Advantech PCM-5825 User manual

PCM-5825
NS Geode Single Board
Computer with CPU, 4 COMs,
VGA/ CD, Ethernet, and
Audio Interface

ii
Copyright Notice
This document is copyrighted, 2002. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties which may result
from its use.
Acknowledgements
AMD is a trademark of Advanced Micro Devices, Inc.
Award is a trademark of Award Software International, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International
Business Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
C&T is a trademark of Chips and Technologies, Inc.
UMC is a trademark of United Microelectronics Corporation.
Winbond is a trademark of WinbondElectronics Corp.
NS is a trademark of National Semiconductor Inc.
CHRONTEL is a trademark of Chrontel Inc.
For more information on this and other Advantech products please
visit our website at: http://www.advantech.com
http://www.advantech.com/epc
For technical support and service for please visit our support
website at: http://support.advantech.com
This manual is for the PCM-5825 Rev. A201
Part No. 2006582501
2nd Edition, Printed in Taiwan, May 2004

iii
Packing list
Before you begin installing your card, please make sure that the
following materials have been shipped:
•1 PCM-5825Series all-in-one single board computer
• 1 startup manual
• 1 utility disk/CD, driver, and manual (in PDF format)
• 1 2.5" IDE flat cable, 44-pin to 44-pin (part no. 1701440351)
• 1 keyboard / PS2 mouse cable (part no. 1700060201)
• 1 secondary serial port cable (part no. 1701140201)
• 1 parallel cable (part no. 1700260650)
• 1 floppy cable, for 3.5" FDD only (part no. 1701340603)
• 1 audio cable (part no. 1700160160)
• 1 USB cable (part no. 1703100260)
If any of these items are missing or damaged, contact your distribu-
tor or sales representative immediately.

iv
Contents
Chapter 1 General nformation ................................. 1
1.1 Introduction.................................................................. 2
1.2 Features ........................................................................ 3
1.3 Specifications ............................................................... 4
1.3.1 Standard SBC functions ........................................ 4
1.3.2 Local-bus flat panel/VGA interface ...................... 5
1.3.3 Audio function ....................................................... 5
1.3.4 Ethernet interface .................................................. 5
1.3.5 Solid state disk ....................................................... 6
1.3.6 Mechanical and environmental .............................. 6
1.4 Board layout and dimensions .................................... 7
Figure 1-1: PCM-5825 dimensions ............................................ 7
Chapter 2 nstallation ................................................ 9
2.1 Jumpers and connectors .............................................. 10
Table 2-1: Jumpers .................................................................. 10
Table 2-2: Connectors ..............................................................11
2.2 Locating jumpers....................................................... 12
Figure 2-1: Jumpers PCM-5825 .............................................. 12
2.3 Locating connectors ................................................. 13
2.3.1 Component side .................................................... 13
Figure 2-2: Connectors - component side .............................. 13
Figure 2-3: Connectors - solder side...................................... 13
2.4 Setting jumpers.......................................................... 14
2.4.1 Introduction...........................................................14
2.4.2 Settings details ...................................................... 14
2.5 Safety precautions ..................................................... 15
J1: Audio power source ........................................................ 15
J2: Clear CMOS ..................................................................... 15
J3: COM2 selector .................................................................. 15
J4: Watchdog timer ................................................................ 15
J5: Buzzer ............................................................................. 15
J6: LCD power ....................................................................... 15
2.6 Installing DRAM (SODIMMs) ................................. 16
2.6.1 Introduction...........................................................16
2.6.2 Installing SODIMMs ............................................16

v
2.7 IDE hard drive connector (CN15)............................. 17
2.7.1 Connecting the hard drive .................................... 17
2.8 CompactFlash™ disk (CN24) .................................... 18
2.9 Floppy drive connector (CN4) ................................... 18
2.9.1 Connecting the floppy drive ..................................18
2.10 Parallel port connector (CN3) ................................. 19
2.11 Keyboard and PS/2 mouse connector (CN21) ....... 19
2.12 Power connectors ...................................................... 20
2.12.1 Main power connector +5 V, +12 V (CN13) .....20
2.12.2 Auxilary power connector (CN1).......................20
2.12.3 CPU fan power connector (CN6) ......................20
2.13 IR connector (CN12).................................................. 20
2.14 Audio interfaces (CN5, CN9, J1) ............................. 20
2.14.1 Audio connector (CN5) ...................................... 20
2.14.2 CD audio input connector (CN9) ....................... 21
2.14.3 Audio power source setting (J1) ........................ 21
Table 2-3: Audio power source setting .................................. 21
2.15 Serial ports (CN19, CN18, CN2) .............................. 21
2.15.1 COM1 RS-232 port (CN19) ...............................21
2.15.2 COM2 RS-232/422/485 selection (CN18) ......... 22
Table 2-4: COM2 selection (J3) ............................................... 22
2.15.3 COM3/COM4 RS-232 port (CN2) .................... 22
2.15.4 Share IRQ ..........................................................22
Table 2-5: Serial port default settings ..................................... 22
2.16 VGA interface connections ....................................... 23
2.16.1 CRT display connector (CN22) .......................... 23
2.16.2 Flat panel display connector (CN16) .................... 23
2.16.3 LCD power setting (J6)......................................23
Table 2-6: LCD power setting ................................................. 23
2.17 Ethernet interface connections ................................ 24
2.17.1 100Base-T RJ-45 connector (CN20) .................24
2.18 Ethernet LED and HDD/power LEDs ..................... 24
2.18.1 LED1 (Ethernet LED) ....................................... 24
Table 2-7: Ethernet LED setup ................................................ 24
2.18.2 LED2 (Power and HDD LED)..........................24
Table 2-8: HDD/power LED setup ........................................... 24

vi
2.19 Watchdog timer configuration ................................... 25
2.19.1 Watchdog timer action (J4) ................................25
Table 2-9: Watchdog timer action ........................................... 25
2.20 USB connectors (CN7) .............................................. 25
Chapter 3 Software Configuration ......................... 27
3.1 Introduction ................................................................... 28
3.2 Utility CD disk ............................................................... 28
Figure 3-1: Contents of the PCM-5825 utility disk .................. 28
3.3 VGA display software configuration ........................... 29
Figure 3-2: B OS VGA setup screen ...................................... 29
3.4 Connections for two standard LCDs .......................... 31
3.4.1 Connections for 640 x 480 TFT color LCD .........31
3.4.2 Connections for 800 x 600 TFT color LCD .........32
3.5 Ethernet interface configuration ................................. 33
Chapter 4 Award B OS Setup .................................. 35
4.1 System test and initialization ....................................... 36
4.1.1 System configuration verification .........................36
4.2 Award BIOS setup ........................................................ 37
4.2.1 Entering setup .......................................................37
Figure 4-1: B OS setup program initial screen........................ 37
4.2.2 Standard CMOS setup ......................................... 38
Figure 4-2: CMOS setup screen ............................................. 38
4.2.3 BIOS features setup ............................................. 39
Figure 4-3: B OS features setup ............................................. 39
4.2.4 Chipset features setup ..........................................40
Figure 4-4: Chipset features setup ......................................... 40
4.2.5 Power management setup ....................................41
Figure 4-5: Power management setup ................................... 41
4.2.6 PnP/PCI configuration ......................................... 42
Figure 4-6: PnP/PC configuration ........................................... 42
4.2.7 Integrated peripherals ...........................................43
Figure 4-7: ntegrated peripherals .......................................... 43
4.2.8 Load BIOS defaults ............................................. 44
Figure 4-8: Load B OS defaults screen .................................. 44
4.2.9 Change password .................................................45
4.2.10 Auto detect hard disk ......................................... 46
Figure 4-9: DE HDD auto detection screen ............................ 46

vii
4.2.11 Save & exit setup ............................................... 46
4.2.12 Exit without saving ............................................. 46
Chapter 5 SVGA Setup............................................. 47
5.1 Introduction ................................................................... 48
5.1.1 Chipset .................................................................. 48
5.1.2 Display memory ................................................... 48
5.2 Installation of SVGA driver ......................................... 49
5.2.1 Installation for Windows 3.1 ................................. 50
5.2.2 Installation for Cyrix MediaGX ............................53
5.2.3 Installation for Windows NT ................................ 57
5.3 Further information ...................................................... 62
Chapter 6 Audio ....................................................... 63
6.1 Introduction ................................................................... 64
6.2 Installation of audio driver .......................................... 64
6.2.1 Installation for Windows 95/98 .............................65
6.2.2 Installation for Windows NT ................................ 69
Chapter 7 PC Bus Ethernet nterface .................... 73
7.1 Introduction ................................................................... 74
7.2 Installation of Ethernet driver .................................... 74
7.2.1 Installation for MS-DOS and Windows 3.1 ..........74
7.2.2 Installation for Windows 95/98 .............................75
7.2.3 Installation for Windows NT ................................ 78
7.3 Further information ...................................................... 81
Appendix A Pin Assignments ................................. 83
A.1 CRT display connector (CN22) .................................. 84
Table A-1: CRT display connector .......................................... 84
A.2 COM2 RS-232/422/485 serial port (CN18) ............. 84
Table A-2: COM2 RS-232/422/485 series port ....................... 84
A.3 Keyboard and mouse connnector (CN21) ................ 85
Table A-3: Keyboard and mouse connector .......................... 85
A.4 Main power connector (CN3) .................................... 85
Table A-4: Main power connector .......................................... 85
A.5 IDE hard drive connector (CN15) ............................. 86
Table A-5: DE hard drive connector ....................................... 86

viii
A.6 COM1 RS-232 serial port (CN19) ............................ 86
Table A-6: COM1 RS-232 serial port ....................................... 86
A.7 COM3/COM4 Connector (CN2) ............................. 87
Table a-7: COM3/ COM4 RS-232 series Ports ........................ 87
A.8 Ethernet 100Base-T connector (CN20) ................... 87
Table A-8: Ethernet 100Base-T connector ............................. 87
A.9 Auxilary peripheral power connector (CN1) ........... 88
Table A-9: Peripheral power connector ................................. 88
A.10 Floppy drive connector (CN4) ................................. 88
Table A-10: Floppy drive connector ....................................... 88
A.11 Parallel port connector (CN3) .................................. 89
Table A-11: Parallel port connector ......................................... 89
A.12 IR connector (CN12) ................................................. 90
Table A-12: R connector ........................................................ 90
A.13 USB connector (CN7) ............................................... 90
Table A-13: USB connector .................................................... 90
A.14 Audio connector (CN5) ............................................. 90
Table A-14: Audio connector .................................................. 90
A.15 CD audio connector (CN9) ....................................... 91
Table A-15: CD audio connector ............................................. 91
A.16 CPU fan power connector (CN6) ............................. 91
Table A-16: CPU fan power connector .................................. 91
A.17 18-bit LCD display connector (CN16) .................... 92
Table A-17: Flat panel display connector ............................... 92
A.18 CompactFlash™ connector (CN24) ........................ 93
Table A-18: CompactFlash™ card connector (CN24) ........... 93
Appendix B System Assignments ......................... 95
B.1 System I/O ports .......................................................... 96
Table B-1: System /O ports .................................................... 96
B.2 DMA channel assignments......................................... 97
Table B-2: DMA channel assignments .................................... 97
B.3 Interrupt assignments ................................................. 98
Table B-3: nterrupt assignments ............................................ 98
B.4 1st MB memory map ................................................... 99
Table B-4: 1st MB memory map .............................................. 99
Appendix C nstalling PC/104 Modules................ 101
C.1 Installing PC/104 modules ........................................ 102
Figure C-1: PC/104 module mounting diagram ...................... 103

ix
Figure C-2: PC/104 module dimensions (mm) (±0.1) ............ 103
Table C-1: PC/104 connectors (CN14) ................................. 104
Appendix D Programming the Watchdog Timer . 105
D.1 Programming the watchdog timer ........................... 106
Appendix E Mechanical Drawings ....................... 109
E.1 Component side .......................................................... 110
E.2 Solder side ................................................................... 111

x

CHAPTER
General nformation
This chapter gives background informa-
tion on the PCM-5825.
Sections include:
• Board specifications
• Board layout and dimensions
1

2PCM-5825 User's Manual
1.1 ntroduction
The PCM-5825 is the ultimate cost-effective solution for limited
space applications. It is a new NS Geode 3.5" Biscuit PC with
4COM ports and 1-62sec Watchdog timer. It offers all the functions
of an AT-compatible industrial computer on a single board and
only occupies 3½" on a hard drive. The PCM-5825 comes with an
embedded high-performance GX1-300 or GX1-233 processor on-
board. For maximum performance, the PCM-5825 Series also
support an SDRAM SODIMM socket that can accept up to 256
MB memory.
On-board features include an Ethernet interface, audio interface,
socket for Compact Flash Card, Enhanced IDE interface with up to
Ultra DMA transfer protocol, one parallel port, four serial ports (3 x
RS-232 and 1 x RS 232/422/485) with DB-9 connector as COM1, and
a mini-DIN PS/2 keyboard/mouse interface. A SVGA/LCD display
controller (LCD, and CRT displays) allows LCD screen resolutions
of up to 1024 x 768 and CRT resolutions of up to 1280 x 1024 @ 16
colors.
The PCM-5825 complies with the "Green Function" standard and
supports three types of power saving features: Normal, Doze, and
Sleep modes.
The display type configuration is done through software. A single
Flash chip holds the system BIOS and the VGA BIOS. This
minimizes the number of chips and eases configuration. You can
change the display BIOS simply by programming the Flash chip.
If you need any additional functions, the PCM-5825 has a PC/104
connector for future upgrades.

Chapter 1 General nformation 3
1.2 Features
• Ultra-compact size single board computer as small as a 3 1/2"
hard disk drive (145 mm x 102 mm)
• On-board NS GX1-300 or GX-233 CPU
• Up to 256 MB system memory by SODIMM (SDRAM)
• On-board VGA/LCD controller
• On-board 100 BASE-T Ethernet interface
• Supports CompactFlash card
• Built-in Enhanced IDE (AT bus) hard disk drive interface
• On-board mini-DIN PS/2 keyboard/mouse connector
• Four serial ports: three RS-232, one RS-232/422/485 or infared
selectable (uses 16C550 UARTs with 16 byte FIFO)
• 4COM ports share one IRQ
• 62-level Watchdog timer for system reset or IRQ
• Upgradeable through PC/104 module
• Green engine with sleep mode and low power consumption
• Single +5 V power supply

4PCM-5825 User's Manual
1.3 Specifications
1.3.1 Standard SBC functions
•CPU:
- Embedded NS GX1-300 PCM-5825-G0A2
•BIOS: AWARD 256 KB Flash memory
•Chipset: NS CX5530
•System memory: One 144-pin SODIMM socket accepts up to 256
MB SDRAM
•Enhanced IDE interface: Supports up to two EIDE devices. BIOS
auto-detect, PIO Mode 3 or Mode 4 transfer, Ultra DMA33 mode
(ATA-4) up to 33 MB/sec.
•FDD interface: Supports up to two FDDs
•Serial ports: Three serial RS-232 port, one serial RS-232/422/485
port
•Com ports sfare IRQ: 4 COM ports can share one IRQ
•Parallel port: One parallel port, supports SPP/EPP/ECP mode
•Infrared port: Shared with COM2. Transfer rate up to 115 kbps.
•Keyboard/mouse connector: Mini-DIN connector supports
standard PC/AT keyboard and a PS/2 mouse
•USB interface: two USB ports, USB 1.0 compliant
•Power management: Supports power saving modes including
Normal/Doze/Sleep modes. APM 1.1 compliant
•Watchdog timer: 62 interval levels from 1 to 62 seconds. Gener-
ates system reset or IRQ11. Jumperless selection and software
enabled/disabled

Chapter 1 General nformation 5
1.3.2 Local-bus flat panel/VGA interface
•Chipset: NS CS5530A
•Display memory: 1 ~ 4 MB share memory, set in BIOS
•Display type: Supports CRT and TFT LCD displays. Can display
CRT and flat panel simultaneously
•Flat panel display mode: Panel resolution supports up to 1024 x
768 @ 16 bpp. Supports 18-bit TFT LCD panel
•CRT display mode: Non-interlaced CRT monitors resolutions up
to 1280 x 1024 @ 256 colors or 1024 x 768 @ 16 bpp
1.3.3 Audio function
•Chipset: NS CS5530A
•Audio controller: AC97 version 2.0 compliant interface
•Audio interface: Microphone in, Line in, CD audio in, Line out,
Speaker L, Speaker R.
•Power: Accepts +12 V source for improved audio quality
1.3.4 Ethernet interface
•Chipset: RTL 8139
•Ethernet interface: PCI 10/100 Mbps Ethernet. IEEE 802.3 u
protocol compatible
•Connection: On-board RJ-45 connector
• I/O address switchless setting
• Built-in boot ROM

6PCM-5825 User's Manual
1.3.5 Solid state disk
• Supports one 50-pin socket for CompactFlash™ card
1.3.6 Mechanical and environmental
•Dimensions (L x W): 145 mm x 102 mm (5.9" x 4.2")
•Power supply voltage: +5 V (4.75 ~ 5.25 V)
•Power consumption (typical) :
+5 V @ 1.3 A (typical) (for PCM-5825 / GX1-300)
+5 V @ 3 A (Max)
•Operating temperature: 0 ~ 60° C (32 ~ 140° F)
•Weight: 0.77 kg (weight of total package)

Chapter 1 General nformation 7
Figure 1-1: PCM-5825 dimensions
1.4 Board layout and dimensions

8PCM-5825 User's Manual

CHAPTER
nstallation
This chapter tells how to set up the
PCM-5825 hardware, including instruc-
tions on setting jumpers and connecting
peripherals, switches and indicators. Be
sure to read all the safety precautions
before you begin the installation proce-
dure.
2

10 PCM-5825 User's Manual
2.1 Jumpers and connectors
Connectors on the board link it to external devices such as hard
disk drives, a keyboard or expansion bus connectors. In addition,
the board has a number of jumpers that allow you to configure
your system to suit your application.
The table below lists the function of each of the board jumpers and
connectors:
Table 2-1: Jumpers
Label Function
J1 Audio power source setting
J2 Clear CMOS
J3 COM2 setting
J4 Watchdog timer action
J5 Buzzer setting
J6 LCD power selector
