Adeunis RF ARF26 User manual

05-11-V3-psn 1
GENERAL USE 2
CHOICE OF TRANSMISSION CHANNELS 2
DIMENSIONS / PIN ASSIGNMENT 3
CHANNEL MANAGEMENT 3
Principle 3
Timing 4
Transmissionmode 4
Receivermode 5
Dataclkmode 5
Standbyemode 6
Reset6
PROTOCOL 7
Levelbitencoding 7
Levelframeencoding 7
RADIO CHANNEL MANAGEMENT 8
Radiochannelsettling 8
Wakeuptime 8
Transceiver turn around 9
RSSI 9
SPECIFICATIONS 11
INTEGRATION 12
REGULATION COMPLIANCE 13
ARF26
Use
r
Guide
ADEUNIS RF – 283 RUE LOUIS NEEL – 38920 CROLLES FRANCE
DESK : [phone] – FAX [phone] E.MAIL : [e-mail]
________________________________________________________________________________________
SA au capital de 345.000 euros – SIRET 430 190 496 00017 – RCS Grenoble – NAF 322A

05-11-V3-psn 2
The ARF26 radio module is a multi-channel FSK digital transmission radio-frequency
transceiver using the 868-870 MHz band. This transceiver proposes up to 9 transmission
channels enabling two-way half-duplex digital links up to 25 kBps Manchester. The
transceiver is composed of "rough" radio components; the transmission protocol (data
encoding/decoding) and radio module programming are performed by the associated logic.
The 868-870 MHz band is subdivided into 4 sub-bands authorising different duty cycles: ≤
0.1 %, ≤1%, ≤10% and ≤100%. The duty cycle of the product has to be calculated to know
which of the sub-bands can be used by the application. The table below presents the
different sub-bands with their duty cycle and the maximum number of channels that can be
envisaged in each sub-band.
Sub-band
n° 1 2 3 4
Band edges
(in MHz)
868-868.6 868.7-869.2 869.4-869.65 869.7-870 (*)
Duty cycle ≤1% ≤0.1 % ≤10% up to 100%
Maximum
number of
channels
3 3 1 2
(*) The maximum apparent radiated power for sub-band #4 is limited to +7dBm.
The table below gives the details of the available channels:
Sub-band Channel Frequency
868-868.6 MHz 1 868.100 MHz
duty cycle 1% 2 868.300 MHz
3 868.500 MHz
868.7-869.2 MHz 4 868.783 MHz
duty cycle 0.1% 5 868.950 MHz
6 869.117 MHz
869.4-869.65 MHz
duty cycle 10% 7 869.525 MHz
869.7-870 MHz 8 869.775 MHz
duty cycle 100% 9 869.925 MHz
GENERAL USE
CHOICE OF TRANSMISSION CHANNELS

05-11-V3-psn 3
N.B.:
- The signals SLE, SCK and SDATA correspond to the 3-wire serial interface for
programming the transceiver registers.
- The radio module is supplied by an external power source between VDC and GND. The
supply voltage should be chosen in the 3-5V range.
•Principle
The transmitter and receiver have to be configured (frequency registers, control registers...) to
establish the radio link. This register configuration is performed by means of the SLE, SCK
and SDATA 3-wire serial bus.
The number of registers to be programmed depends on the operating mode: transmission,
receipt... Each word is programmed starting with the most significant bit (MSB) and each bit
is loaded on the rising front of SCK.
N.B:
- In transmission mode (Tx) and receipt mode (Rx), the programming is different for any one
channel.
- The transmitter and receiver have to work on the same channel to “understand” each other.
- For this programming, it is understood that low level corresponds to GND and high level to
VDC.
1 - GND RF
2 - ANTENNA
3 - VDC: 3 to 5V power supply
4 - GND: 0V ground
5 - DATAMSG: Data input/output
6 - SLE: Enable input
7 - SCK: Clock input
8 - SDATA: Programming data
input/output
9 - DATACLK: Received data
s
y
nchronisation cloc
k
DIMENSIONS
/
PIN ASSIGNMENTS
CHANNEL MANAGEMENT

05-11-V3-psn 4
•Timings
Programming of a register is performed according to the following timing diagram:
N.B.:
- The number of pulses for SCK corresponds to the number of bits to be sent and depends on
the register. In the example above, there are 37 clock pulses that correspond to the longest
register.
- Between programming of 2 registers, SLE must be kept at “1” for a minimum time of
200 ns.
- The content of the registers (address included) for each operating mode is specified in the
following paragraphs. When programming a register, it is imperative to send the specified
number of bits (cf. tables below), no more no less, to avoid an incorrect programming.
•Transmission mode
In transmission mode, three 37-bit registers (the control register CTRL1 and frequency
registers F0 and F1) and one 7-bit register (control register CTRL3) have to be configured.
Programming of the registers must begin with F0, followed by F1, then CTRL3 and finish
with CTRL1. The table below presents the content of the registers according to the channel:
Channel F0 (hex)
37 bits F1 (hex) 37 bits CTRL3 (hex) 7 bits CTRL1 (hex) 37 bits
1 019CD440E2 03085464E6
2 01A57D72C4 034465D4C4
3 01FD05E6DE 03449DC4FA
4 01019DF274 0380CDF472 09DB005260
5 0188C45666 03855552F4 45
6 018804F4EE 03B195D248
7 01405DE244 03518540C4
8 01059DC6F4 03A1154240 09DB002260
9 01FC3DE658 03506D467E

05-11-V3-psn 5
•Receipt mode
In receipt mode, at least two 37-bit registers (the control register CTRL1 and frequency
register F2) and one 7-bit register (CTRL3) have to be configured. Programming of the
registers must start with F2, followed by CTRL3 and finish with CTRL1. The table below
presents the content of the registers according to the channel:
Channel F2 (hex)
37 bits CTRL3 (hex) 7 bits CTRL1 (hex) 37 bits
1 05C14DD4C8
2 05B57DD2C4
3 05597C52E2
4 058884E26E
5 0539E5D4D0 44 0990000260
6 05C91C50EA
7 056DFD46D8
8 052D6544D0
9 05783DE2D8
•“DATACLK” mode
In receipt mode, a received data synchronisation clock can be available on the DATACLK pin
of the radio module (rising front in the middle of the data). To take advantage of this option,
the control register CTRL2 (27 bits) also has to be configured according to the maximum
transmission rate of the application. In “DATACLK” mode, programming must be started
with F2, followed by CTRL2 then CTRL3, and finally CTRL1.
The table below presents the content of CTRL2 according to the maximum transmission rate
of the application and the content of CTRL1 that has changed (for activation of the
DATACLK).
Transmission rate Transmission rate
(in Manchester) CTRL2 (hex)
27 bits CTRL1 (hex) 37 bits
2 kBps 1 kBps 7D40266
2.4 kBps 1.2 kBps 7D0AD55
4kBps 2 kBps 7CA0133
4.8kBps 2.4 kBps 7C8562B
9.6 kBps 4.8 kBps 7C42B15
10 kBps 5 kBps 7C40014 09B0000260
19.2 kBps 9.6 kBps 7C2160B
20 kBps 10 kBps 7C2000A
39.2kBps 19.6 kBps 7C10C05
40 kBps 20 kBps 7C10005
50 kBps 25 kBps 7C0CD04

05-11-V3-psn 6
N.B.:
- The content of CTRL1 is identical whatever the channel.
- In “DATACLK” mode, the contents of the registers F2 and CTRL3 are the same as in
paragraph 5.4.
- Consult us for other transmission rates.
•Standby mode
To switch to Standby mode, the registers CTRL3 then CTRL1 have to be programmed:
CTRL3 (hex)
7 bits CTRL1 (hex) 6 bits
45 (*) 12
(*): When switching to Standby mode from transmission mode, the register CTRL3 is already
at 45 (hex).
To return to the previous mode, CTRL1 and possibly CTRL3 have to be reprogrammed:
Previous mode CTRL3 (hex)
7 bits CTRL1 (hex) 6 bits
Transmission - 13
Receipt 44 13
•Reset
Reset of all the registers is performed by programming the RESET register:
RESET (hex)
6 bits
Content: 2E
After a reset, the radio module is in standby mode and all the registers have to be
reprogrammed as described above to switch to transmission or receipt mode.

05-11-V3-psn 7
On account of the ARF26 system transmission principle and of the modulation in phase lock
loop, the modulating signals must have a frequency comprised between 1 kHz and 25kHz.
Lower and higher frequencies cannot be transmitted, as they are filtered. This means, among
other things, that the link cannot transmit constant states with a duration of more than 500 µs.
•Level - Bit Encoding
Most conventional hardwired serial links transmit bytes in asynchronous manner using an
NRZ type encoding (1 logic bit = 1 electrical state). This results in the spectrum occupation of
the signals thus generated being about one decade. Furthermore, sampling of the bytes thus
received supposes perfect synchronisation of decoding on the start bit.
In the case of radio transmission, it is preferable to limit the spectrum of the signals to be
transmitted as far as possible, in particular towards low frequencies, even if this means
increasing the main frequency. Moreover, it is advantageous to reset the synchro on each
transmitted bit; receivers are in fact the cause of large duty cycle errors on the electrical states.
Bit encodings should therefore be preferred, for example those proposed below:
Manchester or two-phase:
Differential PWM:
•Level - Frame Encoding
Once the bits have been encoded, it is then imperative that they be transmitted according to a
frame structure; the radio link is very sensitive to binary flow breaks which can only be
minimised by “serialising” the bytes.
A conventional frame structure is shown below:
PROTOCOL

05-11-V3-psn 8
1Preamble: Electrical succession 101010... to fix the receiver polarisation and compensate
the channel settling time.
2Start pattern: Electrical pattern that marks the beginning of the useful data by a break in
the binary flow of the preamble.
3Useful part: Successions of bytes encoded at bit level.
4Stop pattern: Indicates the end of frame (necessary when the frame may be of variable
length).
•Radio channel setting:
This characteristic corresponds to the time required for the first valid bits to be obtained on
receipt on an ARF26 n°2 (DATAMSG2) after a frame has been transmitted from another
distant ARF26 n°1 module (DATAMSG1).
•Wake-up time (Start-up time):
This characteristic corresponds to the time required to switch from Standby mode (low
consumption) to ‘active’ mode (transmission or receipt).
RADIO CHANNEL MANAGEMENT

05-11-V3-psn 9
•Transceiver turn-around:
This characteristic corresponds to the time required to switch from transmission to valid
receipt or vice-versa on the same device, and therefore to a TX_RX control input status
change.
The 3-wire serial bus is bi-directional. It is therefore possible to read the status of certain
registers. The value of the RSSI (received signal strength indicator) is contained in the status
register in the form of a 6-bit word.
To know the value of these 6 bits, you have to go and read the status register according to the
following timing diagram:
- The first 4 bits (0101) correspond to the status register address.
- The 5th bit (1) selects register read mode.
T1: SDATA switching time from input to output on descending front of SCK: 50 ns max.
T2: data propagation delay time after a descending front: 50 ns max.
T3: SDATA switching time from output to input on rising front of SLE: 50 ns max.
The timings indicated in chapter 4.2 remain valid.
The value of the RSSI corresponds to bits D1 (LSB) to D6 (MSB). Bit D7 is of no interest.
The graph below gives a correspondence between the RSSI value and the received power
level.
RSSI

05-11-V3-psn 10
Caution:
- The RSSI level remains an indicator which has to be used with precaution. The curve
presented above may change somewhat from one product to the other.
- This RSSI level can also indicate the presence of a possible interfering source on the
channel used. It is not possible to ensure that the required signal coming from the remote
transmitter is detected and received by examining the RSSI only. The identity of the
transmitter also has to be checked by encodings in the transmitted frames.
The RSSI is a necessary but non-sufficient condition for obtaining correct receipt.

05-11-V3-psn 11
3V 5V
TRANSMITTER
Frequencies 868-870 MHz
9 channels
Power developed (/ 50 Ohms) 8 dBm (*) 10 dBm (*)
Modulation 2FSK +/-25 kHz
Consumption 55 mA 60 mA
RECEIVER
Technology Super-heterodyne with double frequency change
Frequencies 868-870 MHz
9 channels
Sensitivity (at S/N 15dB) 2.2 µV (-100 dBm)
Demodulation 2FSK +/-25 kHz
Bandwith 2 MHz front end
100 kHz back end
Digital output 0/Vdc
Consumption 32 mA 40 mA
COMPLETE SYSTEM
Operating voltage from 3 to 5V (+/- 5%)
Standby current < 2µΑ <2 µA
Transmission rate from 1 to 25 kbps
Manchester
Transmitter wake-up time 10 ms
Receiver wake-up time 10 ms
Turn-around time Tx to Rx 1 ms
Turn-around time Rx to Tx 1 ms
Channel setlling time 1 ms
Temperature -20°C to +70°C
SPECIFICATIONS

05-11-V3-psn 12
•Daughter board:
This daughter board is to be incorporated directly on an electronics mother board by means of
the “COMCLIP” connectors provided on the radio module (cf. dimensions and pin
assignment in chapter 3 of this document).
The mother board can be used to locate the antenna output by means of a 50 Ω printed line.
This line is formed by a printed track 2.5 mm wide which must be situated above a continuous
ground plane (the HF cold point is to be connected as short as possible to this plane). Avoid
running close to digital lines!
•EMC aspect:
When a radio element is integrated in an electronics system, the mother board must be
provided with a ground plane which is as continuous as possible. The GND and GND RF
signals of the module are to be connected as short as possible to this plane. It is preferable that
the module then be fitted on the ground plane side, opposite from the tracks.
Due to the presence of a Receiver part (for the transceiver), some precautions have to be taken
when integrating the ARF26 module. Fitting a receiver with a good sensitivity alongside a
high-speed digital part requires a little succinct filtering described by the diagram below:
A RECEIVER WITHOUT A SQUELCH GENERATES NOISE ON OUTPUT IN THE
ABSENCE OF A RECEIPT SIGNAL. THIS DOES NOT HOWEVER MEAN THAT IT
IS POLLUTED BY INTERFERENCE; THE DATA WILL BE “CLEAR” WHEN
RECEIPT TAKES PLACE.
INTEGRATION

05-11-V3-psn 13
When using radio transceivers in the form of integrated daughter boards, conformity with
regulation compliance relates to the finished product.
In Europe, finished products must comply with the RTTE directive. For this type of radio
application, conformity with the RTTE directive will be established by compliance with
the following requirements:
- EN300220 standard (Efficient use of Radio/ spectrum).
- EN301489 standard (EMC).
- EN60950 standard (Electrical safety if necessary)
Important:
Although the ARF26 daughter boards comply with the criteria and dimensions of the
EN300220 radio standard, their integration in a “mother” electronic system may modify
some electrical characteristics (harmonic levels, spurious RF, etc.)
Before it is sent for laboratory tests, the product therefore has to be examined on our
premises to check that it complies with regulations. After presentation, the product and
the test reports must be kept as proof of conformity.
REGULATION COMPLIANCE
