Addonics Technologies ADSAIDE User manual

T E C H N O L O G I E S
User Guide
SATA - IDE Converter
(ADSAIDE)
Technical Support
If you need any assistance to get your unit functioning properly, please have your
product information ready and contact Addonics Technical Support at:
Hours: 8:30 am - 6:00 pm PST
Phone: [phone]
Email: http://www.addonics.com/support/query/
v4.1.11
Master, Slave & Cable
Select Jumpers
SATA Power and Data Connector
40-Pin IDE Connector
Pin 1 Marker
4-Pin Floppy Power Connector
Front View
Back View Jumper Settings
Master Slave Cable Select
Note:
To set the SATA hard drive as a Master
Device when connected to an IDE channel,
you need to short the top pins located on
the converter by placing a jumper. As a
Slave Device short the middle pins.

Installation:
1. Locate the SATA connector of your SATA drive.
2. Connect the converter board to the SATA connector of the hard drive.
3. Using the provided Y-power cable, connect the 4-pin Floppy connector to
the converter. This will provide power to the converter and to the hard
drive.
4. Connect the IDE ribbon cable to the 40-pin connector on the converter.
The red edge of the ribbon cable needs to line up to pin 1 marker of the
40-pin connector. The other end of the ribbon cable will be connected to
your motherboard’s IDE channel.
15-Pin SATA Power
& 7-pin Data Connector
