Advantech PCA-6028 Installation and operation manual

PCA-6028 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
1. PCA-6028 PICMG 1.0 Single Board Computer
2. 1 PCA-6028 startup manual
3. 1 CD with utility P/N: 2066602800
4. 2 Serial ATA HDD data cables P/N: 1700003194
5. 2 Serial ATA HDD power cables P/N: 1703150102
6. 1 COM + printer ports cable kit P/N: 1701260305
7. 1 4-port USB cable kit P/N: 1700008461
8. Keyboard and mouse Y cable P/N: 1700060202
9. 1 jumper package P/N: 9689000068
10. 1 warranty card P/N: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1: For detailed contents of PCA-6028, please refer
to user manual in the enclosed CD-ROM (in PDF
format).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
PCA-6028 LGA1150 Intel® CoreTM i7/i5/i3/ Pentium®
/PICMG 1.0 Single Board Computer with DDR3 / Dual
GbE LAN
Startup Manual
General
• CPU: LGA1155 Intel® Core™ i7/i5/i3/Pentium®
• BIOS: AMI 128 Mb SPI BIOS
• Chipset: Intel H81
• System memory: Dual Channel 2x 240-pin DDR3
1333/16008GB per DIMM without ECC; Max. capacity up
to 16GB
• SATA ports: 2x SATAII, 2x SATAIII
Note 1: SATA3.0: 600MB/sec; SATA2.0:300MB/sec
• Seriel ports: Two RS-232 with pin Headers
• Parallel port: One parallel port, supports SPP/EPP/ECP
mode
• Keyboard/mouse connector: Supports one standard
PS/2 keyboard and mouse connector and one external
6-pin header
• Watchdog timer: 255 level timer intervals
• USB 2.0: Up to 8(6x Pin header, 1x Type A, 1x Rear in
G2 sku only)
• USB 3.0: 2x Pin header
• GPIO: One programmable 8-bit GPIO pin-header
VGA Interface
• Chipset: Intel® HD Graphics
• Shared system memory is subject to OS
Ethernet Interface
• Chipset Supports:
- LAN1: Intel® I217V
- LAN2: Intel® I211
• Connection: 2 on-board RJ-45 connector with LED
indicators”
Mechanical and Enviromental
• Dimensions: (L x W): 338 x 122 mm
• Power supply voltage: +12 V, +5 V, +3.3 V, +5 VSB
• Power requirements:
CPU: Processor: Intel
®
Core™ i7-4770S;
Memory: 2 DDR3 1600 MHz 8 GB DIMMs
Voltage: +12 V, +5 V, +3.3 V, +5 VSB, -12 V, -5 V
Current: 4.02 A, 1.36 A, 0.81A, 0.09A, 0A, 0A
Operating temperature: 0 ~ 60° C (depending on CPU)
• Weight: 0.5 kg (weight of board)
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the PCA-6028 Series Rev. A1.
Part No. 2006602800
Printed in China
1st Edition,
November 2013

2 PCA-6028 Startup Manual
The board has a number of jumpers that allow you to con-
figure your system to suit your application. The table below
lists the function of each of the jumpers and connectors.
Connectors
Label Function
LPT1 Parallel port, Parallel port x 1, supports
SPP/EPP/ECP mode
LAN1 Intel
®
I217V
LAN2 Intel I211
VGA1 VGA connector
KBMS1 PS/2 keyboard and mouse connector
KBMS2 External keyboard/mouse connector
COM1 Serial port: COM1; RS-232 (9-pin Box
Header)
COM2 Serial port: COM2; RS-232 (9-pin Box
Header)
JIR Infrared connector
JFP3
(Keyboard
Lock and
Power LED)
Power LED
Suspend: Fast ash (ATX/AT)
System On: ON (ATX/AT)
System Off: OFF (ATX/AT)
JFP2 External speaker / SATA HDD LED
connector
JFP1 Power Switch / Reset connector
JCASE1 Case Open
CPUFAN1 CPU FAN connector (4-pin)
LANLED1 LAN1/2 LED extension connector
HDAUD1 HD audio extension module connector
USB12 USB port 1, 2
USB23 USB port 2, 3
USB45 USB port 4,5
USB56 USB port 5, 6
USB78 USB port 7, 8
S ATA 1 Serial ATA1
S ATA 2 Serial ATA2
S ATA 3 Serial ATA3
S ATA 4 Serial ATA4
CPU1 CPU Socket
DIMMA1 Memory connector channel A
DIMMB1 Memory connector channel B
GPIO1 GPIO pin header (SMD pitch-2.0 mm)
LPC1 COM port module expansion pin-header
Jumpers
Label Function
JCMOS1 CMOS clear
JME1 Clear ME data
JWDT Watchdog timer output selection
JOBS1 HW Monitor Alarm
JCMOS1/JME1: Clear CMOS/ME data
Closed Pins Result
1-2 Keep CMOS/ME data (Default)
2-3 Clear CMOS/ME data
H/W monitor alarm (JOBS1)
Function Jumper Setting
Closed Enable OBS alarm (Default)
Open Disable OBS alarm
JWDT1: Watchdog timer output option
Closed Pins Result
1-2 Reserved
2-3 System reset (Default)
JERP1: Deep Sleep S5
Closed Pins Result
1-2 Enabled
2-3 Disabled (Default)
Jumpers and Connectors
1 2 3
1 2 3
1 2 3
Closed Open

PCA-6028 Startup Manual 3
The drivers for the PCA-6028 are located on the software
installation CD. Please click through the folder and follow
the screen instructions to install them.
Caution! The computer is supplied with a battery-powered
realtime clock circuit. There is a danger of explo-
sion if battery is incorrectly replaced. Replace
only with same or equivalent type recommended
by the manufacturer. Discard used batteries ac-
cording to manufacturer’s instructions.
Declaration of Conformity
Figure 1: Board Layout: Jumper and Connector Locations
Board Layout
Software Installation
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditons:
1. This device may not cause harmful interference;
2. This device must accept any interference received,
including interference that may cause undesired opera-
tion.
