Advantech SL305 User manual

LTE Industrial Router
SmartStart SL305
USER MANUAL

SmartStart SL305
c
2022 Advantech Czech s.r.o. No part of this publication may be reproduced or transmitted in any form or
by any means, electronic or mechanical, including photography, recording, or any information storage and retrieval
system without written consent. Information in this manual is subject to change without notice, and does not
represent a commitment on the part of Advantech.
Advantech Czech s.r.o. shall not be liable for incidental or consequential damages resulting from the furnish-
ing, performance, or use of this manual.
All brand names used in this manual are the registered trademarks of their respective owners. The use of
trademarks or other designations in this publication is for reference purposes only and does not constitute an
endorsement by the trademark holder.
i

SmartStart SL305
Used symbols
Danger – Information regarding user safety or potential damage to the router.
Attention – Problems that can arise in specific situations.
Information, notice – Useful tips or information of special interest.
GPL licence
Source codes under GPL licence are available at https://icr.advantech.cz/source-code
address.
Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic
Document No. MAN-0056-EN, revision from March 3, 2022. Released in the Czech Republic.
ii

SmartStart SL305
Contents
1 Safety Instructions 2
2 WEEE directive 3
3 Router Description 4
3.1 LTE Category 4 (Cat.4) ............................... 4
3.2 Basic HW Information ................................ 4
3.3 Configuration and Diagnostics ............................ 4
3.4 Usage of the Router ................................. 5
4 Contents of Package 8
5 Router Design 9
5.1 Router Versions .................................... 9
5.2 Delivery Identification ................................ 10
5.3 Order Codes ..................................... 10
5.4 Basic Dimensions of the Router ........................... 11
5.4.1 Front view ................................... 11
5.4.2 Top view .................................... 11
5.4.3 Bottom view .................................. 12
5.4.4 Rear view ................................... 12
5.5 Mounting recommendations ............................. 13
5.6 Removal from the DIN rail .............................. 14
5.7 Description of the Rear Panel ............................ 15
5.8 Description of the Front Panel ............................ 15
5.8.1 Status indication ............................... 16
5.8.2 Power PWR/IO Connector .......................... 17
5.8.3 Antenna Connector ANT, DIV and WiFi .................. 19
5.8.4 SIM Card Reader ............................... 20
5.8.5 Ethernet Port ETH .............................. 21
5.8.6 Serial Port RS232 .............................. 22
5.8.7 Reset ..................................... 23
6 First Use 24
6.1 Connecting the Router Before the First Use .................... 24
6.2 Start .......................................... 25
6.3 Configuration ..................................... 25
6.3.1 Configuration by web browser ........................ 25
iii

SmartStart SL305
7 Technical Parameters 28
7.1 Basic Parameters ................................... 28
7.2 Technical specification of user interfaces ...................... 29
7.3 Standards and Regulations ............................. 29
7.4 Type Tests and Environmental Conditions ..................... 30
7.5 Technical Parameters of Module .......................... 31
7.6 Technical Parameters of WiFi ............................ 32
7.7 Other Technical Parameters ............................. 32
8 Related Documents 33
9 Troubleshooting 34
9.1 FAQ .......................................... 34
10 Customer Support 37
iv

SmartStart SL305
List of Figures
1 Access to the Internet from LAN .......................... 5
2 Backed up access to the Internet .......................... 6
3 Using a VPN tunnel ................................. 6
4 Serial Gateway .................................... 7
5 Contents of package ................................. 8
6 Front panel ...................................... 9
7 Product label ..................................... 10
8 Front view ....................................... 11
9 Top view ........................................ 11
10 Bottom view ...................................... 12
11 Rear view ....................................... 12
12 Default position of metal DIN rail clip ........................ 14
13 Removal from the DIN rail .............................. 14
14 SmartStart front panel ................................ 15
15 PWR / IO connector .................................. 17
16 Circuit example – connection of power supply ................... 17
17 Binary connection .................................. 18
18 Connecting the antenna ............................... 19
19 SIM cards ....................................... 20
20 Ethernet connector .................................. 21
21 Connection of Ethernet cable ............................ 21
22 RS232 connector ................................... 22
23 Router reset ...................................... 23
24 Router connection .................................. 24
25 Entering the IP address of the router ........................ 25
26 Entering login information .............................. 26
27 Router web interface ................................. 27
v

SmartStart SL305
List of Tables
1 Router versions .................................... 9
2 Delivery identification ................................ 10
3 Order codes overview ................................ 10
4 Front panel description ................................ 15
5 Status indication ................................... 16
6 Connection of PWR / IO connector ......................... 17
7 Characteristics of binary input ............................ 18
8 Connection of Ethernet connector .......................... 21
9 Connection of RS232 connector .......................... 22
10 Description of router reset and restart ....................... 23
11 Basic parameters ................................... 28
12 Technical specification of user interfaces ...................... 29
13 Standards and regulations .............................. 29
14 Type tests and environmental conditions ...................... 30
15 Technical parameters of module for EMEA ..................... 31
16 Technical parameters of WiFi ............................ 32
17 Other technical parameters ............................. 32
1

SmartStart SL305
1. Safety Instructions
Please, observe the following instructions:
•The router must be used in compliance with all applicable international and national laws
and in compliance with any special restrictions regulating the utilization of the router in
prescribed applications and environments.
•To prevent possible injury and damage to appliances and to ensure compliance with
all relevant provisions, use only the original accessories. Unauthorized modifications or
the use of unapproved accessories may result in damage to the router and / or a breach
of applicable regulations. Unauthorized modifications or use of unapproved accessories
may void the warranty.
•The router can not be opened.
•Turn off the router and disconnect it from power supply before handling the SIM card.
•Caution! This equipment is not suitable for use in locations where children are likely to
be present. The SIM card could be swallowed by small children.
•Input voltage must not exceed 36 V DC max.
•Do not expose the router to extreme ambient conditions. Protect the router against dust,
moisture and high temperature.
•Only routers with appropriate certification and labelling should be used in locations where
flammable and explosive materials are present, including gas stations, chemical plants,
or locations in which explosives are used. We remind users of the duty to observe the
restrictions concerning the utilization of radio devices at such places.
•Switch off the router when traveling by plane. Utilization of the router on a plane may
endanger the operation of the plane or interfere with the mobile telephone network, and
may be unlawful. Failure to observe these instructions may result in the suspension or
cancellation of telephone services for the respective client and / or may result in legal
sanctions.
•When using the router in close proximity to personal medical devices, such as cardiac
pacemakers or hearing aids, you must proceed with heightened caution.
•The router may cause interference when used in close proximity to TV sets, radio re-
ceivers or personal computers.
•It is recommended that you create an appropriate copy or backup of all important settings
that are stored in the memory of the device.
2

SmartStart SL305
2. Product Disposal Instructions
The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) directive was in-
troduced to ensure that electrical/electronic products are recycled using the best available
recovery techniques to minimize the impact on the environment. This product contains high
quality materials and components which can be recycled. At the end of it’s life this pro- duct
MUST NOT be mixed with other commercial waste for disposal. The device contains a battery.
Remove the battery from the device before disposal. The battery in the device needs to be
disposed of apart accordingly. Check the terms and conditions of your supplier for disposal
information.
3

SmartStart SL305
3. Router Description
Cellular router SmartStart is designed for wireless communication in the mobile networks
that make use of traditional cellular technologies. The primary purpose of this router is its use
in the newest Category 4 (Cat.4) services on the cellular LTE network.
3.1 LTE Category 4 (Cat.4)
LTE Category 4 (Cat.4) is the next step in 4G LTE device capability. Cat.4 rated SmartStart
routers are capable of achieving typical speeds in 4G coverage areas where the network is
enabled with 20 MHz of contiguous spectrum. The peak downlink data rate for a Category 4
is approximately 150 Mbps. Also in the uplink, LTE Category 4 provides a peak data rate of
50 Mbps.
3.2 Basic HW Information
As a standard, the SmartStart router is equipped with one Ethernet 10/100 Mbps, one
serial interface RS232, one binary input and one output. SL305 also contains two readers for
3 V and 1.8 V SIM cards, which are placed on the rear panel of the device. The router can
be equipped with a WiFi module, but this must be part of the initial configuration – it cannot
be assembled to the router at some point in the future. The SmartStart router is supplied in a
plastic casing.
3.3 Configuration and Diagnostics
The router can be configured using a password-protected Web interface. The web interface
provides (after logging in) detailed statistics about the router activities, signal strength, detailed
system logs etc. This device supports the creation of VPN tunnels using technologies IPSec,
OpenVPN and L2TP for secure communications. There are also supported functions such as
IPv6 (the latest revision of the Internet Protocol), DHCP, NAT, NAT-T, DynDNS, NTP, VRRP,
control by SMS, primary connection backups and many other functions are also supported.
Other diagnostic functions ensuring continuous communication include automatic inspec-
tion of PPP connection offering an automatic restart feature in case of connection is lost, or
hardware watchdog which monitors the status of the router. Using a special window (start up
script window) you may insert Linux scripts for various actions. For some applications is the
key possibility to create several different configurations for one router which can be switched
as needed (e.g. using SMS or status of the binary input). Cellular routers may automatically up-
date configuration and firmware from server. This allows mass reconfiguration of many routers
in one time.
4
