Advantech UNO-2050G User manual

UNO-2050G
LX800 500MHz Automation Computer
with 2 x LAN, 2 x RS-232, 2 x Isolated
RS-232/422/485,16 x Isolated DI/O
User Manual

UNO-2050G User Manual ii
Copyright
The documentation and the software included with this product are copy-
righted 2010 by Advantech Co., Ltd. All rights are reserved. Advantech
Co., Ltd. reserves the right to make improvements in the products
described in this manual at any time without notice. No part of this man-
ual may be reproduced, copied, translated or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reli-
able. However, Advantech Co., Ltd. assumes no responsibility for its use,
nor for any infringements of the rights of third parties, which may result
from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of
Microsoft Corp.
All other product names or trademarks are properties of their respective
owners.
Part No. 2003205012 3rd Edition
Printed in Taiwan October 2010

iii
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its prod-
ucts will be free from defects in materials and workmanship for two years
from the date of purchase.
This warranty does not apply to any products which have been repaired or
altered by persons other than repair personnel authorized by Advantech,
or which have been subject to misuse, abuse, accident or improper instal-
lation. Advantech assumes no liability under the terms of this warranty as
a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous test-
ing, most of our customers never need to use our repair service. If an
Advantech product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will
be billed according to the cost of replacement materials, service time and
freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU speed, Advantech products used, other hardware
and software used, etc.) Note anything abnormal and list any
onscreen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your man-
ual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandize authorization) number from your dealer. This allows
us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and
Replacement Order Card and a photocopy proof of purchase date
(such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for war-
ranty service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.

UNO-2050G User Manual iv
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications
when shielded cables are used for external wiring. We recommend the use
of shielded cables. This kind of cable is available from Advantech. Please
contact your local supplier for ordering information.
FCC Class A
Note: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful inter-
ference in which case the user will be required to correct the interference
at his own expense.
Technical Support and Assistance
Step 1. Visit the Advantech web site at www.advantech.com/support
where you can find the latest information about the product.
Step 2. Contact your distributor, sales representative, or Advantech's cus-
tomer service center for technical support if you need additional
assistance. Please have the following information ready before
you call:
- Product name and serial number
- Description of your peripheral attachments
- Description of your software (operating system, version, appli-
cation software, etc.)
- A complete description of the problem
- The exact wording of any error messages

v
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this user manual for later reference.
3. Disconnect this equipment from DC outlet before cleaning. Do not
use liquid or spray detergents for cleaning.
4. For pluggable equipment, the power outlet shall be installed near
the equipment and shall be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Drop-
ping it or letting it fall could cause damage.
7. Make sure the voltage of the power source is correct before con-
necting the equipment to the power outlet.
8. Place the power cord such a way that people can not step on it. Do
not place anything over the power cord. The voltage and current
rating of the cord should be greater than the voltage and current rat-
ing marked on the product.
9. All cautions and warnings on the equipment should be noted.
10. If the equipment is not used for long time, disconnect it from the
power source to avoid being damaged by transient over-voltage.
11. When power core is connected, never open the equipment. For
safety reasons, the equipment should be opened only by qualified
service personnel.
12. If any of the following situations arises, get the equipment checked
by service personnel:
A. The power cord or plug is damaged.
B. Liquid has penetrated into the equipment.
C. The equipment has been exposed to moisture.
D. The equipment does not work well or you cannot get it to work
according to user manual.
E. The equipment has been dropped and damaged.
F. The equipment has obvious signs of breakage.
13. CAUTION: The computer is provided with a battery-powered
real-time clock circuit. There is a danger of explosion if battery is
incorrectly replaced. Replace only with same or equivalent type

UNO-2050G User Manual vi
recommended by the manufacture. Discard used batteries accord-
ing to the manufacturer’s instructions.
14. This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
15. CAUTION: Always completely disconnect the power cord from
your chassis whenever you work with the hardware. Do not make
connections while the power is on. Sensitive electronic components
can be damaged by sudden power surges.
16. CAUTION: Always ground yourself to remove any static charge
before touching the motherboard, backplane, or add-on cards. Mod-
ern electronic devices are very sensitive to static electric charges.
As a safety precaution, use a grounding wrist strap at all times.
Place all electronic components on a static-dissipative surface or in
a static-shielded bag when they are not in the chassis.
17. CAUTION: Any unverified component could cause unexpected
damage. To ensure the correct installation, please always use the
components (ex. screws) provided with the accessory box.
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the
products from damage.
1. To avoid electrical shock, always disconnect the power from your
PC chassis before you work on it. Don't touch any components on
the CPU card or other cards while the PC is on.
2. Disconnect power before making any configuration changes. The
sudden rush of power as you connect a jumper or install a card may
damage sensitive electronic components.

vii
Contents
Chapter 1 Overview .......................................................... 2
1.1 Introduction ....................................................................... 2
1.2 Hardware Specifications ................................................... 2
1.3 UNO-2050G Series ........................................................... 5
1.4 Chassis Dimensions........................................................... 6
Figure 1.1:Chassis Dimensions ...................................... 6
2.1 UNO-2050G Peripherals ................................................... 8
Figure 2.1:UNO-2050G Front Panel ............................. 8
Figure 2.2:UNO-2050G Rear Panel ............................... 8
2.2 COM1 & 2: RS-232 Interfaces.......................................... 8
2.3 COM3 & 4: Isolated 5-wire RS-232/422/485 ................... 8
Table 2.1:Serial Port Default Setting ............................. 8
2.4 Onboard Isolated Digital Input.......................................... 9
Figure 2.3:Digital Input Connector Pin Assigns ........... 9
Table 2.2:Digital Input Signal Description .................. 10
Figure 2.4:Isolated Digital Input Connection .............. 10
Table 2.3:Interrupt Control Register Bit Map ............. 11
Table 2.4:Interrupt Disable/Enable C. Bit Values ....... 12
Table 2.5:Interrupt Triggering Edge C. Bit Values ..... 12
Table 2.6:Interrupt Flag Bit Values ............................. 12
2.5 Onboard Isolated Digital Output..................................... 13
Figure 2.5:Digital Output Connector Pin Assigns ...... 13
Table 2.7:Digital Output Signal Description ............... 13
Table 2.8:JP12 DO Power On Configuration .............. 14
Figure 2.6:Isolated Digital Output Connection ............ 14
2.6 Onboard Isolated Counter/Timer .................................... 15
Table 2.9:Counter/Timer Control Register Bit Map .... 16
Figure 2.7:Counter 0 Function Block .......................... 17
Figure 2.8:Counter 1 Function Block .......................... 17
Figure 2.9:32-bit Counter Function Block ................... 18
Table 2.10:Counter Clock Source Control Bit ............. 18
Table 2.11:Counter Internal Clock Control Bit ........... 18
Table 2.12:Counter Gate Source Control Bit ............... 19
Table 2.13:Counter Output Destination ....................... 19
Table 2.14:Counter Interrupt Flag Control Bit ............ 20
Table 2.15:32-bit Counter Control Bit ......................... 20
2.7 LAN: Ethernet Connector ............................................... 20
2.8 Power Connector ............................................................. 21
2.9 LED Indicators ................................................................ 21
2.10 PS/2 Keyboard and Mouse Connector ............................ 21
2.11 VGA: VGA Display Connector ...................................... 21
2.12 Programmable LED and Buzzer ..................................... 21
Table 2.16:LED & Buzzer Control Register Bit Map . 21
Table 2.17:Programmable LED Control Bit ................ 22
Table 2.18:Programmable Buzzer Control Bit ............ 22
2.13 RESET: Reset Button...................................................... 22

UNO-2050G User Manual viii
Chapter 3 Initial Setup.................................................... 24
3.1 Insert CompactFlash Card .............................................. 24
3.2 Chassis Grounding .......................................................... 24
Figure 3.1:Chassis Grounding Connection .................. 24
3.3 Connect the Power .......................................................... 25
3.4 Wiring Considerations..................................................... 25
3.5 BIOS Setup and System Assignments ............................ 25
3.6 HDD Extension Flexibility.............................................. 26
Appendix A Pin Assignments ............................................ 28
A.1 Board Connector and Jumpers ........................................ 28
Figure A.1:Connector & Jumper Locations (Top) ....... 28
Figure A.2:Connector & Jumper Locations (Bottom) . 28
Table A.1:UNO-2050G Connectors & Jumpers .......... 29
A.2 Standard RS-232 Serial Port ........................................... 30
Table A.2:RS-232 Serial Port Assignments ................ 30
A.3 Isolated RS-232/422/485 Ports........................................ 31
Table A.3:Isolated RS-232/422/485 Port Assigns ....... 31
Table A.4:Jumpers to Select RS-232/422/485 ............. 31
Table A.5:Auto Flow&Master/Slave Select ................ 32
Table A.6:JP7 RS-422/485 Terminal Resistor Setting 33
Figure A.3:RS-485 Wiring Topology .......................... 34
A.4 Ethernet RJ-45 Connector (LAN1~LAN2)..................... 34
Table A.7:Ethernet RJ-45 Connector Pin Assigns ....... 34
A.5 Phoenix Power Connector (CN3).................................... 35
Table A.8:Phoenix Power Connector Pin Assigns ...... 35
A.6 PS/2 Keyboard & Mouse Connector............................... 35
Table A.9:Keyboard & Mouse Connector Pin Assigns 35
A.7 VGA Display Connector (VGA1)................................... 36
Table A.10:VGA Adaptor Cable Pin Assigns ............. 36
A.8 CompactFlash Master/Slave Jumper Settings (JP3)........ 37
A.9 Enhanced IDE Connector (CN2)..................................... 38
Table A.11:IDE Hard Drive Connector ....................... 38
A.10 UNO-2050G Control Register ........................................ 39
Table A.12:UNO-2050G Control Register .................. 39

2
CHAPTER
1
Overview
This chapter gives background infor-
mation on the UNO-2050G, including
an overview and specifications.
Sections include:
• Introduction
• Hardware Specifications
• Safety Precautions
• UNO-2050G Series
• Chassis Dimensions

UNO-2050G User Manual 2
Chapter 1 Overview
1.1 Introduction
Leveraging field-approved and worldwide-awareness real-time OS tech-
nology, Advantech UNO-2000 series provides Windows CE, WES 2009,
and embedded linux ready solution and support several standard network-
ing interfaces, such as Ethernet, Wireless LAN, RS-232/422/485 and
more. Because of its openness, great expansion capability and reliable
design – fanless and diskless, Advantech UNO-2000 series becomes an
ideal embedded platform to implement custom applications in diversified
applications.
1.2 Hardware Specifications
CPU: AMD Geode LX800-500
Chipset: AMD CS5536
BIOS: AWARD 4Mbit FLASH BIOS
RAM: 256MB DDR RAM on board
VGA: Supports VGA and VESA
- Display memory: 1 ~ 16 MB share memory, set in BIOS
- CRT display mode: Non-interlaced CRT monitors resolutions up to
1280 x 1024 @ 256 colors or 1024 x 768 @ 24 bit
- DB-15 VGA connector
Serial Port: Two standard RS-232 ports
- Data bits: 5, 6, 7, 8
- Stop bits: 1, 1.5, 2
- Parity: none, even, odd
- Speed: 50~115.2K bps
- Data signals: TxD, RxD, RTS, CTS, DTR, DSR, DCD, RI, GND
- Max data distance: 50 feet (15.2 meters)
Serial Port: 2 x 5-wire RS-232/422/485
- Automatic RS-485 data flow control
- 2000 VDC surge protection and 1500 VDC isolation
- Stop bits: 1, 1.5, 2

3 Chapter1
- Parity: non, even, odd
- RS-232 Speed: 50 ~ 230.4 Kbps
- RS-422/485 speed: 50 ~ 921.6 Kbps
- 5-wire RS-232 data signals: TxD, RxD, RTS, CTS, GND
- RS-422 data signals: TxD+, TxD-, RxD+, RxD-, GND
- RS-485 data signals: DATA+, DATA-, GND
- RS-232 max data distance: 50 feet (15.2 meters)
- RS-422/485 max data distance: 4000 feet (1200 meters)
- Plug-in screw-terminal block: Accepts 0.5 mm2to 2.5 mm2,
1 - #12 or 2 - #14 to #22 AWG
Ethernet Port: Dual 10/100Base-T Ethernet
- LAN chip: Realtek 8139DL chipset supports
- LED on the front side
8-ch Isolated Digital Input: (DI0~DI7)
- 2,000 VDC isolation, 2000 VDC ESD protection and 70 VDC
over- voltage protection
- 0 ~ 50 VDC input range and 10 KHz speed
- Input Voltage
- Logic 0: 0 ~ 3 VDC
- Logic 1: 10 ~ 50 VDC
- Input Current
- 10 VDC: 1.7 mA (typical)
- 12 VDC: 2.1 mA (typical)
- 24 VDC: 4.4 mA (typical)
- 48 VDC: 9.0 mA (typical)
-50V
DC: 9.4 mA (typical)
- Interrupt handling capability
- Plug-in screw-terminal block: Accepts 0.5 mm2to 2.5 mm2, 1 -
#12 or 2 - #14 to #22 AWG

UNO-2050G User Manual 4
8-ch Isolated Digital Output: (DO0 ~ DO7)
- 2,000 VDC isolation and 200 mA max / channel sink current
- Keep output status after system hot reset
- 5 ~ 40 VDC output range and 10 KHz speed
- Plug-in screw-terminal block: Accepts 0.5 mm2to 2.5 mm2,
1 - #12 or 2 - #14 to #22 AWG
Two 16-bit Counters/Timers:
- Counter source: DI6 & DI7, Pulse output: DO6 & DO7
- Can be cascaded as one 32-bit counter/timer
- Down counting, Preset counting value
- Interrupt handling, speed: 10 KHz
- Timer time base: 100 KHz, 10 KHz, 1 KHz, 100 Hz
SSD: One Type I / Type II CompactFlash card slot inside the chassis
HDD: Offers HDD Extension kit for installation of 1 standard 2.5" HDD.
LED: 1 power LED, 1 IDE LED, 1 programmable LED and buzzer
Keyboard/Mouse Connector: Mini Din Connector Supports
PS/2 keyboard and mouse
Power Supply Voltage: 9 ~ 30 VDC , reversed wiring protection
Power Consumption: 0.45 A max under +24 V power input or
0.9 A max.under +12 V power input
Power Requirement: 1A typical under +24 V power input or
1.5 A typical under +12 V power input
Operating Temperature: -10 ~ 55° C (14 ~ 131° F)
Chassis Size (WxLxH): 164.8 x 106.5 x 35.5 mm (6.5" x 4.2" x 1.4")
Weight: 0.8 kg

5 Chapter1
1.3 UNO-2050G Series
There are three products in UNO-2050G series as listed as below:
• UNO-2050G: UNO-2050G hardware platform
Packing list
Before installing your board, make sure that the following materials have
been received:
• Warranty certificate
• Software Supporting CD-ROM
• 6P-6P-6P 20cm KB and PS/2 Mouse Y cable (P/N: 1700060202)
• Plug-in Block 2P Female (P/N 1652002205)
• DIN-rail mounting accessory (1997001110, 1997001120, 1997001130,
1997001140)

UNO-2050G User Manual 6
1.4 Chassis Dimensions
Figure 1.1: Chassis Dimensions
106.50
36.90
164.78
188.78

2
CHAPTER
2
Hardware Functionality
This chapter shows how to set up the
UNO-2050G’s hardware functions,
including connecting peripherals,
switches and indicators.
Sections include:
• UNO-2050G Peripherals
• COM1 & 2: RS-232 Interfaces
• COM3 & 4: Isolated 5-wire RS-232/
422/485
• Onboard Isolated Digital Input
• Onboard Isolated Digital Output
• Onboard Isolated Counter/Timer
• LAN: Ethernet Connector
• Power Connector
• LED Indicators
• PS/2 Keyboard and Mouse Connector
• VGA: VGA Display Connector
• Programmable LED and Buzzer for
System Diagnosis
• RESET: Reset Button

UNO-2050G User Manual 8
2.1 UNO-2050G Peripherals
The following two figures show the connectors on UNO-2050G. The fol-
lowing sections give you detail information about function of each
peripheral.
Figure 2.1: UNO-2050G Front Panel
Figure 2.2: UNO-2050G Rear Panel
2.2 COM1 & 2: RS-232 Interfaces
The UNO-2050G offers two standard RS-232 serial communication
interface ports, and they are COM1 and COM2. Please refer to A.2 for its
pin assignments.
2.3 COM3 & 4: Isolated 5-wire RS-232/422/485
The UNO-2050G offers two isolated 5-wire RS-232/422/485 serial com-
munication interface ports, and they are COM3 and COM4. The connec-
tor type of COM3 and COM4 is screw-terminal block that it’s easy for
wiring without additional daughter board. Each port can be configured
individually to either RS-232, RS-422 or RS-485 by using on-board
jumpers (see Appendix A.3), and Table 2-1 lists the default setting of
each port.
Table 2.1: Serial Port Default Setting
COM Port Default Setting
COM3 RS-485
COM4 RS-485

9 Chapter2
16C954 UARTs with 128-byte Standard
Advantech UNO-2050G comes standard with Oxford OX16PCI964
UARTs containing 128 bytes FIFOs. These upgraded FIFOs greatly
reduce CPU overhead and are an ideal choice for heavy multitasking
environments.
Automatic Data Flow Control Function for RS-485
In RS-485 mode, UNO-2050G automatically senses the direction of
incoming data and switches its transmission direction accordingly. There-
fore no handshaking signal (e.g. RTS signal) is necessary. This feature
lets you simply and quickly build an RS-485 network with just two wires.
More importantly, application software previously written for half duplex
RS-232 environments can be maintained without need for modification.
IRQ and Address Setting
The IRQ and I/O address range are both assigned by BIOS. COM3,
COM4 serial ports and on-board digital I/O use the same IRQ.
2.4 Onboard Isolated Digital Input
The UNO-2050G has 8 isolated digital input channels designated
DI0~DI7.
Pin Assignments
The connector type of UNO-2050G is plug-in screw terminal block that
enables you to connect to field I/O devices directly without additional
accessories. Figure 2-3 and Table 2-2 shows its pin assignment as well as
signal description.
Figure 2.3: Digital Input Connector Pin Assigns
DI0
DI1
DI2
DI3
COM
DI4
DI5
DI6
DI7
Isoated DI

UNO-2050G User Manual 10
Isolated Inputs
Each of isolated digital input channels accepts 10 ~ 50 VDC voltage
inputs, and accepts bi-directional input. It means that you can apply posi-
tive or negative voltage to an isolated input pin (Vin). All eight channels
share one common pin (COM). Figure 2-4 shows how to connect an
external input source to one of the UNO-2050G’s isolated input channels.
Please note that DI4 and DI5 may be configured as Counter 0 and
Counter 1’s gate control pins; DI6 and DI7 may be configured as Counter
0 and Counter 1’s clock input pins. Please refer to “Section 2.6” for detail
Figure 2.4: Isolated Digital Input Connection
Table 2.2: Digital Input Signal Description
Signal Name Reference Direction Description
DI <0...7> COM Input Isolated digital input
signals
COM - Input External common
input of DI
PC 5V
IDI channels
InternalExternal
Protection
Circuit
Bi-direction
diode
SVin
(COM)

11 Chapter2
Interrupt Function of the DI Signals
DI0 and DI1 can be used to generate hardware interrupts. A user can
setup the configuration of interrupts by programming the interrupt control
register.
The channels are connected to the interrupt circuitry. Users can disable/
enable interrupt function, select trigger type or latch the port data by set-
ting the Interrupt Control Register of the UNO-2050G. When the inter-
rupt request signals occur, then the software will service these interrupt
requests by ISR (Interrupt Service Routine). The multiple interrupt
sources provide the card with more capability and flexibility.
IRQ Level
The IRQ level is set automatically by the system BIOS. There is no need
for users to set the IRQ level. Only one IRQ level is used although it has
several interrupt sources.
Interrupt Control Register
The Interrupt Control Register controls the function and status of each
interrupt signal source. Table 2-3 shows the bit map of the Interrupt Con-
trol Register. The register is readable/writable register. While being writ-
ten, it is used as a control register; and while being read, it is used as a
status register
DI0EN & DI1EN: DI0 & DI1 Interrupt disable/enable control bit
DI0TE & DI1TE: DI0 & DI1 Interrupt triggering edge control bit
DI0F & DO1F: DI0 & DI1 interrupt flag bit
Table 2.3: Interrupt Control Register Bit Map
Base Address 7 6 5 4 3 2 1 0
Base+02H R/W Interrupt Enable Control/Status Register
DI1EN DI0EN
Base+03H R/W Interrupt Triggering Edge Control/Status Register
DI1TE DI0TE
Base+07H R/W Interrupt Flag/Clear Register
DI1F DI0F

UNO-2050G User Manual 12
Interrupt Enable Control Function
The user can choose to enable or disable the interrupt function by writing
its corresponding value to the interrupt disable/enable control bit in the
interrupt control register, as shown in Table 2-4
Interrupt Triggering Edge Control
The interrupt can be triggered by a rising edge or a falling edge of the
interrupt signal, as determined by the value in the interrupt triggering
edge control bit in the interrupt control register, as shown in Table 2-5.
Interrupt Flag Bit
The interrupt flag bit is a flag indicating the status of an interrupt. It is a
readable/writable bit. To find the status of the interrupt, you have to read
the bit value; to clear the interrupt, you have to write “1” to this bit. This
bit must first be cleared to service the next coming interrupt
Table 2.4: Interrupt Disable/Enable C. Bit Values
DI0EN & DI1EN Interrupt Disable/Enable Control
0 Disable
1 Enable
Table 2.5: Interrupt Triggering Edge C. Bit Values
DI0TE & DI1TE Triggering Edge of Interrupt Signal
0 Falling edge trigger
1 Rising edge trigger
Table 2.6: Interrupt Flag Bit Values
DI0F & DI1F Interrupt Status
Read 0 No interrupt
1 Interrupt occur
Write 0 Don’t care
1 Clear interrupt.
