ADEC Technologies TDC3 F-F-31 Series User manual

Quick Reference Guide for
TDC3 & TDC4 Detector Installation
The following instructions must be closely followed to ensure optimal performance!
1. Detector Mounting Location
Detector in front of the gantry
Models: TDC3-X-F-F-31
Inclination +7°
Detector behind the gantry
Models: TDC3-X-F-B-45 / TDC3-2-B-B-XX
Inclination -7°
Important: Detector must have unobstructed view with all sensors!
oDetector model fits mounting location
oDetector is properly aligned and all sensors have unobstructed view onto the road
2. Wiring
Device Plug Pin Label Pin Device Receptacle
󰓊󰓋1 Supply, Vcc + 1
2 Trigger (optional) 2
3 GND 3
4 Sync 4
5 RS485 Signal A 5
6 RS485 Signal B 6
ADEC Technologies AG ●Gublenstrasse 1 ●CH-8733 Eschenbach SG ●Switzerland ●www.adec-technologies.ch 20.09_EN

Example: Section with 3 detectors
Outstation Detector 1
Master
Detector 2
Slave
Detector 3
Slave with
b
us
t
er
minat
or plug
oSupply voltage at all detectors is within permitted range of 10.5 – 30 V DC
oAll detectors wired according to wiring guidelines
3. Commissioning
oAll detectors successfully completed the auto-configuration process
4. Inspection & Verification
S/N of detector: Site ID:
oCommission process successfully completed according to above instructions
oVerified plausibility of traffic data (recommended)
Installed by: Date:
RS485
Vcc+
GND
RS485 A/B
Sync
Vcc+
GND
RS485 A/B
Sync
Vcc+
GND
ADEC Technologies AG ●Gublenstrasse 1 ●CH-8733 Eschenbach SG ●Switzerland ●www.adec-technologies.ch 20.09_EN
Vcc+
GND
RS485 A/B
Vcc+
GND
RS485 A/B
Vcc+
GND
RS485 A/B
Sync
Vcc+
GND
RS485 A/B
Sync
USB
