Advantech PPC-4150W User manual

User Manual
PPC-4150W
Intel® Atom D2550 processor
basedmicrocomputer,with15.6"
color TFT LCD display

PPC-4150W User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2013
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows is registered trademark of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 200K415020 Edition 1
Printed in China October 2013

iii PPC-4150W User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact your local supplier for
ordering information.
CE
This product has passed the CE test for environmental specifications. Test conditions
for passing included the equipment being operated within an industrial enclosure. In
order to protect the product from being damaged by ESD (Electrostatic Discharge)
and EMI leakage, we strongly recommend the use of CE-compliant industrial enclo-
sure products.
FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Technical Support and Assistance
1. Visit the Advantech web siteat http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

PPC-4150W User Manual iv
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

v PPC-4150W User Manual
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.
Battery Information
Batteries, battery packs and accumulators should not be disposed of as unsorted
household waste. Please use the public collection system to return, recycle, or treat
them in compliance with the local regulations.

PPC-4150W User Manual vi

vii PPC-4150W User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ...............................................................................................2
1.2 Specifications............................................................................................2
1.2.1 Specification Comparison.............................................................2
1.2.2 General Specifications..................................................................3
1.2.3 Power Specifications.....................................................................3
1.2.4 Touchscreen Specifications..........................................................3
1.2.5 Environment Specifications...........................................................3
1.2.6 Certification Specifications............................................................4
1.2.7 IP ..................................................................................................4
1.3 Dimensions ...............................................................................................5
Figure 1.1 PPC-4150W dimensions ............................................5
Chapter 2 System Installation & Setup ...............7
2.1 Quick Start Guide......................................................................................8
Figure 2.1 Front panel .................................................................8
Figure 2.2 Side view....................................................................8
Figure 2.3 Location of I/O interfaces............................................9
Figure 2.4 Grounding screw ........................................................9
Figure 2.5 PCI expansion slot......................................................9
2.2 Installation Procedures............................................................................10
2.2.1 Connect Power Cable.................................................................10
Figure 2.6 Connect power cable................................................10
2.2.2 Connect Keyboard and Mouse ...................................................10
2.3 Install Memory Card................................................................................11
Figure 2.7 ..................................................................................11
Figure 2.8 ..................................................................................11
Figure 2.9 ..................................................................................11
Figure 2.10..................................................................................11
Figure 2.11..................................................................................11
Figure 2.12..................................................................................11
2.4 Install HDD..............................................................................................12
Figure 2.13..................................................................................12
Figure 2.14..................................................................................12
Figure 2.15..................................................................................12
Figure 2.16..................................................................................12
Figure 2.17..................................................................................12
Figure 2.18..................................................................................12
2.5 Install Mini SATA.....................................................................................13
Figure 2.19..................................................................................13
Figure 2.20..................................................................................13
2.6 Install Wireless LAN Card .......................................................................13
Figure 2.21..................................................................................13
Figure 2.22..................................................................................13
Figure 2.23..................................................................................14
Figure 2.24..................................................................................14
Figure 2.25..................................................................................14
Figure 2.26..................................................................................14
Figure 2.27..................................................................................15
2.7 Install the Riser Card...............................................................................15
Figure 2.28..................................................................................15
Figure 2.29..................................................................................15
Figure 2.30..................................................................................16

PPC-4150W User Manual viii
Figure 2.31 ................................................................................. 16
Figure 2.32 ................................................................................. 16
2.8 AT/ATX Function Switch......................................................................... 16
Figure 2.33ATX mode ................................................................ 16
Figure 2.34AT mode................................................................... 16
2.9 Grounding Installation............................................................................. 17
Figure 2.35 ................................................................................. 17
Figure 2.36 ................................................................................. 17
Figure 2.37 ................................................................................. 17
Figure 2.38 ................................................................................. 17
2.10 Hook Installation ..................................................................................... 18
Figure 2.39Hook Installation....................................................... 18
2.11 Independent Quick Installation................................................................ 19
2.12 Cradle Installation Description................................................................ 20
Chapter 3 Jumper Configuration ...................... 21
3.1 Jumper & Connectors............................................................................. 22
Figure 3.1 PCM-8208 front view................................................ 22
3.2 External COM PORT & DIO Switch and PIN Definition.......................... 23
Figure 3.2 COM ports................................................................ 23
Chapter 4 Software Configuration ....................25
4.1 Install Divers ........................................................................................... 26
Figure 4.1 Divers in the CD-ROM.............................................. 26
4.2 BIOS Setup............................................................................................. 27
4.2.1 Enter BIOS.................................................................................. 27
4.2.2 Display Brightness Adjustment................................................... 28
4.2.3 COM2 Mode Selection (RS232/422/485)................................... 30
4.2.4 COM1 & COM2 Pin9 Function Selection.................................... 31
4.2.5 Wake Up by LAN........................................................................ 32

Chapter 1
1General Information
This chapter gives background
information on PPC-4150W panel
PC.
Sections include:
Introduction
Specifications
Dimensions

PPC-4150W User Manual 2
1.1 Introduction
Advantech PPC-4150W are Intel Atom processor based panel PCs with 15.6" color
LCD. Powerful D2550 and Intel NM10 chipset not only meet with most application
requirements, but also ensure the operation reliability under all environments. Built-in
Mini SATA interface can be used as backup HDD solution for OS bootup; Mini PCIe
card interface supports various expansion cards (e.g. wireless LAN) to increase the
device mobility. For safety consideration, PPC-4150W provides 2 Giga LAN configu-
ration. In addition, 4 serial ports and 5 USB V2.0 interfaces make the product suit for
all kinds of advanced applications.
1.2 Specifications
1.2.1 Specification Comparison
Product PPC-4150W
LCD Specification 15.6’’ LCD
Display Type 15.6" TFT LCD (LED backlight)
Max. Resolution 1366 x 768
Color 16.7M
dot matrix 252 (per one triad) x 252 um
Viewing Angle 85 (left), 85 (right),
80 (top), 60 (bottom) (Typ.)
Brightness 300 cd/d2 (Typ.)
Contrast 500 (Typ.)
LCD Operation
Temperature 0 ~ 60° C (32 ~ 140° F)
Backlight Lifecycle 50, 000 hours
Weight 5.46 Kg (12.04 lb)
Dimensions 419.7 x 269 x 59 (mm)
(16.52" x 10.59" x 2.32")

3 PPC-4150W User Manual
Chapter 1 General Information
1.2.2 General Specifications

1.2.3 PowerSpecifications
1.2.4 Touchscreen Specifications
1.2.5 EnvironmentSpecifications
CPU D2550 1.86G 1M
Chipset Intel Atom D2550 + NM10
Memory One 204 pin slot, up to 4 G DDR3 SDRAM
Storage Support one 2.5" SATA HDD
Network(LAN1, LAN2) 2 x Gigabit Ethernet ports
I/O Ports
4 x COM port: 1 x RS-232/422/485; 3 x RS232
5 x USB2.0
2 x Gigabit Ethernet ports
1 x VGA port, 1 x DIO port
1 x Line-out port,1 x Mic-in port, 2 x 1 W speaker (built-in)
1 x Phoenix power port, 1 x Power switch
Expansion Slot 1 x PCIe x1 (standard)
1 x PCI (in the accessory box)
Additional Expansion Slot 1 x Mini PCIe long card slot and 1 x mSATA card slot
System Win XPE / WES 7 / WIN CE 7.0 / Linux
Power
(D2550-NM10) 36 W (test system: Windows7 32bit)
33 W (test system: Windows XP 32bit)
Output Voltage 12 - 30 Vdc, 5 ~ 2 A
Note! The above test conditions are detailed in Note 1.
Type 4-wire projective captive touchscreen (multi-touch function is
only supported in Win 7 or WES 7P OS)
Light Transmission 88%+/-5%
Controller USB interface
Operation Temperature 0 ~ 50° C (32 ~ 122° F)
Storage Temperature -20 ~ 60° C (-4 ~ 140° F)
Relative Temperature 10 ~ 95% @ 40° C (non-condensing)
Shock 10 G peak acceleration (11 msec duration)
Vibration 5 ~ 500 Hz 1 G RMS

PPC-4150W User Manual 4
1.2.6 CertificationSpecifications
1.2.7 IP
Note 1:
PPC-4150W's power test conditions are as follows:
EMC BSMI, CE, FCC Class B
Safety CB, CCC, UL
Front Panel IP Grade IP65
Test
Software Test Configuration Test System
Burn-in 7.0
Memory: Transcend DDR3 1333 SODIMM 4 GB x 1
HDD: Seageat 500G 2.5” SATA II
IO: COM Port RS232 loopback x4, USB2.0 device x3,
USB mouse x1
Windows 7 32bit
Windows XP 32bit

5 PPC-4150W User Manual
Chapter 1 General Information
1.3 Dimensions
Figure 1.1 PPC-4150W dimensions
Note! Supports VESA 100 x 100 mm; please use M4 screw, 6 mm depth
(maximum).Use suitable mounting apparatus to avoid risk of
injury.

PPC-4150W User Manual 6

Chapter 2
2System Installation &
Setup
Sections include:
Quick Installation Guide
Inslation Procedures
Install Memory
Install HDD
Install Mini SATA
Install Wireless LAN
Install Expansion Card
AT/ATX Function Switch
Grounding Installation
Hook Installation
Independent Quick Installation

PPC-4150W User Manual 8
2.1 Quick Start Guide
Before you start to set up the panel PC, take a moment to become familiar with the
locations and purposes of the controls, drives, connectors and ports, which are illus-
trated in the figures below.
When you place the panel PC upright on the desktop, its front panel appears as
shown in Figure 2.1.
Figure 2.1 Front panel
1. I Key
2. Home Key
3. Power status indicator, off (S5): orange, on (S0): blue
Figure 2.2 Side view
1 2 3
1
2
3
4
5

9 PPC-4150W User Manual
Chapter 2 System Installation & Setup
1. Quick installation clip
2. Antenna hole (two)
3. Panel Mount Bracket holes (ten)
4. Side USB 2.0 interface
5. CPU cooler
I/O interfaces:
Figure 2.3 Location of I/O interfaces
A: Line out/Mic in
B: 2 x Giga Ethernet ports
C: 4 x USB 2.0
D: DIO
E: VGA
F: COM 1, 3, 4 ports, COM2 RS232/422/485 port
G: DC power port (12 - 30 V)
H: Power button
I: Speaker
J: Grounding screw (refer to Fig 2.4)
K: PCI/PCIE x1 Expansion slot (refer to Fig 2.5)
Figure 2.4 Grounding screw Figure 2.5 PCI expansion slot
I
H
A B D F G
C E
J
K

PPC-4150W User Manual 10
2.2 Installation Procedures
2.2.1 Connect Power Cable
The panel PC has DC power socket (12 ~ 30 V). When connecting the power cable,
please hold the plug end. Please follow the procedures below:
1. Connect the female end of the power cable to panel PC’s DC socket.
2. Connect the male end of the power cable to power outlet.
Figure 2.6 Connect power cable
2.2.2 Connect Keyboard and Mouse
Connect the keyboard and mouse to panel PC’s I/O interfaces.
2.2.2.1 Power ON
The power button is located in the right bottom side of the panel PC.
Note! Power cable and adapter are optional.

11 PPC-4150W User Manual
Chapter 2 System Installation & Setup
2.3 Install Memory Card
1. Loosen the screws as indicated in the red circle. (See Fig 2.6)
2. Press the red area pull out the card holder (See Fig 2.8 ~ 2.10) and open the
rear cover.
3. Remove the screws as indicated in the red circle. (See Fig 2.11), and take out
the CPU cooler.
Figure 2.7 Figure 2.8
Figure 2.9 Figure 2.10
Note! The black and grey lumps as indicated in the red circle of Fig 2.12 are
cooler pads, which must be removed by professional personnels to
avoid improper use.
Figure 2.11 Figure 2.12
Note! CPU cooler pad surface is isolated by anodization treatment to avoid
static electricity (CPU contact side excluded).

PPC-4150W User Manual 12
2.4 Install HDD
1. Please follow the procedures in Section 2.3 to open the rear cover and remove
the screws as indicated in the red circles in Fig 2.13.
2. Take down the HDD bracket from the reinforced board. (See Fig 2.14)
3. Install the HDD (see Fig 2.15), and take out the 4 screws from the accessory
box to fix the HDD.
4. Lock the HDD bracket, and take out the HDD cable from the accessory box and
connect it to the mainboard. (See Fig 2.16 ~ 2.18)
Figure 2.13 Figure 2.14
Figure 2.15
Figure 2.16
Figure 2.17 Figure 2.18
