Addonics Technologies AAESP1235MK User manual

Installation:
1. Mount the Hybrid Port converter on a 3.5” drive bay.
2. To provide power, connect a 4-pin floppy power cable from the power
supply to the 4-pin floppy power connector on the converter.
3. Using a SATA data cable, connect one end to an onboard or add-in SATA
controller card to the SATA port of the Hybrid Port converter.
Note: For the Hybrid Port converter to support hot swapping, it needs to be
connected to an onboard or add-in SATA controller card that supports hot
swapping.
4. Connect one end of the USB 5-pin header cable to the motherboard and
the other end to the Hybrid Port converter.
T E C H N O L O G I E S
User Guide
12V Hybrid Port Converter
(AAESP1235MK)
(AAESP12SPCI)
5V
eSATAp
Hybrid eSATA
12V
4-pin Floppy
Power Connector
SATA Port
eSATAp Port
USB 5-pin Header
AAESP1235MK
Technical Support
If you need any assistance to get your unit functioning properly, please have your
product information ready and contact Addonics Technical Support at:
Hours: 8:30 am - 6:00 pm PST
Phone: [phone]
Email: http://www.addonics.com/support/query/
v3.1.11

Installation:
1. Mount the Hybrid Port converter on a SCSI1 or PCI.
For mounting the Hybrid Port converter on a PCI, screw the provided PCI bracket
to the SCSI1 bracket.
2. To provide power, connect a 4-pin floppy power cable from the power
supply to the 4-pin floppy power connector on the converter.
3. Using a SATA data cable, connect one end to an onboard or add-in SATA
controller card to the SATA port of the Hybrid Port converter.
Note: For the Hybrid Port converter to support hot swapping, it needs to be
connected to an onboard or add-in SATA controller card that supports hot
swapping.
4. Connect one end of the USB 5-pin header cable to the motherboard and
the other end to the Hybrid Port converter.
eSATAp
Hybrid eSATA
eSATAp
Hybrid eSATA
PCI Bracket
4-pin Floppy
Power Connector
SATA Port
eSATAp Port
Power LED
USB 5-pin Header
AAESP12SPCI
5V
12V
5V
12V
