Advantech MIOS-5250 User manual

User Manual
MIOS-5250
Fanless Embedded Box PC

MIOS-5250 User Manual ii
Attention!
Please note:
This package contains a hard-copy user manual in Chinese for China CCC certifica-
tion purposes, and there is an English user manual included as a PDF file on the CD.
Please disregard the Chinese hard copy user manual if the product is not to be sold
and/or installed in China.

iii MIOS-5250 User Manual
Copyright
The documentation and the software included with this product are copyrighted 2014
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice.
No part of this manual may be reproduced, copied, translated or transmitted in any
form or by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reliable. However,
Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements
of the rights of third parties, which may result from its use.
Acknowledgements
Award is a trademark of Award Software International, Inc.
VIA is a trademark of VIA Technologies, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Cor-
poration.
Intel® and Pentium® are trademarks of Intel Corporation.
Microsoft Windows® is a registered trademark of Microsoft Corp.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
ESS is a trademark of ESS Technology, Inc.
UMC is a trademark of United Microelectronics Corporation.
SMI is a trademark of Silicon Motion, Inc.
Creative is a trademark of Creative Technology LTD.
CHRONTEL is a trademark of Chrontel Inc.
All other product names or trademarks are properties of their respective owners.
For more information about this and other Advantech products, please visit our web-
site at:
http://www.advantech.com/
http://www.advantech.com/ePlatform/
For technical support and service, please visit our support website at:
http://support.advantech.com.tw/support/
Part No. 2006S25020 Edition 1
Printed in China June 2014

MIOS-5250 User Manual iv
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandise
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Declaration of Conformity
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.

v MIOS-5250 User Manual
Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Warnings, Cautions and Notes
Packing List
Before installation, please ensure the following items have been shipped:
1 x MIOS-5250 unit
1 x 2.5” HDD/SSD Assembly Kit
1 x Heatsink Thermal Pad Kit
1 x China RoHS
1 x Heatsink wrench
1 x Mini Jumper(10pcs package)
1 x Startup Manual
1 x Simplified Chinese user manual
Warning! Warnings indicate conditions, which if not observed, can cause personal
injury!
Caution! Cautions are included to help you avoid damaging hardware or losing
data. e.g.
There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.
Note! Notes provide optional additional information.

MIOS-5250 User Manual vi
Ordering Information
Optional Accessories
For MIOS-5250
Model Number Description
MIOS-5250NS6-D0A1E Atom N2600 1.6GHz w/ HDMI+VGA+2*GbE+4*COM+6*USB
MIOS-5250DS8-C0A1E Atom D2550 1.86GHz w/ HDMI+VGA+2*GbE+4*COM+6*USB,
12V DC Phoenix type
Part Number Description
1757003659 AC-to-DC Adapter, DC19 V/3.42 A 65 W, with Phoenix Power Plug
1757003995 AC-to-DC Adapter, DC 12V/5A 60W
1757003996 AC-to-DC Adapter, DC12V/5A 60 W, with Phoenix Power Plug
1700001524 Power Cable 3-pin 180 cm, USA Type
170203183C Power Cable 3-pin 180 cm, Europe Type
170203180A Power Cable 3-pin 180 cm, UK Type
1700008921 Power Cable 3-pin 180 cm, PSE Mark

vii MIOS-5250 User Manual
Safety Instructions
1. Please read these safety instructions carefully.
2. Please keep this User’s Manual for later reference.
3. Please disconnect this equipment from AC outlet before cleaning. Use a damp
cloth. Don’t use liquid or sprayed detergent for cleaning. Use moisture sheet or
clothe for cleaning.
4. For pluggable equipment, the socket-outlet shall near the equipment and shall
be easily accessible.
5. Please keep this equipment from humidity.
6. Lay this equipment on a reliable surface when install. A drop or fall could cause
injury.
7. The openings on the enclosure are for air convection hence protecting the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source when connecting the equipment to
the power outlet.
9. Place the power cord such a way that people cannot step on it. Do not place
anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for long time, disconnect the equipment from mains
to avoid being damaged by transient over-voltage.
12. Never pour any liquid into ventilation openings; this could cause fire or electrical
shock.
13. Never open the equipment. For safety reasons, only qualified service personnel
should open the equipment.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. Do not leave this equipment in an environment where the storage temperature
may go below -40 °C (-40° F) or above 85 °C (185° F). This could damage the
equipment. the equipment should be in a controlled environment.
16. Caution: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer, discard used
batteries according to the manufacturer's instructions.
17. Attention: Danger d'explosion en cas de remplacement incorrect de la pile.
Remplacez-la exclusivement par une batterie identique ou par un type de batte-
rie équivalent recommandé par le fabricant. La mise au rebut des batteries usa-
gées doit se faire conformément aux indications du fabricant de ces batteries.
18. The sound pressure level at the operator's position according to IEC 704-1:1982
is no more than 70 dB (A).
19. RESTRICTED ACCESS AREA: The equipment should only be installed in a
Restricted Access Area.
20. DISCLAIMER: This set of instructions is given according to IEC 704-1. Advan-
tech disclaims all responsibility for the accuracy of any statements contained
herein.

MIOS-5250 User Manual viii
Battery Information
Batteries, battery packs, and accumulators should not be disposed of as unsorted
household waste.
Please use the public collection system to return, recycle, or treat them in compliance
with the local regulations.

ix MIOS-5250 User Manual
Contents
Chapter 1 General Introduction ...........................1
1.1 Introduction ............................................................................................... 2
1.2 Product Features....................................................................................... 3
1.2.1 General ......................................................................................... 3
1.2.2 Display .......................................................................................... 3
1.2.3 Ethernet ........................................................................................ 3
1.3 Mechanical Specifications......................................................................... 4
1.3.1 Dimensions ................................................................................... 4
Figure 1.1 MIOS-5250 Mechanical dimension drawing ............... 4
1.3.2 Weight........................................................................................... 4
1.4 Power Requirement .................................................................................. 4
1.4.1 System Power............................................................................... 4
1.4.2 RTC Battery .................................................................................. 4
1.5 Environment Specification......................................................................... 5
1.5.1 Operating Temperature................................................................. 5
1.5.2 Relative Humidity .......................................................................... 5
1.5.3 Storage Temperature.................................................................... 5
1.5.4 Vibration during Operation ............................................................ 5
1.5.5 Shock during Operation ................................................................ 5
1.5.6 Safety............................................................................................ 5
1.5.7 EMC .............................................................................................. 5
Chapter 2 H/W Installation....................................7
2.1 Jumpers .................................................................................................... 8
2.1.1 Jumper Description ....................................................................... 8
2.1.2 Jumper List ................................................................................... 8
2.1.3 Jumper Settings ............................................................................ 9
2.2 Connectors.............................................................................................. 11
2.2.1 Connector List............................................................................. 11
2.3 Mechanical .............................................................................................. 12
2.3.1 Jumper and Connector Location................................................. 12
Figure 2.1 Jumper and Connector Layout (Top Side) ............... 12
Figure 2.2 Jumper and Connector Layout (Bottom Side) .......... 12
2.4 Connectors.............................................................................................. 13
2.4.1 MIOS-5250 External I/O Connectors .......................................... 13
Figure 2.3 MIOS-5250External Connector Locations (Front Side)
.................................................................................. 13
Figure 2.4 MIOS-5250 External Connector Locations (Back Side)
.................................................................................. 13
Figure 2.5 COM connector ........................................................ 13
Figure 2.6 Ethernet connector ................................................... 14
Figure 2.7 Audio connector........................................................ 15
Figure 2.8 DIO Connector (MIOS-5250).................................... 15
Figure 2.9 USB connector ......................................................... 16
Figure 2.10VGA Connector ........................................................ 16
Figure 2.11Power Input Connector............................................. 16
Figure 2.12Compatible dimension of DC Plug............................ 17
Figure 2.13Power Input Connector (MIOS-5250) ....................... 17
Figure 2.14LED Indicators .......................................................... 17
2.5 Installation ............................................................................................... 17
2.5.1 Memory and Thermal Pad Assembly.......................................... 17
Figure 2.15Tool and component list ........................................... 18
Figure 2.16Illustration for step 2 and step 4 ............................... 18

MIOS-5250 User Manual x
Figure 2.17Illustration for step 3 ................................................. 19
2.5.2 2.5" HDD/SSD Assembly............................................................ 19
Figure 2.18Components list........................................................ 19
Figure 2.19Illustration for step 1 and step 4 ............................... 20
Figure 2.20Illustration for step 2 ................................................. 20
Figure 2.21Illustration for step 3 ................................................. 21
Chapter 3 BIOS Settings .................................... 23
3.1 BIOS Setup ............................................................................................. 24
Figure 3.1 Setup program initial screen..................................... 24
3.2 Entering Setup ........................................................................................ 24
3.3 Main Setup.............................................................................................. 25
Figure 3.2 Main setup screen .................................................... 25
3.3.1 System date / System time ......................................................... 25
3.4 Advanced BIOS Features Setup............................................................. 26
Figure 3.3 Advanced BIOS features setup screen .................... 26
3.4.1 Advantech BIOS Update V1.3 .................................................... 26
3.4.2 ACPI Settings ............................................................................. 27
Figure 3.4 ACPI Setting............................................................. 27
3.4.3 TPM Configuration...................................................................... 28
Figure 3.5 TPM Configuration ................................................... 28
3.4.4 CPU Configuration...................................................................... 28
Figure 3.6 CPU Configuration ................................................... 28
3.4.5 SATA Configuration .................................................................... 29
Figure 3.7 SATA Configuration.................................................. 29
3.4.6 Intel Fast Flash Standby ............................................................. 30
Figure 3.8 Intel Fast Flash Standby........................................... 30
3.4.7 USB Configuration ...................................................................... 30
Figure 3.9 USB Configuration.................................................... 30
3.4.8 Embedded Controller Configuration ........................................... 31
Figure 3.10Embedded Controller Configuration ......................... 31
3.4.9 Super I/O Configuration .............................................................. 32
Figure 3.11Super IO Configuration............................................. 32
3.4.10 AOAC Configuration ................................................................... 33
Figure 3.12AOAC Configuration................................................. 33
3.4.11 PPM Configuration...................................................................... 33
Figure 3.13PPM Configuration ................................................... 33
3.5 Chipset Configuration ............................................................................. 34
Figure 3.14Chipset Setup........................................................... 34
3.5.1 Host Bridge/Intel IGD Configuration ........................................... 35
Figure 3.15Intel IGD Configuration............................................. 35
3.5.2 South Bridge ............................................................................... 36
Figure 3.16South Bridge............................................................. 36
Figure 3.17TPT Device............................................................... 37
3.6 Boot Settings........................................................................................... 38
Figure 3.18Boot Setup Utility...................................................... 38
3.7 Security Setup......................................................................................... 39
Figure 3.19Password Configuration ........................................... 39
3.8 Save & Exit ............................................................................................. 40
Figure 3.20Save & Exit............................................................... 40
3.8.1 Save Changes and Exit .............................................................. 40
3.8.2 Discard Changes and Exit .......................................................... 40
3.8.3 Save Changes and Reset........................................................... 40
3.8.4 Discard Changes and Reset....................................................... 40
3.8.5 Save Changes ............................................................................ 40
3.8.6 Discard Changes ........................................................................ 41
3.8.7 Restore Defaults ......................................................................... 41
3.8.8 Save User Defaults..................................................................... 41

xi MIOS-5250 User Manual
3.8.9 Restore User Defaults................................................................. 41
3.8.10 Boot Override.............................................................................. 41
Appendix A Pin Assignments ...............................43
Appendix B System Assignments ........................65
B.1 System I/O Ports ..................................................................................... 66
B.2 DMA Channel assignments..................................................................... 66
B.3 1st MB memory map ............................................................................... 67
B.4 Interrupt assignments.............................................................................. 67
Appendix C Watchdog Timer Sample Code.........69
C.1 EC Watchdog Timer sample code .......................................................... 70

MIOS-5250 User Manual xii

Chapter 1
1General Introduction
This chapter gives background
information on MIOS-5250 series.

MIOS-5250 User Manual 2
1.1 Introduction
MIOS-5250, an intelligent, fanless embedded system powered by Intel®Atom™
N2600/D2550 Dual Core low power processor with multiple I/O interface. The new
generation Intel®Atom™ processor brings 44% improvement on processing power
and 90% on graphics performance than previous generation Intel®Atom™ proces-
sors. These low-power platforms provide energy-efficient and environmentally
responsible solutions, and serve applications targeted at factory automation,
machine automation, kiosks, and self-service applications; and they operate reliably
in 0 ~ 45 °C environments!
Multifunctional Design
MIOS-5250 is powered by Intel®Atom™ N2600 1.6GHz/D2550 1.86GHz dual core
processors in an Advantech, embedded box PC. All models are fanless, and highlight
various quality features including wide-input power supplies from 12V to 24V, wide
temperature range 0 ~ 45 °C, expandability options, and structural strengthening. It
also provides rich I/O interfaces: up to 6 x USBs, 2 x GbEs, 4 x COMs, and more I/O
via MI/O extension module, and also supports high capacity 2.5” HDD up to 1 TB.
Multiple Display Support
MIOS-5250 supports multiple display types: VGA, HDMI or LVDS display (by
request). The graphic engine is DirectX 9, H/W format decode/Acceleration, MPEG2
(H/W acceleration), H.264/ VC1/ WMV9 (H/W Decode/Acceleration). MIOS-5250
supports dual independent display.
Built in Intelligent Management Tools - Advantech iManager & SUSIAccess
Advantech iManager provides a valuable suite of programmable APIs such as multi-
level watchdog, hardware monitor, system restore, and other user-friendly interface.
iManager is an intelligent self-management cross platform tool that monitors system
status for problems and takes action if anything is abnormal. iManager offers a boot
up guarantee in critical, low temperature environments. iManager makes the whole
system more reliable and more intelligent. MIOS-5250 also supports Advantech’s
own SUSIAccess, which provides easy remote management so users can monitor,
configure, and control a large number of terminals to make maintenance and system
recovery more simple.

3 MIOS-5250 User Manual
Chapter 1 General Introduction
1.2 Product Features
1.2.1 General
CPU: Intel®Atom™ Processor N2600 1.6GHz/D2550 1.86GHz
System Chipset: Intel®Atom™N2600/D2550 + NM10
BIOS: AMI EFI 16-Mbit
System Memory: One DDR3 SODIMM. DDR3 1066 MHz (D2550) or DDR3
800 MHZ (N2600) up to 4 GB
Watchdog Timer: 255-level interval timer, by software setup
I/O Interface: 2 x RS-232, 2 x RS-232/422/485 (default RS-232, RS-422/485
supported by request)
USB: 6 x USB 2.0 compliant ports
Audio: High Definition Audio (HD), Line-in, Line out, Mic-in
DIO: 8 bits general purpose input/output
Storage: 1 x 2.5” SATA HDD (up to 11.5mm height) and 1 x CFast (support by
request)
Expansion Interface: Supports 1 x Mini-PCIe with SIM holder and MIOe for
MI/O extension module
Software API: Advantech iManager and SUSIAccess
1.2.2 Display
Controller: Intel®Atom™ N2600 / D2550
Resolution:
–VGA: Supports up to 1920 x 1200
–HDMI: Supports up to 1920 x 1200,Supports HDMI 1.3, Max data rate up to
1.65Gb/s
–LVDS (support by request):
N2600: 24-bit LVDS1, resolution up to1366 x 768
D2550: 24-bit LVDS1, resolution up to 1440 x 900, 48-bit LVDS2, resolution
up to 1920 x 1080
Dual Display:
–VGA+HDMI, VGA+LVDS, HDMI+LVDS
1.2.3 Ethernet
Chipset:
–LAN1 Intel 82583V
–LAN2 Intel 82583V
Speed: 10/100/1000 Mbps
Interface: 2 x RJ45

MIOS-5250 User Manual 4
1.3 Mechanical Specifications
1.3.1 Dimensions
284.6[11.2] x 151.6[5.96] x 74.5[2.9] Unit: mm [Inch]
Figure 1.1 MIOS-5250 Mechanical dimension drawing
1.3.2 Weight
2.3 kg (5.07 lb)
1.4 Power Requirement
1.4.1 System Power
Minimum power input: MIOS-5250: DC12 V 5A
1.4.2 RTC Battery
Lithium 3 V/210 mAH

5 MIOS-5250 User Manual
Chapter 1 General Introduction
1.5 Environment Specification
1.5.1 Operating Temperature
With 2.5-inch hard disk 0 to 45 °C (32~113° F), with air flow, speed=0.7 m/sec
1.5.2 Relative Humidity
95% @ 40 °C (non-condensing)
1.5.3 Storage Temperature
-40 ~ 85 °C (-40 ~ 185° F)
1.5.4 Vibration during Operation
When system is equipped with SSD: 3Grms, IEC 60068-2-64, random, 5 ~ 500
Hz, 1hr/axis, x,y,z 3 axes.
1.5.5 Shock during Operation
When system is equipped with SSD: 10G, IEC 60068-2-27, half sine, 11 ms
duration.
1.5.6 Safety
UL, CCC, CB
1.5.7 EMC
CE, FCC, CCC

MIOS-5250 User Manual 6

Chapter 2
2H/W Installation
This chapter introduces external
IO and the installation of MIOS-
5250 hardware.

MIOS-5250 User Manual 8
2.1 Jumpers
2.1.1 Jumper Description
Cards can be configured by setting jumpers. A jumper is a metal bridge used to close
an electric circuit. It consists of two metal pins and a small metal clip (often protected
by a plastic cover) that slides over the pins to connect them. To close a jumper, you
connect the pins with the clip. To open a jumper, you remove the clip. Sometimes a
jumper will have three pins, labeled 1, 2 and 3. In this case you would connect either
pins 1 and 2, or 2 and 3.
The jumper settings are schematically depicted in this manual as follows.
A pair of needle-nose pliers may be helpful when working with jumpers. If you have
any doubts about the best hardware configuration for your application, contact your
local distributor or sales representative before you make any changes.
2.1.2 Jumper List
Warning! To avoid damaging the computer, always turn off the power supply
before setting jumpers to clear CMOS. Before turning on the power sup-
ply, set the jumper back to 3.0 V Battery On.
Table 2.1: Jumpers
Label Function
J1 24-bit LVDS1 Power
J2 48-bit LVDS2 Power
J3 Auto Power on setting
J4 COM2 Setting
J5 COM3 setting
J6 Clear CMOS
