ADDCOM ADD-20USB User manual

Operation
1. Adjustable headband for added comfort
2. Adjustable t-bar
3. Noise cancelling microphone
4. In-line receive volume control: Adjust the digital
receive volume control up or down
5. In-line microphone mute button: Push while
recording or speaking and the other party will no
longer hear your voice
6. Hook On/Off with LED indicator
7. Skype for Business/Microsoft Lync compatible USB
Cable
8. Adjustable microphone boom
Adjusting the Headband
Place the headset receiver to your ear and set the T-bar
above your other ear. Adjust the clickstop headband until
comfortable.
The ADD-20USB Headset may be worn on either ear. To switch
sides, simply rotate the microphone boom to the other side.
www.addcom.com MAN_ADD20USB_1016
ADD-20USB Lync Compatible Headset
Thank you for choosing the ADD-20USB Skype for Business/
Microsoft Lync Compatible Monaural Headset.
This user manual will help you in setting up, using and
maintaining your new headset and adapter cord.
Features
1. USB plug & play chip
2. Complete Digital sound card
3. Clear live voice transmission with VoIP
4. Digital in-line receive volume control
5. In-line microphone (Tx) MUTE with LED indicator
6. Hook On/Off with LED indicator
7. ON/OFF Control button with VoIP software (MS-Lync)
Installation
Connect the headset’s USB adapter to your computer’s USB
port for plug & play process. Installation is complete.
ADD-20USB Headset User Manual
1
2
7
4
8
5
6
3

www.addcom.com MAN_ADD20USB_1016
For troubleshooting and support please refer to
www.addcom.com
General USB troubleshooting
Most USB problems can generally be traced to one of the
following problems:
Problem
Computer stops responding, suggesting a malfunctioning or
incorrectly-configured device.
Solution
1. Check that the device is plugged directly into the computer
(root USB Hub) and not into a secondary hub (external USB
device). If the device is plugged into a secondary hub, unplug
the device from the hub and then plug the device directly into
the root hub.
2. If unsuccessful, restart your computer and try the headset again.
3. If unsuccessful, try connecting the headset to another computer.
If the headset works, it is a problem with your computer. If you
encounter the same issue on the new computer, contact your
supplier.
Problem
When USB connection is plugged in, the computer prompts for a
device driver.
Solution
Check with the manufacturer of the device or with your supplier to
determine if the necessary driver is available.
Problem
Device appears as a duplicate of a device in the Device
manager. The second device may be displayed with an
exclamation point in a yellow circle in device manager. You may
be unable to remove the “ghost” device until you unplug the
parent device.
Solution
Make certain that you have the most up-to-date firmware that
is available for both your computer’s BIOS and each individual
device.
Problem
Signal distortion on the headset is present. This may occur if you
plug a high-speed device into a low-speed cable.
Solution
Verify the entire USB chain is working correctly. Confirm that a
device that requires the ability to draw power from the hub is not
plugged into a non-powered hub. If the hub is a powered hub,
verify that the power supply for that hub is configured properly.
ADD-20USB Headset User Manual
