Advantech PCM-5823 Series User manual

Artisan Technology Group is your source for quality
new and certied-used/pre-owned equipment
• FAST SHIPPING AND
DELIVERY
• TENS OF THOUSANDS OF
IN-STOCK ITEMS
• EQUIPMENT DEMOS
• HUNDREDS OF
MANUFACTURERS
SUPPORTED
• LEASING/MONTHLY
RENTALS
• ITAR CERTIFIED
SECURE ASSET SOLUTIONS
SERVICE CENTER REPAIRS
Experienced engineers and technicians on staff
at our full-service, in-house repair center
WE BUY USED EQUIPMENT
Sell your excess, underutilized, and idle used equipment
We also offer credit for buy-backs and trade-ins
www.artisantg.com/WeBuyEquipment
REMOTE INSPECTION
Remotely inspect equipment before purchasing with
our interactive website at www.instraview.com
LOOKING FOR MORE INFORMATION?
Visit us on the web at www.artisantg.com for more
information on price quotations, drivers, technical
specications, manuals, and documentation
Contact us: (888) 88-SOURCE | [e-mail] | www.artisantg.com
SM
View
Instra

PCM-5823
NS Geode Single Board
Computer with CPU SVGA/LCD,
Dual Ethernet Interface
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Copyright Notice
This document is copyrighted, 2000. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties which may result
from its use.
Acknowledgements
AMD is a trademark of Advanced Micro Devices, Inc.
Award is a trademark of Award Software International, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International
Business Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
C&T is a trademark of Chips and Technologies, Inc.
UMC is a trademark of United Microelectronics Corporation.
Winbond is a trademark of WinbondElectronics Corp.
NS is a trademark of National Semiconductor Inc.
CHRONTEL is a trademark of Chrontel Inc.
For more information on this and other Advantech products please
visit our website at:http://www.advantech.com
http://www.advantech.com/epc
For technical support and service for please visit our support
website at: http://support.advantech.com
This manual is for the PCM-5823 Rev. A102
Part No. 2006582300
1st Edition Printed in Taiwan Oct 2000
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Packing list
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 PCM-5823 Series all-in-one single board computer
• 1 startup manual
• 1 utility disk/CD, driver, and manual (in PDF format)
• 1 2.5" IDE flat cable, 44-pin to 44-pin (part no. 1701440351)
• 1 keyboard / PS2 mouse cable (part no. 1700000190)
• 1 secondary serial port cable (part no. 1701140201)
• 1 parallel cable (part no. 1700260250)
• 1 floppy cable, for 3.5" FDD only (part no. 1701340603)
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
elbaTnosirapmoCledoMseireS3285-MCPehT
002-VLXG003-1XG 9318LTR pihcNAL
letnI RE95528 pihcNAL
1A0D-3285-MCP XX
1A0G-3285-MCP XX
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Contents
Chapter 1 General Information ........................ 1
1.1 Introduction.................................................................. 2
1.2 Features......................................................................... 3
1.3 Specifications ................................................................ 4
1.3.1 Standard SBC functions ........................................ 4
1.3.2 Local-bus flat panel/VGA interface...................... 5
1.3.3 Audio function (Optional)..................................... 5
1.3.4 Dual Ethernet interface ......................................... 5
1.3.5 Mechanical and environmental ............................. 6
1.3.7 Solid state disk ...................................................... 6
1.4 Board layout and dimensions...................................... 7
Chapter 2 Installation.................................. 9
2.1 Jumpers and connectors............................................ 10
2.2 Locating jumpers ....................................................... 12
2.3 Locating connectors ................................................... 13
2.3.1 Component side .................................................. 13
2.3.2 Solder side........................................................... 14
2.4 Setting jumpers .......................................................... 15
2.4.1 Introduction......................................................... 15
2.5 Safety precautions ...................................................... 17
2.6 Installing DRAM (SODIMMs) ................................. 18
2.6.1 Introduction......................................................... 18
2.6.2 Installing SODIMMs .......................................... 18
2.7 IDE hard drive connector (CN10) ............................ 19
2.7.1 Connecting the hard drive ................................... 19
2.8 CompactFlash™ disk (CN19) ................................... 20
2.9 Floppy drive connector (CN12) ................................ 20
2.9.1 Connecting the floppy drive................................ 20
2.10 Parallel port connector (CN1)................................... 21
2.11 Keyboard and PS/2 mouse connector (CN8) ........... 22
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2.12 Power connectors ....................................................... 22
2.12.1 Main power connector +5 V, +12 V (CN9)...... 22
2.12.2 Auxilary power connector (CN4) ..................... 22
2.12.3 CPU fan power connector (CN5)...................... 22
2.13 IR connector (CN7).................................................... 22
2.14 AC 97 Audio interfaces (CN2, optional) .................. 23
2.15 Serial ports (CN18, CN13)......................................... 23
2.15.1 COM1 RS-232 port (CN18).............................. 23
2.15.2 COM2 RS-232/422/485 selection (CN13)........ 23
2.16 VGA interface connections........................................ 25
2.16.1 CRT display connector (CN18) ........................ 25
2.16.2 Flat panel display connector (CN12) ................ 25
2.16.3 LCD power setting (J1)..................................... 25
2.19 Ethernet LED and HDD/power LEDs ..................... 26
2.19.1 LED1 (Ethernet LED) ....................................... 26
2.19.2 D9, D10 (Power and HDD LED)...................... 26
2.20 Watchdog timer configuration ................................. 26
2.18 Dual Ethernet interface connections ........................ 27
2.18.1 100Base-T RJ-45 connector (CN15. CN16) ..... 27
2.18.2 Ethernet power select (J4)................................. 27
2.20.1 Watchdog timer action (SW2) .......................... 28
2.21 USB connectors (CN11) ............................................... 28
2.23 ATX power control conn. (CN14, CN2)................... 29
2.23.1 ATX feature connector (CN14) and power button
(CN 21) ........................................................................ 29
Chapter 3 Software Configuration ................. 31
3.1 Introduction................................................................ 32
3.2 Utility CD disk............................................................ 32
3.3 VGA display software configuration........................ 33
3.4 Connections for two standard LCDs........................ 35
3.4.1 Connections for Toshiba LTM10C042
(640 x 480 TFT color LCD)................................ 35
3.4.2 Connections for Toshiba LTM12C275A
3.5 Ethernet interface configuration .............................. 37
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 4 Award BIOS Setup ........................ 39
4.1 System test and initialization
4.1.1 System configuration verification....................... 40
4.2 Award BIOS setup ..................................................... 41
4.2.1 Entering setup ..................................................... 41
4.2.2 Standard CMOS setup......................................... 42
4.2.3 BIOS features setup ............................................ 43
4.2.4 Chipset features setup ......................................... 44
4.2.5 Power management setup ................................... 45
4.2.6 PnP/PCI configuration ........................................ 46
4.2.7 Integrated peripherals ......................................... 47
4.2.8 Load BIOS defaults............................................. 48
4.2.9 Change password ................................................ 49
4.2.10 Auto detect hard disk ........................................ 50
4.2.11 Save & exit setup .............................................. 50
4.2.12 Exit without saving ........................................... 50
Chapetr 5 SVGA Setup................................ 51
5.1 Introduction................................................................ 52
5.1.1 Chipset ................................................................ 52
5.1.2 Display memory.................................................. 52
5.2 Installation of SVGA driver...................................... 53
5.2.1 Installation for Windows 3.1 .............................. 54
5.2.2 Installation for Cyrix MediaGX Certified drivers
for Windows 95/980. Insert the disk into the CD-ROM
drive. ............................................................................ 57
5.2.3 Installation for Windows NT .............................. 61
5.3 Further information................................................... 66
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 6 Audio ....................................... 67
6.1 Introduction................................................................ 68
6.2 Installation of audio driver ....................................... 68
6.2.1 Installation for Windows 95/98 .......................... 69
6.2.2 Installation for Windows NT .............................. 73
Chapter 7 PCI Bus Ethernet Interface ............. 77
7.1 Introduction................................................................ 78
7.2 Installation of Ethernet driver.................................. 78
7.2.1 Installation for MS-DOS and Windows 3.1........ 78
7.2.2 Installation for Windows 95/98 .......................... 79
7.2.3 Installation for Windows NT .............................. 82
7.3 Further information................................................... 85
Appendix A Pin Assignments........................ 87
CRT display connector (CN17) ........................................... 88
LCD connector (CN3) .......................................................... 88
COM2 RS-232/422/485 serial port (CN13) ........................ 89
Keyboard and mouse connnector (CN8)............................ 89
Main power connector (CN9).............................................. 90
IDE hard drive connector (CN10) ...................................... 90
COM1 RS-232 serial port (CN18)....................................... 91
Ethernet 100Base-T connector (CN15, CN16)................... 91
Auxilary power connector (CN4)........................................ 92
Floppy drive connector (CN12)........................................... 92
Parallel port connector (CN1)............................................. 93
IR connector (CN7) .............................................................. 94
USB connector (CN4)........................................................... 94
AC97 Audio connector (optional) (CN2)............................ 94
CPU fan power connector (CN5) ........................................ 95
ATX power stand by (feature) connector (CN14) ............. 96
ATX power button & power LED connector (CN21) ....... 96
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Appendix B System Assignments................... 97
B.1 System I/O ports......................................................... 98
B.2 DMA channel assignments ........................................ 99
B.3 Interrupt assignments.............................................. 100
B.4 1st MB memory map ............................................... 101
Appendix C LCD Services ........................... 103
C.1 LCD services............................................................. 104
Appendix D Installing PC/104 Modules........... 105
D.1 Installing PC/104 modules....................................... 106
Appendix E Programming the Watchdog Timer . 109
E.1 Programming the watchdog timer ......................... 110
Appendix F Mechanical Drawings ....................... 113
F.1 Component side ........................................................ 114
F.2 Solder side................................................................. 115
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Tables
Table 2-1: Jumpers ................................................................................................. 10
Table 2-2: Connectors ............................................................................................. 11
Table 2-3 COM2 select (SW2) ................................................................................ 23
Table 2-4: Serial port default settings ..................................................................... 24
Table 2-5: LCD power setting ................................................................................. 25
Table 2-7: Ethernet LED setup................................................................................ 26
Table 2-8: HDD/power LED setup........................................................................... 26
Table 2-6: Ethernet power select ............................................................................ 27
Table 2-9: SW2 Watchdog timer action .................................................................. 28
Table A-1: CRT display connector .......................................................................... 88
Table A-2: Flat panel display connector ................................................................. 88
Table A-3: COM2 RS-232/422/485 series port ....................................................... 89
Table A-4: Keyboard and mouse connector ........................................................... 89
Table A-5: Main power connector ........................................................................... 90
Table A-6: IDE hard drive connector....................................................................... 90
Table A-7: COM1 RS-232 serial port ...................................................................... 91
Table A-8: Ethernet 100Base-T connector ............................................................. 91
Table A-9: Peripheral power connector .................................................................. 92
Table A-10: Floppy drive connector ........................................................................ 92
Table A-11: Parallel port connector ........................................................................ 93
Table A-12: IR connector ........................................................................................ 94
Table A-13: USB connector .................................................................................... 94
Table A-14: Audio connector................................................................................... 94
Table A-17: CPU fan power connector ................................................................... 95
Table A-20: ATX power feature connector (CN23)................................................. 96
Table A-21: ATX power button & power LED connector (CN24) ........................... 96
Table B-1: System I/O ports.................................................................................... 98
Table B-2: DMA channel assignments ................................................................... 99
Table B-3: Interrupt assignments .......................................................................... 100
Table B-4: 1st MB memory map ........................................................................... 101
Table D-1: PC/104 connectors (CN6) ................................................................... 108
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Figures
Figure 1-1: PCM-5823 Series dimensions ............................................. 7
Figure 2-1: Jumpers............................................................................... 12
Figure 2-2: Connectors - component side (PCM-5823) ...................... 13
Figure 2-3: Connectors - solder side (PCM-5823)............................... 14
Figure 3-1: Contents of the PCM-5823 Series utility disk .................. 32
Figure 3-2: BIOS VGA setup screen..................................................... 33
Figure 4-1: BIOS setup program initial screen ................................... 41
Figure 4-2: CMOS setup screen............................................................ 42
Figure 4-3: BIOS features setup ........................................................... 43
Figure 4-4: Chipset features setup....................................................... 44
Figure 4-5: Power management setup ................................................. 45
Figure 4-6: PnP/PCI configuration........................................................ 46
Figure 4-7: Integrated peripherals........................................................ 47
Figure 4-8: Load BIOS defaults screen................................................ 48
Figure 4-9: IDE HDD auto detection screen ........................................ 50
Figure D-1: PC/104 module mounting diagram................................. 107
Figure D-2: PC/104 module dimensions (mm) (±0.1) ........................ 107
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

CHAPTER
General Information
This chapter gives background informa-
tion on the PCM-5823.
Sections include:
• Board specifications
• Board layout and dimensions
1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2PCM-5823 User's Manual
1.1 Introduction
Advantech’s new PCM-5823 NS Geode Series is a 3.5" SBC
which offers an onboard NS Geode GX1-300 processor or GXLV-
200 processor, plus support for dual ethernet for network functions
such as Firewall, Network monitoring, Router or Gateway
functions. Other onboard features include VGA/LCD, a Compact-
Flash™ card socket, and watchdog timer. With the 586-level NS
Geode processor mounted directly on board, upgrade and system
configuration is much more convenient as is the benefits of fanless
operation in temperatures up to 60° C (140° F). This board is a
feature-packed, 586-level, hassle-free solution for space critical
applications.
The flexible, dual Ethernet capability of the PCM-5823 gives
network administrators another tool to deal with today's changing
application needs. The board comes with the top-of-the-line Intel
82559ER LAN chips or cost-effective RTL 8139C LAN chips,
depending on users needs. Used as a DMZ device, the PCM-5823
could act as a firewall that sits between the internet and a compa-
ny's internal network. This applies to Web (HTTP) servers, FTP
servers, SMTP (e-mail) servers or DNS servers. The PCM-5823
can also be used as an internet-network gateway (router) that
connects a number of local networks. Once again, the dual
ethernet capability and processing power of the PCM-5823 gives it
the ability to perform these functions. The compact size, low
power consumption and fanless operation also allow it to be used
"exactly" where you need it as well.
The PCM-5823 Series complies with the "Green Function"
standard and supports three types of power saving features:
Normal, Doze, and Sleep modes.
The display type configuration is done through software. A single
Flash chip holds the system BIOS and the VGA BIOS. This
minimizes the number of chips and eases configuration. You can
change the display BIOS simply by programming the Flash chip.
If you need any additional functions, the PCM-5820 Series has a
PC/104 connector for future upgrades.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 1 General Information 3
1.2 Features
• Ultra-compact size single board computer as small as a 3 1/2"
hard disk drive (145 mm x 102 mm)
• On-board NS GX1-300 or GXLV-200 CPU
• Up to 128 MB system memory by SODIMM (SDRAM)
• On-board VGA/LCD controller
• On-board Dual 100Base-T Ethernet interface
• Supports CompactFlash card
• Built-in Enhanced IDE (AT bus) hard disk drive interface
• On-board mini-DIN PS/2 keyboard/mouse connector
• Two serial ports: one RS-232, one RS-232/422/485 or infared
selectable (uses 16C550 UARTs with 16 byte FIFO)
• Upgradeable through PC/104 module
• Green engine with sleep mode and low power consumption
• Single +5 V power supply
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4PCM-5823 User's Manual
1.3 Specifications
1.3.1 Standard SBC functions
•CPU:
- Embedded NS GXLV-200/2.2V (for PCM-5823-DOA1)
- Embedded NS GX1-300/1.8V (for PCM-5823-GOA1)
•BIOS: AWARD 256 KB Flash memory
•Chipset: NS CX5530
•System memory: One 144-pin SODIMM socket accepts up to
128 MB SDRAM
•Enhanced IDE interface: Supports up to two EIDE devices.
BIOS auto-detect, PIO Mode 3 or Mode 4 transfer, Ultra
DMA33 mode (ATA-4) up to 33 MB/sec.
•FDD interface: Supports up to two FDDs
•Serial ports: One serial RS-232 port, one serial RS-232/422/485
port
•Parallel port: One parallel port, supports SPP/EPP/ECP mode
•Infrared port: Shared with COM2. Transfer rate up to 115
kbps.
•Keyboard/mouse connector: Mini-DIN connector supports
standard PC/AT keyboard and a PS/2 mouse
•USB interface: two USB ports, USB 1.0 compliant
•Power management: Supports power saving modes including
Normal/Doze/Sleep modes. APM 1.1 compliant
•Watchdog timer: 1.6 sec. intervals
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 1 General Information 5
1.3.2 Local-bus flat panel/VGA interface
•Chipset: NS CX5530
•Display memory: 1 ~ 4 MB share memory, set in BIOS
•Display type: Supports CRT and TFT LCD displays. Can
display CRT and flat panel simultaneously
•Flat panel display mode: Panel resolution supports up to 1024
x 768 @ 18 bpp. Supports 18-bit TFT LCD panel
•CRT display mode: Non-interlaced CRT monitors resolutions
up to 1280 x 1024 @ 256 colors or 1024 x 768 @ 16 bpp
1.3.3 Audio function (Optional)
•Chipset: NS CX5530
•Audio interface: AC97 version 2.0 compliant interface for
optional audio module for complete audio capability; line-in,
line out, CD audio-in, microphone
1.3.4 Dual Ethernet interface
•Chipset: Intel®82559ER or Realtek RTL 8139
•Ethernet interface: PCI 10/100 Mbps Ethernet. IEEE 802.3 u
protocol compatible
•Connection: 2 RJ-45 connector with LED on the frontside
• I/O address switchless setting
• Built-in boot ROM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6PCM-5823 User's Manual
1.3.5 Mechanical and environmental
•Dimensions (L x W): 145 mm x 102 mm (5.9" x 4.2")
•Power supply voltage: +5 V (4.75 ~ 5.25 V)
•Power consumption :
- +5 V @ 4.0 A (maximum)
- +5 V @ 1.5 A with GX1-300, 64 MB SODIMM and 40 MB
CFC
- +5 V @ 1.5 A with GXLV-200, 64 MB SODIMM and 40 MB
CFC
•Operating temperature: 0 ~ 60° C (32 ~ 140° F)
•Operating humidity: 0 ~ 90%, Relative humidity,
noncondensing
•Weight: 0.77 kg (weight of total package)
1.3.7 Solid state disk
• Supports one 50-pin socket for CompactFlash™ card
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 1 General Information 7
Figure 1-1: PCM-5823 Series dimensions
1.4 Board layout and dimensions
PCM-5823
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
