTICE
The following style conventions and terminology are used throughout this guide.
INSPECTINGYOUR SHIPMENT
Upon receipt of the equipment:
• Unpack each container and visually inspect the contents for signs of damage. If the equipment has been dam-
aged in transit, immediately report the extent of damage to the transportation company and to ADC. Order
replacement equipment, if necessary.
• Check the packing list to ensure complete and accurate shipment of each listed item. If the shipment is short or
irregular, contact ADC as described in Product Support on page 143. If you must store the equipment for a pro-
longed period, store the equipment in its original container.
Element Meaning
Bold font Text that you must input exactly as shown (e.g., type 1 for card 1), menu buttons
(e.g., ACCEPT SHELF OPTIONS) or menu screen options (e.g., ALARMS screen) that
you must select
Italic font Variables that you must determine before inputting the correct value (e.g., Password )
Monospace font References to screen prompts (e.g., Invalid Password...Try Again:.)
Reader Alert Meaning
Alerts you to supplementary information
!
IMPORTANT Alerts you to supplementary information that is essential to the completion of a task
ATTENTION
Alerts you to possible equipment damage from electrostatic discharge
CAUTION Alerts you to possible data loss, service-affecting procedures, or other similar type
problems
WARNING Alerts you that failure to take or avoid a specific action might result in hardware damage or
loss of service
DANGER Alerts you that failure to take or avoid a specific action might result in personal harm

Table of Contents
March 13, 2003 SCP-FLL812-011-01H
ADC Telecommunications, Inc. iii
Revision History ...................................................................................................................... i
Using this Technical Practice ..................................................................................................ii
InspectingYour Shipment .................................................................................................. ii
Overview ................................................................................................................................. 1
Description ........................................................................................................................ 1
Functions and Features .................................................................................................... 2
HDSL Transmission .......................................................................................................... 3
Sealing Current ................................................................................................................. 3
DISABLED ................................................................................................................... 3
ENABLED .................................................................................................................... 3
Subscriber Drop Testing .................................................................................................... 4
Specifications .......................................................................................................................... 5
Front Panel ............................................................................................................................. 6
Installation and Test ................................................................................................................ 9
Installation ......................................................................................................................... 9
Install a FLL-812 ................................................................................................................ 9
Initialize and Power Up the FLL-812 ................................................................................. 10
Administration ......................................................................................................................... 12
Front Panel Craft Port to Terminal Connections ............................................................... 12
Front Panel Craft Port to Modem Connections ................................................................. 13
Backplane Craft Port to Terminal Connections ................................................................. 14
Backplane Craft Port to Modem Connections ................................................................... 15
Navigational Methods ............................................................................................................. 17
Testing, Configuration, and Maintenance ............................................................................... 18
Menus and Display Structure ............................................................................................ 18
Log On Directly Through the FLL-812 ............................................................................... 19
Log On The FLL-812 Through the FPI-829 ...................................................................... 22
Main Menu Options ................................................................................................................. 26
MAIN — System Summary ............................................................................................... 27
MAIN — Logout ................................................................................................................. 30
Performance Menu Options .................................................................................................... 32
PERFORMANCE — HDSL Summary .............................................................................. 34
PERFORMANCE — HDSL 24 Hour History ..................................................................... 37
PERFORMANCE — HDSL 7 Day History ........................................................................ 40
PERFORMANCE — ISDN Summary ............................................................................... 42

SCP-FLL812-011-01H March 13, 2003
iv ADC Telecommunications, Inc.
PERFORMANCE — ISDN 7 Hour History ........................................................................ 44
Alarm Menu Options ............................................................................................................... 46
ALARMS — Alarms Summary .......................................................................................... 48
ALARMS — COLU System History .................................................................................. 51
ALARMS — RTLU System History ................................................................................... 54
ALARMS — HDSL History ................................................................................................ 57
ALARMS — ISDN History ................................................................................................. 60
ALARMS — CU History .................................................................................................... 64
ALARMS — COLU Faults ................................................................................................. 66
ALARMS — RTLU Faults .................................................................................................. 67
Configuration Menu Options ................................................................................................... 68
CONFIG — Password ....................................................................................................... 71
CONFIG — Date and Time ............................................................................................... 74
CONFIG — System Options ............................................................................................. 76
CONFIG — COLU System Alarm Type ............................................................................ 81
CONFIG — RTLU System Alarm Types ........................................................................... 85
CONFIG — HDSL Alarm Thresholds ................................................................................ 88
CONFIG — HDSL Alarm Types ........................................................................................ 91
CONFIG — ISDN Options ................................................................................................. 94
CONFIG — ISDN Alarm Thresholds ................................................................................. 97
CONFIG — ISDN Alarm Types ......................................................................................... 100
CONFIG — Channel Unit Alarm Types ............................................................................. 103
CONFIG — POTS Options ............................................................................................... 106
CONFIG — LS/GS Options ............................................................................................... 109
CONFIG — Set Factory Defaults ...................................................................................... 112
CONFIG — Channel Configuration ................................................................................... 114
Test Menu Options .................................................................................................................. 117
TEST — Subscriber Drop Test .......................................................................................... 119
TEST — Subscriber Bypass ............................................................................................. 122
TEST — Metallic Access ................................................................................................... 124
Information Menu Options ...................................................................................................... 129
INFO — LU Inventory ........................................................................................................ 130
INFO — COCU Inventory .................................................................................................. 131
INFO — RTCU Inventory .................................................................................................. 132
INFO — Doublers .............................................................................................................. 133
INFO — Common Cards ................................................................................................... 134
INFO — Help ..................................................................................................................... 135

March 13, 2003 SCP-FLL812-011-01H
ADC Telecommunications, Inc. v
Appendix A ............................................................................................................................. 139
Acronyms ................................................................................................................................ 141
Product Support ...................................................................................................................... 143
Technical Support ..............................................................................................................143
Limited Warranty ...............................................................................................................143
Returns .............................................................................................................................. 143
FCC Class A Compliance ....................................................................................................... 144
Modifications ..................................................................................................................... 144

SCP-FLL812-011-01H March 13, 2003
vi ADC Telecommunications, Inc.

List of Figures
March 13, 2003 SCP-FLL812-011-01H
ADC Telecommunications, Inc. vii
Figure 1. Typical PG-Flex Universal System with MLT Test Capability ................................ 2
Figure 2. FLL-812 Front Panel .............................................................................................. 6
Figure 3. Front Panel Craft Port to Terminal Connections .................................................... 12
Figure 4. Front Panel Craft Port to Modem Connections ..................................................... 13
Figure 5. Backplane Craft Port to Terminal Connections Using a Null Modem Cable ......... 14
Figure 6. Backplane Craft Port to Modem Connections ....................................................... 15
Figure 7. Terminal Menu and Display Structure .................................................................... 18

SCP-FLL812-011-01H March 13, 2003
viii ADC Telecommunications, Inc.

List of Tables
March 13, 2003 SCP-FLL812-011-01H
ADC Telecommunications, Inc. ix
Table 1. HDSL Distances ..................................................................................................... 3
Table 2. DC Resistive Signatures ........................................................................................ 4
Table 3. Specifications .........................................................................................................5
Table 4. FLL-812 Front Panel LEDs .................................................................................... 7
Table 5. FLL-812 Diagnostic Indicators ............................................................................... 8
Table 6. FLL-812 LED Status ............................................................................................... 11
Table 7. Craft Port Configuration .......................................................................................... 15
Table 8. Modem Settings ..................................................................................................... 16
Table 9. Navigational Keystrokes ......................................................................................... 17
Table 10. Main Menu Options ................................................................................................ 26
Table 11. System Status ........................................................................................................ 29
Table 12. Performance Menu Options ................................................................................... 33
Table 13. HDSL Summary ..................................................................................................... 36
Table 14. Alarm Menu Options .............................................................................................. 47
Table 15. Configuration Menu Options .................................................................................. 68
Table 16. System Options ...................................................................................................... 79
Table 17. Alarm Types Reported ........................................................................................... 83
Table 18. CO Alarms .............................................................................................................. 84
Table 19. RTLU Alarms .......................................................................................................... 87
Table 20. HDSL Alarm Thresholds ........................................................................................ 90
Table 21. HDSL Alarm Types ................................................................................................. 93
Table 22. ISDN Options ......................................................................................................... 96
Table 23. ISDN Alarm Thresholds ......................................................................................... 99
Table 24. ISDN Alarm Types .................................................................................................. 102
Table 25. Channel Unit Alarms .............................................................................................. 105
Table 26. POTS Options ........................................................................................................ 108
Table 27. Test Menu Options ................................................................................................. 118
Table 28. Metallic Access Menu Option Descriptions ............................................................ 128
Table 29. Information Menu Options ...................................................................................... 129
Table 30. Fault Isolation and Troubleshooting ....................................................................... 136

SCP-FLL812-011-01H March 13, 2003
xADC Telecommunications, Inc.

March 13, 2003 SCP-FLL812-011-01H
ADC Telecommunications, Inc. 1
OVERVIEW
The PG-Flex®FLL-812 List 1A 24 Channel Universal Central Office (CO) Line Unit is located in a PG-Flex Central
Office Terminal (COT) Shelf. The PG-Flex system uses High-bit-rate Digital Subscriber Line (HDSL) 2B1Q
technology to transport up to 24 DS0’s of Plain Old Telephone Service (POTS) and Integrated Services Digital
Network (ISDN) service between the FLL-812 and a PG-Flex FRL-842 Remote Terminal (RT) Line Unit. The RT Line
Unit can be line-powered from the COLU or locally powered.
DESCRIPTION
The universal system is comprised of a line unit and channel units at both the COT and RT (Figure 1 on page 2).
Line units and channel units can be hot-swapped without affecting other systems in the same shelf. The POTS
channel units support dial-up modem and group 3 facsimile on all channels.
The COT shelf supports up to four systems, where each system is comprised of one COLU and up to three Central
Office Channel Units (COCUs). The channel units must be the same type of card (POTS or ISDN) as the channel
units installed at the RT. A PG-Flex FPI-829 Pair Gain Test Controller (PGTC) Interface Unit (common to all systems
installed in the shelf) provides an interface for maintenance, alarm relays, and metallic access to the remote
subscriber lines.
RT enclosures support up to four systems, where each system is comprised of one RT Line Unit and up to three
PG-Flex Remote Terminal Channel Units (RTCUs). The channel units must be the same type of card (POTS or
ISDN) as the channel units installed at the COT. RT enclosures are designed for indoor and outdoor applications
and are provided with multiple mounting options.
The FLL-812, in combination with the FRL-842, eliminates the need for a metallic bypass pair for subscriber drop
testing by using a test head in the FRL-842. Results of subscriber drop tests are reported back to the central office
test equipment through the FPI-829 with three-terminal resistive signatures complying with TR-NWT-000909
specifications. The FLL-812 and FRL-842 can optionally be configured to support the metallic bypass pair instead of
using the test head..
If an FPI-729 is installed in the system, craft sessions must be initiated through the front of the FLL-812
because craft sessions with the FLL-812 are not supported through the FPI-729. However, if an FPI-829 is
installed in the system, you can log into the FLL-812 through the FPI-829.
The FLL-712 and FLL-812 COLUs can reside in the same COT shelf and function normally. FLL-812 alarm
reporting is compatible with the FPI-729; however, the FLL-812 critical alarms are mapped to the FPI-729
major alarms. The FLL-812 is not compatible with the FAU-728.
All references to a VT-100 terminal imply that a Personal Computer running VT-100 terminal emulation
software can also be used for accessing the COLU through the Management Unit.
!
IMPORTANT Please refer to Appendix A on page 139 to facilitate proper system configuration. The Feature
Matrix identifies the major features in the CO and RT line units. The Compatibility Matrix provides
CO and RT line unit compatibility information.

SCP-FLL812-011-01H March 13, 2003
2ADC Telecommunications, Inc.
Figure 1. Typical PG-Flex Universal System with MLT Test Capability
FUNCTIONS AND FEATURES
The FLL-812 provides the following functions and features for each 24-channel system in a single COT shelf:
• HDSL line transceivers and power supply
• Front panel status indicators
• Front panel craft terminal interface
• Downloadable software for product maintenance
• Eliminates the requirement for a metallic bypass pair (though supported when needed) for subscriber drop testing
If the FLL-812 is connected to an FRL-842 List 2, the power pairs (as shown in Figure 1) will not be needed
since the FRL-842 List 2 is locally powered.
PG-Flex
COT Shelf
Class 5
Switch
Doubler
Doubler
POTS
&
ISDN
HDSL
(2 pair per RT)
HDSL
(2 pair per RT)
MLT PGTC
VT-100 Terminal
FPI-829
HDSL
(2 pair per RT)
HDSL
(2 pair per RT)
Power
(2 pair per Doubler)
Power
(2 pair per Doubler)
Central
Office
Switch
FLC-706
FLC-706
FLC-703
FLC-703
FLC-703
FLC-703
FLL-812 FLL-812
PG-Flex
RT
FRC-753
FRC-753
FRC-756
FRL-842
PG-Flex
RT
POTS
&
ISDN
FRC-753
FRC-753
FRC-756
FRL-842
24 Tip-Ring
Cross-Connects
per System
24 Tip-Ring
Cross-Connects
per System
Office
Clock
Composite Clocks
(2 shielded pairs)
Not Required
for POTS)
28 Conductor
PGTC Cable
(optional)
(optional)

March 13, 2003 SCP-FLL812-011-01H
ADC Telecommunications, Inc. 3
HDSL TRANSMISSION
The FLL-812 card uses HDSL 2B1Q Technology to transport 24 DS0s plus an operations channel for management
control over two copper pairs. Adaptive equalization, scrambling, and a four-level 2B1Q line coding scheme are
used to maximize distance and minimize crosstalk.
The line interface is a two-pair, 784 Kbps full-duplex 2B1Q transmission format. The signal characteristics on the
carrier pairs comply with TR-NWT-001210, Generic Requirements for HDSL Systems.
Table 1 shows the maximum distance between the COT and the RT for various gauge wire with up to two doublers
in the circuit. Because of HDSL transmission technology, the HDSL pairs require no special conditioning and may
include unterminated bridge taps; however, they cannot include load coils.
Table 1. HDSL Distances
When the RT is powered from the COT, two auxillary power pairs are required between the COT and RT for each
doubler installed in the HDSL circuit. These power pairs should meet the same criteria as the HDSL pairs. Refer to
the COT Shelf and RT Enclosure technical practices for additional information on the power pairs. The RT can also
be locally powered to eliminate the need for auxiliary power pairs.
SEALING CURRENT
The FLL-812 provides line powering voltage even if the RT Line Unit is locally powered. In this configuration, the
locally powered RT Line Unit draws no current on the HDSL pairs. In order to allow the operating company to “wet”
the HDSL lines, the locally powered RT Line Unit provides a provisionable sealing current load circuit. This feature is
provisionable as ENABLED or DISABLED. The default is DISABLED. Refer to CONFIG — System Options section
for a description of provisioning the sealing current feature.
DISABLED
If a single span system is used, no current flows in the span between the RT and the COT. If doublers are used, no
current flows in the span between the last doubler and the RT. Current does flow in the spans between the CO and
doublers since the doublers are still line powered.
ENABLED
The Sealing Current load is automatically applied for a period of 15-20 seconds, once every 24 hours at the system
clock time of 00:05. A minimum of 20 mA is drawn through each conductor of HDSL (side 1 + side 2) during the time
the sealing current feature is active. The current flow is ramped at a rate less than 20 mA/second to meet industry
standard requirements for pulsed sealing current.
Gauge Wire
HDSL Distance (6 dB Margin / 35 dB Loss / 68°F) Analog Drop
(530 Ω)No Doubler 1 Doubler 2 Doublers
26 AWG (0.4 mm) 9.0 kft (2.8 km) 18.0 kft (5.6 km) 27.0 kft (8.4 km) 6.3 kft (1.9 km)
24 AWG (0.5 mm) 12.3 kft (3.8 km) 24.6 kft (7.6 km) 36.9 kft (11.4 km) 10.2 kft (3.1 km)
22 AWG (0.6 mm) 16.1 kft (5.0 km) 32.2 kft (10.0 km) 48.3 kft (15.0 km) 16.3 kft (5.0 km)
19 AWG (0.9 mm) 22.8 kft (7.0 km) 45.6 kft (14.0 km) 67.4 kft (21.0 km) 32.9 kft (10.0 km)

SCP-FLL812-011-01H March 13, 2003
4ADC Telecommunications, Inc.
SUBSCRIBER DROP TESTING
Test results on POTS subscriber drops can be displayed through a maintenance screen during a craft session or as
three-terminal resistive signatures (compliant with TR-909) reported back to the MLT system through the FPI-829.
Wire the PG-Flex COT Shelf to the FPI-829 per local procedure. Table 2 shows the signature resistances that are
presented to the CO test system for various line conditions.
Table 2. DC Resistive Signatures
Test Failure Condition TR (kΩ) TG, RG (kΩ)
RT Equipment Failure RT detected, but no response from RT 17.8 90.9
Foreign Voltage on Drop TG or RG > 10 Vrms
TG or RG > 6 Vdc
27.8 90.9
All Tests OK No failures detected 38.3 90.9
Ringer Test REN > 5.0 or
REN < 0.2
48.3 90.9
Resistive Fault on Drop TG, RG, or TR ≥150 kΩ58.0 90.9
Receiver Off-Hook Phone is off-hook 68.0 90.9
Hazardous Potential on
Drop
TG or RG > 50 Vrms
TG or RG > 135 Vdc
78.5 90.9
COTS/RT Facility Failure RT not detected ≥ 1,000 90.9
The resistive signatures on the FPI-829 List 3 are biased to -14 Vdc.
The resistive signatures shown in Table 2 are typical. Refer to the FPI-829 technical practice for specific
resistive signatures provided by the various models of the FPI-829.
The FLL-812 can be configured to use a metallic bypass pair for subscriber drop testing in cases when MLT
does not support TA-909 resistive signatures.

March 13, 2003 SCP-FLL812-011-01H
ADC Telecommunications, Inc. 5
SPECIFICATIONS
Table 3 lists the specifications for the FLL-812.
Table 3. Specifications
Category Item Value
Electrical Input Voltage -42.5 Vdc to -56.5 Vdc
Input Power 145 Watts (maximum)
Output Voltage ± 130 Vdc
Output Power 100 Watts (maximum)
Voltage Safety A2 compliant per GR-1089-CORE
Compliance NEBS SR-3580 Level 3
Human Safety UL-1950 for Restricted Access
Emissions Radiation and Immunity GR-1089-CORE for Class A equipment
HDSL Line Interface Two pair full duplex 2B1Q transmission format
Signal Characteristics TR-NWT-001210, Generic Requirements for
HDSL Systems
Environmental Elevation -200 ft. to 13,000 ft.
-60 m to 4,000 m
Temperature -40° F to +150° F
-40° C to +65° C
Humidity 5% to 95% (non-condensing)
Physical Height 5.5 in. (14.0 cm.)
Width 2.0 in. (5.1 cm.)
Depth 10.5 in. (26.7 cm.)
Weight 2.0 lbs. (0.9 kg.)

SCP-FLL812-011-01H March 13, 2003
6ADC Telecommunications, Inc.
FRONT PANEL
Figure 2 shows the FLL-812 front panel and Table 4 on page 7 lists the LEDs and LED status for the
FLL-812. Table 5 on page 8 lists the LED indications for the FLL-812 diagnostic and maintenance modes.
Figure 2. FLL-812 Front Panel
PWR
LOOP 1
LOOP 2
SYNC
SYNC
TEST
ALARM
MARGIN
MARGIN
FAULT
RS 232
FLL 812
LINE UNIT
LIST
Loop 1 Status
Loop 2 Status
Test Indicator
Alarm Indicator
Fault Indicator
RS-232 Maintenance Por
t

March 13, 2003 SCP-FLL812-011-01H
ADC Telecommunications, Inc. 7
Table 4. FLL-812 Front Panel LEDs
LED Color State Description
PWR Green On COLU power supply is normal
Flashing COLU is attempting to power-up the RT Line Unit or
Doubler Unit
Off COLU is not receiving power or internal fault
Loop 1 SYNC Green On Loop 1 is in synchronization between the COLU and
RT Line Unit or Doubler Unit
Flashing Loop 1 is attempting to synchronize with the RT
Line Unit or Doubler Unit
Off Active RT Line Unit or Doubler Unit is not detected
Loop 1 MARGIN Yellow On Loop 1 margin at the COLU is equal to or below the
provisioned threshold level
Flashing Loop 1 margin at the RT Line Unit or Doubler Unit is
equal to or below the provisioned threshold level
Off Loop 1 margin at the COLU and RT Line Unit or
Doubler Unit is above the provisioned threshold
level
Loop 2 SYNC Green On Loop 2 is in synchronization between the COLU and
RT Line Unit or Doubler Unit
Flashing Loop 2 is attempting to synchronize with the RT
Line Unit or Doubler Unit
Off Active RT Line Unit or Doubler Unit is not detected
Loop 2 MARGIN Yellow On Loop 2 margin at the COLU is equal to or below the
provisioned threshold level
Flashing Loop 2 margin at the RT Line Unit or Doubler Unit is
equal to or below the provisioned threshold level
Off Loop 2 margin at the COLU and RT Line Unit or
Doubler Unit is above the provisioned threshold
level
Test Yellow On Test active
Off Test not active
ALARM
(refer to Table 30 on page
136 for troubleshooting
details)
Red On COLU alarm condition exist
Flashing RT Line Unit alarm condition exist
Off No alarm conditions exist
FAULT
(refer to Table 30 on page
136 for troubleshooting
details)
Red On Fault in the COLU
Off No fault is detected

SCP-FLL812-011-01H March 13, 2003
8ADC Telecommunications, Inc.
Table 5. FLL-812 Diagnostic Indicators
LED State Description Action
PWR LED On,
All other LEDs Flashing
FLL-812 is running in Boot Mode Application software must be re-
installed. Contact Product Support
for additional information.
PWR LED On,
All other LEDs sequencing
downward
Software download to FLL-812 Wait for download to complete and
FLL-812 to re-start
PWR LED On,
All other LEDs sequencing
upward
Software download to the FRL-842
connected to FLL-812
Wait for download to complete and
FLL-812 to re-start
