ADEMCO 4140XMPT2 User manual

VISTA
4V40XMPI!2
PARTITIONED SECURITY SYSTEM
WITH SCHEDULING
INSTALLATIONINSTRUCTIONS
E!m!EEl
4140XMPT2-INST S/93 (pat of N5944-2)
Addition of new 5800 series
transmitters with this control panel is
prohibited, other than for repair of
existing installations. Non-permitted
use voids U.S. warranty.

CONGRATU’TIONS!
On Your Purchase Of The Ademco 4140XMPT2 w
The purpose of these Installation Instructions is to give you acomplete
overview of the system, and provide instructions for installing abasic
system.
CONTACTING TECHNICAL SUPPORT
PLEASE,
Before you call Technical Support, be sure you:
cREAD THE INSTRUCTIONS!
cCheck all wiring connections.
cDetermine that the power supply and/or backup battery are
supplying proper voltages.
cVerify your programming information where applicable.
●Note the proper model number of this product, and the
version level (if known) along with any documentation that
came with the product.
QNote your ADEMCO customer number and/or company
name.
Having this information handy will make it easier for us to serve
you quickly and effectively.
You may contact Technical Support via Toll Free Fax. Please include your
return fax number. You will receive areply within 24 hours. You may also
contact Technical Support via modem to ATLIS-BBS, Tech Support’s
Electronic Bulletin Board System. Replies are posted within 24 hours.
East Coast Technical Support: 1-800-645-7492 (8 a.na.-6 p.m. E.S. T.)
West Coast Technical Support: 1-800-458-9469 (8 a.m.-5 p.m. P. S. T.)
Technical Support Fax Number: 1-800-447-5086
ATLIS-BBS Electronic Bulletin Board System: 1-516-496-3980
(1200 -9600 Baud, 8Data Bits, 1Start/Stop Bit, No Parity)
-2-

SUMMARY OF SYSTEM FEATURES ................,,,.......................................................................5
General Information.........................................................................................................5
System Features .............................................................................................................6
Programming Features .....................................................................................................7
Communication Features ..................................................................................................7
INTRODUCTIONTO THE PARTITIONED SYSTEM........................................................................8
Introduction ...................................................................................................................8
Bask Patitibning Features ...............................................................................................8
Examples ~Patiitioning ..................................................................................................9
Global Partitioning Featuresand Resources .........................................................................9
Partition Specific Features................................................................................................9
SCHEDULINGOVERVIEW......................................................................................................10
Ma@rFeatur~~Whduling ............................................................................................lO
AccessDoorControl ........................................................................................................10
Time-Driven Event Programming .......................................................................!..... ............10
End User Scheduling (#83 Menu Mode)................................................................................10
ZONE TYPES &APPLICABLE SENSORS ...................................................................................ll
BASIC9HARD-WIRED ZONES................................................................................................13
Zone l...........................................................................................................................l3
Zone 9...........................................................................................................................l3
Zones 2.8 .....................................................................................................................l4
2-WIRE POLLING LOOP EXPANSION (Zones 10through 87).........................................................l5
General ltiormation .........................................................................................................l5
Intercom lntederence ..............................m.......................................................................l5
Advisories .....................................................................................................................l5
lm~tiantl Fauh Annunciation ............................................................................................l6
timpatible Polli~Loop Devi@s........................................................................................l6
WIRELESS EXPANSION (Zones 1-63).......................................................................................l7
General information.........................................................................................................l7
4280Seties Raeiver .......................................................................................................l8
4281 Seties R~eiver .......................................................................................................18
5881 Seties Rweiver .......................................................................................................l 8
Transmitters ...................................................................................................................l9
Wireless Zone Types ........................................................................................................2O
Advisories .....................................................................................................................2O
Fault Annunciation ...........................................................................................................2O
Important Battery Notice ...................................................................................................2l
Compatible5700 Series Wireless Devices............................................................................2l
Compatible5800 Sefies Mreless Devices............................................................................22
VOLTAGETRIGGERS (tinnmor J7) .......................................................................................23
General information.........................................................................................................23
Ground &ad Mdule ........................................................................................................23
Remote Keyswitch ...........................................................................................................24
Remote Console Sounder Operation ....................................................................................25
0UTPUTCONTROL(4204RelayModule/X-10 Devices)................................................................26
General ltiormation .........................................................................................................26
4204 Relay Module..........................................................................................................26
4300 Transformer &X-10 Devices .......................................................................................26
Examples Of Uses For Relay s............................................................................................27
REMoTEwNsoLEs ............................................................................................................3o
General .........................................................................................................................3o
4137m .........................................................................................................................3o
5137AD.........................................................................................................................3o
6139 ...........................................................................................................................3o
Prqramming The tinsoles ...............................................................................................3l
Mounting ~etinwles ....................................................................................................3l
Wtingtinwles ..............................................................................................................3l
Poweting Additional Conales ............................................................................................3l
EXTERNALSOUNDERS .........................................................................................................32
Relay OutWt ..................................................................................................................32
UL Household Installations ................................................................................................32
Non.ULlnstallations ........................................................................................................32
timpatibie Sounders.......................................................................................................32
PHONEwNNEcToNs .........................................................................................................32 -3-

Mounting~eCabinet Lo& ...............................................................................................33
PrtmarylJower ................................................................................................................34
Ba&.Up Power...............................................................................................................34
Earth Ground Connections ................................................................................................34
Power-UpProcedu re........................................................................................................34
SEITING THE REAL-TIME CLOCK............................................................................................36
●
SECURITYACCESS CQDES ...................................................................................................37
General Information.........................................................................................................37
User Codes &Levels Of Authority .......................................................................................37
Multiple Partition Access Examples ....................................................................................39
To ADD aMaster, Manager or Operator code.........................................................................4O
To CHANGE aMaster, Manageror Operatorcode ..................................................................41
To Deletea Master, ManagerorOperator de ......................................................................4l
To EXIT The User Code Entry Mode.....................................................................................4l
KEYPADFUNCTIONS ............................................................................................................42
General information .........................................................................................................42
Arming Functions ............................................................................................................42
A=esstintrol ...............................................................................................................~
Delay closing window .......................................................................................................~
Pa~ition "Goto"timmands ...............................................................................................U
View Capabilities Of AUser ...............................................................................................43
Viewing Downloaded Messages ..........................................................................................~
Using The Buik.ln User's Manual ........................................................................................~
Displaying Descriptors .....................................................................................................44
Panic Keys ....................................................................................................................44
Trouble Conditions ...........................................................................................................~
"Ch=k Messages ..........................................................................................................U
OtherTrouble Conditions ..................................................................................................M
Power Failure ..................................................................................................................~
EvENTLmGING .....................................................D...........................................................45
~\
Event Logging Printer Connections .....................................................................................45
Event kgging Procedures................................................................................................46
Prqramming ..................................................................................................................46
Event Logging Display &Print Modes ..................................................................................46
Clear Event Log ..............................................................................................................47
Screen Definkions ...........................................................................................................47
DIRECT WIRE Downloading ................................................................................................48
Spli~ual Re~tiing .........................................................................................................49
AdemmbwSpd .........................................................................................................49
SescotiRadionics ...........................................................................................................49
&2 Re~tiing .................................................................................................................49
4+2 Express ...................................................................................................................50
Ademm High Speed RepfliW ...........................................................................................5O
Contact ID Reporting ........................................................................................................5l
U:ing Test Mode .............................................................................................................52
Armed System Test .........................................................................................................52
Turning The System OverTo~e User................................................................................53
DIP SWITCH TABLES .............................................................................................................56
suMMmYoFsYsTEMmMANDs ........................................................................................59
-4-

SUMMARY OF SYSTEM FEATURES
General Information
NOTE: At least one
5137AD or 6139
addressable alpha
display console must
be used with this
system.
The following table liststhe major features of the 4140XMPT2 system.
~ystem The 4140XMPT2 Control is amicroprocessor based,
programmable, partitioned system, and features EEROM
memoty technology (power bss does not result in the
bss of information).
?ones Supported ●Suppotts up to 9traditional wired zones of protection.
QExpandable to 87 zones (consisting of combinations of
wired and/or wireless zones) using 2-wire polling bop
devices, and/or 5700 or 5800 series wireless
transnltfers.
●Zones oan be distributed among up to 8bgioal partitions
of operation.
%e Zones ●Supports up to sixteen 2-wire smoke detectors (zone 1).
●Other zones can be fire zones using 4-wire smoke and
heat detectors and/or polling loop detectors.
3utput Control ●Supports up to 16 devices (4204 relay modules or X-1O
devices).
●These devices can be put under schedule mntrol.
Remote Consoles ●Supports up to sixteen addressable remote consoles
(6139, 5137AD, 4137AD).
Keyswitch Supports the Ademco 4146 keyswitch.
Programming ●Programming can be performed at the office prior to
installation, or on the job site directly from the console.
●Can be downloaded from aremote location or at the job
site (using aPC/laptop with 41OOSMSerial Module) by
using the Ademco 4130PC Downloading Software.
●The Control is pre-programmed with aset of standard
values that is designed to meet the needs of many
installations. These values, however, can be changed to
suitthe needs of any particular installation.
●The Control can also be pre-programmed by the installer
with one of four standard communication default
programming values, thus further saving time and effort.
User Codes Supports up to 128 user codes, maximum of 99 per
paftition
Panic Keys Provides 3panic key functions.
Communication Ademco low speed, SESCOA/RADIONICS, Ademco
Express, Ademco High Speed, Ademco Contact ID
Before Installing this partitioned system, become completely familiar
with the partitioning concepts, including zone distribution (each zone can be
assigned to only one partition), user code usage and authority levels, and the
user-friendly menu mode of programming. In addition, become familiar with the
scheduling and output relay features.
-5-

The following table lists the sDecialsystem features of the 4140XMPT2 svstem.
Global Arming
Polling Loop
Glass Break Detectol
Quick Bypass
(Forced 6ypaSS)
Memory-Of-Alarm
Circuit Breakers
Built-in Users Manua
Descriptors
Cabinet
Scheduling
Wireless
Event Logging
Access Control
●Allows users to easily arm multiple partitions via console
DromDts.
●Built-in polling loop interface, with polling loop terminals
located on the panel’s terminal block, allows expansion
up to 87 zones.
●Supports up to 50 latching type 2-wire glass break
detectors on zone 8.
●Quick (forced) bypass feature bypasses ailfaulted
zones with single key entry sequence.
●Memory-of-alarm feature, which, upon disarming the
system, automatically displays all zones that were in an
alarm condition while the systemwas armed.
“Self resetting cirwit breaker protection eliminates the
need to replace blown cartridge fuses.
●Built-in Users Manual (5137 AD/6139 onlv). Bv
depressing and holding any”of the function keys-on th~
console for 5seconds, abrief explanation of that
function scrolls across the alpha-numeric display.
●All programmed descriptors can be displayed (one at a
time) by pressing and holding the READY key for 5
seconds, then releasing the key. This serves as acheck
for installers to be sure all descriptors are entered
properly.
●Large cabinet with removable door for easier
installations.
●Scheduling feature allows installer and/or user to
automate system operation and/or turn on lights, etc.
●Auto-arm/disarm of system.
●Tempora~ schedules can be programmed by user.
●System operation can be restricted to cerlain times.
●Wireless suppoti of 5700 or 5800 series transmitters
using 4280, 4281 or 5881 type receivers.
●Event Logging feature keeps record of all events, which
can be printed automatically or on demand.
“Provides user activated access control command which
pulses arelay output for controlled opening of access
doors.
-4
-6-

. .. . . . . .. . .. . . . . .. . . .. ... .. . . .
Programming Poaturos
Communication
Features
.-
User Codes .Upto 128 user 8ecurity @e8 (maxt 99 per paftitbn) can
be programmed, each with varbu8 leve18of authorfty.
ln8taller Code ●Installer code override feature. Installer code will dbarm
system only if it was used to annthe system.
Alpha Descriptors ●Aii zones and partitions can be assigned alpha
descriptions.
●The ietter “s” or”’$” can be added to descriMors,
Custom Words I●Up to 20 custom words can be added to the built-in
vooabularv,
Comm. Fieids I●Easy programming for communication fieids, Simpiy
enter the reuml code for each zone.
Comm. Defauits ●Communication defauit programming can be ioaded
anytime, and does not affect non-communication
programfieids.
Downloading I●Direct wire downloading can be done without amodem,
by using aPC or Laptop computer and 41OOSMSeriai
Moduie.
#93 Menu Mode ●Easy programming of zones using the user friendiy #93
Menu Mode.
Scheduling Menus ●Easy scheduling programming using the #80 Menu
Mode.
The foiiowing tabie iists the communication features of the 4140XMPT2 system.
Zone Reports ●Aii 87 zones can report to acentrai station using any
reporting format.
Exception Reporting ●Open/close reporting by exception means reports occur
only if outside predetermined time windows.
Caiiback ●Caliback defeat option for downloading.
Reai-Time Cbck ●Reai-Time ciock for time reiated functions. NOTE:
5137AD or 6139 aipha consoie must be used to set the
reai-time ciock, or can be set using Downloader software.
AC Loss Reporting ●Random AC Loss and AC Restore reporting option
sends report randomiy from 10-40 minutes after AC ioss,
to heip prevent centrai stations from receiving an
overioad of reports due to area biackouts.
Test Reporting ●Inteiiigent test reporting option means test reports wili
not be sent if any other report was sent within the
programmed test repod intervai.
Spiit/Duai Reporting “SpliUDuaireporting communicator options avaiiabie.
Cancel Report ●Option to aliow acancei report to be sent, even after Beil
Time-out has ended.
Voitage Triggers ●Used to interface with LORRA or other devices.
●PC Downloader can command output voltage triggers to
puise on for 2seconds.
Phone Numbers ●Primary and secondary phone number capability.
“Can program different formats for each phone number.
UL NOTE: Downloading is not permissible for UL installations.
-7-

This section IS Intended to aivo vou an overview of ~artitlonlna conce~te. For speelfic questions on
programming or using spe;iflc ‘aspects of the pa~el, pleae~ refsr ‘to the SYSTEM ‘OPERATION
section of this msnual snd the PROGRAMMING GUIDE.
Introduction The partitioned system represents the latest in security protection technology.
Combining wired, wireless and polling loop zones into one powerful control, this
control communicator is capable of supporting atrue “partitioned” environment. A
partitioned environment is one whereby multiple unrelated users wish to be
protected by asecurity system, yet each user requires the operational freedom to
have the system behave as if it was theirs and theirs alone. This global definition
imtMiesalot of thinas in terms of the required features of the equipment you will
install. Some basic f;atures are listed below: . .
—.- .... . -,. -.-,., –-. ,.,-.. .– ... . . ..... ..—-------- -. .L– . . .A”, .m-l-- -.. _.-—
6asic Parmtionmg
Features Simple ●Easyto use and program asthe simplest alarm system,
Secure ●Integrity of security is not compromised for any users of
the svstem.
Reliable “Inherent reliability of the partitioned system is equal to a
stand alone alafi system-ifpurchased separately;
Consoies cFlexible number of consoles per partition (up to atotal of
16 in asystem, an~ay you want to assign’them).
●Appropriate sounds and messages to assigned
consoles only (each system appears to be independent
to users).
“Ability to inhibit other consoles from using your partition
(totalsecurity in astrip mall environment).
User Codes ●128 User Codes assigned virtually anyway you want
them (99 max. in any partition, otherwise no restrictions).
Enough to handle the largest commercial jobs.
●Multiple levels of authority per partition (allows key
people in apartition to have complete control and limit
system tampering by others).
Zones “87 zones employing wired, wireless or multiplex
technology (install any mix for any type of construction
challenges).
Partitions ●Any zone can be assigned to any particular partition
(easyto install,allows logical assgnment by the dealer).
●“GOTO function provides access to other partitions
(idealfor executive access to factory for example).
●Intelligent partition/zone menu programming help
(simplifies the programming and reduces errors)
●Programmable 4-character partition name displayed on
alpha consoles when needed (no need to memorize
numbers -name and number are shown for You).
-8-

Examnles Of In survevirm dealers throughout the countrv, we have learned of two global
Partitlonlng
Global Partltlonlng
Features and
Resources
Partition Speclflc
Features
applicatibn;for partitioned %ontrol panels. ‘One is atypical two family fiouse
(residential), the other aFactory/Office environment. These broad classifications
can better be understood by way of examples.
Two Family House: You’ve just arrived at ajob site to quote asecurity system.
The owner wants an alarm system which he can use for his family (living upstairs)
and he also wants to provide protection for the separate living quarters of his
mother (living downstairs with separate entrance). The owner obviously wants to
keep costs down yet provide protection and flexibility for his mother living
downstairs. You could choose to install atraditional alarm panel to keep costs
down, but the system woukf be very limiting for either the mother or the upstairs
family. To meet the flexibility requirements as desired, you could install two
traditional alarm panels, but the cost might cause you to lose the business. The
4140XMPT2 solves all these problems.
Factory/OffIce: You arrive at asmall manufacturing concern boking to provide
protection throughout their offices as well as their factory. The very nature of the
business is such that factory workers come to work at 7:30AM and leave at 4PM,
while the offices are open 8:30AM to 6:OOPM.Some executives even want to
stay late at nightor come back to work after 6:OOPM.Installingtwo panels (one for
the factory, one for the offices) would certainly work at acost premium, but think
of all the complexity when owners tried to gain access to the factory after
hours...two access codes to remember, accidental false alarms. Even the real
frustration of not being able to properly program the two systems to allow easy
access from the factory to office or vice versa! Install apartitioned system, your
programming problems are over, and the owners of the business will appreciate
its flexibility and ease of use!
In any system, cefiain physical system components and features are shared by all
partitions or assigned to aspecific partition. The following elements are shared or
assignable to aspecific artition:
Shared By All Partitions Assignable To One Partition
Dialer d
Alarm Relay/Sounder d#(using relay outputs)
Power Supply d
Wireless Keypad /
Keyswitch Station /
In addition to the physical devices which are shared, the system shares some
software features on a global basis aswell. These include:
Panic Code Reports .........................................Comnm code for any partition
Low Battery Reporting ......................................Repods as Partition 1
AC Power Reporting Options ............................Repofls as Partition 1
Test Reporting Interval .....................................Globalfor the Panel
Download Phone Number ................................Globalforthe Panel
Communication Format .....................................Globalforthe Panel
Rotary/Touch Tone ..........................................Global for the Panel
Download Callback defeat .................................Globalfor the Panel
Installer Code ...................................................Gbklfor all Partitions
Many devices and functions need to be reserved on a partition basis to provide
proper operation and flexibility for installations. The items assignable on a per
partition basis include:
●Consoles ●Enable/Disable Chime Mode
QEntry and Exit Delays ●“Go To” Partition function
sConsole Sound during Exit Delay ●Swinger Suppression
●Primary Subscriber Number ●BurglaryAlarm Comm. Delay
●Secondary Subscriber Number cOpen/close for Installer Code
cEnable/Disable of Panic Keys ●Confirmation of Arming Ding
●Enable/Disable of Duress ●Alarm Sounder Duration
●Multiple Alarm Reporting ●User Codes
sQuick Arm enable/disable
●Inhibfl Bypass of one Zone
-9-

Major Features Of
Scheduling
Access Door Control
Time-Driven
Event Programming
End User Scheduling
(#83 Menu Mode)
Scheduling is an exciting new feature of the 4140XMPT2 and provides the
following ftinctions. -
Arm/Disarm control I
Scheduling can be used to automate some of the system operation:
Auto arming and disarming at predetermined times.
Auto-armwarning
Useroptionto delay auto arm
Provision for temporary schedule of up to one week
Provisionfor aholiday schedule
Limitation of arming and disarming to specifictimes
—Control of when disarming will occur
Open/close by exception
Scheduling provides ameans of reporting openings/closings by exception:
sends report only if action does not occur.
Inhibflopening/closing reports if within aTime Window
—Send early to operVclosereports if done earlier than window
—
cSend lateto open/close reports if window is missed.
Relay Control (Time Driven Events)
Scheduling can also automatically perform relay driven actions at predetermined
times:
Can turn lights or other devices ordoff at specific times
—One shot action of light or other device
X-1Ocontrol for the automation of lights and appliances
—
Daylight Savings Time
Automatic time adjustment for daylight savings time
—
Scheduled events are programmed using auser friendly menu mode of
programming (#80 mode), explained in detail in the separate PROGRAMMING
GUIDE. This menu programming takes you step by step through the options.
The following overview will give you an understanding of the scheduling
concepts. Refer to the PROGRAMMING GUIDE for detailed programming
instructions.
The system also provides ameans of access control. Entry of USER CODE+ O
will cause amomentary trigger of apre-set output device. Each partition can have
its own output device. The trigger will occur on the device tied to the partition for
the console on which the keys were pressed. The access control relay is
programmed in partition-specific field 1’76.
This very powerful feature allows arming, disarming, relay modules or X-1O
devices to be activated automatically, based on the time windows described
previously. Time driven events can also be used to assign additional open/close
window schedules, so that more than one schedule per day can be programmed.
The system supports up to 20 time driven events. Refer to the PROGRAMMING
GUIDE-Scheduling Programming for more detailed information.
The system provides up to 20 “timers” available to the end user for the purpose
of activating output devices at preset times and on preset days. These timers are
analogous to the individual appliance timers that might be purchased at a
department store. The typical uses for this feature could be control of lights or
appliances, typically via X-1Omodules. These modules are programmed into the
system by the installer during #93 Menu Mode-Device Programming. The end
user needs only to know the output device number (relay number) and its alpha
descriptor, both programmed by the installer via Relay Programming and Alpha
Programming respectively. To enter this mode, the user enters CODE+ #+83.
The installer may set certain relays to be “Restricted”, since asystem may have
some devices (Relays or X-1O)which are not intended to be under the control of
end users, such as relays activating fire doors or relays activating certain
machinery. This option, set during #93 Menu Mode-Relay Programming, will
restrict operation by the end user. w
-1o-

ZONE TYPES &APPLICABLE SENSORS
Type 00
Zone Not Used
Type 01
Entry/Exit #1 Burglary.
Type 02
Entry/Exit #2 Burglary.
Type 03
Perimeter Burglary.
Type 04
Interior, Follower.
Type 05
Trouble by Day/Alarm
by Night.
The 4140XMPT2 supports up to 87 zones of hard-wire, polling loop and/or
wireless protection, distributed among up to 8partitions. The following table lists
the zone numbers and the types of sensors that can be used with each in this
system:
one Sensors
12-wire smoke detectors (if used)
7keyswitch (if used)
8latching type glass break detectors (if used)
1-9 traditional hard-wired zones
1-63 5700 eerieswirelees devices
1-87 5800 series wireless devices
10-87 polling loop devices
95 “/1 panic
96 #13panic
99 ●/# panic
Each zone must be assigned to azone type, which defines the way in which the
system responds to faults in that zone. In addition, there are three keypad
activated zones (PANIC keys, see note below) for each partition, apolling loop
supervision zone, and four RF supervisory zones, two for each RF Receiver
installed, Zone types are defined below.
Program azone with this zone type ifthe zone is not used,
This zone type provides entry delay whenever the zone is faulted if the control is
armed in the Away or Stay modes. When the panel is armed in the Instant or
Maximum modes, no entry delay is provided. Exit delay begins whenever the
control is armed, regardless of the arming mode selected. These delays are
programmable. This zone type is usually assigned to sensors or contacts on
doors through which primary entry and exit will take place.
This zone type provides asecondary entry delay whenever the zone is faulted if
the panel is armed in the Away and Stay modes. When the panel is armed in the
Instant or Maximum modes, no entry delay is provided. Secondary exit delay
begins whenever the control is armed, regardless of the arming mode selected.
These delays are programmable. This zone type is usually assigned to sensors or
mntacts on doors through which secondary entry and exit will take place, and
where more time might be needed to get to and from the console. Delay time must
be greater than Zone type 1. (Ex.: agarage, loading dock, or basement door)
This zone type gives an instant alarm if the zone is faulted when the panel is
armed in the Away, Stay, Instant or Maximum modes. This zone type is usually
assigned to all sensors or contacts on exterior doors and windows.
This zone type gives adelayed alarm (using the programmed Entry/exit time) if
the Entry/Exit zone is faulted first. Otherwise this zone type gives an instant
alarm. This zone type is active when the panel is armed in the Away or maximum
modes. Maximum mode eliminates the delay though. This zone type Is
bypassed automatically when the panel Is armed In the Stay or
Instant modes. This zone type is usually assigned to azone covering an area
such as afoyer, lobby, or hallway through which one must pass upon entry (After
faulting the entry/exit zone to reach the console to disarm the system.) Since this
zone type is designed to provide an instant alarm if the entry/exit zone is not
violated first, it will protect an area in the event an intruder hides on the premises
prior to the system being armed, or gains access to the premises through an
unprotected area.
This zone type will give an instant alarm if faulted when armed inthe Away, Stay,
Instant or Maximum (night) modes. During the disarmed state (day), the system
will provide alatched trouble sounding from the console (and acentral station
report, if desired). This zone type is usually assigned to azone which contains a
foil-protected door or window (such as in astore), or to azone covering a
“sensitive” area such as astock room, drug supply room, etc. This zone type can
also be used on a sensor or contact in an area where immediate notification of an
entry is desired.
-11-

Type 06
24-hour Went Alarm.
Type 07
24-hour Audible Alarm.
Type 08
24-hour Auxiliary
Alarm.
Type 09
Supewised Fire. (No
Verification)
Type 10
interior w/Deiay.
Type 20
Arm-Stay*
Type 21
Arm=Away*
Type 22
Disarm’
Type 23
No Aiarm Response
This zone type sends areport to the Central Station but provides no console
display or sounding. This zone type is usually assigned to azone containing an
Emergency button.
This zone type sends areport to the Central Station, and provides an alarm sound
at the console, and an audible external alarm. This zone type is usually assigned
to azone that has an Emergency button.
This zone type sends areport to Central Station and provides an alarm sound at
the console. (No beii output is provided). This zone type is usually
assigned to azone containing abutton for use in personal emergencies, or to a
zone containing monitoring devices such as water sensors, temperature sensors,
etc.
This zone type provides afire alarm on short circuit and a trouble condition on
open circuit. The beil output will pulse when this zone type is faulted. This zone
type is always active and cannot be bypassed. This zone type can be
assigned to any wired zone, but oniy certain wireiess systems
zones.
This zone type gives entry delay (using the programmed entry time), if tripped
when the panel is armed in the Away mode. This zone type is also active during
maximum mode, but no delay is provided (alarms occur immediately if zone is
tripped). This zone type is bypassed when the panei is armed in the
Stay or instant modes. Delay begins whenever sensors in this zone are
violated, regardless of whether or not an entry/exit delay zone was tripped first.
This is aspecial purpose zone type used with 5800 series wireless pushbutton or
contact closure or opening, and which will result in arming the system in the STAY
mode when the zone is activated.
This is aspecial purpose zone type used with 5800 series wireless pushbutton or
contact closure or opening, and which will result in arming the system in the
AWAY mode when the zone is activated.
This is aspecial purpose zone type used with 5800 series wireless pushbutton or
contact closure or opening, and which will result in disarming the system when
the zone is activated.
This zone type can be used on a zone when an output relay action is desired, but
with no accompanying alarm (ex. lobby door access).
●Note that these zone types are not for use by 5700 series devices.
NOTE FOR PANiC KEYS
Keypad panic zones share the same zone response type for all 8partitions, but
panics may be individually enabled for each partition.
iMPORTANT! FAULT ANNUNCIATION
Polling loop and RF faults (zones 88-91 &97) will repori as trouble conditions
only, and as such, should be assigned either zone type 00 if no annunciation is
desired, or zone type 05 if annunciation as trouble condition is desired. See
FAULT ANNUNCIATION notes in POLLING LOOP and WiRELESS EXPANSION
sections for more information.
-12-

BASIC 9HARD-WIRED ZONES
Zone 1Tha fnllatuinfi tshla m}mm arivae 7nna i fiharaAnrieibe
rI Iw Ivlwwl! 1~ *UUIW Uu$lll Ila# IAUCI &wl IV IWI mmUWLUI *s#J9wu.
Applications Can be used for EOLR supervised or closed circuit
unsupewised devices. It is the only zone that supports
2-wire smoke detectors.
Zone Response Type: Any
Response Time 350 msec
Max. Zone Resistance 100 ohms, excluding EOLR
Unsupervised Usage ●Cut red PCB jumper.
●Only closed circuit devices can be used.
EOLR Supervised sLeave red PCB jumper intact.
●Supports both open circuit and closed circuit devices.
●Connect open circuit device in parallel across the loop.
The 2,000 ohm EOLR must be connected across the
loop wires at the last device.
●Connect closed circuit device in series with the loop.
EOLR Fire Zone: ●Leave red PCB jumper intact.
●Assgn zone type 09 (fire)
sSupports up to sixteen (16) 2-wire smoke detectors
●Semnd CODE +OFF sequence momentarily
interrupts power to reset the smoke detectors.
●See table below for compatible detectors.
Compatible Smoke Detectors
Detector Type Device Model #
Photoelectric w/heat sensor, direct wire......................System Sensor 2300T
Photoelectric, direct wire .........................................System Sensor 2400
Photoelectric w/heat sensor, direct wire......................System Sensor 2400TH
Photoelectric w/B401B base.....................................System Sensor 2451
Photoelect. w/heat sensor &B401Bbase....................SystemSensor 2451TH
Ionization, direct wire..............................................System Sensor 1400
Ionization w/B401Bbase .........................................System Sensor 1451
Photoelectric duct detector
wA)H400 base .......................................................System Senmr2*l
Ionization duct detect. w/DH400 base ........................System Sensor 1451DH
Zone 1Advisories
Ifthe EOLR is not at the end of the loop, the zone is not properly supervised. The
system may not respond to an open circuit within the zone.
The alarm current provided by this zone is sufficient to supporl operation of only
one detector in the alarmed state.
UL NOTE: EOLR are required for UL installations.
zone 9The foliowina table summarizes zone 9characteristics. 4
Applications This zone is unsupervised and is suitable for monitoring
fast acting glass break sensors or vibration sensors when
orormammed for fast resoonse.
Response Type Any typeexcept fire
Response Time Normal (350 msec)or Fast (l Omsec)selected in field ●14.
Max. Zone Resistance 300 ohms
Unsupervised Usage ●Only closed circuit devices can be used.
●Connect these devices in series with one another
between terminals 22 &23.
Zone 9Advlsorles
Avoid using mechanical magnetic or relay type contacts in this zone when
programmed for fast response.
UL NOTE: The interconnecting wires from zone 9shall be no longer than 3feet,
with no interveningwalls or barriers for UL installations.
-13-

—
Zones 2-8 t_hefollowing table sur
Applications
Zone Response Type
Response Time
Max. Zone Resistance
Unsupewised Usage
EOLR Supervised
Glass Break Devces
on Zone 8
Smoke Detectors
on Zones 2-8
narizeszones 2-8 characteristics.
~
Can be used for EOLR supervised or closed circuit
unsupervised devices. Can also support 4-wire smoke
detectors. Zone 8can support Iatchmg glass break
●Zones 1-7:300 ohms, excluding EOLR
“Zone 8: 100 ohms, excluding EOLR
●EOLR disabled infield *41 (enter 1).
●Only closed circuit devices can be used.
“EOLR enabled infield “41 (enter O).
●Supports both open circuit and closed circuit devices.
●Connect open circuit devices in parallel across the
loop. The 2,000 ohm EOLR must be connected
across the loop wires et the last device.
sConnect closed circuit devices in series with the loop.
●Supports up to 50 2-wire latching type glass break
detectors.
●Configure as EOLR zone
cSecond CODE +OFF sequence momentarily
interrupts power to reset the glass break detectors.
“See table below for compatible detectors.
.
.
.
.
.
.
Supports as many 4-wire smoke detectors as can be
powered
Assign zone response type 09 (fire).
The zones must be configured for EOLR supervision.
Anormally-closed, momentary switch must be installed
in series with the power to the detectors in order to
allow resetof the smoke detectors after an alarm.
The detectors must be wired in parallel, with the EOLR
at the last detector for full supervision.
To supervise power, aSystem Sensor No. A77-716
EOL Relay Module is reco-mmended.
Compatible Glass Break Detectors
Use detectors which are compatible with the following ratings:
Standby Voltage: 5VDC -13.8VDC
Standby Resistance: Greater than 20k ohms (equivalent resistance of all detectors in
parallel)
Alarm Resistance: Less than 1.1kohms (see note below)
Alarm Current: 2mA-10mA
Reset Time: Less than 6seconds
The IEI 735L series detectors have been tested and found to be compatible with these
ratings. Up to 50 IEI 735L detectors, connected in parallel, may be used (the alarm
current provided by this zone is sufficient to support operation of only one detector in
alarmed state). Follow the manufacturer’s recommendations on proper installation.
Detectors which exceed 1.1kohms in alarm, but maintain avoltage drop in alarm of less
than 3.8 volts can also be used.
Zones 2-8 Advisories
If latching type devices are installed on both zones 1&8, and these zones are
assigned to different partitions, there is apossibility that, if both devices go into
alarm at the same time, the resetting of one device could cause the loss of alarm
memory in the other device.
Use of N.O. or N.C. contacts on the same zone may prevent proper glass break
detector operation.
UL NOTE: 4-wire smoke detectors cannot be used in UL installations.
-14-

2-WIRE POLLING LOOP EXPANSION (Zones 10 through 87)
..- .. . . .. . ... .. . . . ... ..–––– ,––. ,–—.—–.– .,-.,-
111s Iulwwll Mmule aulillllarlLua pu IIIf KI WUP WWJW IWUI Iwial auw IWUW
Applications ●Built-in 2-wire polling loop interface allows the number of
zones to be expanded from the basic 9zones to up to
87 zones using various Remote Point Modules (RPMs).
See ADVISORIES below.
●The polling bop provides power to sensors and sewes
as comnnmication path between the panel and sensors.
“Refer to the list of compatible devices at the end of this
section.
RPM Address (ID) ●Each sensor must be assigned aunique address ID
number (from 10-87) before being connected to the
polling loop. Care must be taken to assign unique ID
numbers to each sensor in order to allow the panel to
supervise and provide console status indications for
individual sensors.
●Most RPMs have DIP switches to set their addresses.
The 4139SN and 4191SN have preprogrammed serial
numbers which must be “learned” by the control via the
#93 menu programming mode.
Connections ●Connect RPM sensors to terminals 24 &25.
●Sensors can be connected to asingle run, or groups of
sensors may be connected to separate wire runs without
affecting the panel’s ability to supervise individual
sensors.
●Follow the wiring instructions provided with individual
sensors. Be sure to obsewe sensor polarity when wiring.
●The maximum allowable wire run length between the
panel and the last sensor on a given wire run is shown in
the table below.
Maximum Polling Loop Wire Runs
Wire Guage Max. Length Note Twisted pair recommended for
#22 gauge 650 feet allnormalwire runs.
#20 gauge 950 feet
#18 gauge 1500feet
#16 gauge 2400 feet
IMPORTANT: The maximum combined polling loop run is 4000’. If using
shielded wire, the maximum is 2000’. If longer wire runs are needed, a4197 Loop
Extender Module must be used (see instructions included with the 4197).
Intercom Interference If an intercom system is being used, the polling loop wires must be as far from the
intercom wiring as possible (minimum 6). If this spacing cannot be achieved,
shielded wire must be used. If this is not done, interference on the intercom
system might occur. Also note that the maximum total wire length supported is cut
in half when shielded wire is used.
Advisories The built-in polling loop has two limitations that must be observed. First, the
maximum allowable current draw from the polling loop is 64mA. Refer to the
POLLING LOOP CURRENT DRAW WORKSHEET (found inthe POWERINGTHE
SYSTEM section of this manual) for current draws of various polling loop devices.
Second, regardless of current draw, no more than 84 devices can be connected
to this loop. Installations which require up to 87 zones will require the use of
4190WH RPMs (which offer 2-points -arght and a left loop -per device) or the
use of a 4197 (which offers another polling loop supporting an additional
64m/V64 points)
Make certain to include the total current drawn on the polling loop in the
AUXILIARY CURRENT DRAW WORKSHEET (see POWERING THE SYSTEM
section) when figuring the total auxiliary load on the panel’s power supply.
-15-

Important! Fault Since the polling loop and the RF receiver(s) are shared among the 8partitions,
Annunciation the scheme for annunciating their failure is asfollows:
Respective faults (for zones 88-91 &97) will report as trouble conditions only, and
as such, should be assigned either zone type 00 if no annunciation is desired, or
zone type 05 if annunciation as trouble condtiion is desired. If the polling loop or w
RF link fails, the corresponding zone number will display atrouble condition for
each partition that uses the device that failed. In additiin, all zones associated with
that device will indicate afault condition. The trouble condition will not interfere
with the ability to arm the partition, butthe faults must first be bypassed.
Compatible Poiiing Loop Devices
4208
Eight Zone Poiling
Loop Expansion
Module
4190WH
Two Zone Remote
Point Moduie
4278
Quad Element Poliing
LooP PIR
4275
Duai Eiement Polling
Loop PiR
4194
Surface Mounted Reed
Contact (Wide Gap)
4197
Polling Loop Extender
Moduie
4192SD
Photoelectric Poiling
Loop Smoke
Detector
4192SDT
Photoelectric Poiling
Loop Smoke Detector
w/Heat Detector
4192CP
ionization Smoke
Detector
4139SN
Auto Smart Surface
Mount Reed Contact
4191SN
Auto Smart Recessed
Reed Contact
“Used to supervise up to 8hard-wired devices via the polling loop. NOTE: Does
not support 2-wire smoke detectors.
●Set DIP switches to identify 8zones.
●The first two zones can be either normal or fast response (DIP switch selectable).
●All zones are EOLR supervised (first six zones =4.7k ohms, last two zones =
30k ohms), provided with the 4208.
●Used to supervise 2hard-wired devices via the polling loop.
cDIP switch programmable.
●The left zone can be EOLR supervised, if necessary, and can accept either
open or closed circuit sensors, and can be set for fast response. The right zone
is unsupervised and can accept closed circuit sensors only.
sQuad element PIR with built-in RPM which is DIP switch programmable and
connects directly to the polling loop. Includes mirrors for both wide angle and
curtain/long range applications. Features an auxiliary sensor loop that permits
connection of another nearby closed circuit alarm sensor (reed contact, etc.).
cDual element PIR with built-in RPM which is DIP switch programmable. Includes
mirrors for both wide angle and curtain/long range applications and can use the
1875PA Pet Alley mirror. Built-in selectable pulse count capability.
cWide gap surface mounted reed contact with built-in RPM, which is DIP switch ~
programmable. \
●Can be used if the 2-wire polling loop must be greater than the recommended
length (4000’ max). By installing a 4197 at the end of the first loop, the polling
loop can be continued. If more than 64mA needs to be drawn from the polling
loop to power RPMs, use of the 4197 provides another loop with 64mA
available.
●Connects to the polling loop and is powered from auxiliary power or by a
separate 729 power supply with battery backup.
“One piece photoelectric smoke detector with built-in RPM which is DIP switch
programmable.
●One piece photoelectric smoke detector with 1350F (57°C) heat detector, and
buitt-in RPMwhich is DIPswitch programmable,
●One piece products of combustion ionization detector with built-in RPM which is
DIP switch programmable.
●Compact surface mount magnetic reed contact with built-in RPM.
●Serial number ID “learned” by control panel.
●Check product availability,
●Recessed (1/2” dia.) magnetic reed contact with built-in RPM.
●Serial number ID “learned” by control panel.
●Check product availability.
-16-

WIR~LMS RXPANSION (Zones 1=63)
Oonwal Information
[Rooolvm’a)
TransmJttcrs Supported
bv varloua rocolvers
Roe.ivor 71
4280 6%
4281M8
4281L 4
S881H84
S881M16
eQni
I’hefoliowlng tables
tones Supported
~FRsoeivers(Qenord
Receiver Supervision
House Identification
Sniffer Mode For
House Id
(Code +[#]+ [2])
rwnarizeswireless exBan8ionoharaoterlstios.
cThe 8ystem supports up to 83 wireless transmitters
(5700 or 5800 series), plus awireless keypad.
BTo expand the system using wireless, one or two of the
same type of RF Reoelverscan be used.
~Any zone from 1-83 can be used as a5700 aerie8
wireless zone. The total number of trarwmlttere
SUPPCNW byeach reoelver Is shown In the transmitted
supportedtable. Any zone from 1=87 can be used asa
5800serieswirelesszone.
The 4140XMPT2 supports the 4280, 4281 and 5881
series RF reoelvere. Refer to the transmitters auppotted
ta:av:r the number of zones supported by each
The receivers respond to status and alarm signals from
wkeleee transmitters (@345MHz USA; 315MHz Canada)
within anominai range of 200 feet, and reiay this
information to the oontroi,
Two of the same type of receivers can be used to
provide either agreater area of coverage, or to provide
redundant protection, The type of receiver used is
identified in program field 1’32,
Receivers must be mounted externally to the controi,
The 4280 &4280-8 receivers are connected to the
poliing loop.
The 4281 and 5881 series receivers are connected to
the consoie data iines.
●
9
9
if the connection is broken between the receiver and the
controi panel, aTROUBLE wili be dispiayed for zones 89
or 91 (if type 05 is assigned). in addition, aii zones
associated with the RF device will report atrouble
condition.
If,within aprogrammed intervai of time, the receiver does
not hear from any of its transmitters, aTROUBLE wiii
appear for zones 88 or 90 (if type 05 is assgned).
4280 oniy: if the cover of the 4280 is removed, a
TROUBLE wiil be dispiayed for zones 89 or 91 (iftype 05
is assiqned).
●Receivers respond oniy to transmitters set to the same
house iD (01-31). This prevents system interference
from transmitters inother nearby systems.
cUse Sniffer Mode (described later) to make sure you do
not choose aHouse IDthat is in use in anearby system.
●4280 house ID is set via DiPswitches.
●4281/5881 (for 5827) house iD is programmed via #93
Menu Mode, Device Programming.
.
9
●
To check for house iDs being used in nearby systems,
set the receiver’s House iD to “00”, then enter your
“Instailer Code”+ [#]+ [2]
The receiverwill now “sniff” out any House iDs in the area
and display them. Keeping the receiver in this mode for
about 2hours wiii give a good indication of the house IDs
being used. To exit the Sniffer Mode, simpiy key your
instailer code +OFF, then set your house iD to onenot
dispiayed in the “Sniffer Mode”.
Important: Since Sniffer Mode effectively disabies RF
point reception, Sniffer Mode cannot be entered whiie
any partitionis armed.
-17-

-.. –... .. . . . . . . . .. . . .. . .
4280 8erles Receiver
4280 is not recommended
for new installation; receiver
is scheduled to be
discontinued.
4281 8erke Receiver
5881 8eriee Receiver
House ID
Receiver Address
Cover Removal
Go/NoGoMode
Spatial Diversity
Transmitter ID
4280 series
Connects to polling
loop
set via D1Pswitches
Set by cutting blue
lumperin 2nd
receiver. Enabled
via fields 1“26 &
1●27.
Causes alarmor
trouble depending
on response type
assigned.
Requires cover
removal.
No. Requires2
receivers for
redundancy or to
expand area of
coverage.
Set via DIP
switches.
4281 series I5881 series
1
Connects to
console lines
programmed via #93 programmedvia #93
Menu Mode. Menu Mode.
Set via DIP
switches.Enabled
via#93Device
Programming.
Does-not cause
alarmor trouble.
Set via DIP
switches. Enabled
via #93 Device
Programming.
Does not cause
alarm or trouble.
Automatic upon
entering test mode.
Yes. Eliminates
nulls and voids. 2nd
receiver expands
coverage area or
provides additional
redundancy.
Set via DIP
switches.
Automatic upon
entering test mode.
Yes. Eliminates
nulls and voids. 2nd
receiver expands
coverage area or
provides additkmal
redundancy.
Serial numbers are
“learned” by the
system.
.
.
●
✎
✎
✎
✎
✎
●
✎
●
✎
✎
●
lm~ortant: Note that if usirw two RF Receivers, one of them must be
powered from auxiliary power; so as not to exceed the 64mA polling loop
current rating.
Set field 1*32 to O.
For more information regarding the 4280 installation, refer to the installation -
instructions provided with the 4280.
If using a4280-8, only up to 8zones can be enabled as RF zones. If more than
8zones are enabled, the message “SET-UP ERROR” (or E8 on non-alpha
consoles) will be displayed.
Refer to the maximum polling loop wire runs described in the POLLING LOOP
section when connecting 4280s to the polling loop.
IMPORTANT: The maximum combined polling loop run is 4000’. If using
shielded wire, the maximum is 2000.
Set field 1*32 to 1.
Using #93 Menu mode-Device Programming, select as RF device type.
Set house ID via #93 Menu Mode.
Set receiver% device address using its DIP switches. Lower numbered
address is primary receiver (supervisory fault ID 90, 91). Higher numbered
address is secondary receiver (receiverfautt ID88, 89).
Important: 4281 microprocessor must have part number N5334VX, where xis
any number. The microprocessor is located just above the DIP switch on the
PC board.
Set field 1*32 to 2.
Using #93 Menu mode-Device Programming, select as RF device type.
Set house ID via #93 Menu Mode (needed for 5827 keypad only).
Set receivets device address using its DIP switches. Lower numbered
address is primary receiver (supervisory fault ID 90, 91). Higher numbered
address is secondary receiver (receiverfault ID88, 89). v
-18-

Transmitters
NOTE: After replacing abw
or dead battery, activate the
transmitter and enter the
security code +OFF to clear
its memory of the “Low
Battery” signal.
IwI Wllww II wLauIw WJI IuIlal Kwu wvuUIUW um m IIILK71 uIaIaULWI I=L*O.
‘transmitters(Generel) ●Supports 5700 or 5800 series transmitters.
●Each transmitter has its own unique transmitter ID
number (Zone #). 5700 series transmitters use DIP
switches to set the ID. 5800 series transmitters must
have their ID nurrbers “learned” by the system.
●5700 series transmitters and the 5827 keypad must also
be set for ahouse ID. Other 5800 series transmitters
have built-in serial numbers and do not require ahouse
ID to be set. After installation, check that all transmitters
have been assigned the proper house ID by using the
procedure described later.
‘rans. SupervWlon ●Each transmitter (except 5701, 5727, 5802, 5802CP &
5803) is supervised by acheck-in signal that is sent to
the receiver at 70-90 minute intervals. If at least one
Check-in is not received from atransmitter within a
programmed interval (field 1*31), the console will display
the transmitter number and “CHECK” will be displayed.
●Each transmitter (including 5701; 5727, 5802, 5802CP
&5803) is also supervised for low battery conditions, and
will transmit alow battery signal to the receiver when the
battery has approximately 30 days of life remaining. The
console will display the transmitter number and “LO
BAT”.
;800 Series “Learn” ●5800 series transmitters have built-in serial numbers that
must be “learned” by the system during programming.
Referto the PROGRAMMING GUIDEfor details.
:hecking Trans. ●To check that all transmitters have been set property,
>peration including setthe receiver to the proper house ID
)IP &serialnumber and enter the Installer code +[#]+ [3].
Code +[#]+ [3]) ●All transmitters that have been enabled for the partition in
which the test was initiated will be displayed. As each
transmitter checks in (up to 2hours), its ID number will
disappear. Afaster way to do this is to fault each
transmitter, which causes atransmission to be sent to the
receiver. When all transmitters have checked in, there
should be no ID numbers displayed.
●NOTE: Repeatthis procedure for each parlition that uses
RFtransmitters.
‘Go/No Go” Test ●This mode helps determine the best location for each
ulode (Patented) transmitter and is activated by putting the control panel in
the TEST mode (4280 requires removing the itscover).
cThe receiver’s sensitivity is reduced by half. Once
transmitters are placed in their desired locations and the
approximate length of wire to be run to sensors is
connected to the transmitter’s screw terminals, open
circuit each transmitter. Do not conduct this test withyouf
hand wrapped around the transmitter.
●If asingle receiver is used, the console will beep three
times to indicate signal reception. If two receivers are
used, the console will beep once if the first receiver
received the signal, twice if the second receiver received
the sgnal and three times if both receivers heard the
signal (which is desirable for redundant configurations).
●If the console does not beep, reorient or move the
transmitter to another location. Usually afew inches in
eitherdirection is all that is required.
●To exit this mode, enter the installer code and press
OFF (replace the 4280s cover). Note that the Receiver’s
sensitivity isfully restored when this mode is exited.
-19-

Note On RF Keys 5800 series RF keys can be used to arm and disarm the system. These
(5801, S803, etc.) transmitters include the 5801, 5803, and any other 5800 series transmitter if
programmed for one of zone type responses 20-22. These transmitters are tied ,
to auser in order to provide arecord of who armed or disarmed the system.
Because of this, an RF button will not armor disarm asystem unless it has been w
assigned to auser, which is done during the “add auser” function (see Add A
User Code section). In addition, when the user is deleted from the system, the
key is deactivated. To test whether the keys are assigned to users or not, use the
test mode. When the appropriate button is pressed, the corresponding zone will
be displayed on the console and will remain there until test mode is terminated.
Wirelees Zone Types Each RF zone can be programmed to respond as any zone type such as
ENTRY/EXIT, INTERIOR, PERIMETER, etc. (see the ZONE TYPES section for a
complete explanation of each zone type).
Desired alarm responses for 5700 series devices are as follows:
ZONE TYPE TRANSMITTER ID #
Entry/Exit Burg 1through 47 *
Perimeter Burg 1through 47 ●
Interior Burg 1through 47 ●
32 through 47 *(5775)
Fire 46 through 63 ●
48 through 55 “’ (5706)
24 Hour Panic 46 through 63*
(silent or audible) 62 or 63 ●** (5701)
Day/Night Burglary 1through 47 ●
24 Hour Auxiliary 1through 47 *
NOTES:
●Note that zones 1-63 can be used, but have the following limitations: Transmitters set
for zones 48-55 will transmit once every 12 seconds while the zone is faulted.
Transmitters set for zones 56-63 will transmit once every 3seconds while faulted.
These two ranges of zone numbers could adversely affect transmitter battery life.
Transmitters set for an ID of 32 through 47 will have a 3 minute lock-out between *
transmissions. Use this last range of zone ID numbers for sensors protecting
frequently used doors or windows to conserve battery life.
** Transmitter IDs48 through 55 have highest signal priority.
*•* Transmitter IDs 62 and 63 are unsupervised to allow removal of the 5701 off premises
.- signal prioriiy is lower than that of fire, but higher than burglary.
Advlsorles 1. Do not place transmitters on or near metal objects. This will decrease range
and/or block transmissions.
2. Place the receiver in ahigh, centrally located area for best reception. Do not
place receiver on or near metal objects.
3. For maximum range, the RF receiver must be at least 10 feet from the Control
panel or any remote consoles to avoid intederence from their microprocessor.
UL NOTE: For UL Household Burglary Installations, wired loops
connected to these devices cannot exceed 3feet.
4. If dual receivers are used:
A. Both must be at least 10 feet from each other, as well as from the Control
panel and remote consoles.
B. The house IDs must be the same.
C. Using two Receivers does not increase the number of transmitters the
system can suppofi (83transmitters, plus awireless keypad).
Fault Annunciation Since the polling loop and the RF receiver(s) are shared among the 8partitions,
the scheme for annunciating their failure is as follows:
Respective faults (for zones 88-91 &97) will report as trouble conditions only, and
as such, should be assigned either zone type 00 if no annunciation is desired, or
zone type 05 if annunciation as trouble condition is desired. If the polling loop or
RF link fails, the corresponding zone number will display atrouble condition for
each partition that uses the device that failed, In addition, all zones associated with
that device will indicate afault condition. The trouble condition will not interfere ~
with the ability to arm the parlition, butthe faults must first be bypassed.
NOTE: 5800 series transmitters have built-in tamper protection and will
annunciate as a“CHECK” condition unless field ●24 is disabled.
-20-
