Advantech USC-160 Series Installation and operation manual

USC-160 Series
Startup Manual
*Please use only VESA compatible mounting
– detailed table stand & wall mount datasheet available
to download at Advantech’s website.
RFID Embedded
(optional)
Appearance
75x75 VESA
Rear
V iew
I/O Appearance
Front View
Camera embedded (Optional )
Touch Panel &
LCD Display
Cable Cover
Micro SD slot
SIM slot

Power On Computer
1. Connect an adaptor with input voltage rated 12V/3A for all USC-160 series.
2. Be sure to always handle power cords by holding plug ends only. Please refer to
I/O ports section above to find the DC/AC inlet and power switch.
3. Be sure screen light up and running process
Please read these safety instructions carefully and follow these instructions for use.
Repair of the device may only be carried out by trained service personnel. Advantech
recommends that a service contract be obtained with Advantech service and that all
repairs also be carried out by them; otherwise the correct functioning of the device
may be compromised.
WARNING!
Because of the danger of electric shock, never remove the cover of a device while it
is in operation or connected to a power outlet.
If one of the following situations arise, have the equipment checked by service
personnel:
• The power cord or plug is damaged.
• Liquid has penetrated the equipment.
• The equipment has been exposed to moisture.
• The equipment does not work well, or you cannot get it to work according to
the user’s manual.
• The equipment has been dropped and damaged.
• The equipment has obvious signs of breakage. Disconnect this equipment from
any AC outlet before cleaning.
• Use a damp cloth. Do not use liquid or spray detergents for cleaning and keep
this equipment away from humidity
CAUTION! To avoid short-circuits and otherwise damaging the device, do not allow
fluids to come in contact with the device. If fluids are accidentally spilled on the
equipment, remove the affected unit from service as soon as possible and contact
Power On Computer
Safety Instructions

service personnel to verify that patient safety is not compromised. If your computer
clock is unable to keep accurate time or the OS configuration resets to default,
please check the battery.
CAUTION! Do not replace the battery yourself. Please contact a qualified technician
or your retailer.
The computer is provided with a battery-powered real-time clock circuit. There is a
danger of explosion if battery is incorrectly replaced. Replace

only with same or equivalent type recommended by the manufacturer. Discard used
batteries ac- cording to the manufacturer’s instructions.
VESA Mount & Mechanical Drawing & Opening Drawing
