INSTALLATION GUIDE
MILA II SINGLE SPRAY SLIDE SHOWER DSHSKCSR2
WHAT IS IN THE PACK
1 x Rail & Slider
2 x Wall Anchors
1 x Flow Restrictor
& Sleeve1 x Hose
2 x Screws
1 x Elbow
2 x Mounting
Bracket
1 x Single Spray
Handpiece
Rail can only be
installed with
the handpiece
on the right.

It is essential that the
mounting brackets are
installed with the grub
screw hole facing the
right as shown.
Mount the rail onto the brackets in place. Ensure
that both rail and bracket are secured.
It is recommended that silicone sealant be used to
seal the fixing brackets.
Tighten the grub screw
on rail with an allen key.
Screw the elbow into the water outlet (wingback).
Sealant required on thread to achieve a water tight
seal. For Mains Pressure, fit flow restrictor into the
handpiece first. Screw the hose onto the elbow and
handpiece and attach the handpiece to the slider on
the rail.
685mm C-C
grub screw
hole
1. 3. 4.2.
HOW TO INSTALL
INSTALLING INTO STUD/NOG...(RECOMMENDED)
Untighten the grub
screw from the rail with
an allen key.
Remove the
brackets from the rail.
Mount the brackets into position (685 Centre -
Centre).
5. 8. 9.
INSTALLING INTO CONCRETE/BRICK WALL...
Pre-drill holes to 685 Centre - Centre
and fit the wall anchors then follow
the above instruction.
685mm C-C
