1 POD-6552 Startup Manual
POD-6552 Intel ® Celeron ® M 600 SBC with
VGA/LCD and Ethernet
Startup Manual
Before you begin installing your card, please make sure
that the following materials have been shipped:
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the POD-6552, please
refer to the enclosed CD Disc or disk (in PDF for-
mat).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
http://www.adobe.com/products/acrobat/
readstep2.html (Acrobat is a trademark of Adobe.)
Standard SBC Functions
• CPU: Intel Celeron M 600 w/o L2 cache. Socket
479(Optional for Celeron M CPU)
• BIOS: Award 4Mbit Flash BIOS
• System memory: 200-pin DDR SODIMM x 1, accepts
DDR 266 128/256/512 MB DRAM
• 2nd cache memory: 0 KB
• Enhanced IDE interface: Two channels support up to
four EIDE devices. BIOS auto-detect, PIO Mode 3 or
Mode 4, supports up to UDMA 100 mode. CFC card
occupies secondary master.
• Optional FDD Interface: Supports up to two FDDs
• Serial ports: Four serial RS-232 ports,
COM1,COM3&COM4: RS-232, COM2: RS-232/422/485
• Parallel port: One parallel port, supports EPP/ECP
mode
• Keyboard/mouse connector: Supports a standard PS/
2 Keyboard and PS/2 Mouse
• Power management: Supports power saving modes
including Normal/Standby/Suspend modes. APM 1.2
compliant
• Watchdog timer: 255 level timer intervals
• USB: Six USB 2.0 compliant universal serial bus ports
• IrDA(Optional): 115Kbps, IrDA 1.0 compliant
• Expansion: One PC/104 connector; Two PCI slots
expansion; ISA with 1*8 bit ISA slot by a PCI to ISA
bridge
Solid State Disk
• Supports CompactFlash Card type I/II
VGA/LCD Interface
• Chipset: Intel 852GM chip integrated
• Frame buffer: Supports 64MB frame buffer with system
memory
• Interface: 4X AGP VGA/LCD interface, Support for 9,
12, 15, 18bit TTL TFT(Optional for 16- or 24-bit DSTN
panel)
• Display mode: CRT Mode: 1024 x 768@16bpp (85Hz);
LCD Modes: 1280 x 1024@16bpp (60Hz), 1024 x
768@16bpp (60Hz)
• LV D S : Supports 1 Channel 18bit LVDS inter-
face(Optional for 2 Channel 2 x 18bit LVDS)
• Dual Independent Display: CRT+LVDS, CRT+TV-Out,
LVD S+ TV-O ut
Ethernet interface
• Chipset: RealTek 8100BL
• Ethernet interface: IEEE 802.3u 100BASE-T Fast Eth-
ernet compatible
• I/O address switchless setting
• Built-in boot ROM
Packing List Specifications
• 1 POD-6552 all-in-one single board computer
• Mini Jumper (yellow) p/n: 1653300100
• Mini Jumper (black) p/n: 1653302122
Optional
• 1 Startup manual
• CD-ROM or disks for utility, drivers, and manual (in
PDF format)
• Wiring kit for POD-6552 p/n:PCM-10586-
K100
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com.tw/support
This manual is for the POD-6552 Series Rev. A1.
Part No. 200K655200 1st Edition
May 2005.
POD-6552 Intel® Celeron® M 600 SBC with VGA/LCD and Ethernet

2 POD-6552 Startup Manual
TV-Out
• Chipset: Chrontel CH7009
• Supports TV output
• Supports NTSC and PAL formats
• Support s-video
• TV output supports graphics resolutions up to 1024 x 768
pixels
Audio Function
• Chipset: Realtek ALC202
• Audio controller: AC97 3D surround sereo sound
• Supports Speaker out, CD-input, Line-in, Line-out, Micro-
phone
Mechanical and Environmental
• Dimensions: (L x W)203 x 146 mm (8" x 5.75")
• Power supply voltage: +5 V, ±12V ±5%
Power requirements:
Max: (Win2000, Kpower)
2.8A@+5V (W/Celeron M 600MHz, 128MB DDR333)
0.25A@+12V (W/Celeron M 600MHz, 128MB DDR333)
Typical:(Win2000, Kpower)
1.9 A@+5 V ( W/Celeron M 600MHz, 128MB DDR333 )
0.10 A@+12V V (( W/Celeron M 600MHz, 128MB DDR333 )
• Operating temperature:0 ~ 60° C (32~140° F)
• Operating Humidity:0% ~ 90% Relative Humidity, noncon-
densing
Weight: 0.85 kg (weight of total package)
The board has a number of jumpers that allow you to con-
figure your system to suit your application.
The table below lists the function of each of the jumpers
and connectors.
Jumpers and Connectors
Jumpers
Label Function
J1,J2,J3,J4 Setting COM2 RS232/422/485
J5 LCD voltage setting
J6 SM BUS Connector
J7 PCI VIO setting
J8 CMOS setting
Connectors
Label Function
CN1 VGA D-SUB connector
CN2 COM port 1,2
CN3 TV-Out connector
CN4 USB port 0,1
CN5 PS/2 Mouse/keyboard connector
CN6 LAN connector
CN7 VGA connector
CN8 Audio connector
CN9 COM port 3,4
CN10 IrDA connector
CN11 USB port 4,5
CN12 USB port 2,3
CN13 PS/2 connector
CN14 LVDS connector
CN15 LCD Backlight connector
CN16 CD-IN connector
CN17 TTL LCD connector or DSTN connector
CN18 PC104 connector
CN19 ISA connector
CN20 EBX POWER connector
CN21 -5V & -12V connector
CN22 CF connector
CN23 ATX connector
CN24 Secondary IDE connector
CN25 Primary IDE connector
CN26 Panel connector
CN27 Floppy connector
CN28 Print connector
FAN1,2 FAN connector
J2/J3/J4 Setting COM2 RS232/422/485
RS232 RS422/RS485
J2(1)~J3(1) J3(1)~J4(1)
J2(2)~J3(2) J3(2)~J4(2)
J2(3)~J3(3) J3(3)~J4(3)
J2(4)~J3(4) J3(4)~J4(4)
RS232 RS422/485
J1 Setting COM2 RS232/422/485
RS232 RS422 RS485
1~2(default) 3~4 5~6
Connectors
Label Function
531
642
531
642
531
642

POD-6552 Startup Manual 3
POD-6552 Mechanical Drawing (Component side)
J5 Setting LCD Voltage
Pins Voltage
1~2 +5V
2~3 +3.3V (default)
J6 SM BUS Connector
Pins Signal
1+5V
2SM_CLOCK
3SM_DATA
4GND
123 123
J7 PCI VIO
Pins Voltage
1~2 +5V(default)
2~3 +3.3V
J8 Clear CMOS
Pins Signal
1~2 Clear CMOS
123 123
12
Dimension and Location
-

4 POD-6552 Startup Manual
POD-6552 Connectors and Jumpers Location (Component side)
