Advantech PCM-9570 Installation and operation manual

PCM-9570/S Startup Manual 1
PCA-9570/S Socket 370 Celeron™ SBC with 3D LCD/ Ethernet/SCSI
PCM-9570/S Socket 370 Celeron™ SBC with
3D LCD/Ethernet/SCSI
Startup Manual
Packing ListPacking List
Packing ListPacking List
Packing List
Before you begin installing your card, please make
surethat the following materials have been shipped:
• 1 PCM-9570/9570S all-in-one single board computer
• 1 startup manual
• CD-ROM or disks for utility, drivers, and manual (in
PDF format)
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note: For detailed contents of the
PCM-9570/9570S, please refer to the
enclosed CD-ROM or disk (in PDF format).
SpecificationsSpecifications
SpecificationsSpecifications
Specifications
Standard SBC Functions
•CPU: Socket 370 for Intel®Celeron™ processor
•BIOS: Award 256 KB Flash memory
•System memory: Two 144-pin SO DIMM sockets
accept 16 ~ 128 MB SDRAM
•Enhanced IDE interface: Supports up to two EIDE
devices. BIOS auto-detect, PIO Mode 3 or Mode 4,
UDMA/33 transfer
•FDD interface: Supports up to two FDDs
•Serial ports: Four serial RS-232 ports, COM1, 3, 4:
RS-232, COM2: RS-232/422/485
•Parallel port: One parallel port, supports
SPP/EPP/ECP mode
•Infrared port: Shared with COM2. Transfer rates up
to 115 Kbps
•Keyboard/mouse connector: Supports standard
PC/AT keyboard and a PS/2 mouse
•Power management: Supports power saving
modes including Normal/Standby/Suspend modes.
APM 1.1 compliant
•Watchdog timer: 63 level timer intervals
• USB: Two Universal Serial Bus ports
Solid State Disk
• Supports one 50-pin socket for CompactFlash card
VGA/LCD Interface
•Chipset: Trident Cyber 9525DVD 2.5 MB SDRAM on
chip
•Interface: 2 x AGP interface, 3D 64-bit engine
Ultra2 SCSI (PCM-9570S only)
• Chips: Symbios SYM53C893 chips
•Performance: Ultra2 SCSI interface, up to 80
MB/sec. transfer rate
PanelLink (optional)
• Chips: Si I 154 PanelLink digital transmitter
•Scalable bandwidth: 25 ~ 112 MHz (VGA to
SAGG)
Mechanical and Environmental
•Dimensions (L x W): 203 x 146 mm (8" x 5.75")
•Power supply voltage: +5 V ±5%
•Power requirements: 5.2 A @ +5 V (typical, 64
MB DRAM, Celeron™-433 CPU)
•Operating temperature: 0 ~ 60° C
•Weight: 0.7 kg (weight of total package)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the PCA-6751/6751V series Rev.A1
Part No. 2006957000 1st Edition
Printed in Taiwan August 1999

2PCM-9570/S Startup Manual
Jumpers and ConnectorsJumpers and Connectors
Jumpers and ConnectorsJumpers and Connectors
Jumpers and Connectors Locating Jumpers
Jumper settings
The board has a number of jumpers that allow you to
configure your system to suit your application.
The table below lists the function of each of the
jumpers and connectors.
Label Function
J1 CMOS clear
J2 Watchdog timer action
J3 SCSI terminator power enable/disable
J4 ATX power switch button
J6 COM port RI pin setting
J7 PanelLink control
J9 Buzzer enable/disable
J10 COM2 RS-232/422/485 setting
J11 ATX power on function select
J12 LAN controller power select
SW1 Panel type select
Label Function
CN1 Ethernet 100/10Base-T connector
CN2 ATX feature connector
CN4 SCSI connector
CN5 Keyboard and PS/2 mouse connector
CN6 Main power connector
CN8 IR connector
CN9 Floppy drive connector
CN10 PC/104 ISA-bus expansion
CN11 IDE hard drive connector
CN12 Parallel port connector
CN13 Backlight connector
CN14 Peripheral power connector
CN15 CRT display connector
CN16 Flat panel connector
CN17 Ext. flat panel display connector
CN18 Front panel connector
CN19 USB channel 1, 2 connector
CN20 COM-port connector
CN21 CFC connector
CN22 PanelLink connector
FAN1 Fan power connector
J1: CMOS clear
Closed pins Result
1-2 Normal (3 V battery on)*
2-3 Clear CMOS
J2: Watchdog timer action
Closed pins Result
1-2 IRQ11
2-3 System reset
J3: SCSI terminator
Pins Result
Closed Terminator on
Open Terminator off*
J4: ATX power switch button
Power on/off toggle button
J6: COM1-4 RI settings
Pins Com port RI Power setting
1-2 COM1 RI pin +5 V
3-4 COM1 RI pin +12 V
5-6 COM1 RI pin R I*
7-8 COM2 RI pin +5 V
9-10 COM2 RI pin +12 V
11-12 COM2 RI pin R I*
13-14 COM3 RI pin +5 V
15-16 COM3 RI pin +12 V
17-18 COM3 RI pin R I*
19-20 COM4 RI pin +5 V
21-22 COM4 RI pin +12 V

PCM-9570/S Startup Manual 3
J7: PanelLink control
Open Closed
1-2 Falling-edge latch* Rising-edge latch
3-4 Pixel/clock* 2 pixels/clock
J9: Buzzer enable/disable
Pins Result
Closed Buzzer enabled
Open Buzzer disabled
J10: COM2 RS-232/422/485 select
RS-232* RS-422 RS-485
1-2 Open Open Closed
3-4 Open Closed Open
5-6 Closed Open Open
7-9 Closed Open Open
8-10 Closed Open Open
9-11 Open Closed Closed
10-12 Open Closed Closed
13-15 Closed Open Open
14-16 Closed Open Open
15-17 Open Closed Closed
16-18 Open Closed Closed
J11: ATX power on function select
1-2 +5 V*
2-3 ATX standby 5 V
J12: LAN controller power select
1-2 Default off*
2-3 Default on
*default setting
SW1: Panel type select
Pin Panel Type
1234 5 6
0 0 0 0 0 NC TFT 640 x 480 18 bits
0 X 0 0 0 NC TFT 800 x 600 18 bits
0 0 X 0 0 NC TFT 1024 x 768 24 bits
0 X X 0 0 NC TFT 1024 x 768 36 bits
0 0 0 0 X NC STN 640 x 480 16 bits
0 X 0 0 X NC STN 800 x600 16 bits
0 0 X 0 X NC STN 1024 x 768 16 bits
0 X X 0 X NC STN 1024 x 768 24 bits
Locating Connectors
PCM-9570/S connectors (solder side)
Note: If the "1" in SW1 is in the OFF position, the
LCD is disconnected.
PCM-9570/S connectors (component side)

4PCM-9570/S Startup Manual
PCM-9570/S Mechanical DrawingPCM-9570/S Mechanical Drawing
PCM-9570/S Mechanical DrawingPCM-9570/S Mechanical Drawing
PCM-9570/S Mechanical Drawing
Be sure to use the correct component side. Improper
installation can cause serious damage to your
hardware!
PCM-9570/S mechanical drawing (solder side)
PCM-9570/S mechanical drawing (component side)
