Advantech ICR-2031 User manual

LTE Industrial Router
ICR-2031
USER MANUAL

ICR-2031
© 2023 Advantech Czech s.r.o. No part of this publication may be reproduced or transmitted in any form or by
any means, electronic or mechanical, including photography, recording, or any information storage and retrieval
system without written consent. Information in this manual is subject to change without notice, and does not
represent a commitment on the part of Advantech.
Advantech Czech s.r.o. shall not be liable for incidental or consequential damages resulting from the furnish-
ing, performance, or use of this manual.
All brand names used in this manual are the registered trademarks of their respective owners. The use of
trademarks or other designations in this publication is for reference purposes only and does not constitute an
endorsement by the trademark holder.
i

ICR-2031
Used symbols
Danger – Information regarding user safety or potential damage to the router.
Attention – Problems that can arise in specific situations.
Information, notice – Useful tips or information of special interest.
Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic
Document No. MAN-0057-EN, revision from June 20, 2023. Released in the Czech Republic.
ii

ICR-2031
Contents
1 Product Overview 2
1.1 Product Introduction ................................. 2
1.2 Product Usage Examples .............................. 3
1.3 Hardware Overview ................................. 5
1.4 Order Codes ..................................... 7
1.5 Product Revisions .................................. 7
1.6 Package Contents .................................. 8
1.7 Product Dimensions ................................. 9
1.8 Mounting Recommendations ............................ 11
1.9 Wall Mounting ..................................... 12
1.10 DIN Rail Mounting .................................. 13
1.11 Product Label ..................................... 14
2 Hardware Functionality 15
2.1 SIM Card Slot ..................................... 15
2.2 Antennas ....................................... 16
2.3 Ethernet Interfaces .................................. 16
2.4 Power Supply ..................................... 17
2.5 I/O Port Interfaces .................................. 18
2.6 LED Status Indication ................................ 19
2.7 Reset Functions ................................... 20
3 First Use 21
3.1 Accessories Connection ............................... 21
3.2 Router Configuration ................................. 21
4 Technical Specifications 23
4.1 Basic Parameters ................................... 23
4.2 Standards and Regulations ............................. 24
4.3 Type Tests and Environmental Conditions ..................... 25
4.4 Parameters of Cellular Module ........................... 26
4.5 Parameters of WiFi .................................. 27
4.6 Parameters of I/O Ports ............................... 28
4.7 System Configuration ................................ 28
Appendix A: Troubleshooting 29
Appendix B: Customer Support 32
iii

ICR-2031
Appendix C: Regulatory & Safety Information 33
Appendix D: Related Documents 35
iv

ICR-2031
List of Figures
1 Access to the Internet from LAN .......................... 3
2 Backed up Access to the Internet .......................... 3
3 Using VPN Tunnel .................................. 4
4 Hardware Overview of the Router .......................... 5
5 Router Dimensions – Top, Side and Front View with Wall Mount Clip ...... 9
6 Router Dimensions – Top, Side and Front View with DIN Rail Clip ........ 10
7 Screwed Wall Mounting Clip ............................. 12
8 Position of the DIN Rail Clip ............................. 13
9 Removing Router from the DIN Rail ......................... 13
10 Product Label ..................................... 14
11 SIM Card Insertion .................................. 15
12 Ethernet Connector Pinout .............................. 16
13 Connection of Power Supply ............................ 17
14 Position of the Grounding Screw .......................... 17
15 I/O Connector Pinout ................................. 18
16 Functional Scheme of the Binary Interface ..................... 18
17 Resetting the Router ................................. 20
18 Router’s Web Interface ................................ 22
v

ICR-2031
List of Tables
1 Hardware Overview of the Router .......................... 6
2 Order Codes Overview ................................ 7
3 HW Revisions History ................................ 7
4 Contents of Package ................................. 8
5 Ethernet Connector Pinout Description ....................... 16
6 Power Supply Pinout ................................. 17
7 I/O Ports Pinout .................................... 18
8 LED Status Indication ................................ 19
9 Basic Parameters ................................... 23
10 Standards and Regulations ............................. 24
11 Type Tests and Environmental Conditions ..................... 25
12 Technical Parameters of Cellular Module ...................... 26
13 Technical Parameters of WiFi ............................ 27
14 Electrical Characteristics of Binary Input ...................... 28
15 System Configuration ................................ 28
1

ICR-2031
1. Product Overview
1.1 Product Introduction
Industrial cellular router ICR-2031 is designed for wireless communication in mobile net-
works that use traditional cellular technologies.
The primary purpose of this router is its use in the Category 4 (Cat.4) services on the
cellular LTE network. Cat.4 rated router is capable of achieving typical speeds in 4G coverage
areas where the network is enabled with 20 MHz of contiguous spectrum. The peak downlink
data rate for Category 4 is approximately 150 Mbps. In the uplink, LTE Category 4 provides
a peak data rate of 50 Mbps.
The router is equipped with one Ethernet port and with one digital input together with
one digital output. The router can be equipped with a WiFi module, but this must be part of
the initial configuration – it cannot be assembled to the router at some point in the future.
The router supports VPN tunnel creation using various protocols to ensure safe commu-
nications. The router provides diagnostic functions which include automatic monitoring of the
wireless and wired connections, automatic restart in case of connection losses, and a hard-
ware watchdog that monitors the router status.
With open Linux platform and wide possibilities of programming customer SW applications
in Python,C/C++. The Advantech existing app library Router Apps (formerly User modules)
with apps already developed to enhance specific router functionality including industrial pro-
tocol conversions and support of IoT platforms such as MS Azure,Cumulocity,ThingWorx,
and others are supported on the router.
Examples of possible applications
• mobile office
• fleet management
• security system
• telematic
• telemetric
• remote monitoring
• vending and dispatcher machines
2

ICR-2031
1.2 Product Usage Examples
The router is primarily intended for these basic situations:
I. Access to the Internet from LAN
Figure 1: Access to the Internet from LAN
II. Backed up access to the Internet (from LAN)
Figure 2: Backed up Access to the Internet
3

ICR-2031
III. Secure networks interconnection or using VPN
Figure 3: Using VPN Tunnel
4

ICR-2031
1.3 Hardware Overview
The router case preview is shown in Figure 4. A short description of hardware parts of the
router is listed in Table 1, including the links to the chapters with a detailed description.
Figure 4: Hardware Overview of the Router
# Item/Caption Type Description
1 Grounding
screw
M3 Pay attention to proper grounding; see Chapter 2.4.
2 PWR
IN/OUT
6-pin
terminal
Power supply, binary input, and binary output interfaces.
See Chapter 2.4, Chapter 2.5 for more information, Chap-
ter 4.6 for I/O parameters.
3 WiFi RP-SMA
female
Connector for the WiFi antenna; see Chapter 2.2 and
Chapter 4.5 for WiFi parameters.
4 LEDs - Status LED indication; see Chapter 2.6.
5 RST - Button to reboot the router or to restore the default
configuration; see Chapter 2.7.
Continued on the next page
5

ICR-2031
Continued from previous page
# Item/Caption Type Description
6 ETH0 RJ45 100 MB Ethernet connection for the LAN; see Chapter 2.3.
7 ANT SMA
female
Connector for the main antenna of the cellular module; see
Chapter 2.2.
8 DIV SMA
female
Connector for the second antenna of the cellular module
(required for the MIMO DL); see Chapter 2.2.
9 SIM slot Micro SIM One SIM card slot; see Chapter 2.1.
10 DIN clip - DIN rail clip, not included as standard accessories; see
Chapter 1.10.
11 Wall clip - Wall mounting clip, included as standard accessories; see
Chapter 1.9.
Table 1: Hardware Overview of the Router
6

ICR-2031
1.4 Order Codes
Order codes overview is shown in the table below.
Order code Features – interfaces
ICR-2031 LTE Cat.4 with 3G/2G fallback cellular module, 64 MB NOR Flash, 1x ETH,
1x Binary Input, 1x Binary Output, 1x SIM reader
ICR-2031WLTE Cat.4 with 3G/2G fallback cellular module, 64 MB NOR Flash, 1x ETH,
1x Binary Input, 1x Binary Output, 1x SIM reader, WiFi
Table 2: Order Codes Overview
1.5 Product Revisions
For the product revision history, see the table below. The revision number is printed on the
packaging and product labels.
The router GUI can also display the product revision under Status -> General -> System
Information -> Product Revision. Please note that the default revision (Rev.1.0) is unavailable
here.
Rev.# Description
1.0 Initial version (revision not printed on the labels).
2.0 New design of the mainboard; see PCN-2023-05 for details.
Table 3: HW Revisions History
7

ICR-2031
1.6 Package Contents
The standard set of router includes items listed in the following table:
Item# Description Figure Q’ty
1 Router 1 pcs
2 Wall mounting clip with screws 1 set
3
6-pin terminal block for power sup-
ply, digital input and digital output (de-
ployed on the router)
1 pcs
4 Printed Quick Start Guide Leaflet 1 pcs
Table 4: Contents of Package
8

ICR-2031
1.7 Product Dimensions
For the dimensions of the product see the figures below. Note that all sizes are measured
in millimeters.
Variant with Wall Mounting Clip
Figure 5: Router Dimensions – Top, Side and Front View with Wall Mount Clip
9

ICR-2031
Variant with DIN Rail Clip
Figure 6: Router Dimensions – Top, Side and Front View with DIN Rail Clip
10

ICR-2031
1.8 Mounting Recommendations
The router can be placed:
• on a flat surface,
• on a wall using the wall mounting clip (see Chapter 1.9),
• on a DIN rail EN 60715 with the metal DIN rail clip (see Chapter 1.10)
For most applications with a built-in router within a switchboard, it is possible to recognize
two kinds of environments:
• A non-public, industry environment of low voltage with high interference,
• a public environment of low voltage and without high interference.
For both of these environments, it is possible to mount the router to a switchboard, af-
ter which there is no need to have examination immunity or issues in connection with EMC
according to EN 61439-1:2011.
In compliance with the EN 61439-1:2011 specification, it is necessary to observe the
following assembly instructions for a router attached to a switchboard:
• For whip antennas it is recommended to observe a minimum distance of 6 cm from ca-
bles and metal surfaces on every side in order to avoid interference. When using an
external antenna separate from the switchboard it is necessary to fit a lightning conduc-
tor.
• When mounting a router on sheet-steel we recommend using a cable antenna.
• For all cables, we recommend to bind the bunch, and for this we recommend:
–The length of the bunch (the combination of power supply and data cables) should
be a maximum 1.5 m. If the length of data cables exceeds 1.5 m or if the cable is
leading towards the switchboard, we recommend installing surge protectors.
–Data cables must not have a reticular tension of ∼230 V/50 Hz or ∼120 V/60 Hz.
• Sufficient space must be left between each connector for the handling of cables,
• To ensure the correct functioning of the router we recommend the use of an earth-
bonding distribution frame for the grounding of the grounding screew, see Chapter 2.4.
11

ICR-2031
1.9 Wall Mounting
The wall mounting clip is supplied with the router as standard accessories.
The router can be screwed to a wall (or another surface) using the wall mounting clip.
There are two wholes on the clip with a diameter of 4 millimeters. For detailed information
about the mounting dimensions see Figure 5in Chapter 1.7.
When mounting the wall mounting clip, tighten the screws with max. torque of 0.4 Nm.
Figure 7: Screwed Wall Mounting Clip
12

ICR-2031
1.10 DIN Rail Mounting
The DIN rail clip is not supplied with the router as standard accessories, but it can be ordered
by the order code BB-DIN-ICR32.
The DIN rail clip is suitable for a DIN rail according to EN 60715 standard only. The default
position of the clip is shown in Figure 8.
When mounting the DIN rail clip, tighten the screws with max. torque of 0.4 Nm.
Figure 8: Position of the DIN Rail Clip
To remove the router from the DIN rail it is necessary to lightly push down the router so
that the bottom part of the DIN rail clip hitched to the DIN rail get out of this rail and then fold
out the bottom part of the router away from the DIN rail, see Figure 9.
Figure 9: Removing Router from the DIN Rail
13

ICR-2031
1.11 Product Label
The figure below shows an example of the product labels with all the information printed
on them.
Figure 10: Product Label
14
