GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
AccreditedLab.OfBSMI,NEMKO,NVLAP Page 1 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
European Union [EU]
EMC Directive [89/336/EEC, As Amended]
EMC Test Report
For:
Advantech Co., Ltd.
EUT: Mother Board
Model Number: AIMB-562 Series
Prepared for:
Advantech Co., Ltd.
No.1, Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 114, Taiwan
Report By : Global EMC Standard Tech. Corp.
No.3 Pau-Tou-Tsuo Valley, Chia-Pau
Tsuen, Lin Kou Hsiang, Taipei County,
Taiwan, R.O.C.
Tel : [phone]
Fax : [phone]
Test results given in this report only relate to the specimen(s) tested, measured.
This report is the property of GesTek, and shall not be reproduced, other than in full, without the written consent of GesTek.
The report must not be used by the client to claim product certification, approval, or endorsement by any agency of the federal government.
A
ll data in this report are traceable to national standard or international standard.

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
AccreditedLab.OfBSMI,NEMKO,NVLAP Page 2 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
TABLE OF CONTENTS
Description Page
1. CERTIFICATION 3
2. SUMMARY OF TEST RESULTS 4
3. GENERAL INFORMATION 5
3.1 PRODUCT DESCRIPTION 5
3.2 TEST MODES & EUT COMPONENTS DESCRIPTION 5
3.3 CONFIGURATION OF THE SYSTEM UNDER TEST 6
3.4 TEST FACILITY 10
4. CONDUCTED EMISSION MEASUREMENT 11
4.1 TEST EQUIPMENTS 11
4.2 TEST METHOD 11
4.3 BLOCK DIAGRAM OF TEST SETUP 11
4.4 CONDUCTED EMISSION LIMITS 12
4.5 EUT CONFIGURATION ON MEASUREMENT 12
4.6 CONDUCTED EMISSION DATA 12
4.7 OPERATING CONDITIONS OF THE EUT 12
4.8 CONDUCTED EMISSION MEASUREMENT RESULTS 13
5. RADIATED EMISSION MEASUREMENT 15
5.1 TEST EQUIPMENT 15
5.2 TEST METHOD 15
5.3 BLOCK DIAGRAM OF TEST SETUP 16
5.4 RADIATED EMISSION LIMITS 17
5.5 EUT CONFIGURATION 18
5.6 OPERATING CONDITIONS OF THE EUT 18
5.7 RADIATED EMISSION DATA 18
5.8 RADIATED EMISSIONS MEASUREMENT RESULTS 19
6. HARMONIC CURRENT EMISSIONS, VOLTAGE
FLUCTUATIONS AND FLICKER MEASUREMENT 22
6.1 TEST EQUIPMENT 22
6.2 TEST METHOD 22
6.3 BLOCK DIAGRAM OF TEST SETUP 22
6.4 LIMITS OF HARMONIC CURRENT EMISSIONS 23
6.5 OPERATING CONDITIONS OF THE EUT 23
6.6 TEST PROCEDURE 23
6.7 TEST RESULT 23
7. ESD IMMUNITY TEST 26
7.1 TEST EQUIPMENT 26
7.2 TEST METHOD 26
7.3 BLOCK DIAGRAM OF TEST SETUP 26
7.4 SEVERITY LEVELS 27
7.5 OPERATING CONDITIONS OF THE EUT 27
7.6 TEST PROCEDURE 27
7.7 TEST RESULT 28
8. RF FIELD STRENGTH SUSCEPTIBILITY TEST 29
8.1 TEST EQUIPMENT 29
8.2 TEST METHOD 29
8.3 BLOCK DIAGRAM OF TEST SETUP 29
8.4 SEVERITY LEVELS 30
8.5 OPERATING CONDITIONS OF THE EUT 30
8.6 TEST PROCEDURE 30
8.7 TEST RESULT 31
9. ELECTRICAL FAST TRANSIENT/BURST IMMUNITY TEST32
9.1 TEST EQUIPMENT 32
9.2 TEST METHOD 32
9.3 BLOCK DIAGRAM OF TEST SETUP 32
9.4 SEVERITY LEVELS 33
9.5 OPERATING CONDITIONS OF THE EUT 33
9.6 TEST RESULT 34
10. SURGE IMMUNITY TEST 35
10.1 TEST EQUIPMENT 35
10.2 TEST METHOD 35
10.3 BLOCK DIAGRAM OF TEST SETUP 35
10.4 SEVERITY LEVELS 35
10.5 OPERATING CONDITIONS OF THE EUT 36
10.6 TEST PROCEDURE 36
10.7 TEST RESULT 37
11. CONDUCTED DISTURBANCE SUSCEPTIBILITY TEST 38
11.1 TEST EQUIPMENT 38
11.2 TEST METHOD 38
11.3 BLOCK DIAGRAM OF TEST SETUP 38
11.4 SEVERITY LEVELS 38
11.5 OPERATING CONDITIONS OF THE EUT 38
11.6 TEST PROCEDURE 39
11.7 TEST RESULT 40
12. VOLTAGE DIPS AND SHORT INTERRUPTIONS TEST 41
12.1 TEST EQUIPMENT 41
12.2 TEST METHOD 41
12.3 BLOCK DIAGRAM OF TEST SETUP 41
12.4 SEVERITY LEVELS 41
12.5 OPERATING CONDITIONS OF THE EUT 41
12.6 TEST PROCEDURE 41
12.7 TEST RESULT 42
13. PHOTOGRAPHS FOR TEST 43
13.1 TEST PHOTOGRAPHS FOR CONDUCTION 43
13.2 TEST PHOTOGRAPHS FOR RADIATED 44
13.3 TEST PHOTOGRAPHS FOR HARMONIC/FLICKER 45
13.4 TEST PHOTOGRAPHS FOR ESD 46
13.5 TEST PHOTOGRAPHS FOR ESD TEST POINTS 47
13.6 TEST PHOTOGRAPHS FOR RS 48
13.7 TEST PHOTOGRAPHS FOR EFT 49
13.8 TEST PHOTOGRAPHS FOR SURGE 50
13.9 TEST PHOTOGRAPHS FOR CS 51
13.10 TEST PHOTOGRAPHS FOR DIPS 52
14. PHOTOGRAPHS FOR PRODUCT 53
15. EMI/EMS REDUCTION METHOD DURING COMPLIANCE
TESTING 59

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 3 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
1. CERTIFICATION
Applicant : Advantech Co., Ltd.
EUT Description : Mother Board
Model Number : AIMB-562 Series
Brand Name : Advantech
Serial Number : N/A
Tested Power Supply : 230Vac/50Hz
MEASUREMENT PROCEDURES USED :
EN 55022: 1998 + A1: 2000 + A2: 2003 AND
EN 61000-3-2: 2000 & EN 61000-3-3: 1995 + A1: 2001
EN 55024: 1998 + A1: 2001 + A2: 2003 AND IEC 61000-4 SERIES REGULATIONS
For EN 55022: 1998 + A1: 2000 + A2: 2003:
The measurements shown in the attachment were made in accordance with the procedures
indicated, and the maximum emissions from the equipment were found to be within the
applicable EN 55022: 1998 + A1: 2000+ A2: 2003 limits.
For EN 55024: 1998 + A1: 2001 + A2: 2003:
The measurement results are contained in this test report and show that the EUT to be
technically compliant with the EN 55024: 1998 + A1: 2001 + A2: 2003 Immunity regulations.
GENERAL REMARKS:
The tests were performed according to the technical requirement of EUT.
Electro-magnetic Radiated Emission Interference Measurement (EN 55022)
Electro-magnetic Conducted Emission Interference Measurement (EN 55022)
Harmonic Current Emissions (EN 61000-3-2)
Voltage Fluctuation and Flicker Measurement (EN 61000-3-3)
ESD Immunity Test (IEC 61000-4-2)
RF Field strength Susceptibility Test (IEC 61000-4-3)
Electrical Fast Transient/Burst Immunity Test (IEC 61000-4-4)
Surge Immunity Test (IEC 61000-4-5)
Conducted disturbance Susceptibility Test (IEC 61000-4-6)
Low Frequency Signals Immunity Test (IEC 1000-2-2)
Power Frequency Magnetic Field Immunity Test (IEC 61000-4-8)
Voltage Dips/Short Interruptions Test (IEC 61000-4-11)
;AS/NZS CISPR 22 Limits and Methods of Measurement of Radio Interference Characteristics of Information Technology
equipment :2002
Date of Test : May 21, 2005 －May 24, 2005
Issue Date : October 04, 2006
In order to ensure the quality and accuracy of this document, the contents have been thoroughly
reviewed by the following qualified personnel from GesTek Lab.
DocumentedBy: AdministrativeReviewedBy:
Gina Li / adm. Dept. Technical Report Author Rini Chen / adm. Dept. Supervisor
Technical Reviewed By: Approved By :
Perry Lin / end. Dept. Engineer Tonny Lin / General Manager

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 4 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
2. SUMMARY OF TEST RESULTS
STANDARD TEST ITEM TEST
RESULT REMARKS
Conducted emission
(Mode 1) PASS The worst emission frequency is 1.9563 MHz.
And minimum passing margin is –16.93 dB.
EN 55022
Class B
(1)AS/NZS CISPR 22
(for C-Tick) Radiated emission
(Mode 1) PASS
The worst emission frequency is 500.0025 MHz at
Vertical.
And minimum passing margin is –3.11 dB.
Height of antenna is 1 M.
Angle of turntable is 117°.
Harmonic Current
Emissions PASS
EN 61000-3-2: 2000
EN 61000-3-3: 1995 +
A1: 2001 Voltage Fluctuation and
Flicker Measurement PASS
With regards to the EN 61000-3-2, the PC must be
tested at full load in order to reach the assigned
current of the Power supply. With Dummy Load
Active Power > 75W
EN 55024
IEC 61000-4-2: 1995 +
A1: 1998 + A2:2000
Electrostatic
Discharge(ESD) PASS Contact discharge up to ±4kV .
Air discharge up to ±8kV .
EN 55024
IEC 61000-4-3: 2002 +
A1: 2002
RF field strength
Susceptibility PASS
80-1000MHz
(1kHz sinewave with 80% Amplitude Modulation:
3V/m)
80, 120, 160, 230, 434, 460, 600, 863 and 900MHz:
3V/m
EN 55024
IEC 61000-4-4: 2004 Electrical Fast Transients/Burst PASS ±0.5kV, ±1.0kV (AC Input) ±0.5kV(LAN)
EN 55024
IEC 61000-4-5: 1995 +
A1: 2000 Surge PASS ±0.5kV, ±1kV, ±2kV (AC Input)
EN 55024
IEC 61000-4-6: 2003 +
A1: 2004
Conducted Disturbance
Susceptibility PASS 0.15-80MHz
(1kHz sinewave with 80% Amplitude Modulation: 3V)
0.2, 1, 7.1, 13.56, 21, 27.12 and 40.68MHz: 3V
Voltage short
Interruptions >95% reduction, 5s
EN 55024
IEC 61000-4-11: 1994
+ A1: 2001 Voltage Dips PASS >95% reduction, 10 ms
30% reduction, 500 ms

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 5 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
3. GENERAL INFORMATION
3.1 PRODUCT DESCRIPTION
Product Name :Mother Board
Model Number :AIMB-562 Series
Brand Name :Advantech
Serial Number :N/A
Applicant : Advantech Co., Ltd.
Address : No.1,Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 114,
Taiwan
Manufacturer : Advansus Corp.
Address : No.1,Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 114,
Taiwan
Power Supply : From PC Computer’s S.P.S.
Input: 115~240V, 10A, 50/60Hz
Power Cord : 3Pins, Non-Shielded, 1.8m, Detachable
3.2 TEST MODES & EUT COMPONENTS DESCRIPTION
EUT: Mother Board, M/N: AIMB-562 Series
Test Mode Mode 1
CPU INTEL 3.8G/800MHz
Mother Board (EUT) ASUS, M/N: P5LD2-VM DH, BSMI ID: D33005
SATA H.D.D. Seagate, M/N: ST3120026AS, BSMI ID: D33027
F.D.D. Panasonic, M/N: JU-256A398PC, BSMI ID: D33083
CD-ROM ASUS, M/N: CD-S520/A, BSMI ID: 41016007
Memory elixir, 512MB x 4, PC 4300 DDRII
Audio On Board
GIGABIT LAN On Board
VGA On Board
S.P.S. Seventeam, M/N: ST-402HLP, BSMI ID: D33108,
Input: 115~240V, 10A, 50/60Hz
Resolution 1920 x 1440, V-Sync: 60Hz
Note:
1. According to pre-scan data, we determine the data shown in this test report, which
Reflects the worst-case data for each operation mode.
2. This report was copied from GesTek report No.0603035, which changed the brand
name and model number and manufacture and applicant and added mother board
color picture for the requirement of marketing.

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 6 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
3.3 CONFIGURATION OF THE SYSTEM UNDER TEST
Device No. Configuration
CPU :INTEL 3.8G/800MHz
Mother Board
(EUT) :ASUS, M/N: P5LD2-VM DH
SATA H.D.D. : Seagate, M/N: ST3120026AS, BSMI ID: D33027
F.D.D. :Panasonic, M/N: JU-256A398PC,
BSMI ID: D33083
CD-ROM : ASUS, M/N: CD-S520/A, BSMI ID: 41016007
Memory : elixir, 512MB x 4, PC 4300 DDRII
Audio : On Board
GIGABIT LAN : On Board
VGA : On Board
PC System -----
S.P.S. :Seventeam, M/N: ST-402HLP,
BSMI ID: D33108,
Input: 115~240V, 10A, 50/60Hz
D-Sub Monitor M01-029
Manufacturer : ADI
Model Number : MICRO SCAN G1000
Serial Number : N/A
BSMI ID : 3892A351
FCC ID : N/A
Data Cable : Shielded, detachable, 1.5m, VGA Cable
Power Cord : 3Pin, Shielded, Detachable, 1.5m
PS2 Keyboard K01-087
Manufacturer : IBM
Model Number : SK-8811
Serial Number : 01979618
BSMI ID : 3902B330
FCC ID : N/A
Data Cable : Shielded, Undetachable, 1.8 m
PS2 Mouse M02-300
Manufacturer : IBM
Model Number : MU29J
Serial Number : 23021308
BSMI ID : 3902A581
FCC ID : N/A
Data Cable : Shielded, Undetachable, 1.5m
Printer P01-018
Manufacturer : Hewlett Packard
Model Number : 2225C
Serial Number : 2548S40842
BSMI ID : 3892A957
FCC ID : BS46XU2225C
Data Cable : Shielded, Detachable, 1.2m, Parallel Cable
Power Cord : Non-Shielded, Detachable, 1.8m

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 7 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
Device No. Configuration
Modem M03-018
Manufacturer : ACEEX
Model Number : 1414V
Serial Number : 0046171
BSMI ID : N/A
FCC ID : IFAXDM1414
Data Cable : T Type:RS232, Shielded, Detachable, 1.2m
Power Cord : Non-Shielded, Detachable, 1.5m
Line : Type:RJ11(4P2C), Detachable, 1.8m
Phone : Type:RJ11(4P2C), Detachable, 1.8m
Headset &
Earphone E01-088
Manufacturer : Good Vision
Model Number : LY-MIC02
Serial Number : N/A
Data Cable : Non-Shielded, Undetachable, 1.8 m
Power Cord : N/A
Headset &
Earphone E01-106
Manufacturer : Good Vision
Model Number : LY-MIC02
Serial Number : N/A
Data Cable : Non-Shielded, Undetachable, 1.8 m
Power Cord : N/A
Cassette Recorder R02-027
Manufacturer : PANASONIC
Model Number : RQ-L11LT
Serial Number : N/A
BSMI ID : R31017
FCC ID : N/A
Power Cord : N/A (Battery 1.5V*2)
Cassette Recorder R02-028
Manufacturer : PANASONIC
Model Number : RQ-L11LT
Serial Number : N/A
BSMI ID : R31017
FCC ID : N/A
Power Cord : N/A (Battery 1.5V*2)
5.1 CHANNEL
Speaker S01-049
Manufacturer : OZAKI
Model Number : EM98806
Serial Number : N/A
BSMI ID : 3912B015
FCC ID : N/A
Date Cable : Non-Shielded,Detachable, 1.3m
Power Cord : Non-Shielded, unetachable, 1.8m
External USB 2.0
Hard Disk U02-050
Manufacturer : TERASYS
Model Number : F12-UF
Serial Number : A0100215-34P0030
BSMI ID : 4912A002
Data Cable : Shielded, detachable, 1.5m
AC Power Adaptor : YHI M/N: YS-1015-U12A BSMI ID: 4872A185
Input: AC IN: 100V 50/60Hz 35VA
Output: DC +12V, 1.25A

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 8 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
Device No. Configuration
External USB 2.0
Hard Disk U02-051
Manufacturer : TERASYS
Model Number : F12-UF
Serial Number : A0100215-34P0030
BSMI ID : 4912A002
Data Cable : Shielded, detachable, 1.5m
AC Power Adaptor : YHI M/N: YS-1015-U12A BSMI ID: 4872A185
Input: AC IN: 100V 50/60Hz 35VA
Output: DC +12V, 1.25A
External USB 2.0
Hard Disk U02-052
Manufacturer : TERASYS
Model Number : F12-UF
Serial Number : A0100215-34P0030
BSMI ID : 4912A002
Data Cable : Shielded, detachable, 1.5m
AC Power Adaptor : YHI M/N: YS-1015-U12A BSMI ID: 4872A185
Input: AC IN: 100V 50/60Hz 35VA
Output: DC +12V, 1.25A
External USB 2.0
Hard Disk U02-053
Manufacturer : TERASYS
Model Number : F12-UF
Serial Number : A0100215-34P0030
BSMI ID : 4912A002
Data Cable : Shielded, detachable, 1.5m
AC Power Adaptor : YHI M/N: YS-1015-U12A BSMI ID: 4872A185
Input: AC IN: 100V 50/60Hz 35VA
Output: DC +12V, 1.25A
External USB 2.0
Hard Disk U02-054
Manufacturer : TERASYS
Model Number : F12-UF
Serial Number : A0100215-34P0030
BSMI ID : 4912A002
Data Cable : Shielded, detachable, 1.5m
AC Power Adaptor : YHI M/N: YS-1015-U12A BSMI ID: 4872A185
Input: AC IN: 100V 50/60Hz 35VA
Output: DC +12V, 1.25A
External USB 2.0
Hard Disk U02-055
Manufacturer : TERASYS
Model Number : F12-UF
Serial Number : A0100215-34P0030
BSMI ID : 4912A002
Data Cable : Shielded, detachable, 1.5m
AC Power Adaptor : YHI M/N: YS-1015-U12A BSMI ID: 4872A185
Input: AC IN: 100V 50/60Hz 35VA
Output: DC +12V, 1.25A

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 9 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
Device No. Configuration
External USB 2.0
Hard Disk U02-056
Manufacturer : TERASYS
Model Number : F12-UF
Serial Number : A0100215-34P0030
BSMI ID : 4912A002
Data Cable : Shielded, detachable, 1.5m
AC Power Adaptor : YHI M/N: YS-1015-U12A BSMI ID: 4872A185
Input: AC IN: 100V 50/60Hz 35VA
Output: DC +12V, 1.25A
External USB 2.0
Hard Disk U02-057
Manufacturer : TERASYS
Model Number : F12-UF
Serial Number : A0100215-34P0030
BSMI ID : 4912A002
Data Cable : Shielded, detachable, 1.5m
AC Power Adaptor : YHI M/N: YS-1015-U12A BSMI ID: 4872A185
Input: AC IN: 100V 50/60Hz 35VA
Output: DC +12V, 1.25A
Far End Network
Server ----- Manufacturer : ASUS
Model Number : AP160R
Power Cord : Non- Shielded, Detachable, 1.8m
HUB ----- Manufacturer : D-Link
Model Number : DGS-1005D
Power Cord : Non- Shielded, Detachable, 2.0m, 2pin

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 10 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
3.4 TEST FACILITY
Items Required (IEC 68-1) Actual
Temperature (°C) 15-35 25-29
Humidity (%RH) 25-75 (45-75 for ESD, 1st, ed.)
(30-60 for ESD, 2nd. ed)
50-60 for ESD
52-63 for others
Barometric pressure
(mbar) 860-1060 950-1000
Site Description : December 31, 2005 File on NEMKO EMC Laboratory Authorization
Gaustadalleen 30, Postbox 73 Blindern, 0314 Oslo, Aut. No.: ELA 126
Aug. 15, 1997 Recognition on Det Norske Veritas AS
Statement No:510-96-1017
Accreditation on NVLAP effective through September 30, 2005.
For CISPR 22, FCC Method and AS/NZS CISPR 22 Measurement.
NVLAP Lab Code: 200085-0
Registration on VCCI effective through June 28, 2007.
Registration No.: R-291 and C-305
Recognized by the Council of Chinese National Laboratory Accreditation
As an accredited laboratory and registration No.:1082.
Registration on CNLA effective through April 30, 2006.
Name of firm : Global EMC Standard Tech. Corp.
Site location : No. 3 Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang,
Taipei County, Taiwan, R.O.C.
200085-0

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 11 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
4. CONDUCTED EMISSION MEASUREMENT
4.1 TEST EQUIPMENTS
Item Instrument Manufacturer Model Serial No. Last Cal. Date
1 Test Receiver R & S ESHS30 828109/010 01/20/05
2 L.I.S.N.(EUT) ROLF HEINE NNB-2/16Z 98091 12/08/04
3 L.I.S.N.(AE) ROLF HEINE NNB-2/16Z 99042 12/17/04
4 Pulse Limiter R & S ESH3-Z2 357.8810.52 08/06/04
5 RF CABLE GTK N/A GTK-E-A154-01 12/01/04
6 50 Ohm Terminator GTK N/A GTK-E-A130-01 10/09/04
7 Shielded Room GTK N/A B5 N/A
Note: All equipment upon which need to calibrated are with calibration period of 1 year.
4.2 TEST METHOD
According to EN 55022: 1998 + A1: 2000 + A2: 2003
4.3 BLOCK DIAGRAM OF TEST SETUP
Note: This is a reprehensive setup diagram for Table-top EUT.
For Floor-standing EUT, the table will be removed with all others setup condition remain the same.
Metal Ground Plane
80cm
40cm
Load
Non-conducted table L.I.S.N.
(
EUT
)
EUT:
Mother Board
Pulse Limiter
Test Receiver
Transformer/ Convertor
80cm
Filter(EUT)
Filter(AE)
L.I.S.N.
(
AE
)

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 12 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
4.4 CONDUCTED EMISSION LIMITS
Maximum RF Line Voltage dB(uV)
Frequency Class A Class B
MHz QUASI-PEAK AVERAGE QUASI-PEAK AVERAGE
0.15 to 0.50 79 66 66 to 56 56 to 46
0.50 to 5.0 73 60 56 46
5.0 to 30 73 60 60 50
Remarks: In the Above Table, the tighter limit applies at the band edges.
4.5 EUT CONFIGURATION ON MEASUREMENT
4.5.1 FOR POWER LINE
The equipments, which are listed at 4.1, are installed on Conducted Emission Test to meet the
Commission requirement and operating in a manner which tends to maximize its emission
characteristics in a normal application.
The device under test, installed in a representative system as described in section 4.3, was
placed on a non-conductive table whose total height equaled 80 cm. The EUT was powered
through one L.I.S.N. whose the signal output was terminated to the receiver. The other
peripherals were powered from another L.I.S.N. whose the signal output was terminated by 50
Ohms terminator.
4.6 CONDUCTED EMISSION DATA
The measurement range of conducted emission, which is from 0.15 MHz to 30 MHz,was
investigated. The initial step in collecting conducted data is a spectrum analyzer peak scan of the
measurement range for all the test modes. Then the worst modes were reported the following data
pages.
The final measurement equal to Receiver reading plus a Correction factor when AMN insertion
loss bigger than 0.5dB, the receiver added the correction factor to the reading level automatically.
4.7 OPERATING CONDITIONS OF THE EUT
The exercise program used during conducted emission measurement was designed to exercise
the EUT in a manner similar to a typical use. The exercise sequence is listed as below:
1. Setup the EUT and simulators as shown on 4.3
2. Turn on the power of all equipments.
3. Boot the P.C. from Hard Disk and setup the video to windows XP, active all devices.
4. Adjust to appropriate video resolution.
5. Connect the Far End Network Server and run test program “test.bat “.
6. The EUT exchange the information with the GesTek server via HUB.
7. Active other internal devices such as network function.
8. Run “Dell test” and “ H.D.D. R/ W “ test program under windows XP.
9. P.C. sent “H” pattern to monitor, make the “H” pattern full in the screen.
10. P.C. sent “H” pattern to parallel and serial port.
11. Repeat above steps.

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 13 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
4.8 CONDUCTED EMISSION MEASUREMENT RESULTS
Date of Test May 23, 2005 Temperature 23 ℃
EUT Mother Board Humidity 59 %
Test Mode Mode 1 Display Pattern H Pattern
Line
No. Frequency
MHz Reading Level dBµV Factor dB Measurement dBµV Limit dBµV Over Limit dB Detector
1 0.1576 24.71 10.04 34.75 65.59 -30.84 QP
2 0.1576 20.35 10.04 30.39 55.59 -25.20 AVG
3 0.2338 17.45 10.07 27.52 62.31 -34.79 QP
4 0.2338 13.99 10.07 24.06 52.31 -28.25 AVG
5 0.3148 16.46 10.10 26.56 59.84 -33.28 QP
6 0.3148 12.38 10.10 22.48 49.84 -27.36 AVG
7 4.7808 17.65 10.35 28.00 56.00 -28.00 QP
8 ★4.7808 12.06 10.35 22.41 46.00 -23.59 AVG
9 15.8205 14.11 10.58 24.69 60.00 -35.31 QP
10 15.8205 7.51 10.58 18.09 50.00 -31.91 AVG
11 22.9480 12.08 10.77 22.85 60.00 -37.15 QP
12 22.9480 6.42 10.77 17.19 50.00 -32.81 AVG
Remarks :
1 All readings are Quasi-peak and Average values.
2 “ ★” means that this data is the worse case emission level.
Line

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 14 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
Date of Test May 23, 2005 Temperature 23 ℃
EUT Mother Board Humidity 59 %
Test Mode Mode 1 Display Pattern H Pattern
Neutral
No. Frequency
MHz Reading Level dBµV Factor dB Measurement dBµV Limit dBµV Over Limit dB Detector
1 0.1551 25.81 10.04 35.85 65.72 -29.87 QP
2 0.1551 22.70 10.04 32.74 55.72 -22.98 AVG
3 0.1792 26.46 10.05 36.51 64.52 -28.01 QP
4 0.1792 24.94 10.05 34.99 54.52 -19.53 AVG
5 0.3900 19.75 10.12 29.87 58.06 -28.19 QP
6 0.3900 17.61 10.12 27.73 48.06 -20.33 AVG
7 ★1.9563 28.95 10.12 39.07 56.00 -16.93 QP
8 1.9563 17.41 10.12 27.53 46.00 -18.47 AVG
9 3.7642 13.05 10.23 23.28 56.00 -32.72 QP
10 3.7642 9.52 10.23 19.75 46.00 -26.25 AVG
11 23.5501 10.67 10.80 21.47 60.00 -38.53 QP
12 23.5501 4.52 10.80 15.32 50.00 -34.68 AVG
Remarks :
1 All readings are Quasi-peak and Average values.
2 “ ★” means that this data is the worse case emission level.
Neutral

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 15 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
5. RADIATED EMISSION MEASUREMENT
5.1 TEST EQUIPMENT
The following test equipments are used during the radiated emission tests:
Radiated emission measurement was performed at: Site #1 Site #2 Site #3 Site #4
Item Instrument Manufacturer Model Serial No. Last Cal. Date
1 Test Receiver R & S ESCS30 100035 06/10/04
2 Spectrum Analyzer HP 8542E 3520A00123/342
7A00118 07/21/04
3 Pre-Amplifier HP 8447F OPT
H64 3113A04487 10/09/04
4 BILOG Antenna SCHAFFNER CBL6112B 2580 11/30/04
5 RF Cable GTK N/A GTK-E-A152-01 12/29/04
6 Open Site GTK N/A B2 11/23/04
Note: All equipment upon which need to calibrated are with calibration period of 1 year.
5.2 TEST METHOD
According to EN 55022: 1998 + A1: 2000 + A2: 2003
Radiated emission measurement was performed at the antenna to EUT distance of 10 meters.

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 16 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
5.3 BLOCK DIAGRAM OF TEST SETUP
5.3.1 BLOCK DIAGRAM OF CONNECTIONS BETWEEN EUT AND SIMULATORS
Note: This is a reprehensive setup diagram for Table-top EUT.
For Floor-standing EUT, the table will be removed with all others setup condition remain the same.
H
ea
d
se
t
&
Earphone
Modem
D-Sub Monitor
HHHHHHHH
HHHHHHHH
HHHHHHHH
HHHHHHHH
PS2
Mouse
Far End Network Server HUB GIGABIT LAN
Printer
H
ea
d
se
t
&
Earphone PS2
Keyboard
Cassette
Player
EUT: Mother Board
(In the PC System)
P.C.
Cassette
Player
External USB 2.0 Hard Disk
5.1
CHANNEL
Speaker

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 17 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
5.3.2 OPEN AREA TEST SITE & ANECHOIC CHAMBER SETUP DIAGRAM
Note: This is a reprehensive setup diagram for Table-top EUT.
For Floor-standing EUT, the table will be removed with all others setup condition remain the same.
5.4 RADIATED EMISSION LIMITS
Class B Limits
Frequency Distance Field Strength
MHz Meter dB(µV/m)
30 to 230 10 30
230 to 1000 10 37
Class A Limits
Frequency Distance Field Strength
MHz Meter dB(µV/m)
30 to 230 10 40
230 to 1000 10 47
Remark: 1. The tighter limit shall apply at the edge between two frequency bands.
2. Distance refers to the distance in meters between the measuring antenna and
the closest point of any part of the device or system.
EUT
FRP Dome
Test
Receiver
A
ntenna Mast
TO controlle
r
To Receive
r
Metal Full Soldered Ground Plane
Non-Condu
ctive Table
10m
1m to 4m
80cm
Broadband or
Dipole Antenna
A
ntenna height
can be moved
from 1m to 4m;
A
ntenna and
turntable distance
10m

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 18 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
5.5 EUT CONFIGURATION
The EUT, which is listed at 5.3.1. , was installed at the Radiated Emission Test site to meet
the Commission requirements and operated in a manner, which tends to maximize its
emission characteristics in a normal application.
The EUT, installed in a representative system as described in section 5.3.2, was placed on a
non-conductive table whose total height equaled 80 cm. This table can be rotated 360 degrees.
The measurement antenna was mounted to a non-conductive mast capable of moving the
antenna vertically. Antenna height was varied from 1 meter to 4 meters and the system under
test was rotated from 0 degree through 360 degrees relative to the antenna position and
polarization (Horizontal and Vertical). Also the I/O cable positions were investigated to find the
maximum emission condition.
5.6 OPERATING CONDITIONS OF THE EUT
Same as conducted emission measurement, which is listed in 4.7
5.7 RADIATED EMISSION DATA
The frequency range of radiated emissions from 30 MHz to 1 GHz was investigated. The initial
step in collecting emission data was a spectrum analyzer peak scan of the frequency range for
all the test modes. Then the worst modes were reported the following data pages.

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 19 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
5.8 RADIATED EMISSIONS MEASUREMENT RESULTS
Date of Test May 21, 2005 Temperature 20 deg/C
EUT Mother Board Humidity 62 %RH
Working Cond. Mode 1 Display Pattern H Pattern
Antenna distance 10m at Horizontal Frequency Range 30-1000MHz
No. Frequency
MHz Reading Level dBµV Factor dB/m Measurement dBµV/m Limit dBµV/m Over Limit dB Detector
1 125.0000 39.80 -13.98 25.82 30 -4.18 QP
2 165.9130 38.20 -15.44 22.76 30 -7.24 QP
3 172.8500 38.50 -15.75 22.75 30 -7.25 QP
4 192.0130 38.43 -15.65 22.78 30 -7.22 QP
5 200.0013 36.55 -15.87 20.68 30 -9.32 QP
6 233.4400 39.30 -13.17 26.13 37 -10.87 QP
7 ★240.0213 46.50 -12.77 33.73 37 -3.27 QP
8 299.9950 36.80 -10.22 26.58 37 -10.42 QP
9 400.0025 35.67 -7.78 27.89 37 -9.11 QP
10 480.0363 35.00 -6.29 28.71 37 -8.29 QP
11 500.0015 35.00 -6.16 28.84 37 -8.16 QP
12 540.0400 34.82 -5.44 29.38 37 -7.62 QP
13 600.0475 34.56 -4.05 30.51 37 -6.49 QP
14 720.0575 35.10 -2.11 32.99 37 -4.01 QP
15 1000.0000 29.30 2.67 31.97 37 -5.03 QP
Remarks:
21. All Readings below 1GHz are Quasi-Peak.
2. Emission Level= Reading + Factor (Could have ±0.01 tolerance due to computer automatically round off calculation).
3. Over Limit (Margin Value)=Measurement level-Limit value.
4. The “★” means this data is worst-case Measurement level.

GESTEK Lab Report No.: 0609083 Rev. 1
N0 3, Pau-Tou-Tsuo Valley, Chia-Pau Tsuen, Lin Kou Hsiang, Taipei County, Taiwan, R.O.C. Tel:[phone] Fax:[phone]
Accredited Lab. Of BSMI, NEMKO, NVLAP Page 20 of 59
Listed Lab. of AUSTEL, Commerce, FCC, VCCI NVLAP Lab Code:200085-0
Date of Test May 21, 2005 Temperature 20 deg/C
EUT Mother Board Humidity 62 %RH
Working Cond. Mode 1 Display Pattern H Pattern
Antenna distance 10m at Vertical Frequency Range 30-1000MHz
No. Frequency
MHz Reading Level dBµV Factor dB/m Measurement dBµV/m Limit dBµV/m Over Limit dB Detector
1 50.1250 42.30 -18.01 24.29 30 -5.71 QP
2 83.2500 39.80 -19.41 20.39 30 -9.61 QP
3 125.0500 40.00 -13.98 26.02 30 -3.98 QP
4 133.3750 38.00 -13.98 24.02 30 -5.98 QP
5 172.9000 36.30 -15.75 20.55 30 -9.45 QP
6 192.0005 38.92 -15.65 23.27 30 -6.73 QP
7 199.9960 37.30 -15.87 21.43 30 -8.57 QP
8 215.9985 36.80 -14.16 22.64 30 -7.36 QP
9 233.5000 42.10 -13.17 28.93 37 -8.07 QP
10 240.0000 46.10 -12.77 33.33 37 -3.67 QP
11 250.0005 39.63 -11.98 27.65 37 -9.35 QP
12 300.0300 37.69 -10.22 27.47 37 -9.53 QP
13 375.0045 35.43 -8.28 27.15 37 -9.85 QP
14 400.0800 36.35 -7.78 28.57 37 -8.43 QP
15 480.0325 40.00 -6.29 33.71 37 -3.29 QP
16 ★500.0025 40.05 -6.16 33.89 37 -3.11 QP
17 540.0400 32.20 -5.44 26.76 37 -10.24 QP
18 600.0455 34.04 -4.05 29.99 37 -7.01 QP
19 720.0000 35.60 -2.11 33.49 37 -3.51 QP
20 999.9900 27.30 2.67 29.97 37 -7.03 QP
Remarks:
1. All Readings below 1GHz are Quasi-Peak.
2. Emission Level= Reading + Factor (Could have ±0.01 tolerance due to computer automatically round off calculation).
3. Over Limit (Margin Value)=Measurement level-Limit value.
4. The “★” means this data is worst-case Measurement level.
