Universal Space B-310 User manual

Operation Manual
www.universal-space.com

Have Questions? Contact us!
International Support Center USA Support Center
Tel: [phone]
Fax: [phone]
Email: ser[email protected]
Tel: [phone]
Fax: [phone]
Email: [e-mail]

Ocean carousel Manual
1
Non-technical personnel who do not have technical knowledge and
Expertise should refrain from performing such work that this manual
require or perform tasks which are not explained in this manual. Failing
to comply can cause severe accidents such as electric shock or other
serious injuries. All repairs must be performed to original manufacturer
specifications.
WARNING: To reduce the risk of fire, electric shock or personal injury,
unplug or disconnect the machine from the power supply before
servicing.
CONTENT
IMPORTANT SAFETY INSTRUCTIONS........................................................................ 3
1. SPECIFICATIONS ..................................................................................................... 4
2. PACKAGE CONTENTS.............................................................................................. 5
3. PART NAME ............................................................................................................. 6
4. SET UP & INSTALLATION........................................................................................ 7
5. HOW TO PLAY ........................................................................................................11
6. GAME OPTION .......................................................................................................12
7. ERROR MESSAGE AND RECOVERY ....................................................................14
8. MAINTENANCE & INSPECTION ...........................................................................15
9. OVERALL CONSTRUCTION ...................................................................................16

Ocean carousel Manual
2
Thank you for purchasing Ocean carousel. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE, NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

Ocean carousel Manual
3
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install
outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

Ocean carousel Manual
4
1. SPECIFICATIONS
Rated power supply: AC220-240V,50/60Hz
Power consumption: 400W
Dimension: W54×H91.2 in
Weight：Approximately 551.2 lb
Part No: O101
Model No: B-310
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Note: Game parameters are subject to change without notice.
91.2 inches
Φ54 inches

Ocean carousel Manual
5
2. PACKAGE CONTENTS
Open the package and make sure all the items are included:
1. Following accessories
NOTE: Part models are subject to change without notice.
No. Part No. Code Name Spec. Qty Picture
1 O101-001-000 2.19.01.000012 Fuse φ5-20mm 3
2 O101-002-000 25302222002 Key 2222 1
3 O101-003-000 25300000107 Key 2233 2
4 O101-004-000 Manual English 1

Ocean carousel Manual
6
3. PART NAME
Service door
Coin Ass
y
.
Header Ass
y
.
Play field
Steel pole
Base Ass
y
.
Pillar

Ocean carousel Manual
7
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install
outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid
Place the unit on a dry level surface
Ventilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position.
NOTICE
Be careful not to damage the machine during transport.
Always unplug the game before moving.
Keep the machine in upright position during transport.
For longer distance transport, package the game properly to prevent damages.
4.2 Level Adjustment
Install this machine on a flat surface. Adjust levers to lift casters off the ground to level the
game
. If the game is installed on an unsuitable floor, it could cause game malfunction.
To secure the game, adjust the Leveler down until it touches the floor, lifting the casters off
the ground by 0.2 in. Repeat the same for all levelers.
Leveler Caster
Move F
i
Caster Leveler
About 0.2 in
Move Fix
NOTICE
Make sure the machine is level.

Ocean carousel Manual
8
4.3 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Play area: 54 in
Service area: 20 in
4.4 Connecting Power
WARNING: Check the voltage rating before you connect the equipment to
an electrical outlet to ensure that the required voltage and frequency match
the available power source. Please refer the label of the machine.
Do not plug the equipment power cables into an electrical outlet if the power cable
is damaged.
Avoid overloading on one electrical outlet as it could generate heat and fire resulting
from overload.
Connect the grounding conductor to the earth terminal (GND):
Power plug
Power outlet
Power socket
Power plug
Power cord
The machine
Service area

Ocean carousel Manual
9
WARNING
Ensure no heavy objects rest on the power cord. Check to make sure the game cabinet
does not sit on the power cord as this could damage the cord and become hazardous.
To disconnect the game, grip the plug and pull it from the wall outlet. Never pull by the
cord.
To prevent electric shock, do not touch the power plug if your hand is wet.
Ensure the power cord is not located where it can be stepped on or tripped over.
4.5 Disassembly
The dismantle steps as below:
1. Dismantle the Characters(fish& turtle & sea horse):
Use the Hexagon Key to lose the two bolts of the character seat, the pack them with
the bubble- coat wrapping separately.
Use the M6 hexagon keys to loosen the two bolts to dismantle
the fish and sea horse.
Use the M6 hexagon keys to loosen the two bolts
to dismantle the turtle.

Ocean carousel Manual
10
2. Dismantle the header and the Pillar
a. Use the Philips screwdriver to loosen 8 bolts under the header.
b. Take out the header (It is recommended to have the minimum of 2 staff
members available for this step).
c. Use a Hexagon Key to loosen 3 bolts on the upper side of the header and unplug
the connector on the top of the pillar.
d. Use a spanner to loosen three bolts which used to fixed three steel popes
e. Take out the base of the header. (It is recommended to have the minimum of 3
staff members available for this step)
f. Use a M8 hexagon key to loose four bolts on the bottom of the pillar and unplug
the connector at the bottom of the pillar. Then, remove the pillar.
c
e
a d
b
M8 Bolt The bottom connector

Ocean carousel Manual
11
3.Dismantle 3 steel poles.
4. Pack up six parts with bubble-coat separately after disassembling the machine, for sand
or other hard substances may scratch the surface of the machine.
5. Please assemble the game in reversed order.
6. Change the PCB or the transformer (Refer Page 22)
a. Loose the 2 bolts which are used to fixed the electric box.
b. Unplug all connectors behind the electric box and take it out.
c. Loosen the 4 bolts which on the surface of the electric box.
5. HOW TO PLAY
1. Insert coin. Ride starts. Be sure to fasten the seat belt before the game is on.
2. The ride will go around and play with music.
3. Don’t leave the seat before the machine is stop.
Rotate and remove them.

Ocean carousel Manual
12
6. GAME OPTION
6.1 Use the service key to open the operation door.
1. Volume Adjustment:
Turn it in clockwise to increase the volume, and counterclockwise to reduce.
2. Play Counter:
Record the playing times.
3. Reset Button:
Press it to renew the game.
4. Service Button:
Press it to enter the check model or get a free play.
5. DIP SW
Set the parameters of the game.
6. Coin counter:
Record the coin(s) of the game.
7. Power SW:
Turn it ON to power on the machine, contrarily turn OFF the machine.
8. Voltage SW:
Use it to change the input Voltage, 110V or 220V;
※Note: Be sure to turn off the power before setting this SW.
9. Fuse: Use to security the all the electric parts of the game.
10.The Box Handle: It is easy for user to draw out the electric box to service the game.

Ocean carousel Manual
13
6.2 Switches control signal and illumination
1. Refer the attached I/O chart and the schematic.
2 . To adjust DIP, please refer the I/O chart. The initial setting is in capitalization.
3．Adjust DIP：（the initial setting）
The above are subject change without notice.
The parameters Adjustment of the game, setting the DIP SW to change the parameters,
the detail as below:
① Coin(s)(A):
Coins(A) Options SW11 SW12 Note
SW11
～
SW12
4 on on Insert 4 coin play 1 games
3 off on Insert 3 coin play 1 games
2 on off Insert 2 coin play 1 games
1 OFF OFF Insert 1 coin play1 games
②Time per Game:
Time per Game Options SW13 SW14 SW15 Note
SW13
～
SW15
300 on on on 300 seconds/game
240 off on on 240 seconds/game
180 on off on 180 seconds/game
120 off off on 120 seconds/game
90 on on off 90 seconds/game
75 OFF ON OFF 75 seconds/game
60 on off off 60 seconds/game
45 off off off 45 seconds/game
③Background:
Select the background music for the game
Background Options SW16 SW17 Note
SW16
～
SW17
Alternate 2 ON ON
T
he music 1 and music 2 play in
alternate every game.
Alternate 1 on on
T
he music 1 and music 2 play in
alternate every dialysis .
Music 1 on off Play Music1 only
Music 2 off off Play Music 2 only.
④State:
State Options SW16 Note
SW18 Testing on
Setting it to enter the test model
Working OFF Setting it to the working model
※ Please refer the I/O chart and the main board figure.
12345678
SW1 ON DIP

Ocean carousel Manual
14
7. ERROR MESSAGE AND RECOVERY
7.1Trouble Shootings
Please confirm whether every connector connected tightly.
Symptom Possible Cause Recommended action
Game will not
start
Frame assembly connector fell or
is loose Plug in connector tightly.
Frame assembly fault Contact with UNIS Service.
Power cutting Circuit protector make power SW
in cutting state
Turn on power SW again. If appeared
again and again, machine has
anomaly. Please contact with UNIS
Service.
Game will not
coin up
Coin mech. fault or sample coin
not installed. Change coin mech. or sample coin.
Coin mech. signal cable loose. Check coin mech. signal cable loose.
IO control board no signal. Change IO board.
No sound
Volume set too low. Raise the volume.
Connector loose. Plug in connector tightly.
PCB fault. Change PCB.
Speaker fault. Change speaker.
POT installation error. Install POT correctly.
POT fault. Change POT.

Ocean carousel Manual
15
8. MAINTENANCE & INSPECTION
8.1 Safety Check
Check the points listed before operating the machine. These checks are necessary for safe
machine operation:
1. Test game before operation each day.
2. Conduct monthly routine checks of game components ensure good working condition
3. Check the machine regularly for dust and clean when necessary.
Note: Parts and components require preventative maintenance to maintain proper
operation.
• Before servicing the machine, be sure to turn power off. Servicing without turning the
power off can cause electric shock or short circuit.
• To avoid electric shock or short circuit, do not plug then unplug the power quickly
• Do not expose power cords and earth wires, these are susceptible to damage.
• Damaged cords and wires can cause electric shock or short circuit and should be
replaced immediately.
• When or after installing the product, avoid pulling the power cord to prevent
unnecessary wear and tear. Use the power button to disconnect power.
• In case the power cord is damaged, ask for replacement through where the product was
purchased from or replace locally. Continued usage of damaged cord can cause fire,
electric shock or leakage.
• Perform grounding appropriately. Inappropriate grounding can cause electric shock.
• Use fuses that meet specified rating. Fuses exceeding can cause an electric shock.
• Should a problem occur, turn off the power immediately and stop operating the
machine. Unplug the power cord of the service outlet. Operating the machine without
correcting the problem may cause a fire or injuries.
• Insert the power plug securely into the outlet. Poor contact may cause overheating,
resulting in fire or burns.
• To ensure the warning labels attached on the machine are visible and legible, install
the machine in a well-lit location, and keep the labels clean at all times. Make sure the
labels are not hidden behind other game machines.
WARNING

Ocean carousel Manual
16
9. OVERALL CONSTRUCTION
9.1 General Assembly
NO Part No. Code Name Material & SPEC. QTY
1O101-348-000 206.5.08.16.009
Marquee decal Plexi. 3
2 O101-436-000 2.22.02.010003
Led light bracket MR16 3
3 O101-601-000 204.5.08.16.001 Header Fiber glass 1
4 O101-355-000 206.5.08.16.003 Light cover Plexi. 15
5 O101-432-000 2.20.03.000006
Light bulb 15
O101-433-000 2.22.01.000090 Light socket 12V/3W 15

Ocean carousel Manual
17
NO Part No. Code Name Material & SPEC. QTY
6 O101-434-000 2.17.04.000078 Light board seaLMP001.PCB 15
7 O101-422-000 2.28.01.000022
Speaker 'MULKA/4.0"/4Ω/10W 2
O101-349-000 202.5.08.16.036 Speaker net cover Q235 2
8 O101-431-000 2.27.02.000002 Fan SUNON DP200A 1
9
O101-602-000 204.5.08.16.002 Header plate Fiber glass 1
O101-336-000 202.5.08.16.017
Header connected
embedded part Q235 1
10
O101-603-000 204.5.08.16.003 Pillar Fiber glass 1
O101-335-000 202.5.08.16.016
Pillar(fiber glass)
embedded part Q235 1
O101-353-000 206.5.08.16.007 Pillar soft pad Soft rubber 1
11 O101-419-000 2.24.01.080001 Red button(M) 3
12 O101-435-000 2.20.04.000007 Led light DC12V/MR16-18 3
13 O101-342-000 202.5.08.16.021 Up decoration Stainless steel 3
14 O101-340-000 202.5.08.16.019 Stainless steel pillar Stainless steel 3
15 O101-605-000 204.5.08.16.005
Horse Fiber glass 1
O101-343-000 202.5.08.16.022 Horse embedded part Q235 1
16 O101-608-000 204.5.08.16.008 Base fiber glass fiber glass 1
17 O101-346-000 202.5.08.16.025 Horse handle Stainless steel 1
18
O101-604-000 204.5.08.16.004 Fish Fiber glass 1
O101-344-000 202.5.08.16.023 Fish embedded part Q235 1
O101-347-000 202.5.08.16.026 Fish handle Stainless steel 1
19 O101-606-000 204.5.08.16.006
Turtle Fiber glass 1
O101-345-000 202.5.08.16.024 Turtle embedded part Q235
20 O101-414-000 2.66.000186 Seat belt 1
O101-358-000 HYSJ.35 Seat belt fixed part 1
21 O101-341-000 202.5.08.16.020 Bottom decoration Stainless steel 3
22 O101-338-000 202.5.08.16.034 Coin box frame Q235 1
23 O101-356-000 202.5.08.16.040 Locking blade Q235 1
24 O101-402-000 2.53.02233001 Lock 2233 1
25 O101-418-000 2.23.01000001
Coin mech. 1
O101-420-000 2.24.01.000011 Red button(S) 3
26 O101-412-000 2.51.02.000039 Handle rubber WH125 6
27 O101-326-000 2.60.00009000 Leveller 4
28
O101-354-000 206.5.08.16.008 Wave soft pad Soft rubber 3
O101-607-000 204.5.08.16.007 Wave Fiber glass 3
O101-351-000 202.5.08.16.038 Wave mounting part Q235 9
29 O101-350-000 202.5.08.16.037 Pedal Aluminum plate 3
30 O101-356-000 202.5.08.16.040 Locking blade Q235 1
31 O101-401-000 2.53.02222001 Lock 2222 1
32 O101-339-000 202.5.08.16.035 Coin box Q235 1
33 O101-608-000 204.5.08.16.008 Base fiber glass fiber glass 1
34 O101-411-000 2.55.01.000056 2.5” caster 4
